1996 FORD EXPLORER Owners Manual

104
*
[LG38450( X)01/95]
Low Fuel Level
*
[LG38500( X)01/95]
This warning message is displayed when you have
approximately 50 miles (80 km) left before you run out of fuel.
*
[LG38550( X)01/95]
Low Oil Level
*
[LG38600( X)01/95]
This warning message is displayed when your engine oil level is
low. If this warning message is displayed, check the level of the
engine oil.
*
[LG38650( X)02/95]
To check your oil:
*
[LG38700( X)05/95]1.
Park your vehicle on level ground, turn off the engine and
wait at least 5 minutes for the oil to drain back into the oil
pan.
*
[LG38750( X)01/95]2.
Use the dipstick to check the oil. If the level is low, add oil,
but do not overfill.
*
[LG38800( X)01/95]
If you are parked on a steep incline, the LOW OIL LEVEL
warning may come on when you start your vehicle, even
though the oil is at the correct level.
*
[LG38850( X)01/95]
For information about adding oil, seeEngine oilin the Index.
%*
[LG38900( X)05/95]
Low Washer Fluid Light
*
[LG38950( X)04/95]
This warning message is displayed when the washer fluid
reservoir is less than one quarter full.
[LG39000( X)01/95]
Check Head Lamps
[LG39050( X)08/94]
This warning message is displayed when you turn on your
headlamps and at least one of them is burned out. A high beam
headlamp burn out is not monitored.
[LG39100( X)04/94]
Check Tail Lamps
[LG39150( X)04/94]
This warning message is displayed when you turn on your rear
parking (tail) lamps and at least one of them is burned out.
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

Warning Lights and Gauges
105
[LG39200( X)04/94]
Check Brake Lamps
[LG39250( X)03/95]
This warning message is displayed when you turn on your
brakelamps by pressing the brake pedal and at least one of the
lamps is burned out.
[LG39300( X)04/94]
If you use additional lights, such as trailer lights, or if you
replace the headlamps or bulbs with equipment that is not equal
to the original equipment from Ford, you may get a false
ªCHECK LAMPSº warning or no warning at all.
[LG39350( X)06/94]
Air Ride Switch Off (If equipped)
[LG39400( X)03/95]
This warning message is displayed when the air suspension
switch, located in the rear jack stowage area on the left side, is
off. For information about the operation of the air suspension
switch, seeAutomatic ride control systemin the Index.
[LG39450( X)06/94]
Check Air Ride System (If equipped)
[LG39500( X)03/95]
This warning message is displayed when an air suspension
system fault has been detected. If this warning message is
displayed while driving, safely pull off the road at your earliest
convenience. If the vehicle is loaded beyond the recommended
maximum payload, the CHECK AIR RIDE SYSTEM message
may be displayed. This is a normal condition if the vehicle is
overloaded. To correct this condition, remove or redistribute the
payload per the recommended maximum requirements. Turn the
ignition switch from ON to OFF and ON again. If the warning
message reappears, turn the air suspension switch (located in
the rear jack stowage area on the left side) OFF and take your
vehicle to a dealership for service as soon as possible.
*
[LG39550( X)01/95]
Change Oil Soon or Oil Change Required
*
[LG39600( X)01/95]
One of these warning messages is displayed when the engine oil
life remaining is 5% or less. When Oil Life Left is between 5%
and 0%, the ªCHANGE OIL SOONº message will be displayed.
When Oil Life Left reaches 0%, the ªOIL CHANGE REQUIREDº
message will be displayed.
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

106
*
[LG39650( X)01/95]
An oil change is required whenever indicated by the M/C. USE
ONLY RECOMMENDED ENGINE OILS (SeeEngine oilin the
Index).
*
[LG39700( X)01/95]
The M/C will tell you the percent of oil life left during System
Check. This percentage is based on your driving history and the
time since your last oil change. In order to ensure accurate oil
life left indications, you should only perform the following OIL
CHANGE RESET Procedure after you have the oil changed.
*
[LG39801( X)01/95]
Oil Change Reset
[LG39901( X)08/94]
A press of the OIL CHANGE RESET switch will allow you to
reset the oil life feature to 100% (or your Personalized Oil Reset
Percentage). After you have the oil changed, you must execute
the following procedure. Press the OIL CHANGE RESET switch
and hold for five seconds as the M/C counts down for five
seconds. After a successful reset the Message Center will display
ªOIL LIFE RESET TO 100%.º If you have established a
Personalized Oil Reset Percentage, the display will show that
percentage instead of 100%. To ensure accurate oil life
indicators, perform this reset procedure only after an oil change.
[LG40001( X)08/94]
Your Personalized Oil Reset Percentage allows you to establish a
smaller oil change interval than the manufacturer's
recommended interval. To establish your Personalized Oil Reset
Percentage perform the following procedure:
[LG40101( X)08/94]1.
Press and hold the OIL CHANGE RESET switch and press
the RESET switch while the display is still counting down
the 5 seconds to reset. The display will change to ªSTART
OIL LIFE AT XXX%.º
[LG40201( X)08/94]2.
Press the OIL CHANGE RESET switch until the displayed
percentage is the Personalized Oil Reset Percentage that you
desire. Your choices are 100%, 90%, 80%, 70%, 60%, 50%,
40% and 30%.
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

