[SR02850(ALL)05/95]
RWARNING
Ford recommends that all safety belt
assemblies and attaching hardware should
be inspected by a qualified technician
after any collision. Safety belt assemblies
not in use during a collision should also
be inspected and replaced if either
damage or improper operation is noted.
*
[SR02900(ALL)08/95]
RWARNING
To reduce the risk of serious injury in a
collision, children should always ride with
the seatback upright.
*
[SR03000(ALL)08/95]
RWARNING
Never let a passenger hold a child on his
or her lap while the vehicle is moving.
The passenger cannot protect the child
from injury in a collision.
*
[SR03200(ALL)09/95]
RWARNING
Lock the doors of your vehicle before
driving to lessen the risk of the door
coming open in a collision.
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

14 %
*
[SR05725(ALL)08/95]
Automatic locking mode
*
[SR05750(ALL)08/95]
In this operating mode, the shoulder belt
retractor will be automatically locked and will
remain locked when the combination
lap/shoulder safety belt is buckled, and does not
allow the occupant freedom of movement. This
mode provides the following:
*
[SR05775(ALL)08/95]
q
A tight lap/shoulder belt on the occupant.
*
[SR05800(ALL)08/95]
q
Child safety seat installation.
*
[SR05810(ALL)08/95]
RWARNING
Rear-facing infant seats should never be
placed in the front seats.
*
[SR05825(ALL)09/95]
This modemust be usedwhen installing a child
safety seat on the front passenger seat and rear
outboard seats where dual locking retractors are
provided.
*
[SR05830(ALL)08/95]
To switch the retractor from the emergency
locking mode to the automatic locking mode,
perform the following steps:
*
[SR05875(ALL)08/95]
1. Buckle the lap/shoulder combination belt.
*
[SR05900(ALL)09/95]
2. Grasp the shoulder portion of the belt and
pull downward until all of the belt is
extracted and, when allowed to retract, a
clicking sound is heard. At this time, the belt
retractor is in the automatic locking mode
(child restraint mode).
*
[SR05925(ALL)08/95]
3. A clicking sound will continue to be heard
as the belt is allowed to retract. This
indicates that the retractor is in the
automatic locking mode.
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

15
*
[SR05930(ALL)08/95]
NOTE: When the combination lap/shoulder
belt is unbuckled and allowed to
retract completely, the retractor will
switch to the vehicle sensitive
(emergency) locking mode. See the
detailed instructions underSafety Seats
for Childrenin this chapter.
%*
[SR05940(ALL)08/95]
Shoulder Belt Height Adjustment
*
[SR05950(ALL)08/95]
Driver and right front passenger
*
[SR05960(ALL)06/95]
You can adjust the shoulder belt height to one of
five (5) positions.
[SR05962(ALL)06/95]
To adjust the belt down, pinch the release
button. To adjust the belt up, slide the adjuster
up. (You do not have to pinch the release
button.)
*
[SR05964(ALL)06/95]
Make sure the adjuster is firmly in one of the
five positions. The belt should be adjusted up or
down until the belt rests on your shoulder near
your neck.
[SR05966(ALL)06/95]
one third page art:0001402-B
The shoulder belt height adjuster
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

16
*
[SR05968(ALL)06/95]
RWARNING
Position the shoulder belt height adjuster
so that the belt rests across the middle of
your shoulder. Be sure the shoulder belt is
properly positioned on your shoulder each
time you use the belt. If the shoulder belt
is off your shoulder, on your upper arm
or neck, there is a greater risk of severe
injury in a collision.
[SR06000(ALL)04/95]
Safety Belts for Rear-Facing Occupants
(Wagon)
[SR06050(ALL)05/95]
RWARNING
Never use child safety seats in the third
seat of a wagon.
[SR06060(ALL)10/95]
Your vehicle is equipped with safety seat belts
containing an adjust tongue at the rear-facing
seating positions.
[SR06075(ALL)10/95]
When the adjust tongue of the lap/shoulder
combination seat belt is latched into the buckle,
the tongue will allow the lap portion to become
shorter, but locks the webbing in place to restrict
it from becoming longer.
[SR06125(ALL)10/95]
Before you can reach and latch a combination
lap and shoulder belt having an adjust tongue
into the buckle, you may have to lengthen the
lap belt portion of it. To lengthen the lap belt,
pull some webbing out of the shoulder belt
retractor. While holding the webbing below the
tongue, grasp the tongue so that it is parallel to
the webbing and slide the tongue upward.
Provide enough lap belt length so that the
tongue can reach the buckle.
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

