WARNING!
Cargo must be securely tied down before driving your
vehicle. Improperly secured loads can fly off the ve-
hicle, particularly at high speeds, resulting in personal
injury or property damage. Follow the roof rack cau-
tions when carrying cargo on your roof rack.
CAUTION!
•To avoid damage to the roof rack and vehicle, do not
exceed the maximum roof rack load capacity. Always
distribute heavy loads as evenly as possible and
secure the load appropriately.
• Long loads, which extend over the windshield, such
as wood panels or surfboards, should be secured to
both the front and rear of the vehicle.
• Place a blanket or other protection between the
surface of the roof and the load.
• Travel at reduced speeds and turn corners carefully
when carrying large or heavy loads on the roof rack.
Wind forces, due to natural causes or nearby truck
(Continued)
CAUTION! (Continued)
traffic, can add sudden upward loads. This is espe-
cially true on large flat loads and may result in
damage to the cargo or your vehicle.
• Load should always be secured to cross bars first,
with tie down loops used as additional securing
points if needed. Tie loops are intended as supple-
mentary tie down points only. Do not use ratcheting
mechanisms with the tie loops. Check the straps
frequently to be sure that the load remains securely
attached.
3
GETTING TO KNOW YOUR VEHICLE 119

GETTING TO KNOW YOUR INSTRUMENT PANEL
CONTENTS
INSTRUMENT CLUSTER ..................122
▫ Instrument Cluster Descriptions .............123
 INSTRUMENT CLUSTER DISPLAY ...........124
▫ Instrument Cluster Display Location And
Controls ............................ .125
▫ Oil Change Reset ..................... .127
▫ Instrument Cluster Display Menu Items ......127
 TRIP COMPUTER ....................... .133
 WARNING/INDICATOR LIGHTS AND
MESSAGES ........................... .134
▫ Red Telltale Lights .....................134 ▫
Yellow Telltale Lights ....................144
▫ Green Telltale Lights .....................159
▫ Blue Telltale Lights ..................... .161
▫ White Telltale Lights .....................162
▫ Gray Telltale Lights .....................163
 ONBOARD DIAGNOSTIC SYSTEM (OBD II) . . . .164
▫ Onboard Diagnostic System (OBD II)
Cybersecurity ........................ .164
 EMISSIONS INSPECTION AND MAINTENANCE
PROGRAMS .......................... .1654

INSTRUMENT CLUSTER
Base Instrument Cluster
122 GETTING TO KNOW YOUR INSTRUMENT PANEL

Instrument Cluster Descriptions
1. Tachometer•Indicates the engine speed in revolutions per minute
(RPM x 1000). 2. Temperature Gauge
•The temperature gauge shows engine coolant tem-
perature. Any reading within the normal range indi-
cates that the engine cooling system is operating
satisfactorily.
Premium Instrument Cluster
4
GETTING TO KNOW YOUR INSTRUMENT PANEL 123

•The gauge will likely indicate a higher temperature
when driving in hot weather or up mountain grades. It
should not be allowed to exceed the upper limits of the
normal operating range.
WARNING!
A hot engine cooling system is dangerous. You or
others could be badly burned by steam or boiling
coolant. You may want to call an authorized dealer for
service if your vehicle overheats.
CAUTION!
Driving with a hot engine cooling system could dam-
age your vehicle. If the temperature gauge reads “H”
pull over and stop the vehicle. Idle the vehicle with the
air conditioner turned off until the pointer drops back
into the normal range. If the pointer remains on the
“H”, turn the engine off immediately and call an
authorized dealer for service. 3. Instrument Cluster Display
•The instrument cluster display features a driver-
interactive display. Refer to “Instrument Cluster Dis-
play” in “Getting To Know Your Instrument Panel” for
further information.
4. Fuel Gauge •The fuel gauge shows the level of fuel in the fuel tank
when the ignition is in the ON/RUN position
•
The fuel pump symbol points to the side of the
vehicle where the fuel door is located.
5. Speedometer
•Indicates vehicle speed
INSTRUMENT CLUSTER DISPLAY
Your vehicle may be equipped with an instrument cluster
display, which offers useful information to the driver. With
the ignition in the STOP/OFF position, opening/closing of
a door will activate the display for viewing, and display
the total miles, or kilometers, in the odometer. Your instru-
ment cluster display is designed to display important
information about your vehicle’s systems and features.
Using a driver interactive display located on the instru-
ment panel, your instrument cluster display can show you
how systems are working and give you warnings when
124 GETTING TO KNOW YOUR INSTRUMENT PANEL

they aren’t. The steering wheel mounted controls allow
you to scroll through and enter the main menus and
submenus. You can access the specific information you
want and make selections and adjustments.
Instrument Cluster Display Location And Controls
The instrument cluster display features a driver-interactive
display that is located in the instrument cluster.The instrument cluster display menu items consist of the
following:
•
Speedometer
• Driver Assist
• Vehicle Info
• Fuel Economy
• Trip
• Stop And Start — If Equipped
• Audio
• Messages
• Screen Setup
• Settings
Instrument Cluster Display Location
4
GETTING TO KNOW YOUR INSTRUMENT PANEL 125

Setting the system allows the driver to select information
by pushing the following buttons mounted on the steering
wheel:•
UP Arrow Button
Push and release the uparrow button to scroll
upward through the main menu and submenus.
• DOWN Arrow Button
Push and release the downarrow button to scroll
downward through the main menu and
submenus.
• RIGHT Arrow Button
Push and release the rightarrow button to access
the information screens or submenu screens of a
main menu item.
• BACK/LEFT Arrow Button
Push and release the leftarrow button to access
the information screens or submenu screens of a
main menu item.
• OK Button
The OKbutton may be used for the following:
• Select
• Reset (hold)
Instrument Cluster Display Control Buttons
1 — Arrow Up/Down Scroll Through Menus And Submenus
2 — Arrow Right/Left Access Information/Submenu Screens
3 — OK Button For Selecting And Resetting Information
