SERVICE INDICATOR
This programmes service intervals
according  to   the   use   of   the   vehicle.More than 1 000 miles/km before the
next service is due
Example:
  4   800   miles/km   remain
before

  the   next   service   is   due.   When
the ignition is switched on and for a
few

  seconds,   the   screen   shows:
A few seconds after the ignition is
switched on, the oil level is displayed
(depending on version), then the total
distance recorder resumes normal
operation showing the total and trip
distances.
Less than 1 000 miles/km before the
next service is due
Each time the ignition is switched on and for a few
seconds,   the   spanner   flashes   and   the   number   of miles/kilometres

  remaining   is   displayed:
A few seconds after the ignition is
switched on, the oil level is displayed
(depending on version), then the total
distance recorder resumes normal
operation
  and   the   spanner   remains   on.
This indicates that a service should be
carried

  out   shortly.
Service overdue
Operation
A few moments after the ignition
has been switched on, the spanner
indicating a service operation comes
on; the display for the total distance
recorder

gives

(in

round

figures)

the

distance remaining before the next
service.
The points at which a service is due
are calculated from the last indicator
zero


reset.
The point at which a service is due is
determined

by

two

parameters:
-

the distance travelled,
-


the time which has elapsed since
the


last

service.
The distance remaining before the
next service may be weighted by
the time factor, depending on the
type

of

driving. With the engine running the spanner
remains on until the service has been
carried
  out.
For BlueHDi Diesel versions, this
alert
  is   also   accompanied   by   the   fixed
illu

mination of the Service warning
lamp,
  on   switching   on   the   ignition.
Each time the ignition is
switched on and for a few
seconds, the spanner
flashes
  and   the   excess
distance

  is   displayed.
For BlueHDi Diesel versions, the
spanner can also come on early,
according the level of deterioration
of
  the   engine   oil.   Deterioration   of   the
engine oil depends on the conditions of
use

  of   the   vehicle.
READY TO GO
3

48
Berlingo2VP_en_Chap03_Pret-a-partir_ed02-2016
Instruments and controls
Berlingo2VP_en_Chap03_Pret-a-partir_ed02-2016
Trip recorder zero
reset button
After this operation, if you wish
to  disconnect   the   battery,   lock
the


vehicle   and   wait   for   at   least   five
minutes, otherwise the zero re-set will
not


be   registered.
Engine oil level indicator
Depending on your vehicle's engine,
when the ignition is switched on,
the engine oil level is indicated for
a few seconds, after the service
information. Oil level
correct
Low oil level
Flashing of "OIL",
linked
  with   the
service warning lamp,
accompanied by an
audible signal and a message in the
screen, indicates a low oil level which
could
  damage   the   engine.
If   the   low   oil   level   is   confirmed   by   a
check

  using   the   dipstick,   it   is   essential
that

  the   level   is   topped   up.
Oil level gauge
fault
Flashing of "OIL--"
indicates a
malfunction of the
engine   oil   level   indicator.   Contact
a

  CITROËN   dealer   or   a   qualified
workshop.
The level read will only be correct
if the vehicle is on level ground
and the engine has been of
f for
more
  than   30   minutes.Dipstick
A = maximum, never exceed
this level as a surplus of oil
may
  damage   the   engine.
Contact a CITROËN dealer
or   a   qualified   workshop
without

  delay.
B = minimum, top up the level
via   the   oil   filler   cap,   using   the
grade of oil suited to your
engine.
Lighting dimmer
With the ignition on, press
the button until the zeros
appear.
With the lighting on,
press the button to vary
the brightness of the
instruments
  and   controls.
When the lighting reaches
the minimum


(or maximum) setting, release the
button then press it again to increase
(or

reduce)

the   brightness.
As soon as the lighting is of the
required

brightness,   release   the   button.
Zero reset
Your CITROËN dealer or a qualified workshop  carries   out   this   operation
after

  each   service.
However, if you carry out the service
yourself, the re-set procedure is as
follows:
-

switch of
f the ignition,
-

press and hold the trip recorder
reset button,
-


switch
  on   the   ignition.
The
  display   begins   a   countdown.
When the display shows "=0", release
the
  button;   the   spanner   disappears.

49
Berlingo2VP_en_Chap03_Pret-a-partir_ed02-2016Berlingo2VP_en_Chap03_Pret-a-partir_ed02-2016
MANUAL GEARBO x
5-speed
6-speed
To change gear easily, always depress
the

clutch

pedal   fully.
To prevent the mat from becoming
caught

under

the   pedal:
-

ensure that the mat is positioned
and


secured   correctly   on   the   floor,
-

never


fit

one   mat   on   top   of   another.
When driving, avoid leaving your hand
on

the

gear

knob   as   the   force   exerted,
even if slight, may wear the internal
components


of
  the   gearbox   over   time.
Changing into 5th or 6th gear
To engage the gear correctly, move the
gear  lever   fully   to   the   right.
Engaging reverse gear
The lever should be moved slowly
to  reduce   noise.
To engage reverse gear, wait until the
vehicle
  has   come   to   a   complete   stop.
STEERING WHEEL ADJUSTMENT
When the vehicle is stationary,
release
  the   steering   wheel   adjustment
mechanism

  by   pulling   the   lever.
Adjust
  the   steering   wheel   for   height
and

  reach,   then   lock   the   mechanism   by
pushing

  the   lever   fully   forward. In
  the   6-speed   configuration,   raise   the  collar
  below   the   gear   knob.
READY TO GO
3
Gearbox and steering wheel

