NOTE:If snow, ice, mud, or any foreign substance builds
up on the camera lens, clean the lens, rinse with water, and
dry with a soft cloth. Do not cover the lens.
WARNING!
Drivers must be careful when backing up even when
using the Rear Back Up Camera. Always check care-
fully behind your vehicle, and be sure to check for
pedestrians, animals, other vehicles, obstructions, or
blind spots before backing up. You are responsible for
the safety of your surroundings and must continue to
pay attention while backing up. Failure to do so can
result in serious injury or death.
CAUTION!
• To avoid vehicle damage, Rear Back Up Camera
should only be used as a parking aid. The Rear Back
Up Camera is unable to view every obstacle or object
in your drive path.
• To avoid vehicle damage, the vehicle must be driven
slowly when using the Rear Back Up Camera to be
able to stop in time when an obstacle is seen. It is
(Continued)
CAUTION! (Continued)
recommended that the driver look frequently over
his/her shoulder when using the Rear Back Up
Camera.
FOUR WHEEL DRIVE — JEEP ACTIVE DRIVE
(4WD) AND JEEP ACTIVE DRIVE LOW (4WD LOW)
Your vehicle may be equipped with a Power Transfer Unit
(PTU). This system is automatic with no driver inputs or
additional driving skills required. Under normal driving
conditions, the front wheels provide most of the traction. If
the front wheels begin to lose traction, power is shifted
automatically to the rear wheels. The greater the front
wheel traction loss, the greater the power transfer to the
rear wheels.
Additionally, on dry pavement under heavy throttle input
(where one may have no wheel spin), torque will be sent to
the rear in a preemptive effort to improve vehicle launch
and performance characteristics.
6
STARTING AND OPERATING 287

CAUTION!
All wheels must have the same size and type tires.
Unequal tire sizes must not be used. Unequal tire size
may cause failure of the power transfer unit.
Four Wheel Drive (4x4)
The four wheel drive (4WD) is fully automatic in normal
driving mode.
NOTE:It is not possible to carry out the change of mode
when the vehicle exceeds the speed of 75 mph (120 km/h).
Enabling Four Wheel Drive (4x4)
The buttons for the activation of four wheel drive are
located on the device Selec-Terrain and allow you to select
the following:
• 4WD LOCK
• 4WD LOW — (Trailhawk models only) Active Drive Control — If Equipped
The Power Transfer Unit (PTU) is locked to ensure imme-
diate availability of torque to the rear drive axles. This
feature is selectable in AUTO mode and automatic in the
other driving mode. 4WD LOCK can be enabled by the
following ways:
•
When the 4WD LOCK button is pushed.
• When the Selec-Terrain switch is rotated from AUTO to
any other off-road modes.
Selec-Terrain Switch
288 STARTING AND OPERATING

Active Drive With Low Control — (Trailhawk Models
Only)
The 4WD LOW mode helps to improve the off-road
performance in all modes. To enable 4WD Low, please
follow the steps below:
Enabling 4WD LOW
With the vehicle stationary, the ignition in RUN mode or
with the engine running, shift the transmission into NEU-
TRAL and push the button once 4WD LOW. The instru-
ment cluster will display the message4WD LOWonce
the shift is complete. NOTE:
•
Both LOCK and LOW LEDs will blink and then become
active on the Selec-Terrain switch until the shift is
complete.
• The instrument cluster display will illuminate the 4WD
Low icon.
Disabling 4WD LOW
To disable the 4WD LOW mode, the vehicle must be
stationary and the transmission shifted into NEUTRAL.
Push the 4WD LOW button once.
SELEC-TERRAIN
Selec-Terrain combines the capabilities of the vehicle con-
trol systems, along with driver input, to provide the best
performance for all terrains.Selec-Terrain Switch (Trailhawk)
6
STARTING AND OPERATING 289

