1996 FORD TAURUS Owners Manual

15
*
[SR05930(ALL)08/95]
NOTE: When the combination lap/shoulder
belt is unbuckled and allowed to
retract completely, the retractor will
switch to the vehicle sensitive
(emergency) locking mode. See the
detailed instructions underSafety Seats
for Childrenin this chapter.
%*
[SR05940(ALL)08/95]
Shoulder Belt Height Adjustment
*
[SR05950(ALL)08/95]
Driver and right front passenger
*
[SR05960(ALL)06/95]
You can adjust the shoulder belt height to one of
five (5) positions.
[SR05962(ALL)06/95]
To adjust the belt down, pinch the release
button. To adjust the belt up, slide the adjuster
up. (You do not have to pinch the release
button.)
*
[SR05964(ALL)06/95]
Make sure the adjuster is firmly in one of the
five positions. The belt should be adjusted up or
down until the belt rests on your shoulder near
your neck.
[SR05966(ALL)06/95]
one third page art:0001402-B
The shoulder belt height adjuster
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

16
*
[SR05968(ALL)06/95]
RWARNING
Position the shoulder belt height adjuster
so that the belt rests across the middle of
your shoulder. Be sure the shoulder belt is
properly positioned on your shoulder each
time you use the belt. If the shoulder belt
is off your shoulder, on your upper arm
or neck, there is a greater risk of severe
injury in a collision.
[SR06000(ALL)04/95]
Safety Belts for Rear-Facing Occupants
(Wagon)
[SR06050(ALL)05/95]
RWARNING
Never use child safety seats in the third
seat of a wagon.
[SR06060(ALL)10/95]
Your vehicle is equipped with safety seat belts
containing an adjust tongue at the rear-facing
seating positions.
[SR06075(ALL)10/95]
When the adjust tongue of the lap/shoulder
combination seat belt is latched into the buckle,
the tongue will allow the lap portion to become
shorter, but locks the webbing in place to restrict
it from becoming longer.
[SR06125(ALL)10/95]
Before you can reach and latch a combination
lap and shoulder belt having an adjust tongue
into the buckle, you may have to lengthen the
lap belt portion of it. To lengthen the lap belt,
pull some webbing out of the shoulder belt
retractor. While holding the webbing below the
tongue, grasp the tongue so that it is parallel to
the webbing and slide the tongue upward.
Provide enough lap belt length so that the
tongue can reach the buckle.
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

17 [SR06175(ALL)10/95]
To fasten the belt, pull the combination lap and
shoulder belt from the retractor so that the
shoulder belt portion of the safety belt crosses
your shoulder and chest. Be sure the belt is not
twisted. If the belt is twisted remove the twist.
Insert the belt tongue into the proper buckle for
your seating position until you hear a snap and
feel it latch. Make sure the tongue is securely
fastened to the buckle by pulling on the tongue.
*
[SR06201(ALL)07/95]
RWARNING
The lap belts should fit snugly and as low
as possible around the hips, not around
the waist.
*
[SR06225(ALL)03/95]
RWARNING
All front and rear seat outboard
occupants (including pregnant women)
should wear lap and shoulder belts, for
optimum protection in a collision.
*
[SR06251(ALL)05/95]
RWARNING
Failure to follow these precautions could
increase the risk and/or severity of injury
in a collision. 1) Use the shoulder belt on
the outside shoulder only. Never wear the
shoulder belt under the arm. 2) Never
swing it around your neck over the inside
shoulder. 3) Never use a single belt for
more than one person.
*
[SR06275(ALL)03/95]
Due to folding rear seats, sometimes the buckles
and tongues toward the center of the vehicle
may be hidden by the rear edge of the seat
cushion. Pull them out so they will be accessible.
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

18 [SR06301(ALL)10/95]While you are fastened in the seat belt, the
shoulder belt adjusts to your movement.
However, if you brake hard, turn hard, or if
your vehicle receives an impact of 5 mph
(8 km/h) or more, the safety belt will become
locked and help reduce your forward movement.
[SR06500(ALL)03/95]
To unfasten the belt, push the red release button
on the end of the buckle. This allows the tongue
to unlatch from the buckle. While the belt
retracts, guide the tongue to its original position
to prevent it from striking you or the vehicle.
[SR06550(ALL)02/95]
one third page art:0000029-F
Unfastening the combination lap and shoulder belts for the
rear-facing third seat (wagon)
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

