1993 VOLKSWAGEN CORRADO Repair Manual

A - ENGINE/VIN ID
Article Text (p. 2)
1993 Volkswagen Corrado
For Volkswagen Technical Site: http://vw.belcom.ru
Copyright © 1998 Mitchell Repair Information Company, LLC
Wednesday, March 22, 2000 08:47PM
Numbers preceding the explanations in the legend below refer
to the sequence of characters as listed on VIN identification label.
(VIN) W V W C B 5 1 5 2 P C 0 0 0 0 0 1
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
1-3 Indicates Nation of Origin.
4 Indicates Series.
5 Indicates Engine Type.
6 Indicates Restraint System.
7-8 Indicates Body Code.
9 Indicates Check Digit.
10 Indicates Model Year.
11 Indicates Assembly Plant.
12-17 Indicates Production Sequence.
MODEL YEAR VIN CODE APPLICATION TABLEÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄVIN Code Model Year
L .................................... 1990
M .................................... 1991
N .................................... 1992
P .................................... 1993
ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ ENGINE CODE LOCATIONFig. 1: Engine Code Location (4-Cylinder & 5-Cylinder)
Courtesy of Volkswagen United States, Inc.

A - ENGINE/VIN ID
Article Text (p. 3)
1993 Volkswagen Corrado
For Volkswagen Technical Site: http://vw.belcom.ru
Copyright © 1998 Mitchell Repair Information Company, LLC
Wednesday, March 22, 2000 08:47PMFig. 2: Engine Code Location (V6)
Courtesy of Volkswagen United States, Inc.
END OF ARTICLE

A/C COMPRESSOR OIL CHECKING
Article Text
1993 Volkswagen Corrado
For Volkswagen Technical Site: http://vw.belcom.ru
Copyright © 1998 Mitchell Repair Information Company, LLC
Wednesday, March 22, 2000 08:47PM
ARTICLE BEGINNING
1993 GENERAL SERVICING
Compressor Refrigerant Oil Checking
* PLEASE READ THIS FIRST *
NOTE: For compressor applications, see COMPRESSOR APPLICATIONS
TABLE below. DO NOT exceed A/C system refrigerant oil
capacity, when servicing system. See REFRIGERANT OIL &
REFRIGERANT SPECIFICATIONS TABLE.
COMPRESSOR APPLICATION
NOTE: Due to late changes, always refer to underhood A/C
specification label in engine compartment or A/C compressor
label while servicing A/C system. If A/C Specification label
and specifications in this article differ, always use label
specifications.
COMPRESSOR APPLICATION TABLEÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄApplication Compressor
Acura .......................................... Nippondenso 10-Cyl.
Audi
90 ................................................... Zexel 6-Cyl.
100 .................................................. Zexel 6-Cyl.
BMW .................................................... Nippondenso
Or Seiko-Seiki
Chrysler Motors/Eagle
Colt & Summit ................................ Sanden FX105V Scroll
Colt Vista & Summit Wagon .............. Nippondenso 10PA15 10-Cyl.
Stealth ..................................... Sanden FX105VS Scroll
Ram-50 ......................................... Sanden FX80 Scroll
Ford Motor Co.
Capri ......................................... Nippondenso 10-Cyl.
Festiva ........................................ Nippondenso 6-Cyl.
General Motors & Geo
LeMans ......................................... Harrison V5 5-Cyl.
Metro & Tracker ............................... Nippondenso 10-Cyl.
Prizm .................................. Nippondenso 10PA15 10-Cyl.
Storm ............................... Diesel Kiki KC-50 Rotary Vane
Honda
Accord ........................................ Nippondenso 10-Cyl.
Or Hadsys RC-17S 7-Cyl.
Civic ............................................... Sanden Scroll
Civic Del Sol ....................................... Sanden Scroll
Prelude ............................................. Sanden Scroll
Hyundai
Elantra ..................................... Sanden TRF-090 Scroll

