2017 JEEP RENEGADE seat adjustment

▫Keyless Enter-N-Go — Passive Entry — If
Equipped .............................32
▫ Dead Lock Device — If Equipped ............36
▫ Child Locks ...........................37
 SEATS ................................38
▫ Manual Front Seats ......................38
▫ Power Adjustment (Front) — If Equipped ......39
▫ Heated Seats — If Equipped ................41
▫ Rear Seats ............................42
 HEAD RESTRAINTS ......................46
▫ Front Head Restraints ....................46
▫ Rear Head Restraints .....................47
 STEERING WHEEL .......................48
▫ Tilt/Telescoping Steering Column ............48
▫ Heated Steering Wheel — If Equipped .........48
 MIRRORS ..............................49
▫ Inside Day/Night Mirror ..................49 ▫
Auto Dimming Mirror — If Equipped .........49
▫ Outside Mirrors ........................50
▫ Folding Mirror .........................51
▫ Heated Mirrors — If Equipped .............51
 EXTERIOR LIGHTS .......................52
▫ Headlights ............................52
▫ Daytime Running Lights (DRL) — If Equipped . .52
▫ High Beams ...........................52
▫ Flash-To-Pass ..........................53
▫ Automatic Lighting — If Equipped ..........53
▫ Automatic High Beam Headlamp Control — If
Equipped .............................54
▫ Parking Lights .........................54
▫ Headlight Delay ........................54
▫ Front Fog Lights — If Equipped .............55
▫ Turn Signals ...........................55
 INTERIOR LIGHTS .......................56
16 GETTING TO KNOW YOUR VEHICLE

•For emergency exit with the system engaged, rotate the
lock/unlock dial to the unlocked position, roll down the
window, and open the door with the outside door
handle.
WARNING!
Avoid trapping anyone in a vehicle in a collision.
Remember that the rear doors can only be opened from
the outside when the Child-Protection locks are en-
gaged (locked).
SEATS
Seats are a part of the Occupant Restraint System of the
vehicle.
WARNING!
• It is dangerous to ride in a cargo area, inside or
outside of a vehicle. In a collision, people riding in
these areas are more likely to be seriously injured or
killed.
• Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat belts.
(Continued)
WARNING! (Continued)
In a collision, people riding in these areas are more
likely to be seriously injured or killed.
• Be sure everyone in your vehicle is in a seat and
using a seat belt properly.
Manual Front Seats
Manual Seat Adjustment Levers
1 — Forward/Rearward Adjustment Bar
2 — Seat Height Adjustment Lever
3 — Recline Lever
38 GETTING TO KNOW YOUR VEHICLE

WARNING!
•Adjusting a seat while the vehicle is moving is
dangerous. The sudden movement of the seat could
cause you to lose control. The seat belt might not be
adjusted properly and you could be injured. Adjust
the seat only while the vehicle is parked.
• Do not ride with the seatback reclined so that the
shoulder belt is no longer resting against your chest.
In a collision you could slide under the seat belt and
be seriously or even fatally injured. Use the recliner
only when the vehicle is parked.
Manual Front Seats Forward/Rearward Adjustment
On models equipped with manual seats, the adjusting bar
is located at the front of the seats, near the floor. While
sitting in the seat, lift up on the bar and move the seat
forward or rearward. Release the bar once you have
reached the desired position. Then, using body pressure,
move forward and rearward on the seat to be sure that the
seat adjusters have latched.
Height Adjustment
The driver ’s seat height can be raised or lowered by using
a lever, located on the outboard side of the seat. Pull
upward on the lever to raise the seat height or push
downward on the lever to lower the seat height.
Manual Recline Adjustment
To adjust the seatback, lift the lever located on the outboard
side of the seat, lean back to the desired position and
release the lever. To return the seatback, lift the lever, lean
forward and release the lever.
Power Adjustment (Front) — If Equipped
The power seat controls are located on the outboard side of
the seat, close to the floor.
3
GETTING TO KNOW YOUR VEHICLE 39

WARNING!(Continued)
•Seats should be adjusted before fastening the seat
belts and while the vehicle is parked. Serious injury
or death could result from a poorly adjusted seat belt.
• Do not ride with the seatback reclined so that the
shoulder belt is no longer resting against your chest.
In a collision you could slide under the seat belt,
which could result in serious injury or death.
CAUTION!
Do not place any article under a power seat or impede
its ability to move as it may cause damage to the seat
controls. Seat travel may become limited if movement
is stopped by an obstruction in the seat’s path.
Power Lumbar Adjustment— If Equipped
Push the switch forward or rearward to increase or de-
crease the lumbar support. Push the switch upward or
downward to raise or lower the lumbar support. NOTE:
Power seat adjustments are only allowed when the
ignition device is turned to ON, and for about 30 minutes
after it is turned to OFF. The seats can also be moved after
opening/closing the doors for about 30 minutes, locking or
unlocking the doors, or switching on of the front courtesy
lights.
Heated Seats — If Equipped
The heated seat switches are located on the instrument
panel.
You can choose between two heating levels:
• Push the heated seat button
once to turn the HI
setting on.
• Push the heated seat buttona second time to turn
the LO setting on.
• Push the heated seat buttona third time to turn the
heating elements off.
If the HI-level setting is selected, the system will automati-
cally switch to LO-level after approximately 145 minutes of
continuous operation. At that time, the display will change
from HI to LO, indicating the change. The LO-level setting
will turn off automatically after approximately 60 minutes.
3
GETTING TO KNOW YOUR VEHICLE 41