19 [SR06560(ALL)04/95]
Center Occupant Rear Safety Belt (Sedan)
[SR06565(ALL)04/95]
The safety belt in the center rear seating position
has a detachable shoulder belt.
[SR06570(ALL)04/95]
To attach the shoulder belt to the lap belt, pull
the shoulder belt out from the retractor in the
seatback and insert the lap belt connecting pin
into the wide end of the key-slot on the
shoulder belt as shown in Figure 1. Pull the
connecting pin into the narrow end of the
key-slot until you hear a snap and feel it latch.
See Figure 2. Make sure the shoulder belt is
securely fastened to the lap belt by pulling up
on the shoulder belt.
[SR06575(ALL)04/95]
half page art:0001371-B
The reverse side of the lap belt and the detachable
shoulder belt
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

20 [SR06580(ALL)05/95]
half page art:0001372-AThe reverse side of the shoulder belt attached to the lap
belt
[SR06585(ALL)12/95]
RWARNING
The rear center lap belt must be tightened
separately from the shoulder strap. The
lap belt must fit snugly, and as low as
possible around the hips. Do not wear
around your waist. For information about
adjusting the belt, see ªLAP BELTSº in
this chapter.
[SR06590(ALL)04/95]
Detach the shoulder belt before folding down
the passenger side rear seat. To detach the
shoulder belt, slide the connecting pin to the
wide end of the key-slot and lift the shoulder
belt off the connecting pin. As the shoulder belt
retracts, guide the belt so that it does not strike
you or the vehicle.
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

21
%*
[SR06601(ALL)05/95]
Lap Belts
[SR06650(ALL)10/95]
The lap belts in the center front seating position
(if equipped) and center rear seat do not adjust
automatically. You must adjust them to fit
snugly and as low as possible around your hips.
Do not wear the lap belt around your waist.
[SR06675(ALL)04/95]
The front center seat belt buckle and tongue are
stowed in a pocket between the seat cushion and
seatback. Remove them from the stowage pocket
before fastening.
*
[SR06700(ALL)06/95]
Pull the belt across your hips andinsert the
tongue into the correct buckleon your seat
until you hear a snap and feel it lock. Make sure
the buckle is securely fastened.
%*
[SR06750(ALL)06/95]
If you need to lengthen the belt, unfasten it and
tip the belt tongue at a right angle to the belt.
Pull the belt tongue over your lap until it
reaches the buckle.
*
[SR06800(ALL)06/95]
If you need to shorten the belt, pull on the loose
end of the webbing until the belt fits snugly.
[SR06850(ALL)08/95]
one third page art:0000029-F
Unfastening the lap belts for the center front and center
rear seating positions
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

22
*
[SR06900(ALL)08/95]
To unfasten the belt, push the release button on
the end of the buckle. This allows the tongue to
unlatch from the buckle.
*
[SR06925(ALL)07/95]
RWARNING
The lap belts should fit snugly and as low
as possible around the hips, not around
the waist.
%*
[SR07750(ALL)08/95]
Safety Belt Extension Assembly
*
[SR07800(ALL)07/95]
For some people, the safety belt may be too
short even when it is fully extended. You can
add about eight inches (20 cm) to the belt length
with a safety belt extension assembly (part
number 611C22). Safety belt extensions are
available at no cost from your dealer.
[SR07850(ALL)02/95]
This assembly is not for use in the wagon
rear-facing seat.
[SR07900(ALL)05/95]
RWARNING
The use of the safety belt extension in the
wagon rear-facing seat will increase the
risk of personal injury.
*
[SR07924(ALL)08/95]
Use only extensions manufactured by the same
supplier as the safety belt. Manufacturer
identification is located at the end of the
webbing on the label. Also, use the safety belt
extension only if the safety belt is too short for
you when fully extended. Do not use extension
to change the fit of the shoulder belt across the
torso.
*
[SR07925(ALL)08/95]
RWARNING
Failure to follow these instructions will
affect the performance of the safety belts
and increase the risk of personal injury.