A/C COMPRESSOR OIL CHECKING
Article Text (p. 2)
1993 Volkswagen Corrado
For Volkswagen Technical Site: http://vw.belcom.ru
Copyright © 1998 Mitchell Repair Information Company, LLC
Wednesday, March 22, 2000 08:47PM
Excel ........................................ Sanden SD-709 7-Cyl.
Scoupe ................................ Nippondenso 10PA15C 10-Cyl.
Sonata ......................................... Ford FX-15 10-Cyl.
Infiniti
G20 ................................... Atsugi NVR 140S Rotary Vane
J30 ............................................ Calsonic V6 6-Cyl.
Q45 ............................................ Calsonic V5 5-Cyl.
Isuzu (R-12)
Amigo ................................. Diesel Kiki DKS-13CH 6-Cyl.
Pickup
4-Cylinder ............................ Diesel Kiki DKS-13CH 6-Cyl.
V6 ...................................... Harrison R4 4-Cyl. Radial
Stylus ............................ Diesel Kiki DKV-14D Rotary Vane
Rodeo
4-Cylinder ............................ Diesel Kiki DKS-17CH 6-Cyl.
V6 ................................ Diesel Kiki DKV-14D Rotary Vane
Trooper ........................... Diesel Kiki DKV-14D Rotary Vane
Isuzu (R-134a Option) (1)
Amigo, Pickup, Rodeo & Trooper
2.3L & 2.6L Engine ............................ Zexel R-134a 6-Cyl.
3.1L Engine ..................... Harrison R-134a R-4 4-Cyl. Radial
3.2L Engine .............................. Zexel R-134a Rotary Vane
Jaguar
XJS .......................................... Sanden SD-709 7-Cyl.
XJ6 ......................................... Sanden SD-7H15 7-Cyl.
Lexus ................................... Nippondenso 10PA20 10-Cyl.
Mazda
B2200 & B2600i ...................................... Sanden 5-Cyl.
Miata ................................ Nippondenso TV12 Rotary Vane
MPV ........................................... Nippondenso 10-Cyl.
MX-6 & 626 .................................. Panasonic Rotary Vane
Navajo ......................................... Ford FX-15 10-Cyl.
MX-3, Protege & 323 ......................... Panasonic Rotary Vane
929 ......................................... Panasonic Rotary Vane
RX7 .................................. Nippondenso TV12 Rotary Vane
Mercedes-Benz
190E ................................... Nippondenso 10PA15 10-Cyl.
300D/E, 400E & 500E .................... Nippondenso 10PA17 10-Cyl.
300SE/SD, 400SE & 500SEL ............... Nippondenso 10PA20 10-Cyl.
Mitsubishi
Diamante
R-12 ........................................ Sanden FX105VS Scroll
R-134a .............................................. Sanden MSC105
Diamante Wagon ........................ Nippondenso 10PA17C 10-Cyl.
Galant & Mirage .............................. Sanden FX105V Scroll
Eclipse ................................ Nippondenso 10PA17 10-Cyl.
Expo/Expo LRV ......................... Nippondenso 10PA17C 10-Cyl.
Pickup ......................................... Sanden FX80 Scroll
Montero ................................ Nippondenso 10PA15 10-Cyl.
Precis ....................................... Sanden SD-709 7-Cyl.
3000GT
R-12 ........................................ Sanden FX105VS Scroll

A/C COMPRESSOR OIL CHECKING
Article Text (p. 3)
1993 Volkswagen Corrado
For Volkswagen Technical Site: http://vw.belcom.ru
Copyright © 1998 Mitchell Repair Information Company, LLC
Wednesday, March 22, 2000 08:47PM
R-134a .............................................. Sanden MSC105
Nissan
Altima .................................. Zexel DKV-14C Rotary Vane
Maxima & 300ZX ............................... Zexel DKS-16H 6-Cyl.
Quest .......................................... Ford FX-15 10-Cyl.
Pathfinder & Pickup ..................... Zexel DKV-14C Rotary Vane
Sentra & NX ............................. Zexel DKV-14D Rotary Vane
240SX .......................................... Calsonic V5 5-Cyl.
Porsche
911 America Roadster,
RS America & Carrera 2/4 ...................... Nippondenso 10-Cyl.
Saab
900 ................................................. Sanden 5-Cyl.
9000 ............................ Seiko-Seiki SS121 DN1 Rotary Vane
Subaru
Impreza ......................................... Zexel Rotary Vane
Legacy ...................................... Zexel DKS-15CH 5-Cyl.
Calsonic V5-15C 5-Cyl.
Loyale .................................. Hitachi MJS170-5DP 6-Cyl.
SVX ............................................ Calsonic V5 5-Cyl.
Suzuki ......................................... Nippondenso 10-Cyl.
Toyota
Camry ................................. Nippondenso 10PA17C 10-Cyl.
Celica
4A-FE Engine .......................... Nippondenso 10PA15C 10-Cyl.
3S-GTE & 5S-FE Engine .............. Nippondenso 10PA17C/VC 10-Cyl.
Corolla ................................ Nippondenso 10PA15 10-Cyl.
Land Cruiser ........................... Nippondenso 10PA17 10-Cyl.
MR2 .................................... Nippondenso 10P13C 10-Cyl.
Paseo ...................................... Matsushita Rotary Vane
Pickup & 4Runner .............................. Nippondenso 10-Cyl.
Previa ................................ Nippondenso 10PA17E 10-Cyl.
Supra ......................................... Nippondenso 10-Cyl.
Tercel ............................... Matsushita TV10B Rotary Vane
T100 ................................... Nippondenso 10PA15 10-Cyl.
Volkswagen
Cabriolet .................................... Sanden SD-508 5-Cyl.
Or SD-709 7-Cyl.
Corrado SLC .................................. Sanden SD-709 7-Cyl.
EuroVan ...................................... Sanden SD7H15 7-Cyl.
Golf, GTI & Jetta .................. Sanden SD7-V16/SD7-V16L 7-Cyl.
Fox ............................................ Nippondenso 6-Cyl.
Passat ............................. Sanden SD7-V16/SD7-V16L 7-Cyl.
Volvo
240 ......................................... Seiko-Seiki SS-121DS5
850 ......................................... Zexel DKS-15CH 6-Cyl.
940 & 960 ................................... Sanden SD-510 5-Cyl.,
Sanden SD-709 7-Cyl. Or
Seiko-Seiki SS-121DS5
(1) - Standard equipment on some models built after 5/1/93.ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ

