Refill capacities
Specifications 11-7
11
Transfer oil .85 qt (0.8 L) Mitsubishi Motors Genuine LSD gear oilAWC control fluid (includes hydraulic
piping) .95 qt (0.9 L) DIAMOND ATF SP III
Rear differential oil .58 qt (0.55 L) Mitsubishi Motors Genuine LSD gear oilBrake/Clutch (if so equipped) As required Conforming to Brake fluid DOT3 or DOT4 Hood lock release mechanism and safety catch As
required Multipurpose type grease NLGI Grade 2
Engine coolant {includes .63 qt (0.65 L) in reserve tank}
Manual transaxle
7.4 qt (7.0 L)
Mitsubishi Motors Genuine Super Long Life Coolant Premium or equivalent
*
CVT 7.4 qt (7.0 L)Tw i n Clutch SST
7.9 qt (7.5 L)
Washer fluid 4.3 qt (4.0 L) — Refrigerant (air conditioning)
Refer to “Air con- ditioning label” on
page 11-2.
HFC-134a
*: similar high quality ethylene glycol based non-silicate, non
-amine, non-nitrate and non-borate
coolant with long life hybrid
organic acid
technology
LSD: Limited slip differential
Item
Capacity
Lubricants
