2017 JEEP RENEGADE Owners Manual

5. Remove the bulb from the socket.
6. Insert the new bulb in the socket.
7. Reinstall the bulb and socket into the lamp assembly byturning it clockwise, making sure it is locked into place.
8. Reconnect the electrical connector.
9. Reinstall the lamp assembly on the car, making sure it is locked into place. Side Indicators on External Rear View Mirrors – (If
Equipped)
CAUTION!
The procedure is described as a guideline. For the
replacement of the lamp it is recommended that you
contact your authorized dealer.
To replace the bulb proceed as follows:
1. Remove the mirror cap on the outside rear view mirror.
Bulb
Mirror Cap
7
IN CASE OF EMERGENCY 327

2. Remove the transparent lens assembly as shown. 3. Remove the bulb socket and bulb from the transparentlens assembly by rotating the socket counterclockwise.
Removing the mirror capTransparent Lens
328 IN CASE OF EMERGENCY

4. Remove the bulb from the bulb socket by pulling thebulb straight out.
5. Insert the new bulb, making sure that it is locked intoplace.
6. Reinstall the socket in to the transparent lens assembly.
7. Reinstall the cover on the outside rear view mirror, making sure it is locked into place.
Transparent Lens AssemblyBulb And Socket Assembly
1 — Bulb
2 — Bulb Socket
7
IN CASE OF EMERGENCY 329

Rear Tail Lamps
Contain the following:
•Position lights
• Stop lights
• Direction indicator
• REVERSE lights
To replace the bulbs proceed as follows:
1. Open the liftgate.
2. Using a suitable tool remove the door as shown. 3. Using a suitable tool remove fastener.
4. Disconnect the electrical connector by pushing the re-
lease.
Trim Panel Door
Rear Lamp Fastener and Electrical Connector
1 — Fastener
2 — Electrical Connector
330 IN CASE OF EMERGENCY

5. Remove the rear tail lamp, sliding it toward the outsideas shown. 6. Unscrew the screws and remove the rear tail lamp
holder.
Tail Lamp RemovalRear Lamp Assembly
1 — Mounting Screws
7
IN CASE OF EMERGENCY 331

7. Replace the bulb as necessary.
8. Insert the new bulb, making sure it is properly locked.
9. Reassemble the lamp assembly on the rear tail lamphousing, tightening the screws.
10. Reposition the rear tail lamp on the car.
11. Secure the fastener of the rear tail lamp and reconnect the electrical connector. 12. Reinstall the door making sure of its correct locked.
13. Finally close the tailgate.
Center High Mounted Stop Lamp (CHMSL)
The CHMSL is LED. For replacement see your authorized
dealer.
License Plate Lights
To replace the bulbs proceed as follows:
1. Using a suitable tool remove the license plate lens.
Rear Tail Lamp Holder
1 — Tail Light
2 — Reverse Bulb
3 — Position Light/Stop Light/Turn Signal
License Plate Light Location
332 IN CASE OF EMERGENCY

2. Remove the bulbs from the individual side contacts.
3. Insert the new bulbs, and ensure that they are properlylocked between the contacts.
4. Reinstall the license plate lens.
NOTE: If removal the license plate lens using a screw-
driver, be sure to cover the tip of the screwdriver with a
cloth so no damage is done to the lenses or the vehicle
paint.
Replacing Interior Bulbs
Front Courtesy Light
To replace the bulbs proceed as follows:
1. Using a suitable tool remove the front courtesy light as shown.
License Plate Light
Front Courtesy Light Housing
7
IN CASE OF EMERGENCY 333

2. Release the retainer clips and bulb housing as shown.
3. Replace the bulbs by pulling straight out of bulb hous-ing. 4. Insert the new bulbs, making sure that they are properly
locked.
5. Reassemble the bulb housing and courtesy light housing making sure that they are properly locked.
6. Install the front courtesy light making sure that it is properly locked.
Front Courtesy Bulb Housing
1 — Retaining Clips
2 — Bulb Housing
Front Courtesy Bulb Housing
334 IN CASE OF EMERGENCY
