1996 FORD TAURUS Owners Manual

292
*
[SV26300(ALL)01/95]
RWARNING
When replacing full size tires, never mix
radial, bias-belted, or bias-type tires. Use
only the tire sizes that are listed on the
tire pressure decal. Make sure that all tires
are the same size, speed rating, and
load-carrying capacity. Use only the tire
combinations recommended on the decal.
If you do not follow these precautions,
your vehicle may not drive properly and
safely.
*
[SV26400(ALL)01/95]
Tires that are larger or smaller than your
vehicle's original tires may also affect the
accuracy of your speedometer.
%*
[SV27400(ALL)02/95]
Information About Tire Quality Grades
*
[SV27500(ALL)01/95]
New vehicles are fitted with tires that have their
Tire Quality Grade (described below) molded
into the tire's sidewall. These Tire Quality
Grades are determined by standards that the
United States Department of Transportation has
set.
*
[SV27550(ALL)01/95]
Tire Quality Grades apply to new pneumatic
tires for use on passenger cars. They do not
apply to deep tread, winter-type snow tires,
space-saver or temporary use spare tires, tires
with nominal rim diameters of 10 to 12 inches or
limited production tires as defined in Title 49
Code of Federal Regulations Part 575.104(c)(2).
*
[SV27600(ALL)01/95]
U.S. Department of Transportation Ð Tire
quality grades:The U.S. Department of
Transportation requires Ford to give you the
following information about tire grades exactly
as the government has written it.
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

293 %
*
[SV27799(ALL)01/95]
Treadwear
*
[SV27800(ALL)01/95]
The treadwear grade is a comparative rating
based on the wear rate of the tire when tested
under controlled conditions on a specified
government test course. For example, a tire
graded 150 would wear one and one-half (1 1/2)
times as well on the government course as a tire
graded 100. The relative performance of tires
depends upon the actual conditions of their use,
however, and may depart significantly from the
norm due to variations in driving habits, service
practices and differences in road characteristics
and climate.
*
[SV27999(ALL)01/95]
Traction A B C
*
[SV28000(ALL)01/95]
The traction grades, from highest to lowest, are
A, B, and C, and they represent the tire's ability
to stop on wet pavement as measured under
controlled conditions on specified government
test surfaces of asphalt and concrete. A tire
marked C may have poor traction performance.
Warning: The traction grade assigned to this tire
is based on braking (straightahead) traction tests
and does not include cornering (turning)
traction.
*
[SV28299(ALL)01/95]
Temperature A B C
*
[SV28300(ALL)01/95]
The temperature grades are A (the highest), B,
and C, representing the tire's resistance to the
generation of heat and its ability to dissipate
heat when tested under controlled conditions on
a specified indoor laboratory test wheel.
Sustained high temperature can cause the
material of the tire to degenerate and reduce tire
life, and excessive temperature can lead to
sudden tire failure. The grade C corresponds to
a level of performance which all passenger car
tires must meet under the Federal Motor Vehicle
Safety Standard No. 109. Grades B and A
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

294represent higher levels of performance on the
laboratory test wheel than the minimum
required by law. Warning: The temperature
grade for this tire is established for a tire that is
properly inflated and not overloaded. Excessive
speed, underinflation, or excessive loading, either
separately or in combination, can cause heat
buildup and possible tire failure.
%*
[SV28500(ALL)04/95]
Snow Tires and Chains
*
[SV28600(ALL)01/95]
The tires on your vehicle have all-weather treads
that provide traction in rain or snow. However,
during the winter months in some climates, you
may need to use snow tires and occasionally
chains for your tires.
*
[SV28700(ALL)05/95]
RWARNING
Snow tires must be the same size and
grade as the tires you currently have on
your vehicle.
*
[SV28775(ALL)02/95]
Use chains on the tires only in an emergency or
if the law requires them where you live. If you
choose to use chains on your vehicle's tires, be
aware of the following:
*
[SV28825(ALL)08/93]
q
Tire chains may scratch or chip aluminum
wheels. IT IS RECOMMENDED THAT TIRE
CHAINS ARE INSTALLED ON STEEL
WHEELS ONLY. Be sure to remove wheel
covers (if equipped) from steel rims before
using tire chains to avoid scratches or
damage.
[SV28850( T)12/95]
q
Do not use tire chains if your vehicle is
equipped with P225/55VR16 tires (SHO only).
*
[SV28925(ALL)11/94]
q
Local regulations may prohibit or restrict the
use of tire chains. Investigate the laws and
regulations in your area before installing
chains.
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

295
*
[SV28950(ALL)05/95]
q
Put the chains on the front tires tightly with
the ends held down securely. Retighten the
chains after driving 1/2 mile (1 km). Follow
the chain manufacturer's instructions.
*
[SV28975(ALL)05/95]
q
Do not drive faster than 30 mph (50 km/h)
or the chain manufacturer's recommended
speed limit, whichever is lower. Avoid
bumps, holes and sharp turns. If you can
hear the chains rub or bang against your
vehicle, remove the chains to prevent damage
to your vehicle.
*
[SV29025(ALL)11/94]
q
Tire chains may affect vehicle handling. Drive
carefully and avoid hard braking.
*
[SV29050(ALL)11/94]
q
Do not use chains on temporary spare tires.
They may damage the vehicle and the tire.
*
[SV29150(ALL)05/94]
q
Remove tire chains at the first opportunity
after using them on snow and ice. Do not use
the chains on dry roads.
%*
[SV29160(ALL)04/95]
Cleaning the Wheels
*
[SV29170(ALL)05/95]
Wash the wheels with the same detergent you
use to wash your vehicle's body. Do not use
acid-based wheel cleaners, steel wool, abrasives,
fuel, or strong detergents. These substances will
damage protective coatings. Use tar and road oil
remover to remove grease and tar.
*
[SV29180(ALL)09/95]
NOTE: Before going to a car wash, find out if
the brushes are abrasive.
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

