2002 LAND ROVER DISCOVERY Workshop Manual

PANEL REPAIRS
77-2-56 TIMES
Combination panel replacement times - Side panels
Front wing
Front valance assembly
Wing support bracket
Valance outer reinforcement
24.0 RH
24.2 LH 22.7
Front bumper
Front bulkhead assembly
Front wing
Wing support bracket
Headlamp closing panel
Valance upper assembly (front section)
Valance outer reinforcement (front section)
22.4 RH 21.1 RH
23.1 LH 21.6 LH
Panel DescriptionTotal time
Petrol Diesel
Front wing
Front door
11.2 11.2
Rear door
Panel bodyside assembly
19.2 RH 19.1 RH
17.1 LH 17.1 LH
Front door
Rear door
'B/C' Post
19.9 RH
19.8 LH 19.8
Front door
Rear door
'B/C' Post
Front wing
Panel bodyside assembly
33.9 RH 33.9 RH
31.8 LH 31.7 LH
Front door
Front wing
Front wing support bracket
'A' post
23.1 RH 23.0 RH
22.9 LH 22.8 RH Panel DescriptionTotal time
Petrol Diesel

PANEL REPAIRS
TIMES 77-2-57
Combination panel replacement times - Rear end panels
Panel DescriptionTotal time
Petrol Diesel
Rear bumper
Panel bodyside assembly
'E' post assembly
Crossmember outer rear panel (RH/LH section)
Crossmember closing rear panel
31.9 RH 31.9 RH
30.1 LH 30.1 LH
Rear bumper
Panel bodyside assembly
Bodyside inner rear assembly
'E' post assembly
'E' post closing assembly
Crossmember outer rear panel (RH/LH section)
Crossmember closing rear panel
Crossmember rear assembly (RH/LH section)
Rear floor (RH/LH section)
Crossmember closing rear brackets
42.9 RH 42.6 RH
41.1 LH 40.7 LH
Rear bumper
Panel bodyside assembly RH & LH
Bodyside inner rear assembly RH & LH
'E' post assembly RH & LH
'E' post closing assembly RH & LH
Crossmember outer rear panel
Crossmember closing rear panel
Crossmember rear assembly
Rear floor (rear section)
Crossmember closing rear brackets RH & LH
65.9 65.6

PANEL REPAIRS
77-2-58 TIMES

BODY SEALING MATERIALS
MATERIALS AND APPLICATIONS 77-3-1
BODY SEALING MAT ERIALS MATERIALS AND APPLICATIONS
Materials applications
1Between panels - bolted
2Panel edges - bolted
3Between panels - spot welded
4Panel edges - spot welded
5Between panels - bonded
6Panel edges - bonded7Clinch joints - type (a)
8Clinch joints - type (b)
9Clinch joints - type (c)
10Gaps between panels - type (a)
11Gaps between panels - type (b)
12Lap joint

BODY SEALING MATERIALS
77-3-2 MATERIALS AND APPLICATIONS
Approved materials
The following is a table of materials approved by Land Rover for use during body repairs.
Description - Usage Supplier Part Number
Cavity waxes
Inner Cavity Wax (Amber) 3M 08901/11/21
Inner Cavity Wax (Transparent) 3M 08909/19/29
Cavity Wax Croda PW57
Engine bay waxes/lacquers
Astrolan Engine Bay Wax and Cosmetic Wax Astors DA3243/1
Engine Bay Cosmetic Wax/Lacquer Croda PW197
Engine Bay Cosmetic Wax/Lacquer Dinol 4010
Miscellaneous materials
Aerosol Auto Adhesive (Trim) - impact adhesive for trim parts 3M 08080
Flexible Parts Repair Material - rubber modified polypropylene parts 3M 05900
Waterproof Cloth Tape - sealing panel apertures 3M Y387/Y3998
Sound Dampening Foam Gurit-Essex Betacore 7999
Water Shedder Repair (Aerosol) Teroson
Seam sealers
Body Caulking - type (b) gaps between panels 3M 08568
Bolted Panel Sealer - between bolted panels 3M 08572
Drip Chek Clear - bolted, spot welded and bonded panel edges; type (a) and
(b) gaps between panels; type (c) clinch joints 3M 08401
Drip Chek Heavy - type (b) gaps between panels; type (c) clinch joints 3M 08531
Polyurethane Seam Sealer - bolted, spot welded and bonded panel edges;
type (a) and (b) gaps between panels; type (b) clinch joints3M 08684/89/94
Polyurethane Sealer (Sachet) - bolted panel edges; type (b) clinch joints 3M 08703/83/88
Sprayable Sealer - lap joints 3M 08800/23
Super Seam Sealer - lap joints; type (b) clinch joints 3M 08537
Weld Thru' Sealer - between spot welded panels 3M 08626
Betafill Clinch and Brushable Sealer - type (b) clinch joints Gurit-Essex 10211/15/20
Clinch, Joint and Underbody Coating - lap joints Gurit-Essex 10101/10707
Leak Chek Clear - between bolted panels; spot welded and bonded panel
edges; type (c) clinch joints; type (a) gaps between panels Kent Industries 10075
Putty - type (b) gaps between panels Kent Industries
Polyurethane Seam Sealer - bolted, spot welded and bonded panel edges;
between bonded panels; type (a) and (b) gaps between panels PPG 6500
Polyurethane Seam Sealer - bolted, spot welded and bonded panel edges;
between bonded panels; type (b) gaps between panels Teroson 92
Terolan Light Seam Sealer - bolted, spot welded and bonded panel edges;
type (a) and (b) gaps between panels; between bonded panels; type (c)
clinch jointsTeroson

