and hold the lock button on the gear selector. Then shift
back and forth between DRIVE and REVERSE (with auto-
matic transmission) or SECOND GEAR and REVERSE
(with manual transmission), while gently pressing the
accelerator.
Use the least amount of accelerator pedal pressure that will
maintain the rocking motion without spinning the wheels
or racing the engine.
For Vehicles With Automatic Transmission:
Shifts between DRIVE and REVERSE can only be achieved
at wheel speeds of 5 mph (8 km/h) or less. Whenever the
transmission remains in NEUTRAL for more than two
seconds, you must press the brake pedal to engage DRIVE
or REVERSE.
NOTE:Push the ESC Off switch (if necessary), to place
the Electronic Stability Control (ESC) system in Partial Off
mode, before rocking the vehicle. Refer to “Electronic
Brake Control” in “Safety” for further information. Once
the vehicle has been freed, push the ESC Offswitch again
to restore ESC Onmode.WARNING!
Fast spinning tires can be dangerous. Forces generated
by excessive wheel speeds may cause damage, or even
failure, of the axle and tires. A tire could explode and
injure someone. Do not spin your vehicle’s wheels
faster than 30 mph (48 km/h) or for longer than 30
seconds continuously without stopping when you are
stuck and do not let anyone near a spinning wheel, no
matter what the speed.
CAUTION!
•Racing the engine or spinning the wheels may lead
to transmission overheating and failure. Allow the
engine to idle with the transmission in NEUTRAL
for at least one minute after every five rocking-
motion cycles. This will minimize overheating and
reduce the risk of clutch or transmission failure
during prolonged efforts to free a stuck vehicle.
• When “rocking” a stuck vehicle by shifting between
DRIVE/ SECOND gear and REVERSE, do not spin
the wheels faster than 15 mph (24 km/h), or drive-
train damage may result.
(Continued)
7
IN CASE OF EMERGENCY 367

CAUTION!(Continued)
•Revving the engine or spinning the wheels too fast
may lead to transmission overheating and failure. It
can also damage the tires. Do not spin the wheels
above 30 mph (48 km/h) while in gear (no transmis-
sion shifting occurring).
TOWING A DISABLED VEHICLE
This section describes procedures for towing a disabled
vehicle using a commercial towing service.
Towing Condition Wheels OFF The Ground FWD MODELS
FOUR WHEEL DRIVE
Flat Tow NONE NOT ALLOWED NOT ALLOWED
Wheel Lift Or Dolly Tow Rear
NOT ALLOWED NOT ALLOWED
Front OK NOT ALLOWED
Flatbed ALLBEST METHOD OK
368 IN CASE OF EMERGENCY

Proper towing or lifting equipment is required to prevent
damage to your vehicle. Use only tow bars and other
equipment designed for this purpose, following equipment
manufacturer ’s instructions. Use of safety chains is man-
datory. Attach a tow bar or other towing device to main
structural members of the vehicle, not to bumpers or
associated brackets. State and local laws regarding vehicles
under tow must be observed.
NOTE:
•Vehicles with a discharged battery or total electrical
failure when the Electric Park Brake (EPB) is engaged,
will need a wheel dolly or jack to raise the rear wheels
off the ground when moving the vehicle onto a flatbed.
• You must ensure that the Auto Park Brake feature is
disabled before towing this vehicle, to avoid inadvertent
Electric Park Brake engagement. The Auto Park Brake
feature is enabled or disabled via the customer program-
mable features in the Uconnect Settings.
If you must use the accessories (wipers, defrosters, etc.)
while being towed, the ignition must be in the RUN mode.
If the key fob is unavailable, or the vehicle’s battery is
discharged, refer to “Gear Selector Override” in this section for instructions on shifting the transmission out of PARK so
that the vehicle can be moved.
CAUTION!
•
Do not use sling type equipment when towing.
Vehicle damage may occur.
• When securing the vehicle to a flat bed truck, do not
attach to front or rear suspension components. Dam-
age to your vehicle may result from improper towing.
Front Wheel Drive (FWD)
The manufacturer recommends towing your vehicle with
all four wheels OFF the ground on a flatbed.
If flatbed equipment is not available, this vehicle must
towed with the front wheels OFF the ground (using a
towing dolly, or wheel lift equipment with the front wheels
raised).
NOTE: Ensure that the Electric Park Brake is released, and
remains released, while being towed.
7
IN CASE OF EMERGENCY 369

