INTEGRATED HOMELINK TRANSMITTER
BL-169
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
4. CHECK GROUND CIRCUIT
Check continuity between anti-dazzling inside mirror (integrated
homelink transmitter) connector R4 terminal 8 and ground.
OK or NG
OK >> Replace inside mirror assembly.
NG >> Harness for open or short between anti-dazzling inside
mirror (integrated homelink transmitter) body ground. 8 (B) – Ground : Continuity should exist.
PIIA2368E

BL-170
BODY REPAIR
Revision: 2006 November2007 350Z
BODY REPAIRPFP:60100
Body Exterior Paint Color (Coupe)NIS0003T
2S: Solid + Clear, M: Metallic, 2P: 2-Coat pearl, 3P: 3-Coat pearl, CPM: Clear pearl metallic, RP: Multi flex color
SIIA1975E
ComponentColor code BA17 BAX6 BB17 BG41 BK23 BL40 BQX1 BWV2
Description Orange Red Blue Black SilverRed
PurpleWhite Silver
Paint type 2P 2S CPM 2P M RP 3P M
Hard clear coat - X X X - X - -
1Bumper
fasciaBody color BA17 BAX6 BB17 BG41 BK23 BL40 BQX1 BWV2
2Front
pillar
finisherBody color BA17 BAX6 BB17 BG41 BK23 BL40 BQX1 BWV2
3Door
outside
mirrorCase Body color BA17 BAX6 BB17 BG41 BK23 BL40 BQX1 BWV2
Base Body color BA17 BAX6 BB17 BG41 BK23 BL40 BQX1 BWV2
4Center
mud-
guardBody color BA17 BAX6 BB17 BG41 BK23 BL40 BQX1 BWV2
5Door
sash BlackGROSS
88GROSS
88GROSS
88GROSS
88GROSS
88GROSS
88GROSS
88GROSS
88
6Door
outside
handle
and
escutch
eonVelour chromium-
plateCr2p Cr2p Cr2p Cr2p Cr2p Cr2p Cr2p Cr2p
7Fuel
filler lidBody color BA17 BAX6 BB17 BG41 BK23 BL40 BQX1 BWV2

BODY REPAIR
BL-171
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
Body Exterior Paint Color (Roadster)NIS0003U
2S: Solid + Clear, M: Metallic, 2P: 2-Coat pearl, 3P: 3-Coat pearl, CPM: Clear pearl metallic, RP: Multi flex color
SIIA2295E
ComponentColor code BA17 BAX6 BB17 BG41 BK23 BL40 BQX1 BWV2
DescriptionOrang
eRed Blue Black SilverRed
PurpleWhite Silver
Paint type 2P 2S CPM 2P M RP 3P M
Hard clear coat - X X X - X - -
1 Bumper fascia Body color BA17 BAX6 BB17 BG41 BK23 BL40 BQX1 BWV2
2Front pillar
finisherBody color BA17 BAX6 BB17 BG41 BK23 BL40 BQX1 BWV2
3Door outside
mirrorCase Body color BA17 BAX6 BB17 BG41 BK23 BL40 BQX1 BWV2
Base Body color BA17 BAX6 BB17 BG41 BK23 BL40 BQX1 BWV2
4Center mud-
guardBody color BA17 BAX6 BB17 BG41 BK23 BL40 BQX1 BWV2
5Door outside
handle and
escutcheonVelour chro-
mium-plateCr2p Cr2p Cr2p Cr2p Cr2p Cr2p Cr2p Cr2p
6 Fuel filler lid Body color BA17 BAX6 BB17 BG41 BK23 BL40 BQX1 BWV2
7 Storage lid Body color BA17 BAX6 BB17 BG41 BK23 BL40 BQX1 BWV2
8 Trunk lid Body color BA17 BAX6 BB17 BG41 BK23 BL40 BQX1 BWV2

BL-172
BODY REPAIR
Revision: 2006 November2007 350Z
Body Component Parts (Coupe)NIS0003V
UNDERBODY COMPONENT PARTS
SIIA2356E

BODY REPAIR
BL-173
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
1. Front strut housing (RH&LH)
2. Upper front hoodledge (RH&LH)
3. Upper rear hoodledge (RH&LH)
4. Hoodledge reinforcement (RH&LH)
5. Upper dash assembly
6. Lower dash crossmember center reinforcement
7. Lower dash crossmember reinforcement
8. Cowl top
9. Lower dash crossmember assembly
10. Front crossmember center
11. Lower dash crossmember
12. Steering column mounting reinforcement
13. Lower dash
14. Front floor center
15. Front floor
16. Inner sill (RH&LH)
17. Rear seat crossmember reinforcement assembly
18. Rear floor gusset
19. Rear floor front
20. Rear step upper panel assembly
21. Rear step lower panel assembly
22. Inside step panel
23. Rear floor seat belt anchor reinforcement
24. Rear floor rear
25. Spare tire clamp bracket
26. Rear floor side
27. Rear seat crossmember
28. 2ND rear crossmember
29. Rear center crossmember assembly
30. Front side member assembly (RH&LH)
31. Inner front towing hook bracket (RH&LH)
32. Front side member closing plate assembly (RH&LH)
33. Front side member front closing plate (RH&LH)
34. Outer front towing hook bracket (RH&LH)
35. Front side member center closing plate (RH&LH)
36. Front side member rear extension (RH&LH)
37. Front side member rear reinforcement (RH&LH)
38. Front side member outrigger assembly (RH&LH)
39. Rear side member assembly (RH&LH)
40. Rear side member extension (RH&LH)

BL-174
BODY REPAIR
Revision: 2006 November2007 350Z
BODY COMPONENT PARTS
SIIA2357E
1. Hood
2. Front fender (RH&LH)

BODY REPAIR
BL-175
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
3. Front pillar reinforcement assembly (RH&LH)
4. Front pillar hinge brace (RH&LH)
5. Outer front pillar (RH&LH)
6. Inner side roof rail (RH&LH)
7. Outer sill reinforcement assembly (RH&LH)
8. Lower front pillar reinforcement (RH&LH)
9. Lower center pillar bulkhead assembly (RH&LH)
10. Outer rear wheel house extension (RH&LH)
11. Outer lock pillar reinforcement (RH&LH)
12. Inner lock pillar assembly (RH&LH)
13. Inner lock pillar reinforcement (RH&LH)
14. Seat belt anchor assembly (RH&LH)
15. Outer sill brace (RH&LH)
16. Outer rear wheel house (RH&LH)
17. Inner rear wheel house (RH&LH)
18. Inner rear pillar joint (RH&LH)
19. Inner rear pillar (RH&LH)
20. Seat back support (RH&LH)
21. Side parcel shelf (RH&LH)
22. Roof
23. Front roof rail assembly
24. Roof bow No.1
25. Rear roof rail assembly
26. Rear fender assembly (RH&LH)
27. Rear fender (RH&LH)
28. Outer sill extension (RH&LH)
29. Rear fender corner (RH&LH)
30. Fuel filler lid base
31. Parcel shelf
32. Rear panel assembly
33. Rear bumper fascia bracket
34. Rear bumper fascia center bracket (RH&LH)
35. Front door assembly (RH&LH)
36. Outer front door panel (RH&LH)
37. Back door
38. Front bumper reinforcement
39. Front bumper stay (RH&LH)
40. Rear bumper reinforcement
41. Rear bumper stay (RH&LH)

BL-176
BODY REPAIR
Revision: 2006 November2007 350Z
Body Component Parts (Roadster)NIS0003W
UNDERBODY COMPONENT PARTS
SIIA2442E
