2015 LEXUS RX350 Owners Manual

5
When trouble arises
7775-2. Steps to take in an emergency
Use the hook to secure the deck
board as shown in the illustration.
Remove the jack after removing
the hook.
Vehicles with a full-size spare tire
Pull the lever upward to fold back
the front part of the deck board.
Pull on the attached hook to
extend the string.STEP 4
STEP 5
STEP 1
STEP 2

7785-2. Steps to take in an emergency
Use the hook to secure the deck
board as shown in the illustration.
Remove the jack after removing
the hook.STEP 3
STEP 4

5
When trouble arises
7795-2. Steps to take in an emergency
Taking out the spare tire
Lift up the deck board. (See “T aking out the jack” for details.)
Remove the spare tire cover.
Loosen the center fastener that secures the spare tire.
Vehicles with a compact spare tire
Vehicles with a full-size spare tire STEP 1
STEP 2
STEP 3

7805-2. Steps to take in an emergency
Replacing a flat tire
Chock the tires.
Slightly loosen the wheel nuts (one
turn).
Turn the tire jack portion “A” by
hand until the notch of the jack is in
contact with the jack point.STEP 1
Flat tire Wheel chock
positions
Front Left-
hand side Behind the
rear right-
hand side tire
Right-
hand side Behind the
rear left-
hand side tire
Rear Left-
hand side In front of the
front right-
hand side tire
Right-
hand side In front of the
front left-
hand side tireSTEP 2
STEP 3

5
When trouble arises
7815-2. Steps to take in an emergency
Raise the vehicle until the tire is
slightly raised off the ground.
Remove all the wheel nuts and the
tire. When resting the tire on the
ground, place the tire so that the
wheel design faces up to avoid
scratching the wheel surface.STEP 4
STEP 5

7825-2. Steps to take in an emergency
Installing the spare tire
Remove any dirt or foreign matter
from the wheel contact surface. If foreign matter is on the wheel
contact surface, the wheel nuts
may loosen while the vehicle is in
motion, causing the tire to come
off.
Install the spare tire and loosel y tighten each wheel nut by hand
by approximately the same amount.
Vehicles with a compact spare tire
Tighten the nuts until the tapered
portion comes into loose contact
with the disc wheel seat.
Vehicles with a full-size spare tire
Turn the nuts until the washers
come into contact with the wheel.STEP 1
STEP 2
Disc wheel
seatTapered portion
Wheel nut
Disc wheelWa s h e r

5
When trouble arises
7835-2. Steps to take in an emergency
Lower the vehicle.
Firmly tighten each wheel nut two
or three times in the order shown
in the illustration. Tightening torque:
76 ft•lbf (103 N•m, 10.5 kgf•m)
Stow the flat tire, tire jack and all tools.STEP 3
STEP 4
■
The compact spare tire ●
The compact spare tire is identified by the label “TEMPORARY USE ONLY”
on the tire sidewall.
Use the compact spare tire temporarily, and only in an emergency.●
Make sure to check the tire inflatio n pressure of the compact spare tire.
(  P. 815)■
When using the compact spare tire
As the compact spare tire is not equipped with a tire pressure warning valve and
transmitter, low inflation pressure of the spare tire will not be indicated by the tire
pressure warning system. Also, if you repl ace the compact spare tire after the tire
pressure warning light comes on, the light remains on. STEP 5

7845-2. Steps to take in an emergency
■
If you have a flat front tire on a road covered with snow or ice (vehicles with a
compact spare tire)
Install the compact spare tire on one of the rear wheels of the vehicle. Perform the
following steps and fit tire chains to the front tires:
Replace a rear tire with the compact spare tire.
Replace the flat front tire with the tire removed from the rear of the vehi-
cle.
Fit tire chains to the front tires.■
After completing the tire change
The tire pressure warning system must be reset. (  P. 685)STEP 1
STEP 2
STEP 3