A/C COMPRESSOR OIL CHECKING
Article Text (p. 4)
1993 Volkswagen Corrado
For Volkswagen Technical Site: http://vw.belcom.ru
Copyright © 1998 Mitchell Repair Information Company, LLC
Wednesday, March 22, 2000 08:47PM
REFRIGERANT OIL & REFRIGERANT CAPACITY
REFRIGERANT OIL & REFRIGERANT CAPACITY (ACURA THROUGH INFINITI)ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ (1) Oil Refrigerant
Application Ounces Ounces
Acura
Integra .................. (2) 2.0-3.4 ............ 32-34
Legend
Sedan ................... (2) (3) 4.7 .... (4) 24.7-26.5
Coupe ..................... (3) 4.7 .......... 24.7-26.5
Vigor .................... (2) 4.7-4.9 ........ 26.5-28.0
Audi
90 ......................... 7.8-9.2 ...... (5) 23.0-24.8
100 ........................ 7.8-9.2 ...... (5) 21.0-22.8
BMW
318 & 325 Series ........... 3.4-4.8 .......... (6) 35-36
525i & 535i ................ 4.7-6.1 ...... (6) 53.0-55.5
740i & 740iL ............... 4.7-6.1 ...... (6) 53.0-55.5
Chrysler Motors/Eagle
Colt & Summit ............ (2) 4.4-5.1 ............ 26-30
Colt Vista & Summit
Wagon .................... (2) 2.0-3.4 ............... 30
Ram-50 ................... (2) 4.4-5.1 ............... 30
Stealth .................. (2) 4.6-6.0 ............... 29
Ford Motor Co.
Capri ...................... 2.4-3.0 .............. 23-27
Festiva ...................... 10 .................... 25
General Motors & Geo
LeMans ....................... 8.0 ................... 35
Metro ........................ 2.7 ................... 18
Prizm & Prizm LSi ............ 6.0 ................... 25
Storm ........................ 5.1 ................... 21
Tracker ...................... 2.7 ................... 21
Honda
Accord
Nippondenso ................ 3.0-4.1 .............. 28-30
Hadsys ..................... 4.1-4.3 .............. 28-30
Civic ...................... 4.0-4.7 .............. 21-23
Civic Del Sol .............. 4.0-4.7 .............. 21-23
Prelude .................. (7) 4.3-5.0 ............ 21-23
Hyundai
Excel ........................ 8.1 ................ 30-32
Scoupe ....................... 2-3 ................ 28-32
Elantra ...................... 4.0 ................... 32
Sonata ..................... 6.9-7.7 .............. 30-32
Infiniti
G20 .......................... 6.8 ................ 24-29
J30 .......................... 8.5 ............ (8) 24-26
Q45 .......................... 9.7 ................ 38-42

