1996 FORD EXPLORER Owners Manual

Safety Restraints
63
[SR16570( X)02/96]
17-1/2 pica
art:0011244-A
Checking that the seat is secure
[SR16580( X)02/96]10.
Try to pull belt out of the retractor to make sure the
retractor is in the automatic locking mode (you should not
be able to pull more belt out). If the retractor is not locked,
unbuckle the belt and repeat steps 2 through 9.
[SR16590( X)02/96]
To remove the retractor from automatic locking mode, allow
webbing to retract fully to its stowed position and the
retractor will automatically switch back to the vehicle
sensitive locking mode for normal adult usage.
File:03unsrx.ex
Update:Thu Feb 29 09:02:31 1996

64
%*
[SR18400(ALL)06/95]
Attaching Safety Seats With Tether Straps
*
[SR18410(ALL)06/95]
General Instructions
*
[SR18413(ALL)06/95]
Some manufacturers make safety seats that include a tether
strap that goes over the back of the vehicle seat and attaches to
an anchoring point. Other manufacturers offer the tether strap
as an accessory. Contact the manufacturer of your child safety
seat for information about ordering a tether strap.
*
[SR18417( X)06/95]
You can attach a tether strap anchor bracket to the rear floor by
using a tether anchor kit (613D74), available at no charge from
any Ford dealership.
[SR18420(ALL)09/95]
Read and follow the instructions provided with the kit carefully,
for installation of the child tether strap anchor.
[SR18501(ALL)09/95]
Follow the child seat manufacturer's instructions to attach the
tether strap to the tether bracket.
*
[SR18700( X)06/95]
Ford recommends placement of tethered safety seats in a rear
seating position with the tether strap installed to the tether
anchoring point as shown in the instructions provided with the
child tether strap anchor kit.
*
[SR18950(ALL)06/95]
RWARNING
Only use the tether attachment hole locations shown in
the illustrations. The tether anchor may not perform
properly if the wrong mounting location is used.
*
[SR19400( X)06/95]
The rear lap/shoulder safety belts should not be used to secure
the tether strap of a safety seat located in the front seat.
File:03unsrx.ex
Update:Thu Feb 29 09:02:31 1996

Safety Restraints
65
%*
[SR19700(ALL)07/95]
Safety Belts for Children
*
[SR19800(ALL)07/95]
Children who are too large for child safety seats should always
wear safety belts. (See instructions with your child seat, or
contact its manufacturer, to determine maximum size of child
that will safely fit in the seat.)
*
[SR19900(ALL)07/95]
RWARNING
If safety belts are not properly worn and adjusted as
described, the risk of serious injury to the child in a
collision will be much greater.
*
[SR20000(ALL)12/95]
If the shoulder belt portion of one of the lap and shoulder belts
can be positioned so that it does not cross or rest in front of the
child's face or neck, the child should wear the lap and shoulder
belt. Moving the child closer to the center of the vehicle may
help provide a good shoulder belt fit.
*
[SR20050(ALL)07/95]
To improve the fit of lap and shoulder belts on children who
have outgrown child safety seats, Ford recommends use of a
belt-positioning booster seat that is labelled as conforming to all
Federal motor vehicle safety standards. Belt-positioning booster
seats raise the child and provide a shorter, firmer seating
cushion that encourages safer seating posture and better fit of
lap and shoulder belts on the child. A belt-positioning booster
should be used if the shoulder belt rests in front of the child's
face or neck, or if the lap belt does not fit snugly on both
File:03unsrx.ex
Update:Thu Feb 29 09:02:31 1996

66thighs, or if the thighs are too short to let the child sit all the
way back on the seat cushion when the lower legs hang over
the edge of the seat cushion. You may wish to discuss the
specific needs of your child with your pediatrician.
*
[SR20200(ALL)07/95]
Lap belts and the lap belt portion of lap and shoulder belts
should always be worn snugly and below the hips, touching the
child's thighs.
*
[SR20300(ALL)08/95]
RWARNING
To reduce the risk of serious injury in a collision,
children should always ride with the seatback upright.
File:03unsrx.ex
Update:Thu Feb 29 09:02:31 1996

67
Starting Your Explorer
*
[ST01700(ALL)03/95]
Ignition
%*
[ST01800(ALL)01/95]
Understanding the Positions of the Ignition
[ST02000(ALL)04/94]
7-1/2 pica art:0021143-A
The positions of the key in the ignition lock cylinder.
%*
[ST02201(ALL)07/95]
ACCESSORY allows some of your vehicle's electrical accessories
such as the radio and the windshield wipers to operate while
the engine is not running.
*
[ST02301(ALL)01/95]
In order to turn the key from the ON or OFF position to the
ACCESSORY position, you must push the key release button if
your vehicle's manual transmission gearshift is mounted on the
floor.
*
[ST02401(ALL)08/95]
LOCK locks the steering wheel and gearshift lever.
*
[ST02501(ALL)05/95]
RWARNING
Turn the key to LOCK whenever you leave your vehicle.
Always set the parking brake fully and make sure that
the gearshift is securely latched in P (Park) (automatic
transmission) or in 1 (First) (manual transmission). Never
leave your vehicle unattended while it is running.
*
[ST02651(ALL)01/95]
LOCK is the only position that allows you to remove the key.
The LOCK feature helps to protect your vehicle from theft.
*
[ST02701(ALL)05/95]
If your key is stuck in the LOCK position and will not turn,
move your steering wheel left or right until the key turns freely.
File:04unstx.ex
Update:Thu Feb 29 09:22:05 1996

