2017 JEEP RENEGADE child seat

▫Keyless Enter-N-Go — Passive Entry — If
Equipped .............................32
▫ Dead Lock Device — If Equipped ............36
▫ Child Locks ...........................37
 SEATS ................................38
▫ Manual Front Seats ......................38
▫ Power Adjustment (Front) — If Equipped ......39
▫ Heated Seats — If Equipped ................41
▫ Rear Seats ............................42
 HEAD RESTRAINTS ......................46
▫ Front Head Restraints ....................46
▫ Rear Head Restraints .....................47
 STEERING WHEEL .......................48
▫ Tilt/Telescoping Steering Column ............48
▫ Heated Steering Wheel — If Equipped .........48
 MIRRORS ..............................49
▫ Inside Day/Night Mirror ..................49 ▫
Auto Dimming Mirror — If Equipped .........49
▫ Outside Mirrors ........................50
▫ Folding Mirror .........................51
▫ Heated Mirrors — If Equipped .............51
 EXTERIOR LIGHTS .......................52
▫ Headlights ............................52
▫ Daytime Running Lights (DRL) — If Equipped . .52
▫ High Beams ...........................52
▫ Flash-To-Pass ..........................53
▫ Automatic Lighting — If Equipped ..........53
▫ Automatic High Beam Headlamp Control — If
Equipped .............................54
▫ Parking Lights .........................54
▫ Headlight Delay ........................54
▫ Front Fog Lights — If Equipped .............55
▫ Turn Signals ...........................55
 INTERIOR LIGHTS .......................56
16 GETTING TO KNOW YOUR VEHICLE

Arming The Dead Lock Device
•The device works on all doors and requires two presses
of the lock button on the key fob.
• The arming of the device is indicated by three flashes of
the direction indicators.
• The device does not operate if one or more doors are not
properly closed.
Disarming The Device
• The device will automatically disarm by pushing the
unlock button on the key fob.
• Placing the ignition in the ON or RUN position.
Child Locks
To provide a safer environment for small children riding in
the rear seats, the rear doors are equipped with a Child-
Protection Door Lock system.
To use the system, open each rear door, use a flat blade
screwdriver (or ignition key) and rotate the dial to the lock
or unlock position. When the system on a door is engaged,
that door can only be opened by using the outside door
handle even if the inside door lock is in the unlocked
position. NOTE:
•
When the child lock system is engaged, the door can
only be opened by using the outside door handle even
though the inside door lock is in the unlocked position.
• After disengaging the Child-Protection Door Lock sys-
tem, always test the door from the inside to make certain
it is in the desired position.
• After engaging the Child-Protection Door Lock system,
always test the door from the inside to make certain it is
in the desired position.
Child-Protection Door Lock Location
3
GETTING TO KNOW YOUR VEHICLE 37

•For emergency exit with the system engaged, rotate the
lock/unlock dial to the unlocked position, roll down the
window, and open the door with the outside door
handle.
WARNING!
Avoid trapping anyone in a vehicle in a collision.
Remember that the rear doors can only be opened from
the outside when the Child-Protection locks are en-
gaged (locked).
SEATS
Seats are a part of the Occupant Restraint System of the
vehicle.
WARNING!
• It is dangerous to ride in a cargo area, inside or
outside of a vehicle. In a collision, people riding in
these areas are more likely to be seriously injured or
killed.
• Do not allow people to ride in any area of your
vehicle that is not equipped with seats and seat belts.
(Continued)
WARNING! (Continued)
In a collision, people riding in these areas are more
likely to be seriously injured or killed.
• Be sure everyone in your vehicle is in a seat and
using a seat belt properly.
Manual Front Seats
Manual Seat Adjustment Levers
1 — Forward/Rearward Adjustment Bar
2 — Seat Height Adjustment Lever
3 — Recline Lever
38 GETTING TO KNOW YOUR VEHICLE

The center part of the rear seat can also be used as rear
armrest with cupholders.
WARNING!
Be certain that the seatback is securely locked into
position. If the seatback is not securely locked into
position the seat will not provide the proper stability
for child seats and/or passengers. An improperly
latched seat could cause serious injury.
Rear Seat Center Armrest — If Equipped
Rear Armrest
3
GETTING TO KNOW YOUR VEHICLE 45

SAFETY
CONTENTS
SAFETY FEATURES ..................... .168
▫ Anti-Lock Brake System (ABS) .............168
▫ Electronic Brake Control System ............169
 AUXILIARY DRIVING SYSTEMS ............180
▫ Blind Spot Monitoring (BSM) — If Equipped . . .180
▫ Forward Collision Warning (FCW) With Mitigation
Operation — If Equipped .................188
▫ Tire Pressure Monitor System (TPMS) ........195
 OCCUPANT RESTRAINT SYSTEMS ..........203
▫ Occupant Restraint Systems Features ........203
▫ Important Safety Precautions ..............203▫
Seat Belt Systems ..................... .204
▫ Supplemental Restraint Systems (SRS) ........214
▫ Child Restraints ...................... .227
▫ Transporting Pets ..................... .243
 SAFETY TIPS .......................... .243
▫ Transporting Passengers ..................243
▫ Exhaust Gas ......................... .244
▫ Safety Checks You Should Make Inside The
Vehicle ............................. .244
▫ Periodic Safety Checks You Should Make Outside
The Vehicle .......................... .247
5

