2014 MITSUBISHI LANCER SPORTBACK Owners Manual

Power door locks 5-38 Features and controls
5
N00503800134
Ty p e 1 Ty p e 2 If the driver’s door is opened while the igni- tion switch is in a position other than “LOCK” (PUSH OFF), the ignition switch return reminder buzzer will sound intermit-tently to remind you to return the ignition switch to the “LOCK” (PUSH OFF) position. The warning display will be displayed on theinformation screen in the multi-information display.
N00509300593
All of the doors and the rear hatch can belocked or unlocked by pressing the power door lock switch on the driver’s or the frontpassenger’s door.
Ignition switch return reminder system When the F.A.S.T.-key was used to start the engine
Power door locks
NOTE
 When locking or unlocking with the key on the driver’s door, only the driver’s door will lock or unlock.  Repeated continuous operation between lock and unlock could activate the power door locking systems built-in protection circuitand prevent the system from operating. If this occurs, wait about one minute before operating the power door lock switch.
To lock and unlock the doors and rear hatch Using the power door lock switch 1- Lock 2- Unlock
BK0200700US.bo
ok 38 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

“Child safety locks” for rear door
Features and controls 5-39
5
N00563401148
All doors and the rear hatch will unlock when the ignition switch is turned to the “LOCK” position. All doors and the rear hatch will unlock when the selector lever (CVT) or the gearshift lever(Twin Clutch SST) is moved to the “P”
(PARK) position with the ignition switch in the “ON” position.
N00509400204
Child safety locks help prevent rear passen-gers, especially children, from opening the rear door using the inside door handle. A lock lever for the chil
d safety lock is pro-
vided on each rear door. When the lever is in the lock position (1), the rear door cannot be opened using the insidedoor handle. To open the rear door when the child safety lock lever is in the lock position, pull the out-side door handle.When the lever is in th
e release position (2),
the child safety lock is released and the rear door can be opened using the inside door han-dle.
To unlock the doors and rear hatch You can select the functions to unlock the doors and rear hatch either using the igni- tion switch position or using the selector lever {continuously variable transmission (CVT)} position or the gearshift lever (Twin Clutch SST) position.These functions are not activated when the vehicle is shipped from the factory. To acti- vate or deactivate these functions, please contact your authorized Mitsubishi Motors dealer.Using the ignition switch position Using the selector lever {continu- ously variable trans- mission (CVT)} position or the gearshift lever (Twin Clutch SST) position
“Child safety locks” for rear door 1- To lock 2- To releaseVehicles with CVT
Vehicles with Twin Clutch SST
WA R N I N G Always keep the doors tightly closed and locked when driving. An unlocked door may be accidentally opened by a passen- ger, especially by a child who could fallout. Also, if the doors are not locked, there is a greater risk of someone being thrown from the vehicle in an accident.
BK0200700US.bo
ok 39 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Rear hatch 5-40 Features and controls
5
N00510000066
After unlocking, lift the rear hatch.
Pull the rear hatch grip (A) downward as illustrated and release it before the rear hatchcloses completely. Gently slam the rear hatch from the outside so that it is completely closed.
Rear hatch
WA R N I N G It is dangerous to drive with the rear hatch open since carbon monoxide (CO) gas can enter the passenger compartment. CO is an invisible, odorless gas that cancause unconsciousness and even death. When opening and closing the rear hatch, make sure that there are no people nearby and be careful not to hit your head or pinch your hands, neck, etc.CAUTION Do not stand behind the exhaust pipe when loading and unloading luggage. Heat from the exhaust could lead to burns.NOTE
 Locking and unlocking the doors by using the power door locks (driver and front pas- senger side), keyless entry system, or F.A.S.T.-key operation (if so equipped) also locks and unlocks the rear hatch.
To open
CAUTION Make sure there is no one standing nearby when opening the rear hatch.NOTE
 The rear hatch cannot be raised if it is not raised immediately after pressing the rearhatch OPEN switch. If this happens, raise the rear hatch again after pressing the rear hatch OPEN switch.  It is not possible to open the rear hatch while the battery is disconnected. If necessary, usethe inside rear hatch release.  When the battery is reconnected, all doors and the rear hatch will be locked. Unlock them before trying to open the rear hatch.