296
*
[SV29220(ALL)04/95]
Air Filter
% [SV29240(ALL)02/95]
To replace the engine air filter, unclip the two
latches, separate the housing and remove the old
filter. Wipe the interior of the housing clean
before inserting the new filter. Lock the two
latches.
[SV29260(ALL)09/95]
NOTE: Do not use oil-impregnated air filters.
Filters other than the ones specified in
this Owner Guide can cause engine
damage. Your warranties may not
apply if your vehicle is damaged
because you used the wrong air filter.
SeeMotorcraft partsin the Index.
%
*
[SV29300(ALL)05/95]
Automatic Transaxle Fluid
*
[SV29310(ALL)03/95]
Under normal circumstances, you do not need to
check the fluid level of the transaxle, since your
vehicle does not use up transaxle fluid. Refer to
theMaintenance Schedule and Recordbooklet for
replacement intervals. However, if the transaxle
is not working properly Ð for instance, the
transaxle may slip or shift slowly, or you may
notice some sign of fluid leakage Ð the fluid
level should be checked.
%*
[SV29340(ALL)02/93]
Checking the Automatic Transaxle Fluid
*
[SV29350(ALL)02/95]
With the vehicle on a level surface and the brake
pedal fully applied, start the engine and move
the gearshift selector through all of the gears.
Allow sufficient time for each position to engage.
Securely latch the gearshift selector in the P
(Park) position. Fully set the parking brake and
leave the engine running.
*
[SV29370(ALL)01/95]
Wipe off the dipstick cap and pull the dipstick
out. Wipe the indicator end clean. Put the
dipstick back into the filler tube and make sure
it is fully seated. Pull the dipstick out and read
the fluid level.
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

297 [SV29380(ALL)04/95]
one inch art:0000717-E
Automatic overdrive transaxle fluid dipstick
[SV29388(ALL)04/95]
NOTE: Your vehicle should not be driven until
some fluid has been added if the fluid
level is below the bottom hole on the
dipstick and the outside temperature is
above50ÊF (10ÊC). Addonly enough
fluid to bring the level above the
bottom hole.
[SV29395(ALL)04/95]
If the vehicle has not been driven and the fluid
level is above the bottom hole on the dipstick,
do not add fluid. Recheck the fluid level after
your vehicle has reached normal operating
temperature.
*
[SV29396(ALL)05/95]
Normal operating temperature is reached after
driving approximately 20 miles (30 km). The
fluid level should be within the crosshatched
area on the dipstick.
*
[SV29397(ALL)01/95]
NOTE: If the vehicle has been operated for an
extended period at high speeds, driven
in city traffic during hot weather, or
has been pulling a trailer, the vehicle
should be turned off for about 30
minutes to allow the fluid to cool
before checking.
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

298 %
*
[SV29400(ALL)01/95]
Adding Automatic Transaxle Fluid
*
[SV29410(ALL)01/95]
Before adding any fluid, be sure that the correct
type will be used. Correct type is shown on the
dipstick.
[SV29415(ALL)04/93]
Add fluid in 1/2 pint (.25L) increments through
the filler tube to bring the level within the
crosshatched area on the dipstick. If the level is
above the top hole on the dipstick, excess fluid
should be removed by a qualified technician.
%*
[SV29425(ALL)09/95]
NOTE: Always dispose of used automotive
fluids in a responsible manner. Follow
your community's standards for
disposing of these types of fluids. Call
your local recycling center to find out
about recycling automotive fluids.
%
*
[SV30200(ALL)03/95]
Brake Fluid
*
[SV30300(ALL)04/95]
Under normal circumstances, your vehicle
should not use up brake fluid rapidly. However,
expect the level of the brake fluid to slowly fall
as you put more mileage on your vehicle and
the brake lining wears.
%*
[SV30400(ALL)06/93]
You should check the brake fluid at every
scheduled engine oil change, but be sure to
check it at least once a year. You can do this by
looking at the fluid level in the plastic reservoir
on the master cylinder. (SeeThe Engine Typesin
this chapter to locate the master cylinder.) The
fluid level should be at or near the MAX mark.
*
[SV30450(ALL)05/95]
RWARNING
Brake fluid is toxic.
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

299
*
[SV30475(ALL)07/95]
If brake fluid contacts eyes, flush eyes with
running water for 15 minutes. Get medical
attention if irritation persists. If taken internally,
drink water and induce vomiting. Get medical
attention immediately.
*
[SV30500(ALL)10/95]
If the fluid is low, carefully clean and remove
the cap from the reservoir. Fill the reservoir to
the MAX line with Ford High Performance DOT
3 Brake Fluid C6AZ-19542-AB or equivalent
DOT 3 fluid meeting Ford specification
ESA-M6C25-A.
*
[SV30800(ALL)01/95]
RWARNING
If you use a brake fluid that is not DOT
3, you will cause permanent damage to
your brakes.
*
[SV30900(ALL)01/95]
Do not fill the reservoir above the MAX line.
*
[SV31000(ALL)01/95]
If you find that the fluid level is excessively low
Ð below the seam or ridge on the outside of the
plastic reservoir Ð have the brake system
inspected.
*
[SV31100(ALL)01/95]
RWARNING
Do not let the reservoir for the master
cylinder run dry. This may cause the
brakes to fail.
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com
