CRUISE CONTROL SYSTEM
Article Text (p. 5)
1993 Volkswagen Corrado
For Volkswagen Technical Site: http://vw.belcom.ru
Copyright © 1998 Mitchell Repair Information Company, LLC
Wednesday, March 22, 2000 08:58PM
CONTROL UNIT
Removal & Installation
Remove glove compartment. Remove control module mounting
bracket. Remove control unit wiring harness connectors. Remove control
module. To install, reverse removal procedure.
STEERING COLUMN CONTROL SWITCH
Removal & Installation
Remove steering wheel. Loosen steering column switch clamp
and pull up steering column switch. Disconnect electrical connector
and remove steering column control switch. To install, reverse removal
procedure.
VACUUM PUMP
Removal & Installation
On Corrado SLC and Passat models, remove windshield washer
mounting bracket. Remove battery. On all models, remove screws and
vacuum pump fender. See Fig. 7 or 8. To install, reverse removal
procedure.Fig. 7: Identifying Vacuum Pump Components
(Corrado SLC & Passat)
Courtesy of Volkswagen United States, Inc.Fig. 8: Identifying Vacuum Pump Components (EuroVan)
Courtesy of Volkswagen United States, Inc.

CRUISE CONTROL SYSTEM
Article Text (p. 6)
1993 Volkswagen Corrado
For Volkswagen Technical Site: http://vw.belcom.ru
Copyright © 1998 Mitchell Repair Information Company, LLC
Wednesday, March 22, 2000 08:58PM
VACUUM SERVO
Removal & Installation
1) Detach linkage and remove vacuum hose from vacuum servo.
Remove nut and servo from bracket. To install, reverse removal
procedure. Adjust linkage as necessary.
TESTING
VACUUM CHECK
Locate vacuum pump. See Fig. 7 or 8. Remove vacuum line from
vacuum pump. Push vacuum actuator diaphragm inward. Apply brake pedal
by hand until pressure is felt. Release brake pedal. If diaphragm
moves, repair or replace as necessary.
WIRING DIAGRAMS
See appropriate chassis wiring diagram in WIRING DIAGRAMS.
END OF ARTICLE
