IGNITION SWITCH
Models With Keyless Enter-N-Go — Passive Entry
This feature allows the driver to operate the ignition switch
with the push of a button as long as the key fob is in the
passenger compartment.
The push button ignition has three operating positions. The
three positions are OFF, ON, and RUN.
NOTE:If the ignition switch does not change with the
push of a button, the key fob may have a low or dead
battery. In this situation, a back up method can be used to
operate the ignition switch. Put the nose side (side opposite
of the emergency key) of the key fob against the ENGINE
START/STOP button and push to operate the ignition
switch. The push button ignition can be placed in the following
positions:
OFF
•
The engine is stopped.
• No electrical devices are available.
ON
• The vehicle is not running.
• Some electrical devices are available
START/STOP Ignition Button
22 GETTING TO KNOW YOUR VEHICLE

NOTE:
•The vehicle must be equipped with an automatic trans-
mission to be equipped with Remote Start.
• Obstructions between the vehicle and key fob may
reduce this range.
Remote Start Cancel Message — If Equipped
The following messages will display in the instrument
cluster if the vehicle fails to remote start or exits remote
start prematurely:
• Remote Start Cancelled — Door Open
• Remote Start Cancelled — Hood Open
• Remote Start Cancelled — Fuel Low
• Remote Start Cancelled — Liftgate Open
• Remote Start Cancelled — Too Cold
• Remote Start Cancelled — Time Expired
• Remote Start Disabled — Start Vehicle To Reset
The message will stay active until the ignition is placed in
the ON/RUN position.
How To Use Remote Start
• Push Remote Start buttonon the key fob twice
within five seconds. Pushing the Remote Start button
a third time shuts the engine off.
• To drive the vehicle, push unlock button, insert the key
in the ignition and turn to the ON/RUN position.
• With remote start, the engine will only run for 15
minutes (timeout) unless the ignition key is placed in the
ON/RUN position.
• The vehicle must be started with the key after two
consecutive timeouts.
All of the following conditions must be met before the
engine will remote start:
• Gear Selector in PARK
• Doors closed
• Hood closed
• Liftgate closed
• Hazard switch off
• Brake switch inactive (brake pedal not pushed)
• Battery at an acceptable charge level
24 GETTING TO KNOW YOUR VEHICLE

•Push the lock button on the interior power door lock
switch with the driver and/or passenger door open.
• Push the lock button on the exterior Passive Entry
Door Handle with a valid key fob available in the same
exterior zone (refer to DoorsinGetting To Know
Your Vehicle for further information).
• Push the lock button on the key fob.
3. If any doors are open, close them.
To Disarm The System
The vehicle security alarm can be disarmed using any of
the following methods:
• Push the unlock button on the key fob.
• Grasp the passive entry door handle to unlock the door,
refer to Doors inGetting To Know Your Vehicle for
further information.
• Cycle the ignition out of the off mode to disarm the
system. NOTE:
•
The driver’s door key cylinder and the liftgate button on
the key fob cannot arm or disarm the vehicle security
alarm.
• The vehicle security alarm remains armed during power
liftgate entry. Pushing the liftgate button will not disarm
the vehicle security alarm. If someone enters the vehicle
through the liftgate and opens any door, the alarm will
sound.
• When the vehicle security alarm is armed, the interior
power door lock switches will not unlock the doors.
The vehicle security alarm is designed to protect your
vehicle. However, you can create conditions where the
system will give you a false alarm. If one of the previously
described arming sequences has occurred, the vehicle
security alarm will arm regardless of whether you are in
the vehicle or not. If you remain in the vehicle and open a
door, the alarm will sound. If this occurs, disarm the
vehicle security alarm.
If the vehicle security alarm is armed and the battery
becomes disconnected, the vehicle security alarm will
3
GETTING TO KNOW YOUR VEHICLE 29

remain armed when the battery is reconnected; the exterior
lights will flash, and the horn will sound. If this occurs,
disarm the vehicle security alarm.
Disabling
To completely disable the alarm (e.g. in the case of long
inactivity of the car), lock the doors by turning the vehicle
key in the exterior door lock cylinder.
NOTE:If the batteries in the key fob discharge in the event
of a failure to the system or to switch off the alarm, place
the ignition in the ON/RUN position.
DOORS
Manual Door Locks
To lock each door, rotate the door lock button on each door
trim panel forward. To unlock the doors, pull the inside
door handle to the first detent or rotate the door lock
button until the lock symbol is no longer visible.
If the lock symbol is visible when the door is shut, the door
will lock. Therefore, make sure the key fob is not inside the
vehicle before closing the door. Locking/Unlocking Doors From Outside
With the doors closed, insert the key blade into the driver
exterior door lock cylinder and turn to the right to lock the
driver’s door.
To unlock the driver ’s door, insert the key blade into the
driver exterior door lock cylinder and turn to the left to
unlock the driver’s door.
NOTE:
The manual lock knob unlocks each individual
door separately.
Manual Door Lock
30 GETTING TO KNOW YOUR VEHICLE

