Mechanical cluster with tachometer
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

Warning Lights and Gauges
81
%*
[LG03000(ALL)06/94]
The Mechanical Cluster
*
[LG03100(ALL)06/93]
The following warning lights and gauges are on the mechanical
cluster. All of the warning lights and gauges alert you to
possible problems with your vehicle. Some of the lights listed
are optional. The following sections detail what each of these
indicators means.
%*
[LG03200(ALL)06/95]
Brake System Warning Light
*
[LG03300(ALL)03/95]
The warning light for the brakes can show two things Ð that
the parking brake is not fully released, or that the brake fluid
level is low in the master cylinder reservoir. If the fluid level is
low, the brake system should be checked by your dealer or a
qualified service technician.
*
[LG03400(ALL)05/94]
This light comes on when you turn the ignition key to START
to verify that the indicator bulb is working. If the light stays on
or comes on after you have released the parking brake fully,
have the hydraulic brake system serviced.
*
[LG03500(ALL)05/95]
RWARNING
The BRAKE light indicates that the brakes may not be
working properly. Have the brakes checked immediately.
[LG03600(ALL)04/94]
6 pica art:0021145-A
Brake warning light symbols
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

82
*
[LG03800(ALL)02/95]
Anti-lock Brake Warning Light
[LG03925(ALL)03/95]
To check the ABS brake warning light, turn the ignition key to
ON. The ABS brake warning light should glow momentarily.
[LG04050(ALL)06/94]
6 pica art:0021146-A
Anti-lock warning light symbol
*
[LG04100(ALL)05/95]
RWARNING
If the anti-lock brake system warning light remains on or
comes on while driving, have the braking system checked
by a qualified service technician as soon as possible.
*
[LG04110(ALL)09/95]
NOTE: If a fault occurs in the anti-lock system, and the brake
warning light is not lit, the anti-lock system is
disabled but normal brake function remains
operational.
%*
[LG04150(ALL)07/95]
Safety Belt Warning Light and Chime
*
[LG04301(ALL)08/95]
The safety belt warning light/chime reminds you to fasten your
safety belt. One of the following will take place:
[LG04325(ALL)03/95]
n
If the safety belt is not buckled when the key is turned to
the ON position, the light comes on for 60 seconds and the
chime sounds for 4 to 8 seconds.
*
[LG04351(ALL)02/95]
n
If the safety belt is buckled while the light is on and the
chime is sounding, both the light and chime turn off.
[LG04355(ALL)03/95]
n
If safety belt is buckled before the key is turned to the ON
position, both the light and the chime will not turn on.
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

Warning Lights and Gauges
83
[LG04400(ALL)08/94]
6 pica art:0021148-B
Safety belt warning light symbol
%*
[LG04420(ALL)01/95]
Air Bag Readiness Light
[LG04430(ALL)06/95]
This light illuminates for approximately six seconds when the
ignition key is turned to the ON position to verify that the
indicator bulb is working and the air bag system is operating
normally.
[LG04435(ALL)04/95]
RWARNING
A problem with the air bag system is indicated by one or
more of the following: the readiness light will either
flash or stay lit, or it will not light, or a group of five
beeps will be heard.
*
[LG04437(ALL)05/95]
RWARNING
If any of these things happen, even intermittently, have
the air bag system serviced at your Ford or
Lincoln-Mercury dealer immediately.
[LG04440(ALL)10/94]
7-1/2 pica art:0021268-A
Air bag readiness light symbol
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