BODY SEALING MATERIALS
MATERIALS AND APPLICATIONS 77-3-3
Terolan Special Brushable Seam Sealer - lap joints Teroson
Terostat Sprayable Seam Sealer - bolted, spot welded and bonded panel
edges; between bonded panels; type (b) gaps between panels Teroson 9320
Terostat 1K PU Seam Sealer (SE 20) - type (a) and (b) gaps between panels;
spot welded and bonded panel edges Teroson
Sealing Compound - bolted, spot welded and bonded panel edges; between
bonded panels; type (b) gaps between panels Wurths 8901001/-/6
Structural adhesives
Automotive Structural Adhesive - between bonded panels; type (a) clinch
joints 3M 08122
Two Part Structural Epoxy - between bonded and spot welded panels; type
(a) clinch joints Ciba-Geigy XB5106/7
Underbody sealers
Body Schutz 3M 08861
Spray Schutz 3M 08877
Crodapol Brushable Underbody Sealer Croda PV75
Terotex Underseal (CP 02) Teroson 9320
Underbody waxes
Bodyguard (Aerosol) 3M 08158/9
Underbody Wax Croda PW61
Underbody Wax Dinol Tectacote 205
Weld-through primers
Weld Thru' Coating 3M 05913
Zinc Spray 3M 09113
Zinc Rich Primer ICI P-565 634 Description - Usage Supplier Part Number

BODY SEALING MATERIALS
77-3-4 MATERIALS AND APPLICATIONS
Application equipment
Manufacturers and suppliers
Suitable application equipment is available from the following manufacturers and suppliers:
3M
Automotive Trades Group
3M UK Plc
3M House
PO Box 1
Market Place
Bracknell
Berks
RG 12 1JU
( (01344) 858611
Cooper Pegler
Burgess Hill
Sussex
RH15 9LA
( (014 446) 42526
SATA Spray Equipment
Minden Industrial Ltd
16 Greyfriars Road
Moreton Hall
Bury St. Edmunds
Suffolk
IP32 7DX
( (01284) 760791
3M Body Schutz Pistol Spraygun 08996
A pistol type spraygun constructed from case and machined light alloy and designed for use with 3M screw fit Body
Schutz containers.
3M Caulking Gun MKIII 8002
A lightweight, robust metal skeleton gun designed to accept 325 mm (13 in) cartridge for dispensing sealants etc. This
gun provides rapid cartridge insertion and loading, with a quick-release lever for accurate control of material ejection
and shut-off.
3M Pneumatic Cartridge Gun 08012
Air line-fed gun for applying 3M cartridge products. Excellent for ease of application to obtain a smooth bead.
Regulator valve for additional control.
3M Pneumatic Applicator Guns
Air line-fed gun for application of 3M sachet sealers (Part Number 08006 for 200 ml and 310 ml sachet applications,
and Part Number 08007 for all size sachets including 600 ml).
Also available: Heavy Duty Manual Gun 08013.
3M Applicator Gun 08190.
For the application of 3M Structural Adhesive 08120.
3M Inner Cavity Wax Applicator Gun 08997
This equipment accepts 1-litre canisters and has a 750 mm (29.572 in) flexible tube.
The approved system is available from all 3M refinishing factors.

BODY SEALING MATERIALS
MATERIALS AND APPLICATIONS 77-3-5
Cooper Pegler Falcon Junior Pneumatic Gun (Airless)
Intended primarily for applying transit wax, this pneumatic sprayer has a 5-litre container with integral hand pump and
provides an effective means of wax spraying without the need for compressed air or additional services.
A selection of nozzles, lances, hose lengths and a trigger valve assembly with integral filter allows flexibility in use.
Additional applications include general maintenance, wax injection and paint application. Heavy-bodied materials
may also be applied. All parts are fully replaceable and a wide range of nozzle configurations is available.
SATA Schutz Gun Model UBE
The SATA Schutz Gun is approved for the retreatment of vehicle underbody areas with protective coatings as
supplied in 1 litre, purpose-designed 'one-way' containers. The screw thread fitting (female on the gun) is standard
to most Schutz-type packs.
SATA HKD1 Wax Injection Injection Equipment
This equipment is approved for carrying out cavity wax re-treatment. The SATA HKD1 set comprises a high quality
forged gun with 1-litre pressure feed container, a flexible nylon lance, a straight 1100 mm (43.307 in) steel lance and
hooked- wand lance. A quick-change coupling is provided as a standard fitting to allow lances to be easily
interchanged. Each lance has an integral, machined nozzle with specialised spray characteristics to suit the type of
box section to be treated.
NOTE: Always clean gun after use with appropriate solvent to maintain efficiency.
Specifications of Model UBE:
Air consumption 7 ft
3/min (200 litres/min) @ 45 lbf.in2
Weight: 23.3oz (220 grams)