HEAD RESTRAINTS
Head restraints are designed to reduce the risk of injury by
restricting head movement in the event of a rear impact.
Head restraints should be adjusted so that the top of the
head restraint is located above the top of your ear.
WARNING!
•All occupants, including the driver, should not oper-
ate a vehicle or sit in a vehicle’s seat until the head
restraints are placed in their proper positions in
order to minimize the risk of neck injury in the event
of a crash.
• Head restraints should never be adjusted while the
vehicle is in motion. Driving a vehicle with the head
restraints improperly adjusted or removed could
cause serious injury or death in the event of a
collision.
Front Head Restraints
Your vehicle is equipped with front driver and passenger
head restraints. To raise the head restraint, pull upward on the head
restraint. To lower the head restraint, push the adjustment
button, located at the base of the head restraint, and push
downward on the head restraint.
NOTE:
The head restraints should only be removed by
qualified technicians, for service purposes only. If either of
the head restraints require removal, see your authorized
dealer.
Head Restraint Adjustment Button
46 GETTING TO KNOW YOUR VEHICLE

WARNING!
•All occupants, including the driver, should not oper-
ate a vehicle or sit in a vehicle’s seat until the head
restraints are placed in their proper positions in
order to minimize the risk of neck injury in the event
of a crash.
• Head restraints should never be adjusted while the
vehicle is in motion. Driving a vehicle with the head
restraints improperly adjusted or removed could
cause serious injury or death in the event of a
collision.
Rear Head Restraints
Your vehicle is equipped with two outboard head restraints
and one center head restraint for its rear passengers. The
rear head restraints can be raised or lowered. When the
center seat is being occupied, the head restraint should be
in the raised position. When there are no occupants in the
center seat, the head restraint can be lowered for maximum
visibility for the driver.
To raise the head restraint, pull upward on the head
restraint. To lower the head restraint, push the adjustment button,
located at the base of the head restraint, and push down-
ward on the head restraint.
NOTE:
The head restraints should only be removed by
qualified technicians, for service purposes only. If either of
the head restraints require removal, see your authorized
dealer.
Adjustment Button
3
GETTING TO KNOW YOUR VEHICLE 47

Security
By selecting the item “Security,” you can make the follow-
ing adjustments:
•Speed Warning:
Set the vehicle speed limit (km/h or MPH), which the
driver is notified through a visual and acoustic signaling
(display of a message and a symbol on the display).
When the speed warning is set, the icon should remain
visualized for the same duration time of the pop up. If the
driver exceeded the speed set the icon should remain for
however long the vehicle is over the set speed.
Driver may also turn the Speed Warning “OFF” should you
choose not to use this feature.
• Seat Belt Reminder:
This function is only viewable when the Seat Belt Re-
minder (SBR) system is active.
• Hill Start Assist (If Equipped):
Activation/Deactivation of the Hill Start Assist system. Safety & Assistance
By selecting the item
Safety & Assistance, you can make
the following adjustments:
• Forward Collision Warning
• Forward Collision Warning Sensitity
• ParkSense (If Equipped): a selection of the type of
information provided by ParkSense
• Rear Parks (If Equipped) Vol.: selection of the volume of
acoustic signals provided by ParkSense
• ParkSense (If Equipped) Vol.: a selection of the volume
of acoustic signals provided by ParkSense
• Front Parks. Vol.: selection of the volume of the beeps
provided by ParkSense
• Warning Buzzer Volume
• Brake Service (If Equipped): activation of the procedure
to carry out braking system maintenance
• Auto Park Brake (If Equipped): enable/disable auto-
insertion of the Electric Parking Brake
• Rain Sensing Wipers
• Lanesense Warning (If Equipped)
4
GETTING TO KNOW YOUR INSTRUMENT PANEL 131

NOTE:The adjustable upper shoulder belt anchorage is
equipped with an Easy Up feature. This feature allows the
shoulder belt anchorage to be adjusted in the upward
position without pushing or squeezing the release button.
To verify the shoulder belt anchorage is latched, pull
downward on the shoulder belt anchorage until it is locked
into position.
WARNING!
• Wearing your seat belt incorrectly could make your
injuries in a collision much worse. You might suffer
internal injuries, or you could even slide out of the
seat belt. Follow these instructions to wear your seat
belt safely and to keep your passengers safe, too.
• Position the shoulder belt across the shoulder and
chest with minimal, if any slack so that it is comfort-
able and not resting on your neck. The retractor will
withdraw any slack in the shoulder belt.
• Misadjustment of the seat belt could reduce the
effectiveness of the safety belt in a crash.
Seat Belts And Pregnant Women
Seat belts must be worn by all occupants including preg-
nant women: the risk of injury in the event of an accident
is reduced for the mother and the unborn child if they are
wearing a seat belt.
Position the lap belt snug and low below the abdomen and
across the strong bones of the hips. Place the shoulder belt
across the chest and away from the neck. Never place the
shoulder belt behind the back or under the arm.
Pregnant Women And Seat Belts
5
SAFETY 211
