2017 Citroen BERLINGO MULTISPACE RHD Owner's Manual

135
Berlingo2VP_en_Chap05_Securite_ed02-2016
135
Berlingo2VP_en_Chap05_Securite_ed02-2016
CHILD SEAT AT THE REAR
Rearward facing
When a rearward facing child seat is
installed on a rear passenger seat,
move the vehicle's front seat forwards
and
  straighten   the   backrest   so   that   the
rearward facing child seat does not
touch

  the   vehicle's   front   seat.
Forward facing
When a forward facing child seat is
installed on a rear passenger seat,
move the vehicle's front seat forwards
and  straighten   the   backrest   so   that   the
legs of the child in the forward facing
child seat do not touch the vehicle's
front

  seat.
Ensure that the seat belt is
correctly
  tensioned.
For child seats with a support leg,
ensure
  that   this   is   in   firm   contact   with
the

  floor. When a child seat is installed on a
passenger seat in row 3, put the
backrests
  of   the   outer   and   centre   seats
in row 2 forward of the seat occupied
by the child seat, in the table position,
or

  if   this   is   not   sufficient,   rermove   the
seats in row 2 so that the child seat or
the the legs of the child do not touch
the

  seats   in   row   2.
Seats in row 3
A child seat with a support leg
must never be installed on a
passenger seat in row 3.
SAFETY
5
Child safety

136
Berlingo2VP_en_Chap05_Securite_ed02-2016
136
Berlingo2VP_en_Chap05_Securite_ed02-2016
DEACTIVATING THE
P
ASSENGER ' S
FRONT
AIRBAG
Never install a rearward facing
child restraint system on a seat
protected

by

an

active

front

airbag.

This could cause the death of the child
or


serious   injury.
The warning label present on both
sides of the passenger's sun visor
repeats
  this   advice.   In   line   with   current
legislation, the following tables contain
this warning in all of the languages
required. For information on deactivating
the passenger's front airbag, refer
to the "Airbags" section in this
chapter