68
*
[ST02801(ALL)03/95]
OFF allows you to shut off the engine and all accessories
without locking the steering wheel or the automatic
transmission gearshift lever.
*
[ST02901(ALL)05/95]
ON allows you to test your vehicle's warning lights (except the
brake system warning light) to make sure they work before you
start the engine. The key returns to the ON position once the
engine is started and remains in this position while the engine
runs.
*
[ST02951(ALL)03/95]
START cranks the engine. Release the key once the engine starts
so that you do not damage the starter. The key should return to
ON when you release it. The START position also allows you to
test the brake warning light.
%*
[ST03025(ALL)08/95]
Ignition Key Buzzer or Chime
*
[ST03050(ALL)08/95]
The buzzer or chime will sound if you open the driver's door
while the key is in the ignition. Never leave your vehicle
unattended with the key in the ignition.
%*
[ST03076(ALL)02/95]
Removing the Key From the Ignition
*
[ST03100(ALL)08/95]
Procedures for removing your key from the ignition will vary,
depending on the type of gearshift your vehicle has. Gearshift
levers may be mounted on the steering column or on the floor
or console.
[ST03117(ALL)05/91]
If you have a manual transmission, you have a key release lever
which allows you to remove your key from the ignition. The
key release lever is on the upper right of the steering column,
just above the key lock cylinder.
*
[ST03300(ALL)08/95]
If your vehicle's gearshift lever is mounted on the
column:
*
[ST03400(ALL)06/95]1.
Put the gearshift in P (Park).
*
[ST03500(ALL)03/91]2.
Set the parking brake fully before removing your foot from
the service brake. (This will avoid ªbindingº or ªloadingº the
park gear if you park on a grade.)
File:04unstx.ex
Update:Thu Feb 29 09:22:05 1996

Starting Your Explorer
69
*
[ST03600(ALL)03/95]3.
Turn the ignition key to LOCK.
*
[ST03700(ALL)03/95]4.
Remove the key.
*
[ST03800(ALL)05/95]
If your vehicle's gearshift lever is mounted on the
floor:
*
[ST03950(ALL)05/95]1.
Put the gearshift in 1 (First).
*
[ST04000(ALL)05/95]2.
Turn the ignition key to OFF.
*
[ST04100(ALL)05/95]3.
Set the parking brake fully before removing your foot from
the service brake.
*
[ST04200(ALL)05/95]4.
Push and hold in the key release button.
*
[ST04300(ALL)05/95]5.
Turn the key to LOCK.
*
[ST04400(ALL)05/95]6.
Remove the key.
*
[ST04600(ALL)05/95]
RWARNING
Always set the parking brake fully and make sure that
the gearshift is latched in P (Park) (automatic
transmission) or 1 (First) (manual transmission).
*
[ST04750(ALL)01/93]
RWARNING
Do not leave children, unreliable adults, or pets alone in
your vehicle. They could accidentally injure themselves
or others through inadvertent operation of the vehicle.
Further, on hot, sunny days, temperatures in a closed
vehicle could quickly become high enough to cause
severe and possibly fatal injuries to people as well as
animals.
File:04unstx.ex
Update:Thu Feb 29 09:22:05 1996

70
%*
[ST04800(ALL)03/95]
Fuel-Injected Engines
*
[ST04900(ALL)03/95]
When starting a fuel-injected engine,the most important thing
to remember is to avoid pressing down on the accelerator
before or during starting. Only use the accelerator when you
have problems getting your vehicle started. SeeStarting Your
Enginein this chapter for details about when to use the
accelerator while you start your vehicle.
*
[ST04950(ALL)03/95]
Starting Your Vehicle
%*
[ST05200(ALL)05/94]
Preparing to Start Your Vehicle
*
[ST05300(ALL)09/95]
RWARNING
Do not start your vehicle in a closed garage or other
enclosed area. Never sit in a stopped vehicle for more
than a short period of time with the engine running.
Exhaust fumes are toxic. SeeGuarding Against Exhaust
Fumesin this chapter for more instructions.
*
[ST05400(ALL)01/95]
Before you start your vehicle, do the following:
*
[ST05500(ALL)08/95]1.
Make sure all occupants in the vehicle buckle their safety
belts. SeeSafety Restraintsin the Index for more details.
*
[ST05600(ALL)03/95]2.
Make sure the headlamps and other accessories are turned
off when starting.
*
[ST05700(ALL)10/94]3.
If you have an automatic transmission,make sure that the
gearshift lever is in P (Park) and the parking brake is set
before you turn the key.
*
[ST05800(ALL)03/91]4.
If you have a manual transmission,make sure that the
parking brake is fully set, push the clutch pedal to the floor,
and put the gearshift into Neutral before you turn the key.
(Remember, the starter will operate only if the clutch pedal
is pushed in all the way).
File:04unstx.ex
Update:Thu Feb 29 09:22:05 1996