50
Berlingo2VP_en_Chap03_Pret-a-partir_ed02-2016Berlingo2VP_en_Chap03_Pret-a-partir_ed02-2016
The information appears
in the instrument panel
in  the   form   of   an   arrow.   It
may be accompanied by a
recommended

  gear.
The system adapts its gear
change recommendation
according to the driving conditions
(slope,

load, ...)   and   the   demands
of the driver (power

, acceleration,
braking, ...).
The

system   never   suggests:
-

engaging
  first   gear,
-

engaging
  reverse   gear.
With an electronic gearbox, the system
is

only

active

in

manual

mode.
GEAR SHIFT INDICATOR
Depending on the driving situation and
your vehicle's equipment, the system
may   advise   you   to   skip   one   (or   more)
gear(s).


Y
ou   can   follow   this   instruction
without engaging the intermediate
gears.
The gear engagement
recommendations must not be
considered

  compulsory.
This
  is
because

  the   configuration   of   the   road,
the

  traffic   density   and   safety   remain
determining factors when choosing
the

  best   gear.
Therefore,
  the   driver
remains responsible for deciding
whether or not to follow the indications
given.
This

  function   cannot   be   deactivated.
System which reduces fuel
consumption by recommending the
most

appropriate

gear.
Gearbox and steering wheel

51
Berlingo2VP_en_Chap03_Pret-a-partir_ed02-2016Berlingo2VP_en_Chap03_Pret-a-partir_ed02-2016
6-SPEED ELECTRONIC GEARBOx
- automatic  mode:   gear   selector   in  position
A.
-

manual
  mode:   gear   selector   in
position

M.
For
  safety:
It is only possible to come out
of position N
  if   the   brake   pedal   is
pressed.
The change from position

A (driving in
automatic mode) to position M (driving
in manual mode) or vice versa can be
made
  at   any   time.
The
  warning   lamp   A
goes
  off   in   the   instrument   panel.
Mode selection Moving off
- To start the engine, the gear
selector must be in position N.
-

Press
  firmly   on   the   brake   pedal.
-

Operate
  the   starter.
-

When the engine is running, place
the gear selector on

R, A or M as
desired.
-

Release
  the   brake   pedal   and
accelerate.
If the gear selector is not in position

N,
and/or
  if   the   brake   pedal   is   not
pressed,

  the   engine   will   not   start.
Repeat

  the   above   procedure.
Reverse gear Engaging reverse gear
Move the gear selector to R.
Only attempt to select reverse gear
when the vehicle is stationary.
Neutral Changing to neutral
Move the gear selector to N.
  If   the
vehicle is moving, do not select this
position

  even   momentarily.
READY TO GO
3
Gearbox and steering wheel

52
Berlingo2VP_en_Chap03_Pret-a-partir_ed02-2016Berlingo2VP_en_Chap03_Pret-a-partir_ed02-2016
Acceleration
For optimum acceleration (e.g. to overtake  another   vehicle),   simply
press the pedal beyond the point of
resistance at the end of its travel, by
pressing

  down   firmly.
Vehicle stationary, with the
engine running
In the event of a prolonged stop with
the engine running, the gearbox
changes automatically to neutral N.
Stopping the vehicle
Before stopping the engine, put the
gear selector in position N.
In all cases, it is essential to apply
the  parking   brake.   Check   that   the
parking

  brake   warning   lamp   is   on   in   the
instrument

  panel.
Before doing anything in the
engine
  compartment,   check   that
the gear selector is in neutral

N.
Changing gear
In situations of high engine speeds
(heavy acceleration), a change
up will not occur unless the driver
operates the electronic gearbox control
paddle. Pull on the "+" control
paddle
  to   change   up.
Pull on the "-" control
paddle to change
down.
-

If the vehicle stops or reduces
speed (for example when
approaching a stop sign),
the gearbox changes down
automatically

,   to   first   gear   if
needed.
-


It is not necessary to release the
accelerator completely during gear
changes.
-


A
gear change instruction is
accepted only if the engine speed
permits.
-

For safety reasons, depending on
the engine speed, a change down
may

  be   performed   automatically.
Manual mode
Changing to manual mode
Move the gear selector to M. Automatic mode Changing to automatic
mode
Move the gear selector to A.
The gearbox then operates in
automatic mode, without any action on
your

part.
It constantly selects the gear that is
best

suited

to

the

following

conditions:
-

driving style,
-


road


profile,
-

optimum


fuel

consumption.
Gearbox and steering wheel

53
Berlingo2VP_en_Chap03_Pret-a-partir_ed02-2016Berlingo2VP_en_Chap03_Pret-a-partir_ed02-2016
STOP & START
The Stop & Start system puts the
engine temporarily on standby - ST OP
mode
  -   during   stops   in   the   traffic   (red
lights,

