Adjusting the angle of the seat backrest
- Operate  the   control   and   adjust   the  angle.
Placing the seat backrest in the
table position
-

Lower
  the   head   restraint   fully.
-

Operate the control to fold the seat
back

  onto   the   seat   cushion.Returning the seat backrest to the
sitting position
-

Release
  the   seat   backrest   by
pullin

g the control, then return it to
its   original   position.
-
Ensure
  that   it   has   correctly   locked
into

  place.
Placing the seat in the fully folded
position
-
Place
  the   seat   in   the   table   position.
-

Pull the red strap, located behind
the seat, to release the feet of the
seat from their anchorage on the
floor

.
-

T
ilt   the   entire   seat   forwards.
Row 2 seat adjustmentsReturning the seat to its original
position
-
Unfold
  the   entire   seat.
Before folding the seat, ensure
that:
-

in row 3, no passenger's
foot is at one of the seat
anchorages

  on   the   floor,
-

the
  seat   is   locked   securely   on
the

  floor,
-

the seat belt is available for
the

  passenger.
EASE OF USE and COMFORT
4
Seats

88
Berlingo2VP_en_Chap04_Ergonomie_ed02-2016Berlingo2VP_en_Chap04_Ergonomie_ed02-2016
Row 3 seat adjustments
Placing the seat backrest in the
table position
-
Lower
  the   head   restraint   fully.
-

Operate the control to fold the seat
backrest

  onto   the   seat   cushion.
Returning the seat backrest to the
sitting position
-

Release
  the   seat   backrest   by
pullin

g the control, then return it to
its
  original   position.
-

Check
  that   it   has   correctly   locked   in
place. Returning the seat to its original
position
-


Push
  the   red   control.
-

Unfold
  the   entire   seat.
Placing the seat in the fully folded
position
-

Place
  the   seat   in   the   table   position.
-

Raise
  the   bar   fitted   with   a   red
strap, located behind the seat, to
release feet of the seat from their
anchorage

  on   the   floor.
-

T
ilt   the   entire   seat   forwards.Ensure
  that:
-

the
  seat   is   locked   securely   on
the

  floor,
-

the seat belt is available for
the

  passenger.
Seats

89
Berlingo2VP_en_Chap04_Ergonomie_ed02-2016Berlingo2VP_en_Chap04_Ergonomie_ed02-2016
Entering, exiting from Row 3
Entering
-
Place the row 2 seat in the table
position.
Exiting
-


Lower
  the   head   restraint   fully.
-

Operate the yellow control, located
on

  the   back   of   the   row   2   seat
backrest.
-


Fold
  the   seat   backrest   to   the   table
position.Ensure that the centre seat belt is
stowed correctly in its housing in
the

  headlining.
-

T
ilt it to the fully folded position to
allow
  access. -

Pull the red strap to place the seat
in

  the   fully   folded   position.
-  T ilt   the   entire   seat   forwards.
-
Exit
  via   the   side   door.
Before
  folding   it   back,   ensure   that
the feet of the passenger in row 3
are not obstructing the row 2 seat
anchoring

  points.
EASE OF USE and COMFORT
4
Seats

90
Berlingo2VP_en_Chap04_Ergonomie_ed02-2016Berlingo2VP_en_Chap04_Ergonomie_ed02-2016
Removing a seat
-
If necessary
, move the front seats
forward.
-

Lower
  the   head   restraint.
-

Place the seat in the fully folded
position.
-


T
ilt the entire seat forwards then
lift it. Refitting the seat
The label on the seat indicates the
position
  in   which   it   must   be   installed.
-

Place
  the   hooks   of   the   front   feet
between

  the   two   bars.
-

Fold
  back   the   seat   to   fix   the   rear
anchoring

  points.
-

Operate the control to raise the
seat

  back   to   its   initial   position.
-

Raise
  the   head   restraint.Ensure
  that   no   object   or   foot   of   a  passenger seated in the rear is
obstructing the anchorage points
or
  preventing   correct   locking   of
the

  seat.
Operating the Row 2 seats
Seats

91
Berlingo2VP_en_Chap04_Ergonomie_ed02-2016Berlingo2VP_en_Chap04_Ergonomie_ed02-2016
Operating the Row 3 seats
Removing the seat
-
Lower
  the   head   restraint.
-

Place the seat in the fully folded
position.
-


T
ilt   the   entire   seat   forwards.
-

On
  each   side,   take   hold   of   the
uprights of the folded seat, tilting it
forward

  slightly,   and   lift   it.Refitting the seat
The label on the seat indicates the
position
  in   which   it   must   be   installed.
-

Place
  the   hooks   of   the   front   feet
between

  the   two   bars.
-

Ensure
  that   no   object   or   foot   is
obstructing the rear anchorage
points and that the seat belt is
positioned correctly and available
for

  use.
-

Fold
  back   the   seat   to   fix   its   rear
anchoring

  feet.
-

Operate the control to raise the
seat

  back   to   its   initial   position.
-

Raise
  the   head   restraint.
Good practice
Following the various operations:
-
do not remove a head restraint
without stowing it; secure it inside
the vehicle,
-


ensure that the passengers can
always access the seat belts and
fasten them easily

,
-

passengers
  must   never   take
their

  seat   without   adjusting   and
fastening

  their   seat   belt.
-

a passenger seated in row 3 must
ensure that he does not obstruct
the row 2 seat anchorage points,
-


a passenger seated in row 3 must
not have the seat in front of them in
row 2 in the folded position; this is
in case the seat could tip towards
the passenger unexpectedly and
injure

  them.
Do
  not   place   hard   or   heavy   objects   on
the

  seat   backs   forming   a   table,   they
could

  become   dangerous   projectiles   in
the

  event   or   sharp   braking   or   impact.
EASE OF USE and COMFORT
4
Seats

92
Berlingo2VP_en_Chap04_Ergonomie_ed02-2016Berlingo2VP_en_Chap04_Ergonomie_ed02-2016
MODULARITY AND DIFFERENT SEAT CONFIGURATIONS
5 seat layouts
Seats

93
Berlingo2VP_en_Chap04_Ergonomie_ed02-2016Berlingo2VP_en_Chap04_Ergonomie_ed02-2016
7 seat layouts
