1996 FORD TAURUS Owners Manual

88 [LG16220(ALL)02/95]This light will come on to show a rear tail lamp
burnout when the light switch is turned to the
parking lamp or headlamp position.
[LG16260(ALL)04/95]
This light will come on to show a brakelamp
burnout only when the brake pedal is pressed.
[LG16280(ALL)02/95]
The light will stay on until the ignition is turned
to the OFF position.
[LG16300(ALL)02/95]
one inch art:0000117-B
Rear lamp out light
[LG16400(ALL)12/91]
NOTE: The warning light may not work or
you may get a false reading if you use
trailer lights or use improper
replacement bulbs.
[LG16700(ALL)12/95]
Anti-Theft Alarm Light
[LG16800(ALL)11/94]
This light is used when you set the anti-theft
alarm system. SeeAnti-theft systemin the Index.
[LG16825(ALL)02/95]
one inch art:0001389-A
Anti-theft alarm light
File:05fclgt.ex
Update:Tue Jan 23 08:14:15 1996
ProCarManuals.com

89 [LG16950(ALL)12/95]
Overdrive Off Indicator
[LG16975(ALL)02/95]
This light tells you that the Overdrive Off (O/D
OFF) switch on the gearshift lever has been
pushed. When the light is on, the transaxle will
not shift into overdrive. Depressing the O/D
OFF switch located below the gearshift release
button on the floor gearshift or located on the
end of the column gearshift will return the
vehicle to ªoverdrive onº mode. The transaxle
will be in the ªoverdrive onº mode when the
vehicle is started even if the ªO/D OFFº mode
was selected when the vehicle was last shut off.
[LG17025(ALL)02/95]
If the light does not come on when the O/D
OFF switch is depressed or if the light flashes
when you are driving, have your vehicle
serviced at the first opportunity. If this condition
persists, damage could occur to the transaxle.
[LG17050(ALL)02/95]
one inch art:0001009-B
Overdrive off indicator
File:05fclgt.ex
Update:Tue Jan 23 08:14:15 1996
ProCarManuals.com

91
Instrument Panel Controls
[IP00400(ALL)05/95]
The main controls for the climate control system,
clock, and radio are in the oval Integrated
Control Panel on the instrument panel.
[IP00410(ALL)04/95]
The controls for the lights and climate control air
registers are also on the instrument panel.
*
[IP00420(ALL)03/95]
Clean the instrument panel lens and woodtone
trim with a soft cloth and a glass cleaner. Do
not use paper towel or any abrasive cleaner to
clean either the lens or the woodtone trim as
these may cause scratches.
%*
[IP00430(ALL)09/95]
NOTE: Any cleaner or polish that increases the
gloss (shine) of the upper part of the
instrument panel should be avoided.
The dull finish in this area is to help
protect the driver from undesirable
windshield reflection.
File:06fcipt.ex
Update:Tue Jan 23 08:13:16 1996
ProCarManuals.com

92 % [IP00470(ALL)04/95]
full page art:0000661-JInstrument panel
File:06fcipt.ex
Update:Tue Jan 23 08:13:16 1996
ProCarManuals.com

93
%*
[IP00500(ALL)06/95]
The Climate Control Systems
*
[IP00600(ALL)06/95]
Your vehicle has one of the following climate
control systems:
[IP00900(ALL)08/95]
q
Manual Heating and Air Conditioning System
[IP01000(ALL)04/95]
q
Electronic Automatic Temperature Control
(EATC) System
*
[IP01100(ALL)06/95]
If you are not sure which system your vehicle
has, see the diagrams on the following pages.
% [IP03150(ALL)08/95]
Manual Heating and Air Conditioning
System
[IP03175(ALL)03/95]
one third page art:0000698-E
The knobs that control the manual heating and air
conditioning system
[IP03200(ALL)08/95]
Fan speed knob
[IP03250(ALL)08/95]
The fan speed knob controls the volume of air
circulated in the vehicle. There are four fan
speeds: LO, medium/low (first dot),
medium/high (second dot), and HI.
[IP03300(ALL)08/95]
Function selector knob
[IP03351(ALL)08/95]
The function selector knob controls airflow to
the inside of the vehicle.
File:06fcipt.ex
Update:Tue Jan 23 08:13:16 1996
ProCarManuals.com

94
*
[IP03401(ALL)08/95]
MAX A/C
[IP03450(ALL)08/95]
MAX A/C uses recirculated air to cool the
vehicle. It allows for faster cooling but is noisier
than A/C. The airflow will be from the
instrument panel registers.
*
[IP03501(ALL)08/95]
A/C
[IP03550(ALL)04/95]
A/C uses outside air to cool the vehicle. It is
quieter that MAX A/C, but not as economical.
The airflow will be from the instrument panel
registers.
%*
[IP03601(ALL)03/95]
VENT
[IP03650(ALL)03/95]
VENT brings in outside air through the
instrument panel registers. It can be used for
heating or ventilating.
[IP03701(ALL)08/95]
OFF
[IP03750(ALL)08/95]
In OFF, outside air is shut out and the fan will
not operate.
[IP03801(ALL)04/95]
S(Panel and floor)
[IP03850(ALL)04/95]
This brings in outside air through the instrument
panel registers and the front and rear floor
ducts. It can be used for heating or ventilating.
*
[IP03901(ALL)08/95]
R(Floor)
[IP03950(ALL)04/95]
This allows for maximum heating. The airflow is
from the front and rear floor ducts.
File:06fcipt.ex
Update:Tue Jan 23 08:13:16 1996
ProCarManuals.com

95 [IP04001(ALL)04/95]
P(Floor and defrost)
[IP04050(ALL)04/95]
This brings in outside air through the floor ducts
and the windshield defroster ducts. It can be
used for heating or ventilation.
%*
[IP04100(ALL)08/95]
V(Defrost)
[IP04150(ALL)04/95]
This brings in outside air through the
windshield defroster ducts. It can be used to
clear ice or fog from the windshield.
[IP04200(ALL)08/95]
Temperature control knob
[IP04250(ALL)08/95]
The temperature control knob may be adjusted
from cool (blue range) to warm (red range).
%*
[IP04700(ALL)04/95]
Electronic Automatic Temperature Control
System
[IP04725(ALL)12/95]
The control for your Electronic Automatic
Temperature Control (EATC) is located at the
center of the instrument panel in the Integrated
Control Panel and will operate only when the
ignition is turned to the ON position.
*
[IP04825(ALL)05/95]
The EATC feature maintains the temperature
you select and automatically controls the airflow
for your comfort. It also allows you to override
the automatic operation with manual override
buttons.
File:06fcipt.ex
Update:Tue Jan 23 08:13:16 1996
ProCarManuals.com

96 [IP04925(ALL)12/95]
full page art:0001285-DThe Electronic Automatic Temperature Control System
File:06fcipt.ex
Update:Tue Jan 23 08:13:16 1996
ProCarManuals.com
