2014 MITSUBISHI LANCER SPORTBACK Owners Manual

Sun visors 5-182 Features and controls
5
N00567000015 N00567100087
Devices of the following types can be con- nected. * : “iPod touch,” “iPod classic,” “iPod” and “iPod nano” are registered trademarks of
Apple Inc. in the United States and other countries.
N00567200017
You can play music files of the following specifications that are saved in a USB mem- ory device or other device supporting massstorage class.
N00524600294
Fold the sun visor downward (1) to reduce front glare while driving. To reduce side glare, turn the visor to the side (2).
Types of connectable devices and supported file specifica- tions

Device types

Model name
Condition
USB memory device
Storage capacity of 256 Mbytes or more
iPod touch
*
F/W Ver.1.1.1 or later
iPod classic
*
F/W Ver.1.0 or later
iPod (fifth genera- tion)
*
F/W Ver.1.2.2 or later
iPod nano (fifth gen- eration)
*
F/W Ver.1.2 or later
iPod nano (second generation)
*
F/W Ver.1.1.2 or later
Models other than USB memory devices and iPods
Digital audio player supporting mass storage class
NOTE
 Depending on the type of the USB memory device or other device connected, the con- nected device may not function properly orthe available functions may be limited.  It is recommended to use an iPod with firm- ware updated to the latest version.  You can charge your iPod by connecting it to the USB input terminal when the ignition switch is in the “ACC” or “ON” position.  Do not keep your USB memory device or iPod in your vehicle.  It is recommended that you back up the files in case of data damage.  Do not connect to the USB input terminal any device (hard disk, card reader, memory reader, etc.) other than the connectabledevices specified in the previous section. The device and/or data may be damaged. If any of these devices
was connected by mis-
take, remove it after turning the ignition switch to the “LOCK” position.
File specifications

Item
Condition
File format
MP3, WMA, AAC, WAV
Maximum number of levels(including the root)
Level 8
Number of folders 700 Number of files 65,535Sun visors
BK0200700US.book
182 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