Warning Lights and Gauges
107
[LG40301( X)08/94]3.
Press the RESET switch to complete the procedure. A press
of any switch besides RESET or OIL CHANGE RESET will
abort this procedure and will not establish your new
Personalized Oil Reset Percentage.
[LG40401( X)08/94]
When your Personalized Oil Reset Percentage has been
established, it will be used beginning with the completion of
your next OIL CHANGE RESET procedure.
File:05unlgx.ex
Update:Thu Feb 29 09:04:08 1996

109
Instrument Panel Controls
[IP00250( X)12/95]
33-1/2 pica
art:0090198-B
Instrument Panel & Controls
File:06unipx.ex
Update:Thu Feb 29 09:05:45 1996

110
[IP00400( X)03/95]
The main controls for the climate control system, lights, message
center, lamps, clocks and radio are on the instrument panel.
%*
[IP00475(ALL)09/95]
NOTE: Any cleaner or polish that increases the gloss (shine)
of the upper part of the instrument panel should be
avoided. The dull finish in this area is to help protect
the driver from undesirable windshield reflection.
%*
[IP00500(ALL)06/95]
The Climate Control Systems
*
[IP00601(ALL)12/91]
Your vehicle is equipped with a control assembly designed to
handle either a combination A/C-Heater System or a
Heater-Only System.
%*
[IP00801(ALL)10/93]
Instrument Panel Registers
*
[IP00901(ALL)02/95]
There are four registers in the instrument panel. Each of these
registers contains a louver assembly which can be manually
adjusted to direct airflow up, down, left and right. An
illustration of the register locations follows.
[IP01201(ALL)04/94]
7-1/2 pica art:0020099-D
Instrument panel registers
[IP01400(ALL)12/91]
Air Conditioning (A/C) Controls (Manual Air
Conditioning)
*
[IP01450(ALL)02/95]
The control for your air conditioning and heater system is
located at the center of the instrument panel below the radio
and will operate only when the ignition key is turned to the
ON position. Your air conditioner and heater will heat and/or
cool your vehicle interior depending on the function position
File:06unipx.ex
Update:Thu Feb 29 09:05:45 1996

Instrument Panel Controls
111 and temperature you select. The function selector control knob
allows you to select heating or cooling and determine where the
air will be directed. The temperature control knob setting
determines the temperature of the air that flows into the vehicle.
[IP01500(ALL)03/95]
10-1/2 pica
art:0020589-G
Climate control knobs
*
[IP01550(ALL)03/95]
To turn your air conditioner and heater system on, select any
position except OFF. This will turn the fan on and allow airflow
into the vehicle. To turn your air conditioner and heater off,
select OFF. This will turn the fan off and stop airflow from
coming into the vehicle.
*
[IP01600(ALL)03/95]
Temperature selection
[IP01650(ALL)03/95]
The temperature control knob is the rotating knob located at the
center of the control with tapered red and blue bands
surrounding most of the knob. The wide red part of the band
(full right) is the heat or warmer area. The wide blue area (full
left) is the cooling or cool temperature area. Any position
selected between full right and full left will give a temperature
between the two extreme temperatures.
File:06unipx.ex
Update:Thu Feb 29 09:05:45 1996

112
*
[IP01700(ALL)03/95]
HFan speed adjustment
[IP01750(ALL)03/95]
The
H(left) knob on the control is the fan control knob which
controls the volume of air flow. Rotate the
Hknob to the right
to increase fan speed and increase the amount of air entering
the vehicle. Four fan speed positions are available and are
indicated by dots beside the
Hcontrol knob. The largest dot is
high speed position.
*
[IP01800(ALL)08/94]
Airflow selections
[IP01850(ALL)08/95]
Q(Panel)
[IP01900(ALL)03/95]
UseQto bring outside air through the instrument panel
registers. You can heat the air in this position by rotating the
temperature knob into the red area. The air CANNOT be cooled
below the outside temperature regardless of the temperature
knob setting. Select A/C or MAX A/C to get cool air through
the instrument panel registers.
*
[IP01950(ALL)08/95]
A/C
[IP02000(ALL)06/94]
Select A/C to get refrigerated outside air through the
instrument panel registers. The A/C position is used for cooling
except when it is extremely hot or fast cooling of the vehicle is
needed. Then, select MAX A/C for fast cooling and return to
A/C when you are comfortable.
*
[IP02050(ALL)08/95]
MAX A/C
[IP02100(ALL)05/95]
The MAX A/C position produces cool air more rapidly to
provide faster cooling of your vehicle. This is possible because
cooler air is drawn from inside the passenger area and
refrigerated again instead of using warmer outside air. Using
inside air will also make the fan sound louder and is normal
when using MAX A/C. The air flow will be from the
instrument panel registers.
