MITSUBISHI LANCER SPORTBACK 2014 8.G Owners Manual Bluetooth® 2.0 interface (if so equipped) 5-174 Features and controls
5
6. The voice guide will say “Number please.” Say the telephone number to reg- ister it. 7. The voice guide will repeat the

Page 242 of 422

MITSUBISHI LANCER SPORTBACK 2014 8.G Owners Manual Bluetooth® 2.0 interface (if so equipped)
Features and controls 5-175
5
6. Operate the Bluetooth
® compatible cellu-
lar phone to set it up so that the phone- book entry you want to register in th

Page 243 of 422

MITSUBISHI LANCER SPORTBACK 2014 8.G Owners Manual Bluetooth® 2.0 interface (if so equipped) 5-176 Features and controls
5
5. The voice guide will say “Home, work, mobile or other?” Select and say the loca- tion where the telephone number you wan

Page 244 of 422

MITSUBISHI LANCER SPORTBACK 2014 8.G Owners Manual Bluetooth® 2.0 interface (if so equipped)
Features and controls 5-177
5
2. Say “Phonebook.” 3. The voice guide will say “Select one of the following: new entry, edit number, edit name, list na

Page 245 of 422

MITSUBISHI LANCER SPORTBACK 2014 8.G Owners Manual Bluetooth® 2.0 interface (if so equipped) 5-178 Features and controls
5
7. When the telephone number deletion is complete, the voice guide will say “<name> <location> deleted” and then the system

Page 246 of 422

MITSUBISHI LANCER SPORTBACK 2014 8.G Owners Manual Bluetooth® 2.0 interface (if so equipped)
Features and controls 5-179
5
1. Press the SPEECH button (except for vehicles with Mitsubishi Multi-Commu- nication System) or PICK-UP button (for vehicles

Page 247 of 422

MITSUBISHI LANCER SPORTBACK 2014 8.G Owners Manual USB input terminal (if so equipped) 5-180 Features and controls
5
The term “IC:” before the radio certification number only signifies that Industry Canada technical specifications were met. The an

Page 248 of 422

MITSUBISHI LANCER SPORTBACK 2014 8.G Owners Manual USB input terminal (if so equipped)
Features and controls 5-181
5
5. To remove the USB connector cable, turn the ignition switch to the “LOCK” posi- tion first and perform the installation steps