12 V power outlet
Features and controls 5-183
5
The vanity mirrors are located on the back of the sun visors.
Cards can be slipped into the front (A) of the lid of the vanity mirror.
N00525000569
12 V power outlets are located in front of the floor console (Type 1, Type 2) and inside of the floor console box (Type 3). The accessory can be operated when the igni- tion switch is in the “
ON” or “ACC” position.
To use a “plug-in” type accessory, pull out theplug, then insert the plug in the socket.
Vanity mirror
Card holder 12 V power outlet
CAUTION Be aware that using electronic equipment with the engine off may run the batterydown. When the 12 V power outlet is not in use, be sure to put on the plug or close the 12 V power outlet cover. This will prevent the 12 V power outlet from becoming dirty and pos-sibly short-circuiting.
NOTE
 If your vehicle is equipped with two 12 V power outlets, both power outlets can be used simultaneously.CAUTION Be sure to use a “plug-in” type accessory operating at 12 V and 120 W or less. When using two 12 V power outlets simulta- neously, make sure that the total power con-sumption of these does not exceed 120 W at 12 V.
Type 1, Type 2
BK0200700US.book
183 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Interior lights 5-184 Features and controls
5
The accessory can be operated when the igni- tion switch is in any position.To use a “plug-in” type accessory, open the cover, then insert the plug in the socket.
N00525300487
N00525801287
The dome light can be turned on by sliding the dome light switch.
Type 3 Type 1Type 2
Interior lights 1- Cargo room light
P.5-186
2- Dome light (Rear)(if so equipped)
 P.5-185
3- Dome light (Front)/Reading lights
 P.5-184
Dome light (Front)/Reading lights Dome light (Front)
1- (DOOR) The dome light comes on when any door or the rear hatch is opened. When all the doors and the rear hatch are closed, the dome light goes off after approximately 30 seconds. However, the light goes off immediately if:
BK0200700US.book
184 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Interior lights
Features and controls 5-185
5
N00553800070
Regardless of the dome light switch position, when you press the lens, the light on the side that is pressed illuminates; when you pressthe lens again, the light goes off.
N00525401502
The dome light can be turned on by sliding the dome light switch.
 The doors and the rear hatch are closed while the ignition switch is in the “ON” position.  The driver’s door is closed after all the other doors and the rear hatch are closed while the lock knob of the driver’s door is in the lock position.  The doors and the rear hatch are closed and the power door lock switch is used to lock the doors.  The keyless entry system remote con- trol transmitter is used to lock the doors and the rear hatch.  In vehicles equipped with the F.A.S.T.-key, the doors and the rear hatch are locked using the F.A.S.T.- key.NOTE
 When the engine is started using the key while the doors and rear hatch are closed, ifyou remove the key, the dome light will illu- minate for approximately 30 seconds before going off.  When the engine is started using the F.A.S.T.-key while the doors and rear hatch are closed, if the ignition switch is moved to the “LOCK” position, the dome light willilluminate for approximately 30 seconds before going off.  The time until the light goes off can be adjusted. See your authorized Mitsubishi Motors dealer for details.
2- (OFF) The dome light goes off.
Reading lights Dome light (Rear)
(if so equipped)
1- (ON) The dome light comes on.2- (
)
The dome light comes on when any door or the rear hatch is opened. When all the doors and the rear hatch are closed, the dome light goes off after approximately 30 seconds. However, the light goes off immediately if:  The doors and the rear hatch are closed while the ignition switch is in the “ON” position.  The driver’s door is closed after all the other doors and the rear hatch are closed while the lock knob of the driver’s door is in the lock posi- tion.
BK0200700US.book
185 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Interior lights 5-186 Features and controls
5
N00526200063
N00526301478
If any of the interior lights are left on with the ignition switch in the “LOCK” position, the lights go off automatically after about 30minutes. The lights come on again if the ignition switch is turned to the “ON” or “ACC” posi-tion, any door or the rear hatch is opened andclosed, or the keyless entry system or F.A.S.T.-key is operated.
 The door and the rear hatch are closed and the power door lock switch is used to lock the doors.  The keyless entry system remote control transmitter is used to lock the doors and the rear hatch.  In vehicles equipped with the F.A.S.T.-key, the doors and the rear hatch are locked using the F. A . S . T. - k e y.
NOTE
 When the engine is started using the key while the doors and the rear hatch are closed,if you remove the key, the dome light will illuminate for approximately 30 seconds before going off.  When the engine is started using the F.A.S.T.-key while the doors and the rearhatch are closed, if the ignition switch is moved to the “LOCK” position, the dome light will illuminate for approximately 30seconds before going off.  The time until the light goes off can be adjusted. See your au
thorized Mitsubishi
Motors dealer for details.3- (OFF) The dome light goes off.
Cargo room light
1- (ON) The light illuminates regardless of whether the rear hatch is open or closed. 2- The light illuminates when the rear hatch is opend, and goes off when the rear hatch is closed. 3- (OFF) The light remains off regardless of whether the rear hatch is open or closed.
Interior light auto-cutout func- tion (dome light and other lights)
NOTE
 The interior light auto-cutout function can be deactivated. The time until the lights auto-matically go off can be adjusted. See your authorized Mitsubishi Motors dealer for details.
BK0200700US.book
186 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Storage spaces
Features and controls 5-187
5
N00526400498
N00551500246
To open the glove compartment, pull the lever (A).
There is a card holder on the inside of the glove compartment.
Storage spaces
CAUTION Never leave lighters, carbonated drink cans, or spectacles in the cabin when parking the vehicle in hot sunshine. The cabin will become extremely hot, so lighters and otherflammable items may catch fire and unopened drink cans (including beer cans) may rupture. The heat may also deform orcrack plastic spectacle parts. Keep the lids of stor
age spaces closed while
driving the vehicle. A lid or the contents of a storage space could otherwise cause injuries during a sudden stop.NOTE
 Do not leave valuables in any storage space when leaving the vehicle.
1- Cargo floor boxes (if so equipped)
 P.5-189
2- Floor console box
P.5-188
3- Front console tray (if so equipped)
 P.5-188
4- Front console boxes (if so equipped)
 P.5-188
5- Glove compartment
P.5-187
Glove compartment
WA R N I N GAn open glove compartment door can cause a serious injury or death to the front passenger in an accident, even if the pas- senger is wearing his/her seat belt. Alwayskeep the glove compartment door closed when driving. NOTE
 The USB input terminal (if so equipped) is located in the glove compartment. For details, refer to “USB input terminal” on page 5-180.
Card holder
BK0200700US.book
187 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Storage spaces 5-188 Features and controls
5
N00547800017
The front console tray is on the front console part.
N00546401097
To open, push the lid.
N00551600175
To open the floor console box, lift the rightrelease lever (A) and raise the lid.
NOTE
 Up to 2 cards will fit in the card holder.
Front console tray
(if so equipped)
CAUTIONDo not use the front c
onsole tray as an ash-
tray. This could cause a fire.
Front console boxes
(if so equipped)
Upper box

Lower box

CAUTION Do not use the front console boxes as an ash- tray. This could cause a fire.
Floor console box
BK0200700US.book
188 ページ ２０１３年２月１５日　金曜日　午後１２時１７分

Cup holder
Features and controls 5-189
5
The tissue holder (A) is located on the under- side of the floor console box lid.
N00552300023
The boxes for storing articles are locatedinside the luggage compartment. To use the boxes, raise the lids (A).
N00527300351
The cup holder is located the middle of the floor console. The cup holder is designed for holding cups or drink-cans securely.
To use the cup holder, open up the lid.
Tissue holder
Cargo floor boxes
(if so equipped)
Cup holder For the front seat
Ty p e 1 Ty p e 2
