1996 FORD TAURUS Owners Manual

97 [IP05025(ALL)03/95]
To turn your EATC on, press the AUTO button
or any of the six manual override buttons along
the bottom of the control.
[IP05125(ALL)03/95]
To turn your EATC off, press the OFF button.
When the system is off, the Display window will
be blank (dark).
[IP05225(ALL)02/95]
If you select AUTO, the system will
automatically determine fan speed and airflow
location. If a manual override button is selected,
your selection determines airflow location only.
Fan speed remains automatic unless you
override it by pressing either side of the FAN
speed button located at the extreme left of the
control panel.
*
[IP05250(ALL)10/95]
Temperature selection
[IP05275(ALL)10/95]
The TEMP button at the upper left of the
Control is for temperature selection. The
aside
of the TEMP button will increase the set
temperature and the
bside of the TEMP button
will lower the set temperature. Pressing the
button and releasing it will change the set
temperature one degree. Holding either side of
the button in will rapidly change the
temperature setting in one degree increments to
either65ÊF (18ÊC) or 85ÊF (29ÊC).Then, the set
temperature will jump5ÊF(3ÊC) andstop at
either60ÊF (16ÊC)which is maximum cooling or
90ÊF (32ÊC)which is maximum heating.
[IP05325(ALL)10/95]
To change the temperature, select any
temperature between6OÊF (16ÊC) and 90ÊF
(32ÊC) by pressing the
aor
bside of the
TEMP button. The EATC will display the
selected temperature.
File:06fcipt.ex
Update:Tue Jan 23 08:13:16 1996
ProCarManuals.com

98 [IP05425(ALL)03/95]If you want continuous maximum cooling, press
the
bside of the TEMP button until60ÊF (16ÊC)
is shown in the display window. Your EATC
will cool at maximum and disregard the60ÊF
(16ÊC) setting until you select a warmer
temperature with the
aside of the TEMP
button. If you want continuous maximum
heating, press the
aside of the TEMP button
until90ÊF (32ÊC) isshown in the display
window. Your EATC will provide maximum
heat regardless of the90ÊF (32ÊC)setting until
you select a cooler temperature with the
bside
of the TEMP button.
[IP05525(ALL)12/95]
one third page art:0001286-D
The display window
[IP05625(ALL)02/95]
The display window will indicate the selected
temperature and the operating function you
have chosen: AUTO or one of the six manual
overrides. It will also indicate manual control of
the fan speed with the word FAN,
H, and dots.
The display window with all possible displays
and their positions are shown here. Normally
not all are shown at the same time but are
included here to familiarize you with the names
and symbols.
File:06fcipt.ex
Update:Tue Jan 23 08:13:16 1996
ProCarManuals.com

99 [IP05650(ALL)10/95]
Changing the display from farenheit to
celsius
[IP05675(ALL)10/95]
To change the temperature display from
Farenheit to Celsius, depress the MAX A/C and
VF-DEF at the same time and hold them
down for about a second. To change back to the
original setting, repeat the process. If the battery
is disconnected, the display will revert to
Fahrenheit and must be reset to Celsius.
*
[IP05725(ALL)01/95]
Automatic operation
[IP05825(ALL)03/95]
Press the AUTO button and select the desired
temperature. The selected temperature and
AUTO will be shown in the Display window.
The EATC will automatically heat or cool to
achieve the set temperature. Under normal
conditions, your EATC will need no additional
attention.
[IP05925(ALL)02/95]
one inch art:0001287-B
The AUTO temperature display
[IP06025(ALL)03/95]
When in AUTO and weather conditions require
heat, air will be sent to the floor. But a feature is
included in your EATC to prevent blowing cold
air to the floor if the engine coolant is not warm
enough to allow heating. The EATC will direct
the airflow to the windshield at low fan speed.
In 3-1/2 minutes or less, the fan speed will start
to increase and the airflow will change to the
floor area.
File:06fcipt.ex
Update:Tue Jan 23 08:13:16 1996
ProCarManuals.com

100 [IP06100(ALL)03/95]When in AUTO and weather conditions require
cooling, the EATC will use outside air or
recirculated air, depending on the temperature
that is selected.
[IP06125(ALL)04/95]
If unusual conditions exist (i.e., window fogging,
etc.), the six manual override buttons allow you
to select special air discharge locations. The fan
speed button allows you to adjust the fan speed
to suit your needs.
[IP06625(ALL)11/94]
Fan speed button
[IP06725(ALL)04/95]
Your EATC automatically adjusts the fan speed
to the existing conditions. You must press AUTO
for automatic fan speed operation. To control the
fan speed yourself, use the button which will
cancel the automatic fan speed control. The
button is located at the left side of the EATC
control panel. It is marked
H. Press the (-) side
for lower speeds. Press the (+) side for higher
speeds.
[IP06925(ALL)03/95]
When you press the fan speed button, the fan
speed will go to manual control. The display
window will show the word FAN,
Hand a
series of dots along with the selected
temperature and operating function.
[IP07025(ALL)02/95]
one inch art:0001290-B
The fan display
File:06fcipt.ex
Update:Tue Jan 23 08:13:16 1996
ProCarManuals.com