.
Child safety

AR
BG
НИКОГА НЕ инсталирайте детско столче на седалка с АКТИВИРАНА предна ВЪЗДУШНА ВЪЗГЛАВНИЦА. Това може да  причини  С
МЪРТ   или   СЕРИОЗНО   НАРАНЯВАНЕ   на   детето.
CSNIKDY neumisťujte   dětské   zádržné   zařízení   orientované   směrem   dozadu   na   sedadlo   chráněné  AKTIVOV ANÝM   čelním  AIRBAGEM.   Hrozí  nebezpečí
  SMRTI   DÍTĚTE   nebo   VÁŽNÉHO   ZRANĚNÍ.
DABrug ALDRIG   en   bagudvendt   barnestol   på   et   sæde,   der   er   beskyttet   af   en  AKTIV  AIRBAG.   BARNET  risikerer   at   blive  AL VORLIGT  KVÆSTET eller
  DRÆBT.
DEMontieren Sie auf einem Sitz mit AKTIVIERTEM Front-Airbag NIEMALS einen Kindersitz oder eine Babyschale entgegen \
der Fahrtrichtung, das
Kind  könnte   schwere   oder   sogar   tödliche   Verletzungen   erleiden.
ELΜη χρησιμοποιείτε ΠΟΤΕ παιδικό κάθισμα με την πλάτη του προς το εμπρός μέρος του αυτοκινήτου, σε μια θέση που προστατεύεται από ΜΕΤΩΠΙΚΟ   αερόσακο   που   είναι   ΕΝΕΡΓΟΣ.  Αυτό   μπορεί   να   έχει   σαν   συνέπεια   το   ΘΑΝΑΤΟ   ή   το   ΣΟΒΑΡΟ  ΤΡ ΑΥΜΑΤΙΣΜΟ   του   ΠΑΙΔΙΟΥ
ENNEVER use a rearward facing child restraint on a seat protected by an ACTIVE AIRBAG in front of it, DEATH or SERIOUS INJURY to the
CHILD can occur
ESNO INSTALAR NUNCA un sistema de retención para niños de espaldas al sentido de la m\
archa en un asiento protegido mediante un AIRBAG
frontal ACTIV ADO,   ya   que   podría   causar   lesiones   GRAVES   o   incluso   la   MUERTE   del   niño.
ETÄrge MITTE KUNAGI paigaldage “seljaga sõidusuunas“ lapseistet juhi kõrvalistmele, mille ESITURVAPADI on AKTIVEERITUD.  T urvapadja  avanemine
  võib   last  TÕSISEL T  või   ELUOHTLIKULT  vigastada.
FIÄLÄ KOSKAAN aseta lapsen turvaistuinta selkä ajosuuntaan istuimelle, jonka edessä suojana on käyttöön aktivoitu TUR VATYYNY.   Sen  laukeaminen
  voi   aiheuttaa   LAPSEN   KUOLEMAN   tai   VAKAVAN   LOUKKAANTUMISEN.
FRNE JAMAIS installer de système de retenue pour enfants faisant face vers l’arrière sur un siège protégé par un COUSSIN GONFLABLE frontal ACTIVÉ.
Cela peut provoquer la MOR
T de l’ENFANT ou le BLESSER GRAVEMENT
HRNIKADA ne postavljati  dječju  sjedalicu  leđima  u  smjeru  vožnje  na  sjedalo  zaštićeno  UKLJUČENIM  prednjim  ZRAČNIM  JASTUKOM.  T o  bi  moglo  uzrokovati
  SMRT  ili  TEŠKU   OZLJEDU   djeteta.
HUSOHA ne   használjon   menetiránynak   háttal   beszerelt   gyermekülést  AKTIVÁL T  (BEKAPCSOLT)   FRONTLÉGZSÁKKAL  védett   ülésen.   Ez   a  gyermek
  HALÁLÁT  vagy   SÚLYOS   SÉRÜLÉSÉT  okozhatja.
ITNON installare MAI seggiolini per bambini posizionati in senso contrario\
a quello di marcia su un sedile protetto da un AIRBAG frontale
ATTIVATO.  Ciò   potrebbe   provocare   la   MORTE   o   FERITE   GRAVI   al   bambino.
LTNIEKADA neįrenkite   vaiko   prilaikymo   priemonės   su   atgal   atgręžtu   vaiku   ant   sėdynės,   kuri   saugoma   VEIKIANČIOS   priekinės   ORO   PAGALVĖS.  Išsiskleidus
  oro   pagalvei   vaikas   gali   būti   MIRTINAI   arba   SUNKIAI  TRAUMUOT AS.
 137
Berlingo2VP_en_Chap05_Securite_ed02-2016
 137
Berlingo2VP_en_Chap05_Securite_ed02-2016
SAFETY
5
Child safety

LVNEKAD NEuzstādiet uz aizmuguri vērstu bērnu sēdeklīti priekšējā pasažiera sēdvietā, kurā ir AKTIVIZĒTS  priekšējais   DROŠĪBAS   GAISA SPIL
VENS.
Tas
  var   izraisīt   BĒRNA

NĀVI   vai   radīt   NOPIETNUS   IEVAINOJUMUS.
MTQatt m’ghandek thalli tifel/tifla marbut f’siggu dahru lejn l-Airbag attiva, ghaliex tista’  tikkawza   korriment   serju   jew   anke   mewt   lit-tifel/tifla
NLPlaats NOOIT een   kinderzitje   met   de   rug   in   de   rijrichting   op   een   zitplaats   waarvan   de  AIRBAG   is   INGESCHAKELD.   Bij   het   afgaan   van   de   airbag  kan
  het   KIND   LEVENSGEVAARLIJK   GEWOND   RAKEN
NOInstaller ALDRI  et   barnesete   med   ryggen   mot   kjøreretningen   i   et   sete   som   er   beskyttet   med   en   frontal  AKTIVER T  KOLLISJONSPUTE,   BARNET risikerer
  å   bli   DREPT  eller   HARDT  SKADET.
PLNIGDY nie   instalować   fotelika   dziecięcego   w   pozycji   "tyłem   do   kierunku   jazdy"   na   siedzeniu   wyposażonym   w   CZOŁOWĄ   PODUSZKĘ  POWIETRZNĄ
  w   stanie  AKTYWNYM.   Może   to   doprowadzić   do   ŚMIERCI   DZIECKA  lub   spowodować   u   niego   POWAŻNE   OBRAŻENIA  CIAŁA.
PTNUNCA instale   um   sistema   de   retenção   para   crianças   de   costas   para   a   estrada   num   banco   protegido   por   um  AIRBAG   frontal  ACTIV ADO.
Esta   instalação   poderá   provocar   FERIMENTOS   GRAVES   ou   a   MORTE   da   CRIANÇA.
RONu instalati NICIODATA un   sistem   de   retinere   pentru   copii,   dispus   cu   spatele   in   directia   de   mers,   pe   un   loc   din   vehicul   protejat   cu  AIRBAG  frontal
 ACTIV AT.  Aceasta   ar   putea   provoca   MOARTEA  COPILULUI   sau   RANIREA  lui   GRAVA.
RUВО ВСЕХ СЛУЧАЯХ ЗАПРЕЩАЕТСЯ использовать обращенное назад детское удерживающее устройство на сиденье, защищенном ФУНКЦИОНИРУЮЩЕЙ   ПОДУШКОЙ   БЕЗОПАСНОСТИ,   установленной   перед   этим  сиденьем.
Эт

