2002 LAND ROVER DISCOVERY Workshop Manual

MANUAL GEARBOX - R380
37-46 OVERHAUL
10.Fit filter to gearbox case.
11.Fit interlock spool to selector shaft.
12.Using new 'O' ring, fit spool retainer and tighten
bolts to 8 Nm (6 lbf.ft).
13.Clean threads of detent plug.
14.Apply Loctite 290 to threads of detent plug, fit
upper detent ball and spring.
15.Fit detent plug and tighten to 25 Nm (18 lbf.ft).
16.Position reverse gear to layshaft.
17.Position reverse gear complete with bearing,
collar and selective spacer to output shaft.
18.Fit 5th / reverse gear synchroniser.

+ MANUAL GEARBOX - R380,
OVERHAUL, Synchronizer assembly - 5th/
reverse.
Housing - gear selector mechanism
$% 37.16.37.01
Disassembly
1.Remove 4 bolts and remove gear selector
housing.
Reassembly
1.Clean mating faces on selector housing and
gearbox.
2.Apply sealant, STC 3254, to selector housing.
3.Clean selector housing bolt threads.
4.Apply Loctite 290 to threads of selector housing
bolts, position selector housing and tighten
bolts to 25 Nm (18 lbf.ft)
5.Adjust gear lever bias springs.

+ MANUAL GEARBOX - R380,
ADJUSTMENTS, Spring - gear lever bias.

MANUAL GEARBOX - R380
OVERHAUL 37-47
Lever - gear change
$% 37.16.04
Disassembly
1.Remove gear selector housing.

+ MANUAL GEARBOX - R380,
OVERHAUL, Housing - gear selector
mechanism.
2.Restrain right hand bias spring using a suitable
pair of grips.
3.Remove 2 bolts securing right hand side of bias
spring adjustment plate.
4.Repeat operations for left hand bias spring.
5.Remove bias springs and adjustment plate.6.Remove lower gear lever.
7.Remove and discard Railko bush.
8.Remove and discard oil seal from housing.
Reassembly
1.Clean components.
2.Apply multi-purpose grease to ball and cross
pins.
3.Apply multi-purpose to new Railko bush and fit
to housing ensuring that slots are correctly
aligned.
4.Lubricate a new seal with gearbox oil and fit, lip
side towards housing using a suitable mandrel.
5.Position lower gear lever to selector housing
ensuring cross pins are located in Railko bush.
6.Position bias spring adjustment plate to
selector housing.
7.Clean threads of bias spring adjustment plate
bolts and apply Loctite 290 to threads.
8.Fit 2 short bolts to secure front of adjustment
plate and tighten to 25 Nm (18 lbf.ft).
9.Position right hand bias spring to pillar ensuring
longest end of spring is against gear lever.
10.Restrain bias spring using a suitable pair of
grips, ensure shortest end of spring is on
outside edge of bolt hole.

MANUAL GEARBOX - R380
37-48 OVERHAUL
11.Fit longest bolt and washer ensuring end of
bias spring is under washer, tighten bolt to 25
Nm (18 lbf.ft).
12.Repeat above procedures for remaining bias
spring.
13.Fit gear selector housing.

+ MANUAL GEARBOX - R380,
OVERHAUL, Housing - gear selector
mechanism.
14.Adjust gear lever bias springs.

+ MANUAL GEARBOX - R380,
ADJUSTMENTS, Spring - gear lever bias.
Housing - clutch
$% 37.12.07
Disassembly
1.Remove clutch release bearing and operating
lever.
2.Remove 6 bolts and remove clutch housing.
Reassembly
1.Clean clutch housing and gearbox mating face.
2.Position clutch housing and tighten bolts to 75
Nm (55 lbf.ft).
3.Fit clutch operating lever and release bearing.

MANUAL GEARBOX - R380
OVERHAUL 37-49
Cover - front
$% 37.12.33.01
Disassembly
1.Remove retaining peg and remove release
bearing.
2.Remove bolt securing clutch release fork,
remove retaining clip and remove clutch
release fork.
3.Remove 2 bolts securing release bearing
sleeve and remove bearing sleeve. 4.Remove 6 bolts securing clutch housing and
remove clutch housing.
5.Remove and discard 6 bolts securing oil seal
housing.
6.Remove oil seal housing.
7.Using a soft metal drift, carefully remove input
shaft front bearing track from housing.
8.Remove oil seal from housing, discard seal.

MANUAL GEARBOX - R380
37-50 OVERHAUL
Reassembly
1.Using a suitable solvent cleaner, clean seal
housing mating faces.
2.Clean seal recess, bearings and bearing
races.
3.Lubricate new oil seal and fit using a suitable
mandrel into housing.
4.Fit input shaft front bearing track using a press
and suitable mandrel.
5.Apply sealant, Part No. STC 4404 to seal
housing, fit new bolts and tighten by diagonal
selection to 25 Nm (18 lbf.ft).
6.Clean clutch housing mating faces, dowels and
dowel holes.
7.Position clutch housing, fit bolts and tighten to
75 Nm (55 lbf.ft).
8.Clean release bearing sleeve mating faces,
dowel and dowel holes.
9.Position release bearing sleeve, fit bolts and
tighten to 25 Nm (18 lbf.ft).
10.Examine clutch release fork pivot points for
wear and replace as required.
11.Apply a smear of Molybdenum disulphide
grease to pivot points and position release fork.
12.Fit retaining clip ensuring it locates over pivot
point washer, fit bolt to release fork and tighten
to 10 Nm (7 lbf.ft).
13.Clean release bearing and bearing sleeve
mating faces.
14.Apply smear of Molybdenum disulphide grease
to release bearing sleeve.
15.Fit release bearing and secure with retaining
peg.

TRANSFER BOX - LT230SE
DESCRIPTION AND OPERATION 41-1
TRANSFE R BOX - LT 230SE DESCRIPTION AND OPERAT ION
LT230SE transfer box

TRANSFER BOX - LT230SE
41-2 DESCRIPTION AND OPERATION
Transfer box cross section
Up to 03 Model Year section shown

TRANSFER BOX - LT230SE
DESCRIPTION AND OPERATION 41-3
1Rear output housing
2Differential rear bearing
3High range gear and bush
4Main casing
5High/low selector sleeve and hub
6Low range gear
7Differential assembly
8Front output housing
9Differential front bearing
10Selective shim - differential bearing pre-load
11Dog clutch - Differential lock - If fitted
12Front output flange
13Differential lock selector shaft - Differential lock
- If fitted
14Selector fork - Differential lock - If fitted
15Front output shaft
16Selective spacer - intermediate gear bearing
pre-load
17Mainshaft input gear
18Selective shim - input gear bearing pre-load
19Intermediate shaft
20Intermediate gear cluster
21Rear output shaft
22Rear output flange