A/C COMPRESSOR OIL CHECKING
Article Text (p. 5)
1993 Volkswagen Corrado
For Volkswagen Technical Site: http://vw.belcom.ru
Copyright © 1998 Mitchell Repair Information Company, LLC
Wednesday, March 22, 2000 08:47PM
(1) - Total system capacity, unless otherwise noted.
(2) - Compressor refrigerant oil capacity.
(3) - Capacity revised by manufacturer in Acura Service News
bulletin number ASN 0793-02.
(4) - Use R-134a refrigerant and ND-Oil 8 (Part No.
38899-PR7-003).
(5) - Use R-134a refrigerant and Polyalkylene Glycol (PAG) oil.
(6) - Use R-134a and Poyalkylene Glycol Oil (Part No.
81-22-9-407-724).
(7) - Use R-134a refrigerant and PAG Refrigerant Oil (Part
No. 38899-P13-003).
(8) - Use R-134a refrigerant and Type "S" Oil (Part
No. KLH00-PAGS0).ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄREFRIGERANT OIL & REFRIGERANT CAPACITY (ISUZU THROUGH MERCEDES)
ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ (1) Oil Refrigerant
Application Ounces Ounces
Isuzu (R-12)
Amigo ........................ 5.0 .................... 26
Pickup
2.3L & 2.6L Engine ........... 5.0 .................... 26
3.1L Engine .................. 6.0 .................... 26
Rodeo
2.6L Engine .................. 5.0 .................... 26
3.2L Engine .................. 5.0 .................... 26
Stylus ....................... 5.0 .................... 21
Trooper ...................... 5.0 .................... 30
Isuzu (R-134a Option) (3)
Amigo & Pickup
2.3L & 2.6L Engine ........... 5.0 .................... 23
3.1L Engine ................ 7.5-8.5 .................. 23
Rodeo ........................ 5.0 .................... 23
Trooper ...................... 5.0 .................... 26
Jaguar
XJS ........................ (2) 4.6 .................. 40
XJ6 ........................ (2) 4.5 .............. (4) 40
Lexus
ES300 ...................... (2) 3.5 ............... 32-35
GS300 ...................... (2) 4.0 ........... (5) 28-32
LS400 .................... (2) 2.8-3.5 ............ (5) 32
SC300 & SC400 .............. (2) 4.0 ............... 32-35
Mazda
B2200 & B2600i ............. (2) 4.5 .................. 28
Miata .................... (2) 2.7-3.3 ................ 28
MPV
Dual Unit ................ (2) 2.7-3.3 ................ 51
Single Unit .............. (2) 2.7-3.3 ................ 37
MX-3 ....................... (2) 5.0 .................. 28

A/C COMPRESSOR OIL CHECKING
Article Text (p. 6)
1993 Volkswagen Corrado
For Volkswagen Technical Site: http://vw.belcom.ru
Copyright © 1998 Mitchell Repair Information Company, LLC
Wednesday, March 22, 2000 08:47PM
MX-6 & 626 ................. (2) 4.3 .................. 26
Protege & 323 ............ (2) 3.9-4.6 ................ 28
Navajo ....................... 7.0 ................. 28-29
929 .......................... 3.6 .................... 28
RX7 ........................ 3.4-4.7 .................. 21
Mercedes-Benz
190E ....................... (2) 4.0 .................. 36
300D/E, 400E & 500E ........ (2) 5.4 .............. (6) 36
300SE/SD, 400SE
& 500SEL ................... (2) 5.4 .............. (7) 43
(1) - Total system capacity, unless otherwise noted.
(2) - Compressor refrigerant oil capacity.
(3) - Standard equipment on some models built after 5/1/93.
Use R-134a Swash Plate Compressor Oil (Part No. 2-90188-
300-0)on 2.3L and 2.6L engine. Use R-134a R-4 Compressor
Oil (Part No. 2-90222-320-0) on 3.1L engine. Use R-134a
Rotary Vane Compressor
Oil (Part No. 2-90188-301-0) on 3.2L engine.
(4) - Use R-134a refrigerant and PAG SP20 refrigerant oil.
(5) - Use R-134a refrigerant and ND-Oil 8 (Part No. 38899-
PR7-003).
(6) - Use R-134a refrigerant and Densooil 8 (Part No. A 001 989
08 03).
(7) - Use R-134a refrigerant and Densooil 8 (Part No. A 001 989
08 03).Use 50 ounces if equipped with rear passenger
compartment A/C-heater system.ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄREFRIGERANT OIL & REFRIGERANT CAPACITY (MITSUBISHI THRU SUBARU)
ÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄÄ (1) Oil Refrigerant
Application Ounces Ounces
Mitsubishi
Diamante
R-12 ....................... 5.4-6.0 ................ 34-38
R-134a ................... (3) 5.7-6.4 .............. 26-28
Diamante Wagon ............... 5.4 ..................... 28
Eclipse .................. (2) 2.0-3.4 ................. 33
Expo/Expo LRV
1.8L ..................... (2) 3.4-4.0 ................. 30
2.4L ..................... (2) 2.0-3.4 ................. 30
Galant ................... (2) 5.0-5.7 ................. 33
Mirage ................... (2) 4.4-5.1 .............. 26-30
Pickup ................... (2) 4.4-5.1 ................. 30
Montero .................. (2) 2.0-3.4 ................. 28
Precis ....................... 8.1 .................. 30-32
3000GT
R-12 ....................... 4.7-6.0 ................... 29
R-134a ................... (3) 4.7-6.0 .............. 26-28
Nissan
