1996 FORD TAURUS Owners Manual

179
*
[AS16600(ALL)08/95]
q
Rewinding the tape
[AS16725(ALL)04/95]
To rewind the tape, press the ªREWº button.
The radio will automatically begin playing
until rewind is manually stopped (by
pressing the ªTAPEº, ªEJº, ªREWº or ªFFº
button) or the beginning of the tape is
reached. The display will show a flashing
X
to indicate rewind.
*
[AS17000(ALL)08/95]
q
Using the ªSEEKº function with your cassette
tape player
[AS17125(ALL)04/95]
While in the tape mode, press the right (
a)
side of the ªSEEKº button to seek forward to
the next selection on the tape (display
indicates ªSEEKº). Press the left (
b) side to
seek the previous tape selection.
*
[AS17135(ALL)09/95]
NOTE: If you want to restart a currently
playing tape selection, press the left
(
b) side of the ªSEEKº button after
approximately three seconds into the
current selection.
*
[AS17200(ALL)08/95]
q
Using the ªSCANº function with your
cassette tape player
[AS17325(ALL)02/95]
Press the ªSCANº button to begin the
forward scan mode on the tape currently
playing, stopping on each tape selection for
approximately an eight-second sampling
(display flashes ªSCANº).
[AS17345(ALL)04/95]
To stop the scan mode on the presently
sampled tape selection press ªSCANº a
second time.
[AS17348(ALL)02/95]
How to change the side of the tape being
played
[AS17350(ALL)02/95]
The alternate side of the tape can be selected at
any time by pressing the ªSIDE 1-2º button.
File:09fcast.ex
Update:Mon Jan 22 15:58:04 1996
ProCarManuals.com

180
*
[AS17400(ALL)08/95]
How to eject the tape
[AS17525(ALL)04/95]
To stop the tape and eject the cassette, press the
ªEJº button. The radio will resume playing if the
power is on. The tape cartridge can be ejected
with radio power (and/or ignition) on or off.
*
[AS17550(ALL)08/95]
How to store the tape
[AS17575(ALL)04/95]
Press the ªAMº or ªFMº button (or ªCDº, if
equipped) to stop the tape player and resume
radio play (or CD-DJ).
*
[AS17600(ALL)08/95]
Using the DolbyHB noise reduction feature
*
[AS17700(ALL)08/95]
NOTE: Noise reduction system manufactured
under license from Dolby Labs
Licensing Corporation. ªDolbyº and
double-D symbol are trademarks of
Dolby Laboratories Licensing
Corporation.
*
[AS17825(ALL)04/95]
Push thekbutton to activate Dolby B Noise
Reduction. Push again to deactivate.
*
[AS18260(ALL)08/95]
Tape error messages
*
[AS18280(ALL)08/95]
Your cassette tape player is equipped to
diagnose certain problems you may experience.
Error codes are as follows:
[AS18325(ALL)04/95]
TD E1 Ð Possible problem tape cartridge. The
cassette player will automatically eject the tape.
Insert the tape again. If the same error code
appears in the display, try a different tape. If the
problem persists, refer the problem to qualified
personnel for service.
[AS18330(ALL)04/95]
TD E2 Ð Radio cannot eject tape. If tape is not
ejected when the ªEJº button is pressed, refer
the problem to qualified personnel for service.
File:09fcast.ex
Update:Mon Jan 22 15:58:04 1996
ProCarManuals.com

