2014 MITSUBISHI LANCER SPORTBACK Owners Manual

Cruise control 5-94 Features and controls
5
Warning display type 2
N00546300057 N00518301583
Cruise control is an automatic speed control system that keeps a set speed. It can be acti- vated at speeds from about 25 mph (40 km/h). Cruise control does not work atspeeds below about 25 mph (40 km/h).
NOTE
 The combination of items shown on the dis- play varies depending on the vehicle model.CAUTION The system may be malfunctioning. Park your vehicle in a safe place and stop theengine. Restart the engine and check whether the dis- play/indicator goes out. If they go out, there is no abnormal condition. If they do not go out or if they turn on frequently, it is not nec-essary to stop the vehicle immediately, but you should have your vehicle inspected by an authorized Mitsubishi Motors dealer or arepair facility of your choice as soon as pos- sible.
To w i n g
CAUTION When towing the vehicle with only the front wheels or only the rear wheels raised off the ground, do not place the ignition switch in the “ON” position. Placing the ignitionswitch in the “ON” position could cause the ASC to operate, resulting in an accident. Note that the correct towing method dependson the transmission type and the vehicle’s drive configuration. For details, refer to
“Towing” on page 8-13.
Cruise control
CAUTIONWhen you do not wish to drive at a set speed, turn off the cruise control for safety. Do not use cruise control when driving con- ditions will not allow you to stay at the same speed, such as in heavy traffic or on roadsthat are winding, icy, snow-covered, wet, slippery, on a steep downhill slope.
 On vehicles equipped with manual transaxle, do not move the gearshift lever to the “N” (Neutral) position while driving at a set speed without depressing the clutch pedal. The engine will run too fast and might bedamaged.NOTE
 Cruise control may not be able to keep your speed on uphills or downhills.  Your speed may decrease on a steep uphill. You may use the accelerator pedal if you want to stay at your set speed.  Your speed may increase to more than the set speed on a steep downhill. You have to usethe brake to control your speed. As a result, the set speed driving is deactivated.CAUTION
BK0200700US.bo
ok 94 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Cruise control
Features and controls 5-95
5
Used to turn on and off the cruise control. Used to reduce the set speed and to set the desired speed. Used to increase the set speed and to return to the original set speed.
Used to deactivate the set speed driving.
N00518400369
1. With the ignition switch in the “ON” posi- tion, press the “ON OFF” switch (A) toturn on the cruise control. The “CRUISE” indicator light in the meter cluster will come on.
Cruise control switches A- “ON OFF” switch B- “COAST SET” switch C- “ACC RES” switch Type 1 Type 2
D- “CANCEL” switch
NOTE
 When operating the cruise control switches, press the cruise control switches correctly.The set speed driving may be deactivated automatically if two or more switches of the cruise control are pressed at the same time.
To activate Type 1
BK0200700US.bo
ok 95 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Cruise control 5-96 Features and controls
5
2. Confirm that the Twin Clutch SST control mode is set to “NORMAL” (on vehicles equipped with Twin Clutch SST). Refer to “Twin Clutch SST control mode”on page 5-75. 3. Accelerate or decelerate to your desired speed, then press and release the “COAST SET” switch (B) when the “CRUISE”indicator light is illuminated. The vehicle will then maintain the desired speed.
N00518500315
There are 2 ways to increase the set speed. Press and hold the “ACC RES” switch (C) while driving at the set speed, and your speedwill then gradually increase. When you reach your desired speed, release the switch. Your new cruising speed is nowset.
NOTE
 If the cruise control is on when the ignition switch is turned to “LOCK” or “ACC” posi- tion, cruise control will be on automatically the next time you start the engine. The“CRUISE” indicator light will also be on.  If the battery voltage is insufficient, the memory data for the cruise control may be erased. As a result, the “CRUISE” indicator light may not come on when you restart the engine.If this happens, press the “ON OFF” switch once again to turn on the cruise control.Type 2
NOTE
 The cruising speed cannot be set when the Twin Clutch SST control mode is set to“SPORT” mode.Type 1 Ty p e 2
NOTE
 When you release the “COAST SET” switch, the vehicle speed will be set.
To increase the set speed “ACC RES” switch
BK0200700US.bo
ok 96 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Cruise control
Features and controls 5-97
5
To increase your speed in small amounts, press the “ACC RES” switch for less than about 1 second and release it.Each time you press the “ACC RES” switch, your vehicle will go about 1 mph (1.6 km/h) faster. While driving at the set speed, use the accel- erator pedal to reach your desired speed andthen press the “COAST SET” switch (B) and release the switch momentarily to set a new desired cruising speed.
N00518600244
There are 2 ways to decrease the set speed. Press and hold the “COAST SET” switch (B) while driving at the set speed, and your speed will slow down gradually.When you reach your desired speed, release the switch. Your new cruising speed is now set.
To slow down your speed in small amounts, press the “COAST SET” switch for less than about 1 second and release it.Each time you press the “COAST SET” switch, your vehicle will slow down by about 1 mph (1.6 km/h). While driving at the set speed, use the brake pedal, which disengages the cruise control,then press the “COAST SET” switch (B) and release the switch momentarily to set a new desired cruising speed.
Accelerator pedal Type 1 Type 2
To decrease the set speed “COAST SET” switch
Ty p e 1 Type 2
Brake pedal Type 1 Type 2
BK0200700US.bo
ok 97 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Cruise control 5-98 Features and controls
5
N00541700027
Depress the accelerator pedal as you would normally. When you release the pedal, you will return to your set speed.