To close
CAUTION To avoid injuring your hand or arm, do not attempt to close the rear hatch without releasing the rear hatch grip (A). Before starting the vehicle, be sure to con- firm that the rear hatch is locked. If the rearhatch opens while driving the vehicle, objects stored in the luggage compartment could fall out into the road.
BK0200700US.bo
ok 40 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Inside rear hatch release
Features and controls 5-41
5
N00523100058
The inside rear hatch release is designed to provide a way to open the rear hatch if the battery is dead or disconnected. The rear hatch release lever (see illustration)is mounted on the rear hatch.
You and your family should familiarize your- selves with the location and operation of the rear hatch release lever. 1. Open the lid (A) inside of the rear hatch.
2. Move the lever (B) to open the rear hatch. 3. Push out on the rear hatch to open it.
N00510200215
The theft-alarm system is designed to provide protection from unauthorized entry into the vehicle. This system is operated in three stages: the first is the “armed” stage, the sec-ond is the “alarm” stage,
and third is the “dis-
armed” stage. If triggered, the system provides both audible and visual alarm sig-nals.
NOTE
 Gas struts (B) are installed in the locations illustrated in order to support the rear hatch. Please observe the following in order to pre- vent damage or faulty operation. • Do not touch, push or pull the gas struts when closing the rear hatch. • Do not attach any plastic material, tape, etc., to the gas struts. • Do not tie string, etc., around the gas struts. • Do not hang objects
on the gas struts.
Inside rear hatch release
To open
CAUTIONAlways keep the release lever lid on rear hatch closed when driving so that your lug- gage cannot accidentally bump the lever and open the rear hatch.
Theft-alarm system
BK0200700US.bo
ok 41 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Theft-alarm system 5-42 Features and controls
5
N00510301196
Park the vehicle and stop the engine. Arm the system as described below. 1. Turn the ignition switch to the “LOCK” position. Also, if a key was used to start the engine, remove the key from the ignition switch.2. Make sure that the engine hood is closed.
3. Lock all doors and the rear hatch by using the keyless entry system or the F.A.S.T.- key operation. At this time, the theft-alarm indicator (A) on the audio panel flashes for confirma- tion.
4. The system has entered the armed stage after about 20 seconds, when the theft- alarm indicator (A) flashing becomes slower.The theft-alarm indicator (A) continues to flash while the system is in the armed stage.
CAUTION Do not modify or add parts to the theft-alarm system. Doing so could cause the theft-alarm to malfunction.
Armed stage
Arm the system and leave
NOTE
 If the engine hood is open, the theft-alarm indicator (A) illuminates and the system can-not enter the armed stage. The system enters the armed stage about 20 seconds after the engine hood is closed.  The system will be disarmed if, while the theft-alarm indicator (A) is illuminated, alldoors and rear hatch are unlocked by using the keyless entry system or the F.A.S.T.-key operation.  The system will be disarmed if, while the theft-alarm indicator is illuminated, the igni-tion switch is turned to the “ON” position.  The system will not be
armed if a door or the
rear hatch or the engine hood is not com- pletely closed. If this happens, rearm the sys- tem as described above.  The theft-alarm system can be activated when people are riding inside the vehicle or when the windows are open. To prevent acci- dental activation of the alarm, do not set thesystem to the system armed mode while peo- ple are riding in the vehicle.
BK0200700US.bo
ok 42 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Theft-alarm system
Features and controls 5-43
5
N00510401201
The alarm will be activated if any of the fol- lowing occur while the vehicle is parked andthe system is armed.  One of the doors and the rear hatch is opened without using the keyless entry system or the F.A.S.T.-key operation. The engine hood is opened.
When the alarm is activated: 1. The headlights blink on and off for 3 min- utes.After 3 minutes the headlights automati- cally shut off. 2. The horn will sound intermittently for 3minutes.
Type 1
Type 2 The alarm can be deactivated in the following ways.  By using the keyless entry system or the F.A.S.T.-key operation to lock or unlock the door or rear hatch. Turn the ignition switch to the “ON” posi- tion.
