2002 LAND ROVER DISCOVERY Workshop Manual

COOLING SYSTEM - V8
26-2-16 REPAIRS
8.Remove 6 scrivets and remove LH and RH air
deflectors from front panel. Disconnect
multiplug of gearbox oil temperature sensor
(arrowed).
9.Remove nut and move horn aside. 10.Remove 2 bolts securing radiator LH and RH
upper mounting brackets to body panel and
remove brackets.
11.Remove 4 screws securing air conditioning
condenser LH and RH upper mounting
brackets to condenser.
12.Remove brackets with rubber mounts from
radiator extension brackets.
13.Position absorbent cloth under each cooler
hose to collect oil spillage.
14.Push against coupling release rings and
disconnect hoses from gearbox oil cooler.
CAUTION: Always fit plugs to open
connections to prevent contamination.
15. If fitted: Push against coupling release rings
and disconnect hoses from engine oil cooler.

COOLING SYSTEM - V8
REPAIRS 26-2-17
16.Remove radiator assembly.
17.Release clip and remove bottom hose from
radiator.
18.Remove 2 bolts and remove extension
brackets from radiator.
19.Remove 2 captive nuts from radiator.
20.Remove 2 screws and remove gearbox oil
cooler from radiator.
21. If fitted: Remove 2 screws and remove engine
oil cooler from radiator.
22.Remove 2 rubber mountings from radiator.
23.Remove sealing strip from bottom of radiator.
24.Remove 2 cowl retaining clips from radiator. Refit
1.Fit cowl retaining clips to radiator.
2.Fit sealing strip to radiator.
3.Fit rubber mountings to radiator.
4.Fit gearbox oil cooler to radiator and secure
with screws.
5. If fitted: Fit engine oil cooler to radiator and
secure with screws.
6.Fit captive nuts to radiator.
7.Fit extension brackets to radiator and secure
with bolts.
8.Fit bottom hose to radiator and secure with clip.
9.Fit radiator and engage lower mountings in
chassis.
10.Ensure connections are clean, then secure
hoses to oil coolers.
11.Fit air conditioning condenser brackets and
secure with screws.
12.Fit radiator upper mounting brackets and
secure with bolts.
13.Fit LH horn and secure with nut.
14.Fit air deflectors and secure with scrivets.
15.Connect multiplug of gearbox oil temperature
sensor.
16.Fit front grille.

+ EXTERIOR FITTINGS, REPAIRS,
Grille - front - up to 03MY.
17.Connect bottom hose to thermostat housing
and secure with clip.
18.Connect top hose to radiator and secure with
clip.
19.Connect bleed hose to radiator and fit clip.
20.Fit lower fan cowl and secure with screws.
21.Fit viscous fan.

+ COOLING SYSTEM - V8, REPAIRS,
Fan - viscous.
22.Top up gearbox oil.
23.Top up engine oil.
24.Refill cooling system.

+ COOLING SYSTEM - V8,
ADJUSTMENTS, Drain and refill.

COOLING SYSTEM - V8
26-2-18 REPAIRS
Thermostat
$% 26.45.09
Remove
1.Drain cooling system.

+ COOLING SYSTEM - V8,
ADJUSTMENTS, Drain and refill.
2.Remove viscous fan.

+ COOLING SYSTEM - V8, REPAIRS,
Fan - viscous.
3.Release 3 clips and disconnect coolant hoses
from thermostat.
4.Remove thermostat.
Refit
1.Position thermostat, connect hoses and secure
with clips.
2.Fit viscous fan.

+ COOLING SYSTEM - V8, REPAIRS,
Fan - viscous.
3.Refill cooling system.

+ COOLING SYSTEM - V8,
ADJUSTMENTS, Drain and refill.
Gasket - coolant pump
$% 26.50.02
Remove
1.Remove auxiliary drive belt.

+ CHARGING AND STARTING,
REPAIRS, Belt - auxiliary drive.
2.Drain cooling system.

+ COOLING SYSTEM - V8,
ADJUSTMENTS, Drain and refill.
3.Remove 3 bolts securing pulley to coolant
pump and remove pulley.
4.Release clip and disconnect feed hose from
coolant pump.