General Information
The following regulatory statement applies to all radio
frequency (RF) devices equipped in this vehicle:
This device complies with Part 15 of the FCC Rules and
with Industry Canada license-exempt RSS standard(s).
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received,
including interference that may cause undesired operation.
NOTE:Changes or modifications not expressly approved
by the party responsible for compliance could void the
user ’s authority to operate the equipment.
OCCUPANT RESTRAINT SYSTEMS
Some of the most important safety features in your vehicle
are the restraint systems:
Occupant Restraint Systems Features
• Seat Belt Systems
• Supplemental Restraint Systems (SRS) Air Bags
• Child Restraints Some of the safety features described in this section may be
standard equipment on some models, or may be optional
equipment on others. If you are not sure, ask your autho-
rized dealer.
Important Safety Precautions
Please pay close attention to the information in this section.
It tells you how to use your restraint system properly, to
keep you and your passengers as safe as possible.
Here are some simple steps you can take to minimize the
risk of harm from a deploying air bag:
1. Children 12 years old and under should always ride
buckled up in a vehicle with a rear seat.
2. If a child from 2 to 12 years old (not in a rear-facing child restraint) must ride in the front passenger seat, move the
seat as far back as possible and use the proper child
restraint (refer to “Child Restraints” in this section for
further information).
3. Children that are not big enough to wear the vehicle seat belt properly (refer to “Child Restraints” in this section
for further information) should be secured in a vehicle
with a rear seat in child restraints or belt-positioning
booster seats. Older children who do not use child
5
SAFETY 203

restraints or belt-positioning booster seats should ride
properly buckled up in a vehicle with a rear seat.
4. Never allow children to slide the shoulder belt behind them or under their arm.
5. You should read the instructions provided with your child restraint to make sure that you are using it
properly.
6. All occupants should always wear their lap and shoul- der belts properly.
7. The driver and front passenger seats should be moved back as far as practical to allow the front air bags room
to inflate.
8. Do not lean against the door or window. If your vehicle has side air bags, and deployment occurs, the side air
bags will inflate forcefully into the space between occu-
pants and the door and occupants could be injured.
9. If the air bag system in this vehicle needs to be modified to accommodate a disabled person, refer to the “Cus-
tomer Assistance” section for customer service contact
information.WARNING!
•Never place a rear-facing child restraint in front of an
air bag. A deploying passenger front air bag can
cause death or serious injury to a child 12 years or
younger, including a child in a rear-facing child
restraint.
• Only use a rear-facing child restraint in a vehicle
with a rear seat.
Seat Belt Systems
Buckle up even though you are an excellent driver, even on
short trips. Someone on the road may be a poor driver and
could cause a collision that includes you. This can happen
far away from home or on your own street.
Research has shown that seat belts save lives, and they can
reduce the seriousness of injuries in a collision. Some of the
worst injuries happen when people are thrown from the
vehicle. Seat belts reduce the possibility of ejection and the
risk of injury caused by striking the inside of the vehicle.
Everyone in a motor vehicle should be belted at all times.
204 SAFETY

NOTE:The adjustable upper shoulder belt anchorage is
equipped with an Easy Up feature. This feature allows the
shoulder belt anchorage to be adjusted in the upward
position without pushing or squeezing the release button.
To verify the shoulder belt anchorage is latched, pull
downward on the shoulder belt anchorage until it is locked
into position.
WARNING!
• Wearing your seat belt incorrectly could make your
injuries in a collision much worse. You might suffer
internal injuries, or you could even slide out of the
seat belt. Follow these instructions to wear your seat
belt safely and to keep your passengers safe, too.
• Position the shoulder belt across the shoulder and
chest with minimal, if any slack so that it is comfort-
able and not resting on your neck. The retractor will
withdraw any slack in the shoulder belt.
• Misadjustment of the seat belt could reduce the
effectiveness of the safety belt in a crash.
Seat Belts And Pregnant Women
Seat belts must be worn by all occupants including preg-
nant women: the risk of injury in the event of an accident
is reduced for the mother and the unborn child if they are
wearing a seat belt.
Position the lap belt snug and low below the abdomen and
across the strong bones of the hips. Place the shoulder belt
across the chest and away from the neck. Never place the
shoulder belt behind the back or under the arm.
Pregnant Women And Seat Belts
5
SAFETY 211
