Dome Light Vanity Mirror
To replace the bulbs proceed as follows:
1. Lift the cover of the mirror and pull out the visor mirrorlight cover.
2. Replace the bulb, releasing it from the side contacts, and then insert the new bulb, making sure that it is properly
locked between the contacts. 3. Reinstall the visor mirror light cover making sure that it
is properly locked.
4. Finally lower the visor mirror cover to the mirror.
Dome Light Glove Compartment
To replace the bulb proceed as follows:
1. Open the glove compartment;
2. Place your fingers inside the light assembly, pull the bulb to replace it.
Visor
1 — Visor Mirror Cover
2 — Visor Mirror LightBulb Removal/Installation
7
IN CASE OF EMERGENCY 335

3. Insert the new bulb, making sure it is properly locked.
Rear Dome Light — Without Retractable Roof
To replace the bulbs proceed as follows:
1. Using a suitable tool release the lamp assembly at boththe ends.
2. Open the flap and replace the bulb. 3. Insert the new bulb, locking it between the contacts.
4. Reinstall the dome light.
Dome Light — MY SKY
To replace the bulbs proceed as follows:
1. Lower the handle in the direction shown remove the
dome light.
Rear Dome Light Housing
1 — Bulb
2 — Flap
Retractable Roof Light
336 IN CASE OF EMERGENCY

2. Replace the bulb by removing it from the side contacts.
3. Insert the new bulb, locking it between the contacts.
4. Reinstall the dome light.
Interior Cargo Lights
To replace the bulbs proceed as follows:
1. Open the luggage compartment and remove the domelight assembly.
2. Open the light cover and replace the bulb. 3. Close the light cover over the bulb.
4. Reinstall the dome light in its correct position.
WARNING!
•Before proceeding with the replacement of the lamp wait
for the exhaust pipes are cool: DANGER OF BURNS!
• Modifications or repair of the electrical system per-
formed incorrectly and without taking into account
the technical characteristics can cause malfunctions
with the risk of fire.
(Continued)
Bulb
Light Cover
7
IN CASE OF EMERGENCY 337

WARNING!(Continued)
•Halogen lamps contain gas under pressure, in the
event of breakage be careful of the projection of
fragments of glass.
• Halogen lamps must be handled by touching only
the metallic part. If the transparent bulb is in contact
with the fingers, reduces the intensity of the emitted
light and you can also affect the life of the lamp. In
case of accidental contact, rub the bulb with a cloth
dampened with alcohol and allow to dry.
FUSES
WARNING!
• When replacing a blown fuse, always use an appro-
priate replacement fuse with the same amp rating as
the original fuse. Never replace a fuse with another
fuse of higher amp rating. Never replace a blown
fuse with metal wires or any other material. Failure
to use proper fuses may result in serious personal
injury, fire and/or property damage.
(Continued)
WARNING! (Continued)
•Before replacing a fuse, make sure that the ignition is
off and that all the other services are switched off
and/or disengaged.
• If the replaced fuse blows again, contact an autho-
rized dealer.
• If a general protection fuse for safety systems (air
bag system, braking system), power unit systems
(engine system, gearbox system) or steering system
blows, contact an authorized dealer.
General Information
The fuses protect electrical systems against excessive cur-
rent.
When a device does not work, you must check the electri-
cal circuit inside the fuse for a break/melt.
Also please be aware that when using power outlets for
extended periods of time with the engine off may result in
vehicle battery discharge.
338 IN CASE OF EMERGENCY

Fuse Removal
To replace a fuse use the extractor attached to the fuse
cover (located on the inside of the engine compartment
fuse cover.
Blade Fuses
1 — Electrical Circuit
2 — Blade Fuse With Good Electrical Circuit
3 — Blade Fuse With Bad Electrical CircuitFuse Extractor Location
7
IN CASE OF EMERGENCY 339

Access To The Fuses
The fuses are grouped into four controllers located in the
engine compartment, under the instrument panel and on
the inside of the left side cargo trim panel.
Engine Compartment Fuses/Distribution Unit
The engine compartment fuse panel is located on the left
side of the engine compartment.Removing Fuse Cover and Locking Screw
Proceed as follows:
•Slowly turn the screw counterclockwise.
• Slowly release the screw.
• Remove the fuse cover by sliding it upward.
Engine Compartment Fuse Cavities
Fuse Panel & Cover Location
1 — Mounting Screw
2 — Fuse Cover
340 IN CASE OF EMERGENCY

Mounting Fuse Cover and Locking Screw
Proceed as follows:
•Properly secure the fuse cover to the box, slide com-
pletely from top to bottom.
• Fully depress the screw, using the special screwdriver
supplied.
• Slowly turn the screw clockwise.
• Release the screw.
Cavity Maxi FuseCartridge Fuse Micro Fuse Description
F01 70 Amp Tan ––Module Body Com-
puter
F02 70 Amp Tan ––Module Body Com-
puter, Rear Distribu- tion Units
Battery Fuse Cover Location
1 — Fuse Cover Tabs
2 — Fuse Cover
7
IN CASE OF EMERGENCY 341

CavityMaxi FuseCartridge Fuse Micro Fuse Description
F03 –20 Amp Blue –Controller Power
Supply Body Com- puter
F04 –30 Amp Pink –Brake Control Elec-
tronics Module
F05 70 Amp Tan ––Electric Power-
Assisted Steering
F06 20 Amp Yellow ––Engine Cooling fan
F07 40 Amp Orange –
1.4 Without A/C
50 Amp Red – 1.4
With A/C And All 2.4 Models –
–Engine Cooling fan
F08 –30 Amp Pink –Automatic Transmis-
sion, GSM
F09 ––5 Amp Tan Control Module En-
gine
F10 ––15 Amp Blue Horn
F11 ––10 Amp Red – 1.4
Engines
25 Amp Clear – 2.4 Engines Supply Secondary
Loads