COOLING SYSTEM - V8
REPAIRS 26-2-19
5.Remove 9 bolts securing coolant pump,
remove pump and discard gasket. Refit
1.Clean coolant pump and mating face.
2.Fit new gasket and coolant pump to cylinder
block. Fit bolts and tighten to 24 Nm (18 lbf.ft).
3.Connect feed hose to coolant pump and secure
with clip.
4.Ensure mating faces of coolant pump pulley
and flange are clean. Fit pulley and tighten
bolts to 22 Nm (16 lbf.ft).
5.Fit auxiliary drive belt.

+ CHARGING AND STARTING,
REPAIRS, Belt - auxiliary drive.
6.Refill cooling system.

+ COOLING SYSTEM - V8,
ADJUSTMENTS, Drain and refill.

COOLING SYSTEM - V8
26-2-20 REPAIRS

MANIFOLDS AND EXHAUST SYSTEMS - TD5
DESCRIPTION AND OPERATION 30-1-1
MANIF OLDS AND EX HAUST SYSTEMS - Td5 DESCRIPTION AND OPERAT ION
Manifold component layout
1Inlet manifold
2Flanged nut 2 off
3Stud 2 off
4Stud 10 off
5Exhaust gasket
6Flanged nut 10 off
7Exhaust manifold
8Inlet gasket
9Flanged bolt 8 off

MANIFOLDS AND EXHAUST SYSTEMS - TD5
30-1-2 DESCRIPTION AND OPERATION
Exhaust system component layout
1Tail pipe/silencer assembly
2Mounting rubber 4 off
3Turbo/Exhaust manifold gasket
4Flanged nut 3 off
5Front pipe assembly
6Flanged nut 2 off
7Intermediate pipe/silencer assembly
8Flanged nut 3 off
9Gasket

MANIFOLDS AND EXHAUST SYSTEMS - TD5
DESCRIPTION AND OPERATION 30-1-3
Description
General
The diesel engine has the inlet manifold attached to the right hand side of the engine and the exhaust manifold
attached to the left hand side of the engine. The inlet manifold directs cooled compressed air from the turbocharger
and intercooler into the cylinders, where it is mixed with fuel from the injectors. Exhaust gases from the exhaust
manifold can also be directed into the inlet manifold via a pipe from the exhaust manifold and an Exhaust Gas
Recirculation (EGR) valve on the inlet manifold. The exhaust manifold allows combustion gases from the cylinders to
leave the engine where they are directed into the exhaust system and turbocharger.
The exhaust system is attached to the turbocharger and is directed along the underside of the vehicle to emit exhaust
gases from a tail pipe at the rear of the vehicle. A silencer is installed midway along the system and a second tail
silencer is located at the rear of the vehicle.
Inlet manifold
The inlet manifold is a one piece aluminium casting. The manifold is secured to the cylinder head with two studs and
flanged nuts and eight flanged bolts. A one piece laminated gasket seals the manifold to the cylinder head.
Four threaded bosses on the manifold provide for the attachment of the fuel cooler. The fuel cooler is secured to the
manifold with four bolts. A boss with two threaded holes allows for the attachment of the combined intake air
temperature/pressure sensor. The sensor is secured to the manifold with two screws and sealed with a gasket.
At the forward end of the manifold, a machined face and four threaded holes provide for the attachment of the EGR
valve. The valve is sealed to the manifold with a gasket.

+ EMISSION CONTROL - Td5, DESCRIPTION AND OPERATION, Emission Control Systems.
Exhaust manifold
The exhaust manifold is made from cast iron. The manifold has five ports, one from each cylinder, which merge into
one flanged outlet connection positioned centrally on the manifold.
The manifold is attached to the cylinder head with ten studs and flanged nuts. A laminated metal gasket seals the
manifold to the cylinder head. The flanged outlet on the manifold provides the attachment for the turbocharger, which
is attached with three studs and flanged nuts and sealed with a metal laminated gasket.
A second flanged outlet, located at the forward end of the manifold, provides attachment for the EGR pipe. The EGR
pipe is secured to the manifold with two cap screws and connected to the EGR valve mounted on the inlet manifold.
There is no gasket used between the pipe and the exhaust manifold.

+ EMISSION CONTROL - Td5, DESCRIPTION AND OPERATION, Emission Control Systems.
Exhaust system
The exhaust system comprises a front pipe, an intermediate pipe which incorporates a silencer and a tail pipe
assembly which also has a silencer. The exhaust system is constructed mainly of 63 mm (2.48 in) diameter extruded
pipe with a 1.5 mm (0.06 in) wall thickness. All pipes are aluminized to resist corrosion and the silencers are fabricated
from stainless steel sheet.