о   может   привести   к

ГИБЕЛИ   РЕБЕНКА   или   НАНЕСЕНИЮ   ЕМУ   СЕРЬЕЗНЫХ   ТЕЛЕСНЫХ   ПОВРЕЖДЕНИЙ
SKNIKDY neinštalujte   detské   zádržné   zariadenie   orientované   smerom   dozadu   na   sedadlo   chránené  AKTIVOV ANÝM   čelným  AIRBAGOM.   Mohlo  by
  dôjsť   k   SMRTEĽNÉMU   alebo   VÁŽNEMU   PORANENIU   DIEŤAŤA.
SLNIKOLI ne nameščajte otroškega sedeža s hrbtom v smeri vožnje, če je VARNOSTNA  BLAZINA  pred   sprednjim   sopotnikovim   sedežem  AKTIVIRANA.
 T akšna   namestitev   lahko   povzroči   SMRT  OTROKA  ali   HUDE   POŠKODBE.
SRNIKADA ne   koristite   dečje   sedište   koje   se   okreće   unazad   na   sedištu   zaštićenim  AKTIVNIM   VAZDUŠNIM   JASTUKOM   ispred   njega,   jer   mogu  nastupiti
  SMRT  ili   OZBILJNA  POVREDA  DETETA.
SVPassagerarkrockkudden fram MÅSTE vara avaktiverad om en bakåtvänd bilbarnstol installeras på denna plats. Annars   riskerar   barnet   att  DÖDAS
  eller   SKADAS  ALL VARLIGT.
TRKESİNLKLE HAVA YASTIĞI  AKTİF   olan   ön   koltuğa   yüzü   arkaya   dönük   bir   çocuk   koltuğu   yerleştirmeyiniz.   Bu   ÇOCUĞUN   ÖLMESİNE   veya   ÇOK  AĞIR
 Y ARALANMASINA  sebep   olabilir.
138
Berlingo2VP_en_Chap05_Securite_ed02-2016
138
Berlingo2VP_en_Chap05_Securite_ed02-2016
Child safety

139
Berlingo2VP_en_Chap05_Securite_ed02-2016
139
Berlingo2VP_en_Chap05_Securite_ed02-2016
RECOMMENDED SEATS
Group 0+: from birth to 13 kgL1
"ROMER Baby-Safe Plus"
Installed
  in   the   rearward   facing   position.
Groups 2 and 3: from 15 to 36 kg L4
"KLIPPAN Optima"
From
  22 kg   (about   6   years),   the   booster   is   used   on   its   own.
L5
"RÖMER KIDFIX"
Can
  be   fixed   on   the   vehicle's   ISOFIX   mountings.
The
  child   is   restrained   by   the   seat   belt.
CITROËN offers a range of recommended child seats which are secured using a three point seat belt.
SAFETY
5
Child safety

140
Berlingo2VP_en_Chap05_Securite_ed02-2016
140
Berlingo2VP_en_Chap05_Securite_ed02-2016
SEATS WITH A SUPPORT LEG
Care must be taken when installing a child seat with a support leg in
the
  vehicle.   In   particular   you   should
look

  for   the   presence   of   a   storage
compartment below the rear seat
footwells.
The centre rear seat does not have
a storage compartment below the
footwell.


