2009.5 Peugeot 308 CC Dag Owner's Manual

1
i
19
INSTRUMENTS and CONTROLS
PETROL - DIESEL MANUAL OR AUTOMATIC GEARBOX INSTRUMENT PANELS
Panel grouping together the vehicle
operation indication dials and warning
lamps.
5. Screen
.

6. Display management button.
Recalls the service information.
Resets the selected function to zero (trip distance recorder or service
indicator).

7. Instrument panel lighting button.
Adjusts the brightness of the lighting of the instruments and controls.
Dials

1. Rev counter.
Indicates the speed of rotation of the engine (x 1000 rpm).

2. Coolant temperature.
Indicates the temperature of the engine coolant (°Celsius).

3. Fuel level.
Indicates the quantity of fuel remaining in the tank.

4. Vehicle speed.
Indicates the current speed of the moving vehicle (mph or km/h).
A. Speed limiter
(mph or km/h) or
Cruise control.

B. Gear change indicator.

C. Automatic gearbox.

D. Trip distance recorder.
(miles or km)

E. Service indicator.
(miles or km) then,
engine oil level indicator
then
distance recorder.
(miles or km)
These three functions are displayed in succession when the ignition is
switched on.
Display
For further information, refer to the
paragraph relating to the button or
function and its associated display.

1
i
20
INSTRUMENTS and CONTROLS
PETROL - DIESEL MANUAL OR AUTOMATIC GEARBOX INSTRUMENT PANELS
Panel grouping together the vehicle
operation indication dials and warning
lamps.
5. Small
screen
.

6. Large central
screen
.

7. Display management button.
Starts a manual CHECK.
Recalls the service information.
Resets the function selected to zero (trip distance recorder or service
indicator).

8. Instrument panel lighting button.
Adjusts the brightness of the lighting of the instruments and controls.
Dials

1. Rev counter.
Indicates the speed of rotation of the engine (x 1000 rpm).

2. Coolant temperature.
Indicates the temperature of the engine coolant (°Celsius).

3. Fuel level.
Indicates the quantity of fuel remaining in the tank.

4. Vehicle speed.
Indicates the current speed of the moving vehicle (mph or km/h).
A. Trip distance recorder.
(miles or km)

B. Distance recorder.
(miles or km)

C. Engine oil level indicator,
service indicator.
(miles or km)
These two functions are displayed when the ignition is switched on,
then disappear after a few seconds.
Displays
For further information, refer to the
paragraph which relates to the but-
ton or function and its associated
display. The following functions are displayed in
accordance with the selection.
-
Warning
lamps/CHECK.
- Tyre under-infl ation detection.
- Speed limiter/Cruise control.
- Gear change indicator.
- Automatic gearbox.
-
Navigation - Guidance/Trip computer.

1
i
21
INSTRUMENTS and CONTROLS
PETROL - DIESEL MANUAL OR AUTOMATIC GEARBOX PC COM 3D INSTRUMENT PANELS
Panel grouping together the vehicle
operation indication dials and warning
lamps.
5. Small
screen
.

6. PC Com 3D 16/9 large central

screen
.

7. Display management button.
Starts a manual CHECK.
Recalls the service information.
Resets the function selected to zero (trip distance recorder or service
indicator).

8. Instrument panel lighting button.
Adjusts the brightness of the lighting of the instruments and controls.
Dials

1. Rev counter.
Indicates the speed of rotation of the engine (x 1000 rpm).

2. Coolant temperature.
Indicates the temperature of the engine coolant (°Celsius).

3. Fuel level.
Indicates the quantity of fuel remaining in the tank.

4. Vehicle speed.
Indicates the current speed of the moving vehicle (mph or km/h).
A. Trip distance recorder.
(miles or km)

B. Distance recorder.
(miles or km)

C. Engine oil level indicator,
s
ervice indicator.
(miles or km)
These two functions are displayed when the ignition is switched on,
then disappear after a few seconds.
Displays
For further information, refer to the
paragraph which relates to the but-
ton or function and its associated
display. The following functions are displayed in
accordance with the selection.
-
Warning lamps/CHECK.
- Tyre under-infl ation detection.
- Speed limiter/Cruise control.
- Gear change indicator.
- Automatic gearbox.
-
Navigation - Guidance/Trip computer.
- Vehicle parameters.

