1996 FORD TAURUS Owners Manual

260
*
[SV04350(ALL)09/95]
NOTE: Read and understandPrecautions When
Servicing Your Vehicleat the beginning
of this chapter before opening the
hood.
%
*
[SV04500(ALL)04/95]
Engine Compartment
*
[SV04600(ALL)09/93]
Your vehicle has one of these types of engines:
[SV04700(ALL)10/95]
q
a 3.0L Vulcan engine
[SV04750(ALL)10/95]
q
a 3.0L Duratec engine
[SV04775( T)08/95]
q
a 3.4L SHO engine
*
[SV04850(ALL)11/94]
The following pages show diagrams of each
engine type and where to find items that you
should regularly service.
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

261 % [SV05000(ALL)02/95]
full page art:0000299-H
The 3.0 liter Vulcan engine
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

262 [SV05025(ALL)02/95]
full page art:0000301-HThe 3.0 liter Duratec engine
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

263 [SV05050( T)02/95]
full page art:0000300-H
The 3.4 liter SHO engine
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

264 %
*
[SV05075(ALL)04/95]
Cleaning the Engine
*
[SV06000(ALL)07/95]
A clean engine is more efficient because the
engine is able to cool properly. A build up of
grease and dirt acts as an insulator, keeping the
engine warmer than normal.
*
[SV06020(ALL)07/95]
q
Extreme care must be used if a power washer
is used to clean the engine. The high pressure
fluid could penetrate sealed parts and
assemblies causing damage or malfunctions.
*
[SV06040(ALL)08/95]
q
In order to avoid possible cracking of the
engine block or fuel injection pump, do not
spray a hot engine or injection pump with
cold water.
*
[SV06060(ALL)07/95]
q
The alternator, distributor and air intake must
be covered. Covering these components will
help prevent water damage.
*
[SV06080(ALL)04/95]
q
Never wash or rinse the engine while it is
running. Water getting into the engine may
cause internal damage.
%
*
[SV06100(ALL)03/95]
Filling the Fuel Tank
[SV06800(ALL)04/95]
1. Turn the engine off. After opening the fuel
door, remove the cap carefully and slowly
by turning it counterclockwise 1/4 turn until
it stops. Pull to remove the cap. A tether
attaches the cap to the fuel filler pipe.
[SV06825(ALL)04/95]
one inch art:0001470-AFile:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

265 [SV06850(ALL)04/95]
RWARNING
The fuel system may be under pressure. If
the fuel cap is venting vapor or if you
hear a hissing sound, wait until it stops
before completely removing the cap.
Otherwise, fuel may spray out and injure
you or others.
*
[SV06900(ALL)05/95]
2. Make sure that you pump unleaded fuel and
put the nozzle all the way inside the fuel
filler pipe.
[SV06950(ALL)09/95]
NOTE: To help reduce early nozzle shutoffs
and fuel spillage, park your vehicle so
that the fuel filler door is not
downhill. Do not tilt or turn the nozzle
upside down when filling. Avoid
excessively fast fuel dispensing rates
(over 10 gallons [38 liters] per minute).
*
[SV07150(ALL)08/95]
NOTE: If you spill any fuel on the body of
your vehicle, clean it off immediately.
The fuel may dull or soften the paint
if you do not wash it off.
[SV07200(ALL)10/95]
3. To replace the fuel cap, align the tabs on the
cap with the notches on the filler pipe. Turn
it clockwise until it stops.
*
[SV07250(ALL)10/95]
4. Push the fuel door closed.
[SV07275(ALL)04/95]
If the Service Engine Soon warning light comes
on and stays on when you start the engine, the
fuel cap may not be properly seated. Turn off
the engine, remove the fuel cap and replace it,
being careful to align the cap properly. For more
information, seeWarning lightsin the Index.
*
[SV07290(ALL)07/95]
If you lose the fuel cap, replace it with an
authorized Motorcraft or equivalent part.
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

266 %
*
[SV07300(ALL)05/95]
RWARNING
If you do not use the proper fuel cap, the
pressure in the fuel tank can damage the
fuel system or cause it to work improperly
in a collision.
*
[SV07350(ALL)05/95]
NOTE: If you replace your fuel cap with an
aftermarket fuel filler cap, the customer
warranty may be void for any damage
to the fuel tank and/or fuel system.
%*
[SV07500(ALL)06/95]
Choosing the Right Fuel
[SV07601(ALL)12/95]
Use only UNLEADED FUEL. Using leaded fuel
is prohibited by federal law. Any vehicle
damage may not be covered by your warranty.
%*
[SV08725(ALL)05/95]
Octane Recommendations
[SV08750( T)02/95]
All models except SHO 3.4L
[SV08800(ALL)04/95]
Your vehicle is designed to use regular fuel
with an octane rating of 87.In most cases it is
not necessary to use a fuel with an octane rating
higher than 87. At service stations, the octane
rating is displayed in a label on the pumps.
*
[SV08900(ALL)06/95]
one inch art:0060001-C
Typical octane rating label
[SV09000(ALL)12/95]
We do not recommend gasolines labeled
ªregularº that are sold with octane ratings of 86
or even less in high altitude areas.
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

267 [SV09100(ALL)12/95]
Do not be concerned if your vehicle sometimes
knocks lightly. However, if it knocks heavily
under most driving conditions on the
recommended octane rating fuel, see your dealer
or a qualified service technician to prevent any
engine damage.
[SV09455( T)02/95]
SHO 3.4L engine
[SV09460( T)02/95]
The SHO 3.4L engine has been designed to
operate using premium unleaded fuel with an
octane rating of 91 or higher. Regular unleaded
fuel with an octane rating of 87 may be used if
necessary. For optimum performance and
driveability, it is recommended that you use
premium unleaded fuel.
[SV09470( T)12/95]
In some high altitude areas, ªpremiumº fuels are
sold with octane ratings of less than 91. It is
recommended that you use only those
ªpremiumº fuels with an octane rating of 91 or
higher.
%*
[SV09490(ALL)08/95]
Fuel quality
[SV09601(ALL)12/95]
Ford approves the use of gasolines, including
those reformulated, that contain oxygenates such
as ethanol (10% maximum) and MTBE (15%
maximum). If methanol is used, the gasoline
should contain no more than 5% with
cosolvents.
[SV09701(ALL)12/95]
If you are experiencing starting, rough idle or
hesitation problems, try a different brand of fuel.
If the condition persists, see your dealer or a
qualified service technician.
*
[SV09800(ALL)06/95]
It should not be necessary to add any
aftermarket products to your fuel tank if you
continue to use a high-quality fuel.
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com