84
[LG04450(ALL)10/94]
Door Ajar Warning Light (If equipped)
*
[LG04460(ALL)08/94]
If the ignition switch is in the ON position and any door or the
liftgate is not completely closed, the light will illuminate.
[LG04480(ALL)10/94]
7-1/2 pica art:0021269-A
Door ajar warning light symbol
%*
[LG04500(ALL)03/95]
Check Engine Warning Light
*
[LG04600(ALL)05/95]
The Powertrain On-Board Diagnostic II (OBD II) system consists
of the hardware and software necessary to monitor the
operation of the powertrain. The OBD II system is designed to
check the function of the vehicle's powertrain control system
during normal operation. If an emission problem is detected, the
Check Engine Warning Light (in the cluster) is turned on.
*
[LG04650(ALL)05/95]
Modification or additions to the vehicle may cause incorrect
operation of the OBD II system. Additions such as burglar
alarms, cellular phones, and CB radios must be carefully
installed. Do not install these devices by tapping into or running
wires close to powertrain control system wires or components.
[LG04675(ALL)02/95]
The light comes on briefly when you turn the ignition key to
the ON position, but it should turn off when the engine cranks.
If the light does not come on when you turn the ignition to the
ON position or if it comes on and stays on when you are
driving, have your vehicle serviced as soon as conveniently
possible. This indicates a possible problem with one of the
engine's emission control systems.You do not need to have
your vehicle towed in.
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

Warning Lights and Gauges
85
*
[LG04680(ALL)05/95]
If the light turns on and off at one (1) second intervals while
you are driving the vehicle, it means that the engine is
misfiring. If this condition persists, damage could occur to the
engine or catalytic convertor. Have your vehicle serviced at the
first opportunity. You do not need to have your vehicle towed
in.
*
[LG04685(ALL)05/95]
If the light turns on and off on rare occasions while you are
driving, it means that a malfunction occurred and the condition
corrected itself.
*
[LG04695(ALL)05/95]
On the fourth engine start up, the Check Engine Warning Light
will turn off as soon as the engine begins to crank. It is not
necessary to have the engine serviced.
[LG04720(ALL)03/95]
Under certain conditions, the Check Engine Warning Light may
come on if the fuel cap is not properly installed. If the light
comes on and you suspect the fuel cap is not properly installed,
pull off the road as soon as it is safely possible and turn off the
engine. Remove and replace the fuel cap, making sure it is
properly seated.
[LG04750(ALL)03/95]
After completing the three consecutive warm-up cycles and on
the fourth engine start-up, the Check Engine Warning Light
should turn off. If the light does not go off after the fourth
engine restart, have your vehicle serviced by your dealer or a
qualified technician.
[LG05300(ALL)04/94]
6 pica art:0021149-A
Check engine warning light symbol
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

86
%*
[LG05835(ALL)10/94]
Overdrive Off Indicator (If equipped)
[LG05850(ALL)05/95]
This light tells you that the Transmission Control Switch (TCS)
on the gearshift lever has been pushed. When the light is on,
the transmission does not shift into overdrive. Depressing the
button on the shifter once more returns the vehicle to overdrive
mode. The transmission will be in the overdrive mode when the
vehicle is started even if the O/D OFF mode was selected when
the vehicle was last shut off.
*
[LG05855(ALL)05/95]
NOTE: If the light does not come on when the TCS is
depressed or if the light flashes when you are driving,
have your vehicle serviced at the first opportunity. If
this condition persists, damage could occur to the
transmission.
[LG05865(ALL)10/94]
6 pica art:0021226-B
Overdrive off light (if equipped)
[LG05870( X)03/95]
Speed Control Light (If equipped)
*
[LG05875( X)07/95]
This light comes on when you turn on the speed control system
and set the speed. The light will be on whenever the speed
control is set, even if you override the set speed by pressing the
accelerator pedal or by pressing the coast button. The light will
go off when the brakes are used or the speed control system is
turned off.
[LG05885( X)07/95]
This light does not indicate any problems with the speed control
system, but is only a convenience to tell you when the speed
control system is active and ready to maintain a set speed.
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

Warning Lights and Gauges
87
[LG05890( X)03/95]
7-1/2 pica art:0090108-A
Speed control light
%*
[LG05900(ALL)01/95]
Charging System Light
*
[LG06000(ALL)03/95]
This light, shown as a battery symbol on your cluster, indicates
that your battery is not being charged and that you need to
have the electrical system checked.
[LG06050(ALL)10/94]
6 pica art:0021150-B
Charging system light symbol
*
[LG06100(ALL)07/95]
This light comes on every time you turn the ignition to the ON
or START position (engine off). The light should go off when
the engine starts and the alternator begins to charge.
*
[LG06300(ALL)01/95]
If the light stays on or comes on when the engine is running,
have the electrical system checked as soon as possible.