1
i
22
INSTRUMENTS and CONTROLS
* According to country.
Instrument panel navigator
associated with the PC Com 3D
General menu

 Press button 1 to gain access to the
general menu and select one of the
following functions:
- "Vehicle parameters",
- "Choice of language",
- "Choice of units".

 Press button 2 or 3 to move on the
screen.

 Press button 1 again to confi rm the
selection. Vehicle parameters

This menu allows you to activate or deacti-
vate certain driving and comfort equipment:
- selective unlocking (refer to the
"Access" section),
- guide-me-home and welcome lighting (refer to the "Visibility" section),
- ambiance lighting (refer to the "Visibility" section),
- daytime running lamps (refer to the "Visibility" section),
- directional headlamps (refer to the "Visibility" section),
- rear parking assistance (refer to the "Driving" section).
Choice of language
This menu allows you to select the lan-
guage used by the screen: Deutsch,
English, Espanol, Français, Italiano,
Nederlands, Portugues, Türkçe * .
Choice of units
This menu allows you to select the units:
temperature (°Celsius or °Fahrenheit)
and fuel consumption (l/100 km, mpg or
km/l).
This group of buttons permits:
-
when stationary , confi guration
of the vehicle's equipment and
of the parameters of the display
(languages, units...),
- while driving , scrolling of the
active functions (trip computer,
navigation...).
Controls
There are four buttons to control the in-
strument panel 16/9 large screen:

1. access the general menu, confi rm
the selection,

2. move up through the menu,

3. move down through the menu,

4. return to the previous screen, exit
from the menu. The general menu and its associat-
ed functions can only be accessed
when stationary, via buttons
1 to 4 .
A message appears on the screen,
above a certain speed threshold,
indicating that the general menu
cannot be displayed.
The trip computer displays can
only be accessed while driving, via
buttons 2 and 3 (refer to the "Trip
computer" paragraph).

1
!
23
INSTRUMENTS and CONTROLS
The warning lamps may come on
continuously or fl ash.
Certain warning lamps may come
on in two different modes. Only by
relating the type of lighting to the
operating status of the vehicle can
it be ascertained whether the situ-
ation is normal or whether a fault
has occurred.
Indicator and warning lamps
Visual indicators informing the driver
that a system is in operation (operation
or deactivation indicator lamps) or of the
occurrence of a fault (warning lamp).
Associated warnings
The switching on of certain warning
lamps may be accompanied by an au-
dible signal and a message on the mul-
tifunction screen.
Operation indicator lamps
If one of the following indicator lamps
comes on, this confi rms that the corre-
sponding system has come into opera-
tion.
Left-hand direction indicator.
Parking brake applied.
Right-hand direction
indicator.
Main beam headlamps.
Dipped beam headlamps.
Diesel engine pre-heating.
Wait until this has gone out be-
fore operating the starter.
Front foglamps.
Rear foglamp.
When the ignition is switched on
The warning lamps come on for a few
seconds when the vehicle's ignition is
switched on.
When the engine is started, these warn-
ing lamps should switch off.
If they remain on, before moving off,
consult the warning lamp concerned.
Common operation indicator lamps