101 [IP07125(ALL)12/95]
You can override the fan speed at any time. If
you use the button to control the fan speed, the
EATC will continue to control the temperature
but you control the fan speed. To return to auto
fan control, press the AUTO button. If you are
operating in one of the override functions (S,
MAX A/C, etc.), automatic fan control will
continue unless you press the fan speed button.
To return to automatic fan control, press the
AUTO button. The EATC will return to
automatic operation. If you want to return to
any override function, press the button for that
function. The fan speed will continue to be
automatically controlled.
*
[IP07225(ALL)01/95]
Manual override buttons
[IP07325(ALL)04/95]
Your EATC has six buttons which allow you to
make special selections. The buttons are located
along the bottom edge of the EATC and allow
you to determine where the air will be
discharged. Pressing any override button
changes the air discharge location only. It does
not affect the ability of the system to control
temperature or the fan speed. Return to fully
automatic operation by pushing the AUTO
button.
*
[IP07425(ALL)01/95]
MAX A/C button
[IP07525(ALL)04/95]
The MAX A/C feature allows for faster cooling
because air is drawn from inside the vehicle.
Using inside air causes the fan to sound louder
which is normal for this selection. The display
window will change to indicate MAX A/C and
the airflow will be from the instrument panel
registers. To exit, push AUTO or any of the
other five manual override buttons.
File:06fcipt.ex
Update:Tue Jan 23 08:13:16 1996
ProCarManuals.com

102 %
*
[IP07625(ALL)01/95]
VENT button
[IP07725(ALL)03/95]
Press this button to select outside air through
the instrument panel registers. The display
window will show the set temperature and
VENT to the lower right of the temperature.
Your EATC will heat the air if the temperature
you have selected is warmer than the outside air
coming into the vehicle. However, the air will
NOT be cooled regardless of the temperature
setting. Airflow will be from the instrument
panel registers.
[IP07825(ALL)04/95]
S(Panel and floor) button
[IP07925(ALL)02/95]
Push this button to get air from the floor and
instrument panel registers at the same time. The
display will show the set temperature andS.
Depending on the selected temperature, the air
will be automatically heated or cooled.
[IP08025(ALL)04/95]
R(Floor)
[IP08125(ALL)03/95]
Airflow will be to the floor when theR(floor)
button is pressed. The display window will
show the set temperature andR(floor) to the
right of the temperature. Fan speed will be
automatic unless manually controlled. If you
override the fan speed and wish to return to
automatic fan control, press AUTO. Then, again
selectR(floor) for airflow to the floor.
[IP08225(ALL)04/95]
P(Floor and defrost)
[IP08325(ALL)02/95]
Press this button to get air to the floor and
windshield defrosters at the same time. The
display will show the set temperature andP.If
the outside temperature is about50ÊF (10ÊC) and
above, the air will be dehumidified to remove
moisture. This will help to prevent fogging in
humid weather.
File:06fcipt.ex
Update:Tue Jan 23 08:13:16 1996
ProCarManuals.com

103 % [IP08425(ALL)07/95]
VF-DEF (Front defrost)
[IP08525(ALL)02/95]
Press theVF-DEF (front defrost) button to
obtain maximum airflow to the windshield.
Adjust the temperature setting as required for
defrosting. The Display window will show the
temperature setting withVto the right of the
temperature. When the outside temperature is
about50ÊF (10ÊC) andabove, the air will be
dehumidified to remove moisture. This will help
prevent fogging in humid weather.
[IP08625(ALL)04/95]
OUTSIDE TEMP button
[IP08725(ALL)05/95]
When this button is pressed, the temperature of
the air outside of the vehicle will show in the
display window. If the EATC is off, the display
will go blank after 4 seconds. If the EATC is on,
the outside temperature will be shown until the
OUTSIDE Temp button is pressed a second time
or another override button is pressed.
*
[IP08825(ALL)01/95]
NOTE: The outside temperature reading is
most accurate when the vehicle is
moving. Higher readings may be
obtained when the vehicle is not
moving. The readings that you get may
not agree with temperatures given on
the radio due to differences in vehicle
and station locations.
*
[IP08850(ALL)04/95]
Service
*
[IP08875(ALL)04/95]
If your EATC is not operating as described here,
take it to your dealer to have it checked. System
diagnostics are built in which will allow your
dealer to readily identify problems that might
occur.
File:06fcipt.ex
Update:Tue Jan 23 08:13:16 1996
ProCarManuals.com

104 [IP08925(ALL)04/95]Operating tips
*
[IP09025(ALL)03/95]
The following tips will help you to get the most
satisfaction from your climate control system.
[IP09125(ALL)04/95]
q
In humid weather, selectVF-DEF (front
defrost) before driving. This will help to
prevent windshield fogging. After a few
minutes of operation, switch to any desired
selection.
*
[IP09325(ALL)03/95]
q
Do not put objects under the front seats that
interfere with the flow of air to the back seat
area.
[IP09425(ALL)04/95]
q
Remove any snow, ice, or leaves from the air
intake area of your climate control system
which could block the air intake. The intake
area is located at the bottom of the
windshield, under the hood at the passenger
side rear corner.
[IP09500(ALL)03/95]
q
If the air conditioner performs well in MAX
A/C but not in A/C, this may indicate that
the MicronAirHfilter (if equipped) needs to
be replaced.
[IP10000(ALL)03/95]
MicronAirHAir Filter (If equipped)
*
[IP10100(ALL)02/95]
Your vehicle may have an air filter that removes
pollen and road dust from outside air before it
is directed to the interior of the vehicle. For
maintenance of this filter, seeServicing Your
Taurus.
% [IP21650(ALL)04/95]
Rear Window Defroster and Heated Side
View Mirrors
*
[IP21700(ALL)02/95]
The defroster for the rear window clears frost,
fog, or thin ice from both the inside and outside
of the rear window and activates the heated side
view mirrors.
[IP21900(ALL)04/95]
The button for the rear defroster and heated side
view mirrors is on the instrument panel.
File:06fcipt.ex
Update:Tue Jan 23 08:13:16 1996
ProCarManuals.com
