1996 FORD EXPLORER Owners Manual

Accessories
329
*
[AC01900(ALL)01/95]
NOTE: When adding accessories, equipment, passengers, and
luggage to your vehicle, do not exceed the total
weight capacity of the vehicle or of the front or rear
axle (GVWR, GAWR as shown on the Safety
Compliance Certification Label). Consult your dealer
for specific weight information.
*
[AC02000(ALL)05/95]
NOTE: The Federal Communications Commission (FCC) or
the Canadian Radio Telecommunications Commission
(CRTC) regulates the use of mobile communications
systems Ð such as two-way radios, telephones, and
theft alarms Ð that are equipped with radio
transmitters. Any such equipment installed in your
vehicle should comply with FCC or CRTC regulations
and should be installed only by a qualified technician.
*
[AC02100(ALL)01/95]
NOTE: Mobile communications systems may harm the
operation of your vehicle, particularly if they are not
properly designed for automotive use or are not
properly installed. For example, when operated, such
systems may cause the engine to stumble or stall. In
addition, such systems may themselves be damaged or
their operation affected by operating your vehicle.
(Citizens band [CB] transceivers, garage door openers,
and other transmitters whose power output is 5 watts
or less will not ordinarily affect your vehicle's
operation.)
*
[AC02200(ALL)05/95]
NOTE: Because we have no control over the installation,
design, or manufacture of such systems, Ford cannot
assume responsibility for any adverse effects or
damage that may result if you use this equipment.
File:14unacx.ex
Update:Thu Feb 29 09:16:06 1996

330
[AC02500( X)05/95]
thirty-two pica
chart:0090199-AFile:14unacx.ex
Update:Thu Feb 29 09:16:06 1996

Accessories
331
[AC02600( X)05/95]
thirty-two pica
chart:0090200-AFile:14unacx.ex
Update:Thu Feb 29 09:16:06 1996

332
[AC02700( X)05/95]
thirty-two pica
chart:0090201-AFile:14unacx.ex
Update:Thu Feb 29 09:16:06 1996

333
Servicing Your Explorer
%*
[SV00300(ALL)03/95]
Service Made Easy
*
[SV00400(ALL)01/95]
Ford has two goals for servicing your vehicle.
*
[SV00500(ALL)01/95]1.
When we can, we design parts that do not need to be
serviced.
*
[SV00600(ALL)01/95]2.
We want to make servicing your vehicle as easy as possible.
To help you:
*
[SV00700(ALL)01/95]
n
We highlight do-it-yourself items in yellow in the engine
compartment so that you can find them easily.
*
[SV00800(ALL)01/95]
n
When possible, we design parts Ð such as the headlamp
bulbs Ð that can be replaced without tools.
*
[SV00900(ALL)05/94]
n
We give you a Maintenance Schedule that makes tracking
routine service for your vehicle easy. The maintenance
schedule is located in theMaintenance Schedule and Record
booklet.
*
[SV01000(ALL)01/95]
This chapter tells you about the basic parts that you need to
check and service regularly.
*
[SV01050(ALL)02/95]
If your vehicle needs professional servicing, your dealership can
provide the parts and service required. Check yourWarranty
Information Bookletto find out which parts and services are
covered. Also see theCustomer Assistancechapter of this Owner
Guide.
*
[SV01300(ALL)03/95]
Ford Motor Company recommends that the Owner Maintenance
Checks listed in theMaintenance Schedule and Recordbooklet be
performed for the proper operation of your vehicle. In addition
to the conditions listed in theOwner Maintenance Checklist,be
alert for any unusual noise, vibration, or other indication that
your vehicle may need service. If you do notice something
unusual, see that your vehicle is serviced promptly.
File:15unsvx.ex
Update:Thu Feb 29 09:20:34 1996

334
%*
[SV01400(ALL)09/95]
NOTE: Always dispose of used automotive fluids in a
responsible manner. Follow your community's
standards for disposing of these types of fluids. Call
your local recycling center to find out about recycling
automotive fluids.
%*
[SV01600(ALL)06/95]
Precautions When Servicing Your Vehicle
*
[SV01700(ALL)06/95]
Be especially careful when inspecting or servicing your vehicle.
Here are some general precautions for your safety:
*
[SV01900(ALL)06/95]
n
If you must work with the engine running, avoid wearing
loose clothing or jewelry that could get caught in moving
parts. Take appropriate precautions with long hair.
*
[SV02000(ALL)06/95]
n
Do not work on a vehicle in an enclosed space with the
engine running, unless you are sure you have enough
ventilation.
*
[SV02100(ALL)08/95]
n
Never get under a vehicle while it is supported only by a
jack. If you must work under a vehicle, use safety stands.
*
[SV02200(ALL)06/95]
n
Keep all lit cigarettes and other smoking materials away
from the battery and all fuel-related parts.
*
[SV02500(ALL)03/95]
If you disconnect the battery, the engine must ªrelearnº its idle
conditions before your vehicle will drive properly. To find out
how the engine does this, seeBatteryin this chapter.
*
[SV02600(ALL)03/95]
Working with the engine off:
*
[SV02660(ALL)03/95]1.
Set the parking brake fully and make sure that the gearshift
is securely latched in P (Park).
*
[SV02700(ALL)06/95]2.
Remove the key from the ignition after you turn the engine
off.
*
[SV02725(ALL)06/95]3.
Block the wheels. This will prevent your vehicle from
moving unexpectedly.
File:15unsvx.ex
Update:Thu Feb 29 09:20:34 1996

Servicing Your Explorer
335
*
[SV02750(ALL)03/95]
Working with the engine on:
[SV02775(ALL)03/95]1.
Set the parking brake fully, and make sure the gearshift is
securely latched in P (Park) (automatic transmission) or
Neutral (manual transmission) and block the wheels.
*
[SV02825(ALL)03/95]2.
Block the wheels. This will prevent your vehicle from
moving unexpectedly.
*
[SV02900(ALL)02/95]
RWARNING
Do not start your engine with the air cleaner removed
and do not remove it while the engine is running.
%*
[SV02950(ALL)03/95]
Opening the Hood
[SV03035(ALL)12/91]1.
Pull the hood release handle, located below the steering
column.
[SV03040(ALL)01/95]
7-1/2 pica art:0020332-B
Hood release handle
*
[SV03050( X)12/91]2.
While applying downward pressure on the hood, push the
hood latch handle located behind the grille near the center
front of the vehicle to the left.
File:15unsvx.ex
Update:Thu Feb 29 09:20:34 1996

336
[SV03750( X)02/95]
17-1/2 pica
art:0020555-G
Hood
*
[SV03775(ALL)09/95]
NOTE: Read and understandPrecautions When Servicing Your
Vehicleat the beginning of this chapter before
opening the hood.
[SV03850( X)08/94]
Close the hood with enough force to make it latch. Be sure to
oil the hood latch every six months to maintain smooth
operation.
*
[SV03900(ALL)05/90]
Always attempt to lift the hood after closing to be sure it is
securely latched.
%*
[SV04500(ALL)04/95]
Engine Compartment
[SV04875( X)03/95]
Your Explorer has either a 4.0 Liter EFI, V-6 engine or a 5.0
Liter EFI, V-8 engine.
[SV05505( X)10/92]
The following page shows a diagram of the engine and where
to find items that you should regularly service.
File:15unsvx.ex
Update:Thu Feb 29 09:20:34 1996