NOTE:The Passive Entry system will not operate if the
key fob battery is dead.
The vehicle doors can also be locked by using the lock
button located on the vehicle’s interior door panel.
Preventing Inadvertent Locking Of Passive Entry Key
Fob In Vehicle (FOBIK-Safe)
To minimize the possibility of unintentionally locking a
Passive Entry key fob inside your vehicle, the Passive Entry
system is equipped with an automatic door unlock feature
which will function if the ignition switch is in the OFF
position. FOBIK-Safe only executes in vehicles with Passive Entry.
There are three situations that trigger a FOBIK-Safe search
in any Passive Entry vehicle:
1. A lock request is made by a valid Passive Entry key fob
while a door is open.
2. A lock request is made by the Passive Entry door handle while a door is open.
3. A lock request is made by the door panel switch while the door is open.
When any of these situations occur, after all open doors are
shut, the FOBIK-Safe search will be executed. If it finds a
Passive Entry key fob inside the car, and it does not find any
Passive Entry key fobs outside the car, then the car will
unlock and alert the customer.
NOTE:The vehicle will only unlock the doors when a valid
Passive Entry key fob is detected inside the vehicle, and no
valid Passive Entry key fob is detected outside the vehicle.
The vehicle will not unlock the doors when any of the
following conditions are met:
•The doors are manually locked using the door lock knobs.
•There is a valid Passive Entry key fob outside the vehicle
and within 5 ft (1.5 m) of either Passive Entry door handle.
DO NOT Grab The Door Handle When Locking
34 GETTING TO KNOW YOUR VEHICLE

To Unlock/Enter The Liftgate
The liftgate Passive Entry unlock feature is built into the
electronic liftgate release. With a valid Passive Entry key
fob within 5 ft (1.5 m) of the liftgate, push the Electronic
Liftgate release to open with one fluid motion.
To Lock The Liftgate
With a valid Passive Entry key fob within 5ft (1.5 m) of the
liftgate, push the Passive Entry lock button located to the
right of electronic liftgate release.
NOTE:
•The liftgate Passive Entry lock button will lock the
liftgate and the doors. The liftgate unlock feature is built
into the Electronic Liftgate release.
• If “Unlock All Doors 1st Press” is programmed in the
instrument cluster display, if equipped, only the liftgate
will unlock when you push the Electronic Release. If
Unlock Driver Door 1st Press is programmed in
Uconnect, the liftgate will unlock when you push the
electronic unlock/lock button on the liftgate. For further
information, refer to “Uconnect Touch Settings” in
“Multimedia.” Emergency Unlocking Driver Door
If the key fob battery is low or dead, the emergency key can
be used to unlock the driver side door lock cylinder.
To release the emergency key, proceed as follows:
1. Slide the emergency key release button to the side.
Liftgate Release/Passive Entry
1 — Electronic Liftgate Release
2 — Liftgate Passive Lock Location
3
GETTING TO KNOW YOUR VEHICLE 35

To operate the courtesy lights, push either the driver or
passenger light switch.
NOTE:
•Before exiting the vehicle, make sure that the interior
lights are turned off. This will prevent the battery from
discharging once the doors are closed.
• If a light is left on, it will automatically be turned off
after approximately 15 minutes after the ignition is in the
OFF position.
Rear Lights
Push the button on the rear dome light once to turn the
light on, the light will remain on at all times. Push the
button a second time to turn the light off, the lights will
remain off at all times.Rear Dome Light
58 GETTING TO KNOW YOUR VEHICLE

Timing Entering The Vehicle
The dome lights illuminate in the following ways:
•When the doors are unlocked, the dome light will
illuminate for approximately 27 seconds.
• When one of the doors is opened, the dome light will
illuminate for approximately three minutes.
• When the doors are closed, the dome light will automati-
cally shut off after approximately 27 seconds.
The timing stops once the ignition is placed in the RUN or
ON position.
The dome light will turn off under any of the following
conditions:
• The dome light is disabled when the ignition is placed in
the RUN or ON position.
• The dome lights will turn off automatically when the
doors are locked.
• The dome lights will automatically turn off after ap-
proximately fifteen minutes of inactivity to preserve the
battery. Timing Exiting The Vehicle
The dome light will illuminate under the following condi-
tions when the ignition is placed to the OFF position and
the key is removed:
•
The dome light will illuminate for 27 seconds after the
ignition is placed in the OFF position.
• The opening of one of the doors (approximately three
minutes).
• After closing a door (approximately 27 seconds).
The dome light timing is disabled when the doors are
locked.
Internal Compartment Lights
Illuminated Vanity Mirrors — If Equipped
An illuminated vanity mirror is located on each sun visor.
To use the mirror, rotate the sun visor down and swing the
mirror cover upward. The lights will turn on automatically.
Closing the mirror cover will turn the light off.
60 GETTING TO KNOW YOUR VEHICLE
