2015 TOYOTA LAND CRUISER Owners Manual

5
When trouble arises
625
5-2. Steps to take in an emergency
LC200_OM_OM60L83U_(U)
If a warning message is displayed
The multi-information display shows warnings of system malfunc-
tions, incorrectly performed operations, or shows messages that
indicate a need for maintenance.
If a warning is shown on the multi- information display, stay calm and
perform the following actions:
Master warning light
The master warning light also
comes on or flashes in order to
indicate that a message is cur-
rently being displayed on the
multi-information display.
Multi-information display
If any of the warning messages is shown again after its correction
procedure has been performed, contact your Toyota dealer.

626 5-2. Steps to take in an emergency
LC200_OM_OM60L83U_(U)
Have the vehicle inspected immediately.Failure to investigate the cause of the following warnings may lead to
the system operating abnormally and possibly cause an accident.
Have the vehicle inspected by your Toyota dealer immediately.
Warning messageDetails
Indicates a malfunction in the automatic
transmission system A buzzer also sounds.
Indicates a malfunction in the steering lock
system A buzzer also sounds.
(If equipped) Indicates a malfunction in the pre-collision sys-
tem
A buzzer also sounds.

5
When trouble arises
627
5-2. Steps to take in an emergency
LC200_OM_OM60L83U_(U)
Indicates a malfunction in the intuitive parking
assist
The site of malfunction is shown flashing on the
display.
Indicates a malfunction in the cruise control
system Press the “ON-OFF” button once to deactivate
the system, and then press the button again to
reactivate the system.
Indicates a malfunction in the dynamic radar
cruise control system (if equipped) Press the “ON-OFF” button once to deactivate
the system, and then press the button again to
reactivate the system.
(If equipped) Indicates a malfunction in the VGRS
A buzzer also sounds.
Warning messageDetails

628 5-2. Steps to take in an emergency
LC200_OM_OM60L83U_(U)
Follow the correction procedures.After taking the specified steps to correct the suspected problem,
check that the warning message goes off.
Warning messageDetailsCorrection procedure
Indicates that one or
more of the doors is
not fully closed The system also indi-
cates which doors are
not fully closed.
If the vehicle reaches
a speed of 3 mph (5
km/h), flashes
and a buzzer sounds
to indicate that the
door(s) are not yet fully
closed. Make sure that all the
doors are closed.

5
When trouble arises
629
5-2. Steps to take in an emergency
LC200_OM_OM60L83U_(U)
(Flashes)
Indicates that the
moon roof is not fully
closed (with the
“ENGINE START
STOP” switch off, and
the driver’s door
open)
Close the moon roof.
(Flashes) Indicates, if the vehi-
cle reaches a speed of
3 mph (5 km/h), that
the parking brake is
still engaged.
Release the parking
brake.
Indicates that the
automatic transmis-
sion fluid temperature
is too high A buzzer also sounds. Immediately stop the
vehicle in a safe place,
shift the shift lever to “P”
and wait until the light
goes off.
If the light goes off,
you may start the vehi-
cle again. If the light
does not go off, con-
tact your Toyota
dealer.
Warning messageDetailsCorrection procedure

630 5-2. Steps to take in an emergency
LC200_OM_OM60L83U_(U)
Indicates that engine
oil level is lowA buzzer also sounds. Check the level of
engine oil, and add if
necessary.
This message may
appear if the vehicle is
stopped on a slope.
Move the vehicle to a
level surface and
check to see if the
message disappears.
Indicates that the
washer fluid level is
low Add washer fluid
Low tire inflation
pressureCheck the tire
inflation pressure,
and adjust to the
appropriate level.
Warning messageDetailsCorrection procedure

5
When trouble arises
631
5-2. Steps to take in an emergency
LC200_OM_OM60L83U_(U)
*: Refer to the separate “Scheduled Maintenance Guide” or “Owner’s Manual
Supplement” for the maintenance interval applicable to your vehicle. Indicates that all main-
tenance according to
the driven distance on
the maintenance
schedule
* should be
performed soon. If necessary, perform
maintenance.
Comes on approxi-
mately 4500 miles
(7200 km) after the
message has been
reset.
Indicates that all main-
tenance is required to
correspond to the
driven distance on the
maintenance sched-
ule
*. Perform the necessary
maintenance.
Please reset the mes-
sage after the mainte-
nance is performed
(
P. 523)
Comes on approxi-
mately 5000 miles
(8000 km) after the
message has been
reset. (The indicator
will not work properly
unless the message
has been reset.)
Warning messageDetailsCorrection procedure

632 5-2. Steps to take in an emergency
LC200_OM_OM60L83U_(U)
Warning messageDetailsCorrection procedure
(Flashes)
(If equipped) Indicates that the pre-
collision system is not
currently functional
because the grille or
the sensor is dirty
• Check the grille and the
sensor and clean them
if they are dirty.
• In case of overheating, the system will become
functional once the sys-
tem cools down.
Indicates that the pre-
collision system is not
currently functional
due to overheating.
Indicates that intui-
tive parking assist is
dirty or covered with
ice
Clean the sensor.
Indicates that remain-
ing fuel is about 4.0
gal. (15.0 L, 3.3 Imp.
gal.) or less Refuel the vehicle.