181 [AS18350(ALL)12/95]
TD E3 Ð Radio cannot insert tape properly. The
cassette player will automatically eject the tape.
Insert tape again. If the same error code appears
in the display, try a different tape. If the
problem persists, refer the problem to qualified
personnel for service.
*
[AS18500(ALL)08/95]
Tips on Caring for the Cassette Player and
Tapes
*
[AS18600(ALL)08/95]
In order to keep your cassette tape player
performing the way it was meant to, read and
follow these simple precautions:
*
[AS18700(ALL)08/95]
q
Using a Ford Cassette Cleaning Cartridge to
clean the tape player head after 10-12 hours
of play will help maintain the best playback
sound and proper tape operation.
*
[AS18800(ALL)08/95]
q
Only cassettes that are 90 minutes long or
less should be used. Tapes longer than 90
minutes are thinner and subject to breakage
or may jam the tape player mechanism.
*
[AS18900(ALL)08/95]
q
Protect cassettes from exposure to direct
sunlight, high humidity and extreme heat or
cold. If they are exposed to extreme
conditions, allow them to reach a moderate
temperature before playing.
*
[AS19000(ALL)08/95]
q
If a tape is loose inside the cassette, tighten it
before playing by putting your finger or a
pencil into one of the holes and turning the
hub until the tape is tight.
*
[AS19100(ALL)08/95]
q
Loose labels on cassette tapes can become
lodged in the mechanism. Remove any loose
label material before inserting cassette.
*
[AS19200(ALL)08/95]
q
Do not leave a tape in the cassette tape
player. High heat in the vehicle can cause the
cassette to warp.
File:09fcast.ex
Update:Mon Jan 22 15:58:04 1996
ProCarManuals.com

182
%*
[AS29351(ALL)02/95]
Ford 6-CD Changer
[AS29401(ALL)04/95]
The Ford 6-CD Changer is in the left of the
trunk or the right of the cargo area. It is
controlled by the audio system buttons.
*
[AS29450(ALL)02/95]
Loading Instructions
[AS29500(ALL)04/95]
1. Open the cover door. Open Compact Disc
Changer trunk unit by sliding door to the
front (sedan) or rear (wagon) (Figure 1).
[AS29550(ALL)04/95]
one third page art:0001464-A
Figure 1
[AS29601(ALL)02/95]
2. Press the orange Eject button to eject the disc
ªmagazineº (holds 6 discs) (Figure 2).
[AS29650(ALL)04/95]
one third page art:0001465-A
Figure 2
File:09fcast.ex
Update:Mon Jan 22 15:58:04 1996
ProCarManuals.com

183 [AS29701(ALL)02/95]
3. Load discs into the disc magazine slots
(numbered 1 through 6 on the window) one
at a time with labeled surfaces upward,
starting with bottom slot number 1
(Figure 3).
[AS29750(ALL)10/95]
one third page art:0001466-B
Figure 3
[AS29775(ALL)04/95]
To remove a compact disc from the disc
magazine, slide the corresponding lever on
the opposite side of the magazine window.
The disc will partially eject.
[AS29800(ALL)02/95]
4. Insert loaded disc magazine into changer
unit with the arrow on top of the disc
magazine pointing toward the changer
(Figure 4). Make sure magazine is fully
inserted into changer.
[AS29850(ALL)04/95]
quarter page art:0001467-A
Figure 4
[AS29950(ALL)02/95]
5. Close unit by sliding changer panel door to
the rear (sedan) or front (wagon).
File:09fcast.ex
Update:Mon Jan 22 15:58:04 1996
ProCarManuals.com

184 [AS30001(ALL)02/95]The Compact Disc Changer unit is now ready to
play using the controls of your audio system.
*
[AS30050(ALL)02/95]
How to Operate the Ford 6-CD Changer
Using the Controls on the Radio
[AS30101(ALL)02/95]
If your vehicle is equipped with the Ford 6-CD
Changer System, you can operate it through the
controls of your audio system.
*
[AS30150(ALL)05/95]
Several of the controls on the radio operate in
the same manner in CD mode as they do in
radio or cassette mode: turning the power on,
volume control and adjusting the bass, treble,
speaker balance or fade.
*
[AS30201(ALL)02/95]
How to begin CD Changer play
*
[AS30250(ALL)02/95]
NOTE: Radio power must be on to operate the
Compact Disc Changer.
[AS30301(ALL)04/95]
Push the ªCDº button to begin CD play. If the
disc magazine has just been installed, the CD
Changer will automatically begin playing the
first track (selection) of the first disc loaded in
the unit. After that, the CD Changer will start
on the disc and track where it was stopped. The
display will indicate ªCD-##º for disc number,
then display ªTR-##º for track number, then
ªDD-TTº for disc number and track number.
[AS30325(ALL)04/95]
If the CD Changer is empty, ªNOº and ªCDº
will flash in the display and radio play will
continue.
*
[AS30350(ALL)02/95]
How to change the disc being played
[AS30401(ALL)02/95]
When in the CD mode, you can change discs by
pressing the right (
a) side of the ªTUNE/DISCº
button (to select the next disc) or the left (
b)
side of the ªTUNE/DISCº button (to select the
previous disc). Play will begin on the first track
of the selected disc.
File:09fcast.ex
Update:Mon Jan 22 15:58:04 1996
ProCarManuals.com