Y
ou   can   therefore   easily   fit   a
child seat with a support leg, whether
installed with the ISOFIX mountings or
using

  the   3   point   seat   belt.
Do not place the support leg on
the storage compartment cover;
it
  might   break   in   a   serious   impact.
Where

  the   adjustments   of   the   support
leg allow it, we suggest two other
possibilities

  for   installation.
At the bottom of the storage
compartment
If the support leg is long enough, you
can  adjust   it   so   that   it   contact   the
bottom

  of   the   storage   compartment.
Remove

  all   objects   from   the   storage
compartment before installin

g the
support
  leg.
Away from the storage
compartment area
If the support leg is long enough and
can  be   inclined   sufficiently   (always
by following the recommendations
given in the installation instructions for
the child seat), you can position the
support

  leg   so   that   it   contacts   the   floor
away

  from   the   storage   compartment.
Adjust

  the   longitudinal   position   of
the front or rear seat to obtain a
satisfactory position for the support leg
away

  from   the   storage   compartment.
If you cannot position the support
leg in the way described, you
should

  not   fit   a   child   seat   with
support

  leg   to   the   seat.
Child safety

141
Berlingo2VP_en_Chap05_Securite_ed02-2016
141
Berlingo2VP_en_Chap05_Securite_ed02-2016
LOCATIONS FOR CHILD SEATS SECURED WITH THE SEAT BELT
* A child seat with support leg must never be installed on an outer passeng\
er seat in row 2, unless you are able to install it in   line   with   the   recommendations   under   "Installing   a   child   seat   with   a   support   leg".
**

A
child   seat   with   support   leg   must   never   be   installed   on   a   passenger   seat   in   row   3.
In accordance with European regulations, this table indicates the option\
s for installing child seats secured using a seat belt
and
  universally   approved   (a)   according   to   the   weight   of   the   child   and   the   seat   in   the   vehicle.
U:
seat suitable for the installation of a child seat secured using the sea\
t belt and universally approved, rearward facing
and/or

  forward   facing.Seat(s)
Weight of the child and indicative age
Under 13 kg
(groups 0 (b) and 0+)
Up to approx 1 year
From 9 to 18 kg
(group 1)
1 to 3 years approx
From 15 to 25 kg
(group 2)
3 to 6 years approx
From 22 to 36 kg
(group 3)
6 to 10 years approx
Row 1 (c) (d) Passenger
seat U
UUU
Row 2 (e)
(5
  and   7   seats) Outer
seats
U*
U* UU
Centre seat UUUU
Row 3 (f) (g)
(7
  seats) All seats
U**U** UU
SAFETY
5
Child safety

142
Berlingo2VP_en_Chap05_Securite_ed02-2016
142
Berlingo2VP_en_Chap05_Securite_ed02-2016
(a)  Universal  child   seat:   child   seat  that can be installed in any vehicle
using
  the   seat   belt.
(b)

Group
  0:   from   birth   to   10   kg.
Cots and baby carriers cannot be
installed on the front passenger
seat

  or   in   row   3.   When   installed   in
row 2, they may prevent the use of
one

  or   more   seat   in   this   row.
(c)

Refer to the legislation in force in
your country before installin

g your
child
  on   this   seat.
(d)

When a rearward facing child seat
is installed on a

front passenger
seat, the passenger's front airbag
must
  be   deactivated.   Otherwise,
the child would risk being
seriously injured or killed if the
airbag is deployed

.
When a forward facing child seat
is installed on a front passenger
seat, the passenger's front airbag
must
  remain   active. Remove and stow the heads
restraint, before installing a child
seat
  with   backrest   on   a   passenger
seat.
Refit

  the   head   restraint   once   the   child
seat

  has   been   removed.
(e)
When a child seat is installed at
the rear
, forward facing or rearward
facing, move the vehicle's seats
in the row in front forwards and
straighten
  their   backrests   to   leave
enough space for the child seat or
the

  child's   legs.
(f)

Put
  the   backrests   of   the   outer   and
centre seats in row 2, located in
front of seat occupied by a child
seat, in the table position, or if this
is

  not   sufficient,   remove   the   seats   in
row 2, so that the child seat or the
child's legs do not touch the seats in
row

  2.
(g)

If the seats in row 3 are occupied,
do not leave a child seat installed
on the foldable row 2 seat, to allow
easy

  access   to   row   3.
Child safety
