REMOTE KEYLESS ENTRY SYSTEM
BL-89
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
ID Code Entry ProcedureNIS0001U
KEY FOB ID SETUP WITH CONSULT-III
NOTE:
If a key fob is lost, the ID code of the lost key fob must be erased to prevent unauthorized use. When
the ID code of a lost key fob is not known, all controller ID codes should be erased. After all ID codes
are erased, the ID codes of all remaining and/or new key fobs must be re-registered.
1. Touch “WORK SUPPORT”.
2. The items shown on the figure can be set up.

“REMO CONT ID REGIST”
Use this mode to register a key fob ID code.
NOTE:
Register the ID code when key fob or BCM is replaced, or when additional key fob is required.

“REMO CONT ID ERASUR”
Use this mode to erase a key fob ID code.

“REMO CONT ID CONFIR”
Use this mode to confirm if a key fob ID code is registered or not.

BL-90
REMOTE KEYLESS ENTRY SYSTEM
Revision: 2006 November2007 350Z
KEY FOB ID SETUP WITHOUT CONSULT-III
PIIA2839E

REMOTE KEYLESS ENTRY SYSTEM
BL-91
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
NOTE:

If a key fob is lost, the ID code of the lost key fob must be erased to prevent unauthorized use. A specific
ID code can be erased with CONSULT-III. However, when the ID code of a lost key fob is not known, all
controller ID codes should be erased. After all ID codes are erased, the ID codes of all remaining and/or
new key fobs must be re-registered.
To erase all ID codes in memory, register one ID code (key fob) five times. After all ID codes are erased,
the ID codes of all remaining and/or new key fobs must be re-registered.

When registering an additional key fob, the existing ID codes in memory may or may not be erased. If five
ID codes are stored in memory, when an additional code is registered, only the oldest code is erased. If
less than five ID codes are stored in memory, when an additional ID code is registered, the new ID code is
added and no ID codes are erased.

If you need to activate more than two additional new key fobs, repeat the procedure “Additional ID code
entry” for each new key fob.

Entry of maximum five ID codes is allowed. When more than five ID codes are entered, the oldest ID code
will be erased.

Even if same ID code that is already in the memory is input, the same ID code can be entered. The code
is counted as an additional code.
Key Fob Battery ReplacementNIS0001V
SEL411Y

BL-92
REMOTE KEYLESS ENTRY SYSTEM
Revision: 2006 November2007 350Z
Removal and Installation of Remote Keyless Entry ReceiverNIS0001W
REMOVAL
1. Remove the instrument passenger panel lower. Refer to IP-13, "(L) Instrument Passenger Panel Lower" .
2. Remove the screw and remote keyless entry receiver connector.
3. Remove the remote keyless entry receiver.
INSTALLATION
Install in the reverse order of removal.
PIIB3798E

DOOR
BL-93
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
DOORPFP:80100
Fitting AdjustmentNIS0001X
COUPE
DOOR
Longitudinal clearance and surface height adjustment at front end
1. Remove the fender protector. Refer to EI-21, "FENDER PROTECTOR" .
2. Loosen the hinge mounting bolts. Raise the door at rear end to adjust.
STRIKER ADJUSTMENT
Adjust the striker so that it becomes parallel with the lock insertion
direction.
PIIA2334E
PIIB1226E

BL-94
DOOR
Revision: 2006 November2007 350Z
ROADSTER
DOOR
Longitudinal clearance and surface height adjustment at front end
1. Remove the fender protector. Refer to EI-21, "FENDER PROTECTOR" .
2. Loosen the hinge mounting bolts. Raise the door at rear end to adjust.
STRIKER ADJUSTMENT
Adjust the striker so that it becomes parallel with the lock insertion
direction.
PIIA7605E
PIIB1226E

DOOR
BL-95
C
D
E
F
G
H
J
K
L
MA
B
BL
Revision: 2006 November2007 350Z
DOVE TAIL FEMALE ADJUSTMENT (ROADSTER)
Adjust the dove tail female so that it becomes parallel with the lock
insertion direction.
Removal and InstallationNIS0001Y
CAUTION:

When removing and installing the door assembly, support the door with a jack and cloth to protect
the door and body.

When removing and installing door assembly, be sure to perform the fitting adjustment Refer to
BL-93, "
Fitting Adjustment" .

Operate with two workers, because of its heavy weight.

Check the hinge rotating part for poor lubrication. If necessary, apply “body grease”.

After installing, check operation.

Apply sealant and coat with the same body color paint to door hinge installation part and mount-
ing nuts.
REMOVAL
1. Pull the lever and remove the door harness connector while
removing tabs of door harness connector.
2. Remove the mounting bolts of the check link on the vehicle.
PIIA7608E
PIIA2514E
PIIA2515E

BL-96
DOOR
Revision: 2006 November2007 350Z
3. Remove the door-side hinge mounting nuts, and remove the
door assembly.
INSTALLATION
Install in the reverse order of removal.
Removal and Installation of Dove Tail Male & Female (Roadster)NIS0001Z
REMOVAL
1. Remove the TORX bolts (T30) of dove tail male.
2. Soft top assembly locate like a figure.
3. Remove the body side welt. Refer to EI-37, "
Removal and Instal-
lation (for Roadster Models)" .
4. Remove the body side weatherstrip. Refer to EI-32, "
Removal
and Installation (for Roadster Models)" .
5. Remove the rear side finisher and kicking plate inner. Refer to
EI-37, "
Removal and Installation (for Roadster Models)" .
6. Remove the shoulder anchor. Refer to SB-6, "
Removal and
Installation of Seat Belt (Roadster)" .
7. Remove the rear side trim. Refer to EI-37, "
Removal and Instal-
lation (for Roadster Models)" .
8. Remove the dove tail female mounting nuts. Remove the dove
tail female.
INSTALLATION
Install in the reverse order of removal.
PIIA2516E
PIIA7607E
PIIA7606E
PIIA7608E