Mode Selection Guide
Rotate the Selec-Terrain knob to select the desired mode.•AUTO: This four-wheel drive operation is a continuous
operation, is fully automatic and can be used on and off
road. This mode balances traction to ensure maneuver-
ability and acceleration improvement compared to a
vehicle with two wheel drive. This mode also reduces
fuel consumption, since it allows the disconnect of the
drive shaft where conditions permit.
• SNOW: This mode allows you to have greater stability
under conditions of bad weather. It’s used on and off
road and on surfaces with poor traction, such as roads
covered with snow. When in SNOW mode (depending
on certain operating conditions), the transmission will
Selec-Terrain Switch
Selec-Terrain Switch (Trailhawk)
290 STARTING AND OPERATING

use second gear (rather than first gear) during launches,
to minimize wheel slippage, except for in 4–Low (Trail-
hawk models only).
• SAND: For off-road driving or use on surfaces with poor
traction, such as sandy bottoms. The transmission is set
to provide maximum traction. This mode allows more
wheel spin and higher shift points to help motor
through loose areas.
• MUD: For off-road driving or use on surfaces with poor
traction, such as roads covered by mud or wet grass.
• ROCK (Trailhawk only): This mode is only available in
4WD LOW range. The device sets the vehicle to maxi-
mize traction and allow the highest steering capacity for
off-road surfaces. This mode gives you the maximum
performance off-road. Use for low speed obstacles such
as large rocks, deep ruts, etc.
NOTE:
• Rock mode is only available on the vehicles equipped
with the Trailhawk package.
• Activate the Hill Descent Control or Selec Speed Control
for steep downhill control. Refer to “Electronic Brake
Control System” in “Safety” for further information.ADDING FUEL
The Capless Fuel System uses a flapper placed at the filler
pipe of the fuel tank; it opens and closes automatically
upon insertion/extraction of the fuel nozzle.
The Capless Fuel System is designed so that it prevents the
filling of an incorrect type of fuel.
Opening The Door
For filling proceed as follows:
• Open the door, by pushing and releasing on the inden-
tation point indicated by the arrow.
Fuel Filler Door
6
STARTING AND OPERATING 291

•Insert the fuel nozzle in the filler pipe and proceed with
filling the fuel tank.
• Before removing the nozzle, wait at least 10 seconds to
allow the fuel to flow inside of the tank.
• Pull the nozzle from the filler pipe and then close the
door. Emergency Refueling Procedure
If the vehicle is out of fuel proceed as follows:
•
Open the liftgate and remove the emergency fuel fill
funnel located in the cargo area.
Filling Procedure
Emergency Fuel Fill Funnel
292 STARTING AND OPERATING

•Open the fuel door.
• Insert the emergency fuel fill funnel in the filler pipe and
proceed to fill the fuel tank. •
Remove the emergency fuel fill funnel, and close the
door.
• Store the emergency fuel fill funnel in the cargo area.
WARNING!
•Do not to affix objects/plugs to the end of the filler
neck other than is provided on the car.
(Continued)
Emergency Fuel Fill Funnel – If Equipped With Full Size
Spare Tire
Fueling With Emergency Fuel Fill Funnel
6
STARTING AND OPERATING 293

WARNING!(Continued)
•The use of objects/plugs do not comply with the
vehicle and may cause pressure increases inside the
tank, creating dangerous conditions.
• Do not approach the neck of the tank with open
flames or lit cigarettes its an extreme fire hazard.
Also, avoid close contact with the filler pipe with
your face, do not inhale harmful vapors.
• Do not use your mobile phone in the vicinity of the
pump fuel nozzle, it can be a possible risk of fire.
VEHICLE LOADING
Certification Label
As required by National Highway Traffic Safety Adminis-
tration regulations, your vehicle has a certification label
affixed to the driver’s side door or pillar.
This label contains the month and year of manufacture,
Gross Vehicle Weight Rating (GVWR), Gross Axle Weight
Rating (GAWR) front and rear, and Vehicle Identification
Number (VIN). A Month-Day-Hour (MDH) number is
included on this label and indicates the Month, Day and
Hour of manufacture. The bar code that appears on the
bottom of the label is your VIN.
Gross Vehicle Weight Rating (GVWR)
The GVWR is the total permissible weight of your vehicle
including driver, passengers, vehicle, options and cargo.
The label also specifies maximum capacities of front and
rear axle systems (GAWR). Total load must be limited so
GVWR and front and rear GAWR are not exceeded.
Payload
The payload of a vehicle is defined as the allowable load
weight a truck can carry, including the weight of the driver,
all passengers, options and cargo.
Gross Axle Weight Rating (GAWR)
The GAWR is the maximum permissible load on the front
and rear axles. The load must be distributed in the cargo
area so that the GAWR of each axle is not exceeded.
Each axle GAWR is determined by the components in the
system with the lowest load carrying capacity (axle,
springs, tires or wheels). Heavier axles or suspension
components sometimes specified by purchasers for in-
creased durability does not necessarily increase the vehi-
cle’s GVWR.