N00510501185
The system will be disarmed if the followingoperation is performed.  The ignition switch is turned to the “ON” position. All doors and the rear hatch are unlocked by the keyless entry system or the F.A.S.T.-key operation.
Alarm stage Type of alarm
NOTE
 The alarm will continue to operate for 3 min- utes. At the end of that period, the alarm will automatically shut off to save battery power. The system will then
be rearmed until the
proper disarming step is taken.  The alarm will resume if unauthorized actions are taken again, even if the alarm has stopped.  While the alarm is operating, a warning is displayed on the information screen in the multi-information display.Horn sounds! Headlights blink on and off!
Alarm deactivation Disarmed stage
BK0200700US.bo
ok 43 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Power windows 5-44 Features and controls
5
N00510601131
Use the following procedure to test the sys- tem:
1. Lower the driver’s window. 2. Arm the system as explained in “Armed stage”. 3. Make sure that the theft-alarm indicatorcomes on and flashes for approximately 20 seconds. 4. Wait a few seconds and then unlock thedriver’s side door by using the inside door lock knob and open the door. 5. Check to be sure that the horn soundsintermittently and the headlights blink onand off when the door is opened. 6. Disarm the system by unlocking all doors and the rear hatch by using the keylessentry system or the F.A.S.T.-key opera- tion.
N00510800325
The main switch located on the driver’s door can be used to operate all door windows. A window can be opened or closed by operat- ing the corresponding switch.Press the switch down to open the window, and pull up the switch to close it. If the driver’s door window switch is fullypressed down/pulled up, the driver’s door window automatically opens/closes com- pletely.
NOTE
 If the UNLOCK button on the remote control transmitter, or the driver’s or front passen- ger’s door lock/unlock switch is pressedwhen all doors and the rear hatch are closed and no door is opened
within approximately
30 seconds, re-arming will automaticallyoccur.  The amount of time after unlocking until the vehicle relocks automatically can be adjusted. See an authorized Mitsubishi Motors dealer for details.  Once the system has been disarmed, it can- not be rearmed except by repeating the arm-ing procedure.
Testing the theft-alarm system Disarm...by using the ke
yless entry system or
F.A.S.T.-key operation
Power windows 1- Open (down) 2- Close (up)
NOTE
 Never try to operate the main switch and sub switch in different directions at the same time. This will freeze the window in posi- tion.  Operating the power windows repeatedly with the engine stopped will run down the battery. Use the window switches only whilethe engine is running. WA R N I N G Before operating the power windows, make sure that nothing can be trapped(head, hands, fingers, etc.) in the window.  Never leave the vehicle with the key in the ignition switch.  Never leave a child alone in the vehicle.
Main switch
BK0200700US.bo
ok 44 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Power windows
Features and controls 5-45
5
If you want to stop the window movement, operate the switch lightly in the reverse direc- tion.
Each sub switch can be used for its own pas- senger door window, unless the driver’s win-dow lock switch is activated. The power windows can be run up or down when the ignition switch is in the “ON” posi- tion. The door windows can be opened or closedfor a 30 second period after the ignition switch is turned to the “ACC” or “LOCK” position. However, once the driver’s door orthe front passenger’s door is opened, the power windows cannot be operated.
N00528800089
If a hand or head is trapped, for safety the door window is automatically lowered a little. After the door window is lowered, pull up the switch again to close the door window.
1- Driver’s door window switch 2- Front passenger door window switch3- Left rear door window switch 4- Right rear door window switch 5- Window lock switch
Sub switch 1- Close (up)2- Open (down)Timer function
Safety mechanism (Driver’s door window only)
WA R N I N G If the safety mechanism is activated three or more times successively, the safetymechanism will be temporarily cancelled. If a hand or head subsequently gets trapped, a serious injury can result. The safety mechanism is deactivated while the switch is pulled up continuously.Therefore be especially careful that hands or head are not trapped in the door win- dow opening. Do not deliberately trap your hands or head in order to activate the safety mecha-nism. Your hand or head could be trapped and personal injury could result.CAUTION The safety mechanism is deactivated just before the door window closes. This allowsthe door window to close completely. There- fore be especially careful that fingers are not trapped in the door window opening.