Depress the brake pedal to decrease the speed. To return to the previously set speed,press the “ACC RES” switch (C). Refer to “To resume the set speed” on page 5-99.
N00518800477
The set speed driving can be deactivated asfollows:  Press the “ON OFF” switch (A). (Cruise control will be turned off.)  Press the “CANCEL” switch (D).
To temporarily increase or decrease the speed To temporarily increase the speed
Type 1 Ty p e 2
To temporarily decrease the speed
To deactivate
Type 1 Ty p e 2
BK0200700US.bo
ok 98 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Cruise control
Features and controls 5-99
5
 Depress the brake pedal.
The set speed driving is deactivated automati- cally in any of the following ways.  When you depress the clutch pedal (on vehicles equipped with manual transaxle). When your speed slow
s to about 10 mph
(15 km/h) or more below the set speed because of a hill, etc. When your speed slow
s to about 25 mph
(40 km/h) or less.  When the Twin Clutch SST control mode is set to “Sport” mode (on vehicles equipped with Twin Clutch SST). Refer to “Twin Clutch SST control mode”on page 5-75.
 When the active stability control (ASC) starts operating. Refer to “Active stability control (ASC)” on page 5-91.
Also, the set speed driving may be deacti- vated as follow:  When the engine speed rises and approaches the tachometer’s red zone (the red-colored part of the tachometer dial).
N00518900250
If the set speed driving is deactivated by thecondition described in “To deactivate” onpage 5-98, you can resume the previously set speed by pressing the “ACC RES” switch (C) while driving at a speed of about 25 mph (40km/h) or higher.
Type 1 Type 2
WA R N I N G On vehicles equipped with continuously variable transmission (CVT) or TwinClutch SST, although the set speed driving will be deactivated when shifting to the “N” (NEUTRAL) position, never move theselector lever (CVT) or the gearshift lever (Twin Clutch SST) to the “N” (NEU- TRAL) position while driving.You would have no engine braking and could cause a serious accident.
CAUTION When the set speed driving is deactivated automatically in any situation other than those listed above, there may be a system malfunction. Press the “ON OFF” switch to turn off thecruise control and have your vehicle inspected by an authorized Mitsubishi Motors dealer or a repair facility of yourchoice.
To resume the set speed
BK0200700US.bo
ok 99 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Tire pressure monitoring system 5-100 Features and controls
5
Under either of the following conditions, however, using the switch does not allow you to resume the previously set speed. In thesesituations, repeat the speed setting procedure:  The “ON OFF” switch is pressed.  The ignition switch is turned OFF.  “CRUISE” indicator light is turned OFF.
N00530201508
The tire pressure monitoring system uses tire inflation pressure sensors (A) on the wheelsto monitor the tire inflation pressures. Thesystem only indicates when a tire is signifi- cantly under-inflated.Tire pressure monitoring system Type 1 Type 2
WA R N I N G The spare wheel does not have a tire infla- tion pressure sensor. When the spare tire is used, the tire pres-sure monitoring system will not work properly. See an authorized Mitsubishi Motorsdealer as soon as possible to replace or repair the original tire.NOTE
 The tire pressure monitoring system is not a substitute for regularly checking tire infla- tion pressures. Be sure to check the tire inflation pressuresas described in “Tires” on page 9-17.  The tire inflation pressure sensor (A) is installed in the illustrated location.
• On vehicles with Type 1 sensor which has the metallic air valve (B), replace grommet (C) with a new one when the tire is replaced. • On vehicles with Type 2 sensor which has the rubber air valve (D), replace rubber valve (D) with new one when the tire isreplaced. For details, please contact your authorized Mitsubishi Motors dealer.NOTE
Type 1Type 2
SC00000600-3.f
m 100 ページ ２０１３年２月１５日　金曜日　午後２時３１分

Tire pressure monitoring system
Features and controls 5-101
5
N00532700122
When the ignition switch is turned to the “ON” position, the tire pressure monitoringsystem warning light normally illuminatesand goes off a few seconds later. If one or more of the vehicle tires (except for the spare tire) is significantly under-inflated, the warning light will remain illuminatedwhile the ignition switch is in the “ON” posi- tion. Refer to “If the warning light/display illumi-nates while driving” on page 5-102 and take the necessary measures. Type 1
Type 2
Tire pressure monitoring sys- tem warning light/display
NOTE
 In addition, the warning display is displayed on the information screen in the multi-infor- mation display.
CAUTION If the tire pressure monitoring system warn- ing light does not illuminate when the igni- tion switch is turned to the “ON” position, it means that the tire pressure monitoring sys-tem is not working properly. Have the sys- tem inspected by an authorized Mitsubishi Motors dealer.In such situations,
a malfunctioning of the
system may be preventing the monitoring of the tire pressure. Avoid sudden braking, sharp turning and high-speed driving.
 If a malfunction is detected in the tire pres- sure monitoring system, the tire pressure monitoring system warning light will blink for approximately 1 minute and then remain continuously illuminated. The warning lightwill issue further warn
ings each time the
engine is restarted as long as the malfunction exists.Check to see whether the warning light goes off after few minutes driving. If it then goes off during driving, there is noproblem. However, if the warning light does not go off, or if it blinks again when the engine isrestarted, have the vehicle inspected by an authorized Mitsubishi Motors dealer. In such situations,
a malfunctioning of the
system may be preventing the monitoring of the tire pressure. For safety reasons, when the warning light appears while driving,avoid sudden braking, sharp turning and high-speed driving.NOTE
 In addition, the warning display is displayed on the information screen in the multi-infor- mation display.CAUTION
