2015 TOYOTA LAND CRUISER Owners Manual

441
3-4. Using the hands-free
system (for cellular phone)
3
Interior features
LC200_OM_OM60L83U_(U)
Dialing by inputting a number
Press the talk switch and say “Dial by number”.
Press the talk switch and say the phone number.
Dial by one of the following methods:
a. Press the off-hook switch.
b. Press the talk switch and say “Dial”.
c. Select “Dial” using .
Dialing by inputting a name
Press the talk switch and say “Dial by name”.
Select a registered name to be input by either of the following
methods:
a. Press the talk switch and say a registered name.
b. Press the talk switch and say “List names”. Press the talk
switch when the desired name is being read aloud.
Dial by one of the following methods:
a. Press the off-hook switch.
b. Press the talk switch and say “Dial”.
c. Select “Dial” using .
STEP1
STEP2
STEP3
STEP1
STEP2
STEP3

442 3-4. Using the hands-free system (for cellular phone)
LC200_OM_OM60L83U_(U)
Speed dialingPress the off-hook switch.
Press the preset button in wh ich the desired number is regis-
tered.
Press the off-hook switch.
When receiving a phone call
■ Answering the phone
Press the off-hook switch.
■ Refusing the call
Press the on-hook switch.
Transferring a call
A call can be transferred between the cellular phone and system
while dialing, receiving a call, or during a call. Use one of the follow-
ing methods:
a. Operate the cellular phone.
Refer to the manual that comes with the cellular phone for the oper-
ation of the phone.
b. Press the off-hook switch*1.
c. Press the talk switch and say “Call Transfer”
*2.
*1:This operation can be performed only when transferring a call from the cellular phone to the system during a call.
*2:While the vehicle is in motion, a call cannot be transferred from
the system to the cellular phone.
STEP1
STEP2
STEP3

443
3-4. Using the hands-free
system (for cellular phone)
3
Interior features
LC200_OM_OM60L83U_(U)
Call waiting
When a call is interrupted by an incoming call from a third party, the
following options will become available:
● Answer the incoming call: Press the off-hook switch. (Press the off-
hook switch again as necessary to switch back and forth between
calls.)
● Refuse the incoming call: Press the on-hook switch.
Using the call history memory
Follow the procedure below to use a number stored in the call history
memory:
Press the talk switch and say “Redial” (when using a number
stored in the outgoing call history memory) or “Call back”
(when using a number stored in the incoming call history
memory).
Select the number by either of the following methods:
a. Say “Previous” or “Go back” until the desired number isdisplayed.
b. Select the desired number using .
STEP1
STEP2

444 3-4. Using the hands-free system (for cellular phone)
LC200_OM_OM60L83U_(U)The following operations can be performed:
Dialing: Press the off-hook switch or select “Dial” using a
voice command or .
Storing the number in the phone book: Select “Store” and then
“Confirm” using a voice command or .
Deleting: Select “Delete” and then “Confirm” using a voice
command or .
■
Call waiting
●If your phone does not support HFP Ver. 1.5, this function cannot be
used.
● Call waiting operation may differ depending on your cellular phone and
service provider.
■ Call history
Up to 5 numbers can be stored in each of the outgoing and incoming call his-
tory memories.
■ When talking on the phone
●Do not talk simultaneously with the other party.
● Keep the volume of the receiving voice down. Otherwise, voice echo will
increase.
STEP3

445
3-4. Using the hands-free system (for cellular phone)
3
Interior features
LC200_OM_OM60L83U_(U)
Setting a cellular phone
Registering a cellular phone in the hands-free system allows the
system to function. The following functions can be used for regis-
tered cellular phones:
■ Functions and operation procedures
To enter the menu for each function, follow the steps below.
Press the off-hook switch and select “Setup” using voice
command or .
Select “Phone Setup” using voice command or .
Select one of the following items using voice command or
.
● Registering a cellular phone
“Pair Phone”
● Selecting a cellular phone to be used
“Select Phone”
● Changing the registered name
“Change Name”
● Listing the registered cellular phones
“List Phones”
● Changing the passkey
“Set Passkey”
● Deleting a registered cellular phone
“Delete”
STEP1
STEP2
STEP3

446 3-4. Using the hands-free system (for cellular phone)
LC200_OM_OM60L83U_(U)
Registering a cellular phoneSelect “Pair Phone” using a voice command or , and perform
the procedure for registering a cellular phone. ( P. 434)
Selecting a cellular phone to be used
Select “Connect Phone (Connect)” using a voice command or
.
Pattern A Select a cellular phone to be used by either of the following
methods, and select “Confirm” using a voice command or
:
a. Press the talk switch and say the name of the desired phone.
b. Press the talk switch and say “List Phones”. When the name of the desired cellular phone is read aloud, press the
talk switch.
Pattern B
Select a cellular phone to be used using .
STEP1
STEP2
STEP2

447
3-4. Using the hands-free
system (for cellular phone)
3
Interior features
LC200_OM_OM60L83U_(U)
Changing the registered name of a cellular phone
Select “Change Name” using a voice command or .
Pattern A Select a name of cellular phone to be changed by either of the
following methods, and select “Confirm” using a voice com-
mand or .
a. Press the talk switch and say the name of the desiredphone.
b. Press the talk switch an d say “List phones”. When the
name of the desired phone is being read aloud, press the
talk switch.
Pattern B
Select the desired phone name to be changed by using
.
Press the talk switch or select “Record Name” using ,
and say a new name.
Select “Confirm” using a voice command or .
STEP1
STEP2
STEP2
STEP3
STEP4

448 3-4. Using the hands-free system (for cellular phone)
LC200_OM_OM60L83U_(U)
Listing the registered cellular phonesSelecting “List Phones” using a voice command or . The list of
registered cellular phones to be read aloud.
When listing is complete, the system returns to “Phone Setup”.
Pressing the talk switch while a name of cellular phone is being read
selects the cellular phone, and the following functions will become
available:
● Selecting a cellular phone: “Connect Phone (Connect)”
● Changing a registered name: “Change Name”
● Deleting a cellular phone: “Delete Phone”
