2015 LEXUS RX350 Owners Manual

7214-3. Do-it-yourself maintenance
4
Maintenance and care ■ Rear bulb locations
Rear turn signal lightBack-up light
Rear side marker light Tail light
Tail light

7224-3. Do-it-yourself maintenance
Replacing light bulbs
■ Headlight high beams
Right side:
Open the cap.
Move the washer fluid filler
opening to allow easy access to
the light bulbs.
Unplug the connector while
depressing the lock release.
Turn the bulb base counterclock-
wise.STEP 1
STEP 2
STEP 3

7234-3. Do-it-yourself maintenance
4
Maintenance and care Replace the light bulb, and install
the bulb base. Align the 3 tabs on the light bulb
with the mounting, and insert.
Turn and secure the bulb base.
Connect the connector. Shake the bulb base gently to
check that it is not loose, turn the
headlight high beams on once and
visually confirm that no light is leak-
ing through the mounting.
When replacing the right side bulb, install by conducting
with the directions reversed.STEP 4
STEP 5
STEP 5STEP 6
STEP 5STEP 1

7244-3. Do-it-yourself maintenance
■ Halogen headlight low beams (if equipped)
Turn the bulb base counterclock-
wise.
Unplug the connector while
depressing the lock release.
Replace the light bulb, and install
the bulb base. Align the 3 tabs on the light bulb
with the mounting, and insert.
Turn and secure the bulb base.
Shake the bulb base gently to
check that it is not loose, turn the
headlight low beams on once and
visually confirm that no light is leak-
ing through the mounting.STEP 1
STEP 2
STEP 3
STEP 4

7254-3. Do-it-yourself maintenance
4
Maintenance and care ■ Front turn signal light
Turn the bulb base counterclock-
wise.
Remove the light bulb.STEP 1
STEP 2

7264-3. Do-it-yourself maintenance
■ Rear turn signal and tail lights
Remove the access hole cover. Use a flathead screwdriver
wrapped in a cloth.
Turn the bulb base counterclock-
wise.
Tail light
Rear turn signal light
Remove the light bulb.
Tail light
Rear turn signal lightSTEP 1
STEP 2
STEP 3

7274-3. Do-it-yourself maintenance
4
Maintenance and care ■ Tail and back-up lights
Remove the access hole cover. Use a flathead screwdriver
wrapped in a cloth.
Turn the bulb base counterclock-
wise.
Tail light
Back-up light
Remove the light bulb.
Tail light
Back-up lightSTEP 1
STEP 2
STEP 3

7284-3. Do-it-yourself maintenance
■ Rear side marker light (right side)
Remove the bolts using a Phillips-
head screwdriver and remove the
clip.
Removing the clip
Installing the clip
Turn the bulb base counterclock-
wise.
Remove the light bulb.STEP 1
STEP 2
STEP 3