  traffic   jams,   or   other...).
The engine restarts automatically -
START mode - as soon as you want to
move
  off.
The
  restart   takes   place   instantly,
quickly

  and   silently.
Perfect for urban use, the Stop & Start
system reduces fuel consumption and
exhaust emissions as well as the noise
level
  when   stationary.
Operation
Going into engine STOP modeThe "ECO" warning lamp
comes on in the instrument
panel and the engine goes
into
  standby:
-

with a manual gearbox
, at speeds
below
  12   mph   (20   km/h),   when   you
put the gear lever into neutral and
release the clutch pedal,
-


with a 6-speed electronic
gearbox

, at speeds below 5 mph
(8
  km/h),   when   you   press   the   brake
pedal or put the gear lever into
position

N. If
  your   vehicle   is   fitted   with   the   system,
a time counter calculates the sum of
the periods in ST

OP mode during a
journey.   It   rests   itself   to   zero   every   time
the

  ignition   is   switched   on   with   the   key.
With a 6-speed electronic
gearbox, for your comfort during
parking   manoeuvres,   STOP

mode
is not available for a few seconds after
coming

  out   of   reverse   gear.
STOP mode does not affect the
functionality of the vehicle, such as
braking,   power   steering,   for   example.
Never refuel with the engine in
STOP mode; you must switch off
the   ignition   with   the   key.Special cases: STOP mode
unavailable
STOP


mode   is   not   invoked   when:
-
the vehicle is on a steep slope
(rising or fallin

g),
-
the driver's door is open,
-

the driver's seat belt is not
fastened,
-

the vehicle has not exceeded

6   mph   (10   km/h)   since   the   last
engine

  start   using   the   key,
-
the engine is needed to maintain
a comfortable temperature in the
passenger compartment,
-

demisting is on,
-

some special conditions (battery
charge, engine temperature,
braking

  assistance,   ambient  temperature...)
  where   the   engine  is needed to assure control of a
system.
In this case, the
"ECO"
warning
  lamp   flashes   for   a
few

  seconds,   then   goes   off.
This operation is perfectly normal.
READY TO GO
3
Stop & Start

54
Berlingo2VP_en_Chap03_Pret-a-partir_ed02-2016Berlingo2VP_en_Chap03_Pret-a-partir_ed02-2016
Going into engine START modeThe "ECO" warning lamp
goes
  off   and   the   engine   starts:
-

with a manual gearbox
, when you
fully depress the clutch pedal,
-

with a 6-speed electronic
gearbox

:
●

gear
  lever   in   position   A or M,
when
  you   release   the   brake
pedal,
●


or
  gear   lever   in   position   N and
the
  brake   pedal   released,   when
you move the gear lever to
position

A or M,
●

or
  when   you   engage   reverse
gear

.
With a manual gearbox in STOP
mode, if a gear is engaged without
fully depressing the clutch pedal, a
warning lamp comes on or a message
is
  displayed   asking   you   to   depress   the
clutch

  pedal   to   restart   the   engine.
Special cases: START invoked
automatically
For your safety and comfort, START is
invoked
  automatically   when:
-

you open the driver's door
,
-

you unfasten the driver's seat belt, In this case the

"ECO"
warning
  lamp   flashes   for   few
seconds,

  then   goes   off.
This operation is perfectly normal.
Deactivation
In certain circumstances, such as the need
to maintain a comfortable temperature in
the passenger compartment, it may be
preferable
  to   deactivate   Stop   &   Start.
At any time, press the "ECO
OFF" switch to deactivate the
system.
This

is

confirmed   by   the   switch   warning
lamp coming on accompanied by a
message

  in   the   screen.
If the system has been deactivated
in STOP mode, the engine restarts
immediately.
Reactivation
Press the "ECO OFF" switch again.
The system is active again; this is
confirmed
  by   the   switch   warning
lamp going of

f and a message in the
instrument
  panel.
The system is reactivated
automatically at every new start
using
  the   key.
Operating fault
In the event of a malfunction
with the system, the "ECO
OFF" switch warning lamp
flashes,  then   comes   on
continuously

.
This
  system   requires   a   specific
battery

  with   a   special   specification
and technology (reference
numbers available from a CITROËN
dealer


or
  a   qualified   workshop).
Fitting a battery not listed by
CITROËN introduces
  the   risk   of
malfunction

  of   the   system.
have

it

checked   by   a   CITROËN   dealer
or


a

qualified   workshop.
In the event of a fault in STOP mode,
the

vehicle   may   stall.
All
  of   the   warning
lamps in the instrument panel come
on.


It

is

then   necessary   to   switch   off
the ignition and start the engine again
using


the
  key.
-

the speed of the vehicle exceeds
15


mph

(25

km/h)

with

a

manual

gearbox


or

7

mph

(11

km/h)

with

the 6-speed electronic gearbox
system,
-
some special conditions (battery


charge,

engine

temperature,

braking
 assistance,


ambient

temperature...)
 where the engine is needed to


assure

control

of

a

system.
Stop & Start
