2015 TOYOTA LAND CRUISER Owners Manual

17
LC200_OM_OM60L83U_(U)
B
Talk switch* P. 433
Telephone switches* P. 433
Cruise control switch P. 214, 218
DISP switch P. 194
: If equipped
*: Refer to “Navigation System Owner’s Manual”.
Audio remote controls
(steering switches)
P. 402
Horn P. 182
Vehicles with a dynamic
radar cruise control:
Vehicle-to-vehicle distance button P. 218

18
LC200_OM_OM60L83U_(U)
Pictorial indexInstrument panel
C
Engine (ignition) switch P. 170
Four-wheel drive control switch P. 244
VIEW switch P. 261

19
LC200_OM_OM60L83U_(U)
D
Roll sensing of curtain shield
airbags off switch
P. 131
Headlight cleaner switch P. 213
Outside rear view mirror control switches P. 91
Intuitive parking assist
switch
P. 233
: If equipped
Instrument panel light control knob P. 186
Odometer/trip meter display change
button
P. 183
Tilt and telescopic steering
control switch
P. 87
Card holder P. 478
VSC OFF switch P. 285
Center differential lock/unlockswitch
P. 244
Heated steering wheel
switch
 P. 491
Manual headlight leveling dial P. 202

20
LC200_OM_OM60L83U_(U)
Pictorial indexLuggage compartment
Head restraint angle lever P. 73
Seatback handles P. 64
Tools P. 641
Seatback angle lever P. 60
Warning reflector holder P. 500
Power outlet P. 489

21
LC200_OM_OM60L83U_(U)

22
LC200_OM_OM60L83U_(U)
For your information
Main Owner’s Manual
Please note that this manual applies to all models and explains all equip-
ment, including options. Therefore, you may find some explanations for
equipment not installed on your vehicle.
All specifications provided in this manual are current at the time of printing.
However, because of the Toyota policy of continual product improvement, we
reserve the right to make changes at any time without notice.
Depending on specifications, the vehicle shown in the illustrations may differ
from your vehicle in terms of equipment.
Noise from under vehicle after turning off the engine
Approximately five hours after the engine is turned off, you may hear sound
coming from under the vehicle for several minutes. This is the sound of a fuel
evaporation leakage check and, it does not indicate a malfunction.
Accessories, spare parts and modification of your Toyota
A wide variety of non-genuine spare parts and accessories for Toyota vehi-
cles are currently available in the market. You should know that Toyota does
not warrant these products and is not responsible for their performance,
repair, or replacement, or for any damage they may cause to, or adverse
effect they may have on, your Toyota vehicle.
This vehicle should not be modified with non-genuine Toyota products. Mod-
ification with non-genuine Toyota products could affect its performance,
safety or durability, and may even violate governmental regulations. In addi-
tion, damage or performance problems resulting from the modification may
not be covered under warranty.

23
LC200_OM_OM60L83U_(U)
Installation of a mobile two-way radio system
The installation of a mobile two-way radio system in your vehicle could affect
electronic systems such as:
●Multiport fuel injection system/sequential multiport fuel injection system
● Cruise control system
● Dynamic radar cruise control system
● Anti-lock brake system
● SRS airbag system
● Seat belt pretensioner system
Be sure to check with your Toyota dealer for precautionary measures or spe-
cial instructions regarding installation of a mobile two-way radio system.

24
LC200_OM_OM60L83U_(U)
Vehicle data recordings
Your Toyota is equipped with several sophisticated computers that will record
certain data, such as:
• Engine speed
• Accelerator status
• Brake status
• Vehicle speed
• Shift position
The recorded data varies according to the vehicle grade level and options
with which it is equipped. Furthermore, these computers do not record con-
versations, sounds or pictures.
●Data usage
Toyota may use the data recorded in these computers to diagnose malfunc-
tions, conduct research and development, and improve quality.
Toyota will not disclose the recorded data to a third party except:
• With the consent of the vehicle owner or with the consent of the lessee if the vehicle is leased
• In response to an official request by the police, a court of law or a govern- ment agency
• For use by Toyota in a lawsuit
• For research purposes where the data is not tied to a specific vehicle or vehicle owner
● Usage of data collected through Safety Connect (U.S. mainland only)
If your Toyota has Safety Connect and if you have subscribed to those ser-
vices, please refer to the Safety Connect Telematics Subscription Service
Agreement for information on data collected and its usage.
