2017 JEEP RENEGADE Owners Manual

CavityMaxi FuseCartridge Fuse Micro Fuse Description
F14 ––7.5 Amp Brown Heater Blow By
F14 ––5 Amp Tan Pump Power After
Run
F15 40 Amp Orange ––Brake Control Mod-
ule Pump
F16 ––5 Amp Tan Engine Control Mod-
ule Power, AutomaticTransmission
F17 ––10 Amp Red – 1.4
Engines
15 Amp Blue – 2.4 Engines Supply Primary
Loads
F18 ––20 Amp Yellow 12V Rear Cargo Out-
let Ignition Powered
F19 ––7.5 Amp Brown Air Conditioner
Compressor
F20 ––5 Amp Tan Electronic Power
Four-Wheel Drive
F21 ––15 Amp Blue Fuel Pump
F22 ––20 Amp Yellow Power Control Mod-
ule Engine
7
IN CASE OF EMERGENCY 343

CavityMaxi FuseCartridge Fuse Micro Fuse Description
F23 ––30 Amp Green Heated Windshield –
If Equipped
F24 ––15 Amp Blue Electronic Unit Sup-
ply Automatic Trans-mission
F30 ––20 Amp Yellow
(Customer Installed) 12V Rear Cargo Out-
let Constant Battery Powered
F83 –40 Amp Green –Air Conditioning Fan
F84 ––30 Amp Green Power Supply All
Wheel Drive
F87 ––5 Amp Tan Gear Selector Auto-
matic Transmission
F88 ––7.5 Amp Brown Heated Outside Mir-
rors
F89 ––30 Amp Green Heated Rear Window
F90 ––5 Amp Tan IBS Sensor (Battery
State Of Charge)
344 IN CASE OF EMERGENCY

Body Computer Fuse Center
The controller is located at the left side of the steering
column at the bottom of the instrument panel.
For the fuse replacement see your authorized dealer.
Body Controller Fuse Cavities
7
IN CASE OF EMERGENCY 345

CavityMini FuseDescription
F31 7.5 Amp BrownFlashes/Electrical Movement Front
Seats/Fan Air Conditioning
F33 20 Amp YellowPower Window Front (Driver Side)
F34 20 Amp YellowPower Window Front (Passenger
Side)
F36 15 Amp BlueSupply Uconnect System, Air Condi-
tioning, Alarm, Power Folding Out-
side Mirrors, USB Port
F37 10 Amp RedSystem Power Forward Collision
Warning Plus, All Wheel Drive
(AWD), IPC
F38 20 Amp YellowCentral Locking
F42 7.5 Amp BrownPower Under Lock and Key
F43 20 Amp YellowBi-directional Pump Washer
F47 20 Amp YellowPower Rear Window (Driver Side)
F48 20 Amp YellowPower Rear Window (Passenger Side)
F49 7.5 Amp BrownSupply ParkSense, Spot Lights Front
Dome, Mirror, Electric Motor Retract-
able Roof, Heated Front Seats, Stabi-
lizer Battery, ESC System, ESL
F50 7.5 Amp BrownSupply Air Bag
346 IN CASE OF EMERGENCY

CavityMini FuseDescription
F51 7.5 Amp BrownAlarm Power, Front Courtesy Light,
Air Conditioning Compressor, Brake
Pedal Switch (NC), Plaque Automatic
Transmission, Compass, Rear Cam-
era, Leveling Headlights, Air Condi-
tioning
F53 7.5 Amp BrownSupply IPC/Starter Device/System
Keyless Enter-N-Go
F94 15 Amp BluePower Socket
7
IN CASE OF EMERGENCY 347

Rear Cargo Fuse/Relay Distribution Unit
To access the fuses, remove the access door from the left
rear panel of the rear cargo area.
The fuses may be contained in two units. fuse holder No. 1
is located closest to the rear of the vehicle and fuse holder
No. 2 (if equipped with trailer towing) is located closest to
the front of the vehicle.
Fuse Holder No. 1
CavityMini FuseDescription
F1 30 Amp BluePower Inverter
F2 20 Amp YellowHIFI Audio System
F3 20 Amp YellowMY SKY
F4 7.5 Amp BrownLumbar Adjustment Front Seat
(Driver Side)
Rear Cargo Fuse Cavities
1 — Fuse Holder No. 1
2 — Fuse Holder No. 2
348 IN CASE OF EMERGENCY

CavityMini FuseDescription
F5 30 Amp GreenPower Seat (Driver Side)
F6 7.5 Amp BrownPower Seat (Driver Side And Passen-
ger Side)
F7 30 Amp GreenLumbar Adjustment Front Seats
(Driver Side And Passenger Side)
F8 20 Amp YellowHeating Front Seats
On the controller there is also a 20 amp fuse for the sun
visor of the retractable roof.
Fuse Holder No. 2
Cavity Mini FuseDescription
F1 10 Amp RedController Exterior Lighting On
Trailer
F5 15 Amp BlueController Exterior Lighting Lights
(Drivers Side)
F6 15 Amp BlueController Exterior Lighting Lights
(Passenger Side)
7
IN CASE OF EMERGENCY 349

JACKING AND TIRE CHANGING
WARNING!
•Do not attempt to change a tire on the side of the
vehicle close to moving traffic. Pull far enough off
the road to avoid the danger of being hit when
operating the jack or changing the wheel.
• Being under a jacked-up vehicle is dangerous. The
vehicle could slip off the jack and fall on you. You
could be crushed. Never put any part of your body
under a vehicle that is on a jack. If you need to get
under a raised vehicle, take it to a service center
where it can be raised on a lift.
• Never start or run the engine while the vehicle is on
a jack.
• The jack is designed to be used as a tool for changing
tires only. The jack should not be used to lift the
vehicle for service purposes. The vehicle should be
jacked on a firm level surface only. Avoid ice or
slippery areas.
Jack Location/Spare Tire Stowage
The jack and tools are located in the rear storage compart-
ment if equipped, inside a special container. 1. Open the liftgate.
2. Lift the access cover using the load floor pull strap.
Jack And Tools
1 — Wheel Bolt Wrench
2 — Jack
3 — Emergency Funnel
4 — Wheel Chocks
5 — Screwdriver
6 — Emergency Allen Key
350 IN CASE OF EMERGENCY