CAUTION!
Towing this vehicle in violation of the above require-
ments can cause severe transmission damage. Damage
from improper towing is not covered under the New
Vehicle Limited Warranty.
Four-Wheel Drive (4WD)
The manufacturer requires towing with all four wheels
OFF the ground. Acceptable methods are to tow the vehicle
on a flatbed, or with one end of the vehicle raised and the
opposite end on a towing dolly.
CAUTION!
•DO NOT tow this vehicle with ANY of its wheels on
the ground. Damage to the drivetrain will result.
•
Front or rear wheel lifts must not be used. Internal
damage to the transmission or power transfer unit will
occur if a front or rear wheel lift is used when towing.
• Towing this vehicle in violation of the above require-
ments can cause severe transmission and/or power
transfer unit damage. Damage from improper towing
is not covered under the New Vehicle Limited War-
ranty.
Emergency Tow Hooks — If Equipped
If your vehicle is equipped with tow hooks, there will be
one in the rear and two mounted on the front of the vehicle.
The rear hook will be located on the driver’s side of the
vehicle.
NOTE: For off-road recovery, it is recommended to use
both of the front tow hooks to minimize the risk of damage
to the vehicle.
Front Tow Hook Locations
370 IN CASE OF EMERGENCY

Place the ignition in the RUN and subsequently on ON,
without opening the door. During towing remember that
not having the aid of the power brakes and the electrome-
chanical power steering, greater force is needed in apply-
ing the brakes and steering of the vehicle.
WARNING!
•Do not use a chain for freeing a stuck vehicle. Chains
may break, causing serious injury or death.
• Stand clear of vehicles when pulling with tow hooks.
Tow straps may become disengaged, causing serious
injury.
CAUTION!
Tow hooks are for emergency use only, to rescue a
vehicle stranded off road. Do not use tow hooks for
tow truck hookup or highway towing. You could
damage your vehicle.
Rear Tow Hook Location
7
IN CASE OF EMERGENCY 371

ENHANCED ACCIDENT RESPONSE SYSTEM
(EARS)
This vehicle is equipped with an Enhanced Accident
Response System.
Please refer to “Occupant Restraint Systems” in “Safety”
for further information on the Enhanced Accident Re-
sponse System (EARS) function.
EVENT DATA RECORDER (EDR)
This vehicle is equipped with an Event Data Recorder
(EDR). The main purpose of an EDR is to record data that
will assist in understanding how a vehicle’s systems per-
formed under certain crash or near crash-like situations,
such as an air bag deployment or hitting a road obstacle.
Please refer to “Occupant Restraint Systems” in “Safety”
for further information on the Event Data Recorder (EDR).
372 IN CASE OF EMERGENCY

SERVICING AND MAINTENANCE
CONTENTS
SCHEDULED SERVICING .................375
▫ Maintenance Plan ...................... .376
 ENGINE COMPARTMENT .................382
▫ 1.4L Turbo Engine ..................... .382
▫ 2.4L Engine .......................... .383
▫ Checking Oil Level .....................383
▫ Cooling System ....................... .384
▫ Adding Washer Fluid ...................385
▫ Maintenance-Free Battery .................385
 DEALER SERVICE ...................... .386
▫ Engine Oil .......................... .386
▫ Engine Oil Filter ...................... .388
▫ Engine Air Cleaner Filter .................388
▫ Air Conditioner Maintenance ..............389▫
Body Lubrication ..................... .390
▫ Windshield Wiper Blades .................390
▫ Exhaust System ....................... .392
▫ Cooling System ....................... .393
▫ Brake System ........................ .398
▫ Manual Transmission — If Equipped ........400
▫ Automatic Transmission — If Equipped ......400
 RAISING THE VEHICLE ..................402
 TIRES ............................... .403
▫ Tire Safety Information ..................403
▫ Tires — General Information ..............410
▫ Tire Types ........................... .416
▫ Spar

e Tires — If Equipped ................418
▫ Wheel And Wheel Trim Care ..............419
8

▫Tire Chains (Traction Devices) .............421
▫ Tire Rotation Recommendations ............422
 DEPARTMENT OF TRANSPORTATION UNIFORM
TIRE QUALITY GRADES ..................424
▫ Treadwear ........................... .424
▫ Traction Grades ....................... .424
▫ Temperature Grades .....................424
 STORING THE VEHICLE ..................425
 BODYWORK .......................... .426▫
Protection From Atmospheric Agents ........426
▫ Body And Underbody Maintenance ..........426
▫ Preserving The Bodywork .................427
 INTERIORS ........................... .428
▫ Seats And Fabric Parts ...................428
▫ Plastic And Coated Parts ..................429
▫ Leather Parts ......................... .429
▫ Glass Surfaces ........................ .430
