Cargo Load Floor
The vehicle is equipped with a load floor that can be
adjusted as needed.
Position 1 (Lowered Position):
This position allows you to make the load floor flat for ease
of loading/unloading objects from the cargo area. This
position also makes it possible to use the space below as
another compartment for storing fragile or smaller objects.
Adjusting The Rear ShelfRear Shelf Pin
3
GETTING TO KNOW YOUR VEHICLE 103

Position 2 (Elevated Position):
When the rear seatbacks and front passenger seat is folded
flat, it will allow for loading objects of long dimensions. It
is recommended to use this position only during the actual
transporting of the objects, then bring the load floor in
position 1.
Table Tilt Load
In addition to the two positions described above, the load
floor can also be placed in a tilted position (slanted toward
the rear seatbacks as to ease the access to the underlying
zone of the luggage compartment (e.g. to pick up the spare
tire or the Tire Service Kit).
Place the load floor in a way that it rests at the supports 1
and 2 on the sides of the cargo area.
The load floor provides securing of any cargo inside this
position, so that the cargo will slide in the case of sudden
braking.
Load Floor
104 GETTING TO KNOW YOUR VEHICLE

Access To The Loading Floor
To access the double load compartment, proceed as fol-
lows:
1. Lift up on the Load Floor Handle.
Table Tilt Load Supports
1 — Loading Floor Support One
2 — Loading Floor Support Two
Load Floor Handle
1 — Cargo Load Floor
2 — Cargo Load Floor Handle
3
GETTING TO KNOW YOUR VEHICLE 105

2. Place the desired objects inside the compartment.
3. Reposition the load floor.
CAUTION!
The load floor must be arranged in a central position
with respect to cargo area.Displacement Load Floor
To position the load from the lower to the upper position,
proceed as follows:
1. Grasp the load floor handle and lift up the load floor.
2. Correctly place the load floor on the side panel guides
and on the rear cross member.
Access To Tire Service Kit Or Spare Tire
To access the Tire Service Kit or spare tire and container
carrier, proceed as follows:
1. Grasp the load floor handle and remove the floor.
2. Pull the tab and lift up on the carpet.
Anchoring Of The Load
The cargo tie-downs, located on the cargo area floor,
should be used to safely secure loads when the vehicle is
moving.
Cargo Area Storage
106 GETTING TO KNOW YOUR VEHICLE

The side panels may be equipped with three grocery hooks
(one on the left side and two on the right side) for securing
loads that are not excessively heavy.
Tie-DownsGroceryHook
3
GETTING TO KNOW YOUR VEHICLE 107

Cargo Box — If Equipped
The cargo area contains a preformed cargo box that can be
used for the storage of objects that allows you to obtain a
uniform level when loading.NOTE:
The cargo box is sized for a maximum capacity of
distributed weight equal to 242 lbs (110 kg).
Grocery Hooks
Cargo Box
108 GETTING TO KNOW YOUR VEHICLE

INTERNAL EQUIPMENT
Glove Compartment
The glove compartment is located on the passenger ’s side
of the instrument panel.
To open the glove compartment proceed as follows:
1. Unlock the compartment using the vehicle emergencykey.
2. Pull the handle to open the compartment.
Once the glove compartment is open, a light will turn on to
illuminate the compartment.
NOTE:
•Do not insert objects in the glove compartment that will
not allow the compartment to fully close.
• The glove compartment should be completely closed
while the vehicle is in motion.
Opening The Glove Compartment
1 — Glove Compartment Handle
3
GETTING TO KNOW YOUR VEHICLE 109

Sun Visors
Sun visors are located on both sides of the rearview mirror.
The visors can be lowered or moved to the side to help
block sunlight from entering the windshield or door glass.
To move the sun visor against the driver or passenger door
glass, remove the sun visor from the hook and turn it
toward the side window.
The visors also have illuminated vanity mirrors to allow
use in low light conditions.Lift upward on the mirror cover to access the mirror.
Extendible Sun Visor
To extend the sun visor, proceed as follows:
1. Place the sun visor against the door glass by detaching
it from the hook and turning it toward the side window.
2. Slide the visor along the rod to provide coverage more to the rear.
Sun Visor Mirror
1 — Sun Visor Mirror CoverSliding Sun Visor
1 — Sun Visor