1
24
INSTRUMENTS and CONTROLS
Foot on brake.
Press the brake pedal to start
the engine with the automatic
gearbox.
Specifi c operation indicator lamps
The other indicator lamps appear on
the large screen, located in the centre
of the instrument panel.
Automatic locking.
If this is displayed, it indicates
that you have activated auto-
matic locking of the doors and
boot while driving.
Speed limiter.
If this is displayed, it indi-
cates that you have activat-
ed the speed limiter mode.
If this is displayed, it indi-
cates that you can set the
speed limiter speed value to
be stored. Cruise control.
If this is displayed, it indicates
that you have activated the
cruise control mode.
If this is displayed it indi-
cates that you can set the
cruise control speed value
to be stored.
Automatic gearbox.
Automatic wiping.
If this is displayed, it indicates
that you have activated the au-
tomatic windscreen wiping.
Automatic lighting.
If this is displayed, it indicates
that you have activated auto-
matic lighting. This display indicates the gear
engaged in the automatic or
manual operation programme.
This display indicates the op-
erating programme selected
(automatic, sport, snow or
manual).
This display indicates the position
that you have selected on the gear
selection gate (P, R, N or D).

1
25
INSTRUMENTS and CONTROLS
Deactivation warning lamps
If one of the following warning lamps
comes on, this confi rms that the corre-
sponding system has been switched off
intentionally. Passenger's airbag system
deactivation.
The passenger's airbag system
is put into service automatically
when the vehicle is started.
A specifi c control switch, lo-
cated on the passenger's side of the
dashboard, permits deactivation of the
system. This is confi rmed by continu-
ous lighting of this warning lamp on the
instrument panel or on the seat belt and
passenger's front airbag warning lamps
display. Dynamic stability control
(ESP/ASR) deactivation
The ESP/ASR system is put
into service automatically when
the vehicle is started.
Common deactivation warning
lamps Specifi c deactivation warning lamps Automatic locking.
If this is displayed, it indicates
that you have deactivated the
automatic locking of the doors
and boot while driving.
Automatic wiping.
If this is displayed, it indicates
that you have deactivated auto-
matic windscreen wiping.
The other warning lamps appear on the
large screen, located in the centre of
the instrument panel.
Speed limiter.
If this is displayed, it indicates
that you have deactivated the
speed limiter.
Cruise control.
If this is displayed, it indicates
that you have deactivated the
cruise control.
Automatic lighting.
If this is displayed, it indicates
that you have deactivated auto-
matic lighting.
A specifi c button, located on
the dashboard, permits deac-
tivation of the system. This is
confi rmed by continuous light-
ing of this warning lamp and of the indi-
cator lamp on the button.
From approximately 30 mph (50 km/h),
the system is reactivated automatically.

1
!
26
INSTRUMENTS and CONTROLS
When the engine is running or the vehi-
cle is moving, the lighting of one of the
following warning lamps indicates the
occurrence of a fault requiring interven-
tion on the part of the driver. Central alert.
Lighting is associated with
the display of another warn-
ing lamp:
- punctured wheel,
- braking,
- power steering,
- engine oil pressure,
- coolant temperature,
stop the vehicle immediately and as
safely as possible.
Service.
If this comes on, it indicates the
occurrence of a problem in one
of the systems which does not
have a specifi c warning lamp.
In order to identify it, consult the mes-
sage on the multifunction screen. Braking.
If this comes on, it indicates the
occurrence of a fault in one of
the braking systems:
- signifi cant drop in the fl uid level in the system,
- electronic brake force distribution (EBFD) faulty (simultaneous lighting
of the ABS warning lamp),
stop the vehicle immediately and as
safely as possible.
When the vehicle is moving, check that
the parking brake is fully released.
Any fault resulting in the displaying
of a warning lamp must be investi-
gated further by reading the associ-
ated message on the multifunction
screen.

Should you encounter any prob-
lems, do not hesitate to contact a
PEUGEOT dealer.
Warning lamps
Anti-lock braking system
(ABS).
If this comes on, it indicates the
occurrence of a fault in the anti-
lock braking system.
However, this does not prevent op-
eration of the vehicle's servo-assisted
braking.
Common warning lamps
After checking:
- that the doors, boot and bonnet are
closed,
- the engine oil level,
- the screenwash fl uid level,
- the remote control battery,
- the pressure of the tyres,
- the end of saturation of the particle emission fi lter (Diesel),
for any other situations, contact a
PEUGEOT dealer.