33 %
*
[SR22000(ALL)01/95]
Safety Seats for Children
*
[SR22100(ALL)05/95]
Use a safety seat that is recommended for the
size and weight of the child. Always follow the
safety seat manufacturer's instructions when
installing and using the safety seat.
*
[SR22125(ALL)08/95]
Ford recommends the use of a child safety seat
having a top tether strap. Install the child safety
seat in a seating position which is capable of
providing a tether anchorage. For more
information on top tether straps seeAttaching
Safety Seats With Tether Strapsin this chapter.
*
[SR22150(ALL)08/95]
When installing a child safety seat, be sure to
use the correct safety belt buckle for that seating
position, and make sure the tongue is securely
fastened in the buckle. For a shoulder/lap belt
combination with a sliding tongue, make sure
the retractor is in the automatic locking mode.
*
[SR22375(ALL)07/95]
Your vehicle is equipped with a right front
passenger air bag. Air bags deploy with great
force, faster than the blink of an eye. Front
passengers, especially children and small adults,
must never sit on the front edge of the seat,
stand near the glove compartment of the
instrument panel, or lean over near the air bag
cover when the vehicle is moving. All occupants
should sit with their backs against the seatback,
move the seat to the most rearward position if
possible and use the safety belts. Children
weighing less than 40 lbs. (18 kg) always should
use child or infant seats.
%*
[SR22400(ALL)07/95]
RWARNING
When using forward-facing child seats
move the passenger seat as far back from
the instrument panel as possible. NEVER
SECURE REAR-FACING INFANT SEATS
IN THE FRONT SEAT.
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

35 [SR22740(ALL)11/94]
half page art:0011286-A
Safety belt buckle placement for child seats
%*
[SR22750(ALL)11/94]
Installing Child Safety Seats in the Front
Passenger Seat and Outer Rear Seating
Positions
*
[SR22800(ALL)06/95]
Your vehicle is equipped with a dual locking
mode retractor on the shoulder belt portion of
the combination lap/shoulder safety belt for the
front passenger seat and rear outer seats. The
automatic locking modemust be usedwhen
installing a child seat or infant carrier in the
front passenger seat or rear outer seats.
*
[SR22850(ALL)09/95]
RWARNING
Never install a rear-facing child seat or
infant carrier in the right front passenger
seat.
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

39
*
[SR23250(ALL)08/95]
4. Grasp the shoulder portion of the belt and
pull downward until all of the belt is
extracted and a click is heard. At this time,
the retractor is in the automatic locking
mode (child seat restraint mode).
See Figure 4.
*
[SR23301(ALL)06/95]
half page art:0011241-A
Setting the retractor to automatic locking mode
*
[SR23350(ALL)07/95]
5. Allow the belt to retract. Pull up on the
shoulder webbing. A clicking sound will be
heard as the belt retracts. This indicates the
retractor is in the automatic locking mode.
Push down on the child seat while you pull
up on the belt to remove any slack in the
belt. Figures 5 and 6.
File:03fcsrt.ex
Update:Mon Jan 22 15:46:18 1996
ProCarManuals.com

42
*
[SR23601(ALL)11/94]
7. Double check that the retractor is in the
automatic locking mode. Try to pull more
belt out of the retractor. If you cannot, the
belt is in the automatic locking mode,
Figure 8.
*
[SR23650(ALL)06/95]
half page art:0011245-B
Checking the retractor
*
[SR23701(ALL)05/95]
8. Check to make sure that the child seat is
properly secured prior to each use. If the
retractor is not locked, repeat steps 4
through 7.
*
[SR23750(ALL)05/95]
NOTE: To remove the retractor from automatic
lock mode, allow seat belt to retract
fully to its stowed position and the
retractor will automatically switch back
to the vehicle sensitive locking mode
for normal adult usage.
