1996 FORD TAURUS fuse chart

303 [SV32900( T)02/95]
If you check the power steering fluid when it is
cold, make sure that the fluid reaches the FULL
COLD range on the dipstick (3.0L Vulcan) or
MIN on the reservoir (3.0L Duratec or 3.4L
SHO). The reading will only be accurate if the
fluid temperature is approximately 50 to85ÊF (10
to 30ÊC).
% [SV32910(ALL)02/95]Fuses and Relays
[SV32915(ALL)04/95]
Fuses (conventional and high current) and relays
protect your vehicle's wiring system from
overloading. If electrical parts in your vehicle are
not working, the system may have been
overloaded and blown a fuse. Before you replace
or repair any electrical parts, check the
appropriate circuit protector. High current fuses
should only be repaired or replaced by your
Ford or Lincoln-Mercury dealer.
[SV33400(ALL)02/95]
The following charts tell you which circuit
protector protects each electrical part of your
vehicle. If a fuse blows, all the parts of your
vehicle that use the circuit will not work.
*
[SV33410(ALL)05/95]
Once you have determined which fuses to check,
follow the procedures underChecking and
replacing fuseslater in this chapter.
*
[SV33500(ALL)08/95]
RWARNING
Always remove the key from the ignition
before working on or replacing fuses.
File:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

311 %
*
[SV35200(ALL)06/95]
Checking and Replacing Fuses
*
[SV35300(ALL)02/95]
If you need to check a fuse, follow these steps:
[SV35400(ALL)11/94]
1. Lift the handle of the fuse panel or power
distribution box to unlatch the cover.
[SV35600(ALL)11/94]
2. On the cover, find the fuse you want to
check. The diagram on the cover tells you
where to locate the fuse on the panel.
[SV35900(ALL)11/94]
3. Check the fuse to see if it is blown. To
remove the fuse, use the pulling tool
attached to the inside cover of the fuse
panel. Look through the clear side of the
fuse to see if the metal wire inside is
separated. If it is, the fuse should be
replaced.
*
[SV36000(ALL)10/95]
quarter page art:0030248-C
Fuse puller tool and fuse
*
[SV36100(ALL)11/94]
4. Replace the fuse with one that has the right
amperage rating. (See the following chart.)
[SV36200(ALL)04/95]
six pica chart:0001443-AFile:15fcsvt.ex
Update:Tue Jan 23 13:58:51 1996
ProCarManuals.com

312 [SV36250(ALL)04/95]
fourteen pica chart:0001468-A
*
[SV36300(ALL)08/95]
RWARNING
Always replace a fuse with one that has
the specified amperage rating. Using a
fuse with a higher amperage rating can
cause severe wire damage and could start
a fire.
[SV36400(ALL)11/94]
5. Put the cover back on.
*
[SV36600(ALL)01/95]
Even after you replace a fuse, it will continue to
blow if you do not find what caused the
overload. If the fuse continues to blow, have
your electrical system checked.
*
[SV37500(ALL)03/95]
The Lights
*
[SV37600(ALL)01/95]
It is a good idea to check the operation of the
following lights frequently:
*
[SV37700(ALL)01/95]
q
headlamps
*
[SV37800(ALL)01/95]
q
tail lamps
*
[SV37900(ALL)01/95]
q
brakelamps
*
[SV37950(ALL)02/95]
q
high-mount brakelamp
