Page 809 of 886
8076-1. Specifications
6
Vehicle specifications Vehicle identification
■ Vehicle identification number
The vehicle identification number (V IN) is the legal id entifier for your
vehicle. This is the primary identification number for your Lexus. It is used
in registering the ownership of your vehicle.
This number is stamped on the top left of the instrument panel. On some mod-
els, this number is also stampe d under the front passenger seat.
This number is also on the Certifi-
cation Label.
■ Engine number
The engine number is stamped on
the engine block as shown.
Page 810 of 886
8086-1. Specifications
Engine
FuelModel 2GR-FE
Ty p e 6-cylinder V type, 4-cycle, gasoline
Bore and stroke 3.70 3.27 in. (94.0 83.0 mm)
Displacement 210.9 cu.in. (3456 cm 3
)
Drive belt tension Automatic adjustment
Fuel type Unleaded gasoline only
Octane rating 87 (Research octane number 91) or higher
Fuel tank capacity
(Reference) 19.2 gal. (72.5 L, 15.9 Imp. gal.)
Page 811 of 886
8096-1. Specifications
6
Vehicle specifications Lubrication system
*: The engine oil capacity is a referenc e quantity to be used when changing
the engine oil. Warm up and turn off the engine , wait more than 5 minutes,
and check the oil level on the dipstick.
■ Engine oil selection
“Toyota Genuine Motor Oil” is used in your Lexus vehicle. Use Lexus
approved “Toyota Genuine Motor Oil” or equivalent to sa tisfy the follow-
ing grade and viscosity.
Oil grade: ILSAC GF-5 multigrade engine oilOil capacity
(Drain and refill
reference*)
With filter 6.4 qt. (6.1 L, 5.4 Imp. qt.)
Without filter 6.0 qt. (5.7 L, 5.0 Imp. qt.)
Page 812 of 886
8106-1. Specifications
Recommended viscosity: SAE 0W-20
SAE 0W-20 is the best choice for
good fuel economy and good
starting in cold weather.
If SAE 0W-20 is not available,
SAE 5W-20 oil may be used.
However, it must be replaced with
SAE 0W-20 at the next oil
change.Oil viscosity (0W-20 is explained here as an example):
• The 0W in 0W-20 indicates the characteristic of the oil which
allows cold startability. Oils with a lower value before the W allow
for easier starting of the engine in cold weather.
• The 20 in 0W-20 indicates the vi scosity characteristic of the oil
when the oil is at high temperature. An oil with a higher viscosity
(one with a higher valu e) may be better suited if the vehicle is oper-
ated at high speeds, or under extreme load conditions.
How to read oil container label:
The International Lubricant Specification Advisory Committee
(ILSAC) Certification Mark is added to some oil containers to help
you select the oil you should use. Outside temperature
Page 813 of 886
8116-1. Specifications
6
Vehicle specifications Cooling system
Ignition system Capacity Without towing pack-
age 9.1 qt. (8.6 L, 7.6 Imp. qt.)
With towing package 10.0 qt. (9.5 L, 8.4 Imp. qt.)
Coolant type Use either of the following.
• “Toyota Super Long Life Coolant”
• A similar high-quality ethylene glycol-
based non-silicate, non-amine, non-nitrite,
and non-borate coolant with long-life
hybrid organic acid technology
Do not use plain water alone.
Spark plug
Make
Gap DENSO FK20HR11
0.043 in. (1.1 mm)
NOTICE■
Iridium-tipped spark plugs
Use only iridium-tipped spark plugs. Do not adjust the spark plug gap.
Page 814 of 886

8126-1. Specifications
Electrical system
Automatic transaxle
6-speed models
* : The fluid capacity is a reference quantity. If replacement is necessary, contact
your Lexus dealer.
8-speed models
* : The fluid capacity is a reference quantity. If replacement is necessary, contact
your Lexus dealer.Battery
Open voltage* at
68 F (20 C): 12.6
12.8 V Fully charged
12.2
12.4 V Half charged
11.8
12.0 V Discharged
(*: Voltage checked 20 minutes after the engine and
all the lights are turned off)
Charging rates 5 A max.
Fluid capacity
* 2WD 6.9 qt. (6.5 L, 5.7 Imp. qt.)
AW D 7.1 qt. (6.7 L, 5.9 Imp. qt.)
Fluid type Toyota Genuine ATF WS
Fluid capacity
* 7.2 qt. (6.8 L, 6.0 Imp. qt.)
Fluid type Toyota Genuine ATF WS
NOTICE
■
Automatic transmission fluid type
Using automatic transmission fluid other than “Toyota Genuine ATF WS” may
cause deterioration in shift quality, lockin g up of your transmission accompanied by
vibration, and ultimately damage the automatic transm ission of your vehicle.
Page 815 of 886
8136-1. Specifications
6
Vehicle specifications Transfer (AWD models)
* : Your Lexus vehicle is filled with “Toyota Genuine Differential Gear Oil” at the
factory. Use Lexus approved “Toyota Genuine Differential Gear Oil” or an
equivalent oil of matching quality that satisfies the above specifications. Please
contact your Lexus dealer for further details.
Rear differential (AWD models)
* : Your Lexus vehicle is filled with “Toyota Genuine Differential Gear Oil” at the
factory. Use Lexus approved “Toyota Genuine Differential Gear Oil” or an
equivalent oil of matching quality that satisfies the above specifications. Please
contact your Lexus dealer for further details.Oil capacity 0.8 qt. (0.8 L, 0.7 Imp. qt.)
Oil type and viscosity
* Toyota Genuine Differential gear oil LT
75W-85 GL-5 or equivalent
Oil capacity 0.5 qt. (0.5 L, 0.4 Imp. qt.)
Oil type and viscosity
* Toyota Genuine Differential gear oil LT
75W-85 GL-5 or equivalent
Page 816 of 886
8146-1. Specifications
Brakes
* 1
: Minimum pedal clearance when depressed with a force of 112 lbf (500 N, 51
kgf) while the engine is running
* 2
: Parking brake pedal travel when depressed with a force of 67.5 lbf (300 N, 31
kgf)
SteeringPe d a l c l e a r a n c e
* 1
3.5 in. (88 mm) Min.
Pedal free play 0.04
0.24 in. (1
6 mm)
Brake pad wear limit 0.04 in. (1.0 mm)
Parking brake lining wear limit 0.04 in. (1.0 mm)
Parking brake pedal travel
* 2
7
10 clicks
Fluid type SAE J1703 or FMVSS No.116 DOT 3
Free play Less than 1.2 in. (30 mm)