185
*
[AS30450(ALL)02/95]
When either side of the button is pressed and
held, the CD changer will continue
fast-forwarding or reversing through the discs in
the disc magazine. During these functions, the
display will indicate the disc number.
*
[AS30501(ALL)10/95]
How to change the track being played
*
[AS30550(ALL)02/95]
Press the right (
a) side of the ªSEEKº button to
seek forward to the next track of current disc.
After the last track has been completed, the CD
player automatically wraps back to the first track
of the current disc.
*
[AS30601(ALL)02/95]
Press the left (
b) side of the SEEK button to
seek in reverse to the previous track on the
current disc. If a selection has been playing for
three seconds or more and you press the left
(
b) side of the SEEK button, the CD Changer
will replay that selection from the beginning.
[AS30625(ALL)04/95]
Using fast forward or reverse
[AS30651(ALL)04/95]
To quickly search for a particular point in a
selection, press and hold the ªFFº or ªREWº
button. Find the desired point by watching the
elapsed playing time in the display or listening
to the sound, then release the button.
*
[AS30800(ALL)02/95]
Operating the Shuffle feature
*
[AS30851(ALL)02/95]
The shuffle feature on your CD player allows
you to listen to your disc selections in a different
order. When this feature is activated, your CD
player will randomly select and play tracks on
the disc.
[AS30900(ALL)02/95]
Press the ªSHUFFLEº button to turn on, press it
again to turn off. When on, the display will
indicate ªSHUFº then the disc and track number
(dd-tt).
File:09fcast.ex
Update:Mon Jan 22 15:58:04 1996
ProCarManuals.com

186
*
[AS30951(ALL)02/95]
Operating the ªSCANº function
*
[AS31000(ALL)02/95]
Press the ªSCANº button to enter the scan
mode. The CD player will begin scanning the
disc, stopping on each listenable track for
approximately an eight second sampling. This
continues until you press the ªSCANº button a
second time.
*
[AS31051(ALL)02/95]
Operating the Shuffle and Scan features
simultaneously
*
[AS31101(ALL)02/95]
Both the shuffle and scan features can be
activated simultaneously. In this mode, the
player will randomly pick a selection and play
the first eight seconds. This process is continued
until either the ªSCANº button or ªSHUFFLEº
button is pressed a second time.
*
[AS31110(ALL)04/95]
Operating the CD Compression feature
*
[AS31120(ALL)04/95]
The compression feature will bring soft and loud
passages closer together for a more consistent
listening level.
[AS31130(ALL)04/95]
To turn the compression on, press the ªCOMPº
button. When the compression feature is
activated, the display will indicate ªCº. Press
again to deactivate.
*
[AS31150(ALL)02/95]
How to stop CD play
[AS31200(ALL)04/95]
While in CD Changer mode, press the ªAMº or
ªFMº button to stop CD play and resume radio
play. Loading a cassette into the cassette deck
(or pressing ªTAPEº if a cassette is already
loaded) will stop CD play and begin cassette
play.
File:09fcast.ex
Update:Mon Jan 22 15:58:04 1996
ProCarManuals.com
