2012 INFINITI G37 Owners Manual

Black plate (456,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]9-6 Technical and consumer informationlimited warranty.
. E-85 is a mixture of approximately 85%
fuel ethanol and 15% unleaded gasoline.
. U.S. government regulations require
ethanol dispensing pumps to be identi-
fied by a small, square, orange and black
label with the common abbreviation or
the appropriate percentage for that
region. STI0505
1. API certification mark
2. API service symbol
ENGINE OIL AND OIL FILTER RE-
COMMENDATION GUID-5DAF484B-5225-4882-BA4B-DB4830EFE0AF
Selecting the correct oil GUID-7E56B07C-FA31-476B-909A-6FD2C08A7626
It is essential to choose the correct grade,
quality, and viscosity engine oil to ensure
satisfactory engine life and performance,
see “ Capacities and recommended fuel/
lubricants ” (P.9-2). INFINITI recommends
the use of an energy conserving oil in
order to improve fuel economy.
Select only engine oils that meet the American Petroleum Institute (API) certifi-
cation or International Lubricant Standar-
dization and Approval Committee (ILSAC)
certification and SAE viscosity standard.
These oils have the API certification mark
on the front of the container. Oils which do
not have the specified quality label should
not be used as they could cause engine
damage.
Oil additives GUID-11AD1E70-8EAE-4D70-880A-3AA3882862D5
INFINITI does not recommend the use of oil
additives. The use of an oil additive is not
necessary when the proper oil type is used
and maintenance intervals are followed.

Black plate (457,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]Oil which may contain foreign matter or
has been previously used should not be
used.
Oil viscosity GUID-6FE50DBA-A088-4DF7-B955-855B7BC409B7
The engine oil viscosity or thickness
changes with temperature. Because of this,
it is important that the engine oil viscosity
be selected based on the temperatures at
which the vehicle will be operated before
the next oil change. Choosing an oil
viscosity other than that recommended
could cause serious engine damage.
Selecting the correct oil filter GUID-FFA0543F-C4EE-4AB0-A3D3-B35085A1CBFE
Your new vehicle is equipped with a high-
quality genuine NISSAN oil filter. When
replacing, use the genuine oil filter or its
equivalent for the reason described in
change intervals.
Change intervals GUID-9DC392AF-E881-459C-941F-E42A7567649C
The oil and oil filter change intervals for
your engine are based on the use of the
specified quality oils and filters. Oil and
filter other than the specified quality, or oil
and filter change intervals longer than
recommended could reduce engine life.
Damage to engines caused by improper
maintenance or use of incorrect oil and filter quality and/or viscosity is not covered
by the new INFINITI vehicle limited warran-
ties.
Your engine was filled with a high quality
engine oil when it was built. You do not
have to change the oil before the first
recommended change interval. Oil and
filter change intervals depend upon how
you use your vehicle. Operation under the
following conditions may require more
frequent oil and filter changes.
. repeated short distance driving at cold
outside temperatures,
. driving in dusty conditions,
. extensive idling,
. stop and go “ rush hour ” traffic,
Refer to the “ INFINITI Service and Main-
tenance Guide ” for the maintenance sche-
dule.
AIR CONDITIONING SYSTEM RE-
FRIGERANT AND LUBRICANT RE-
COMMENDATIONS GUID-A6645D62-AEB6-4D99-B362-51EC90BEBB5E
The air conditioning system in your
INFINITI vehicle must be charged with the
refrigerant HFC-134a (R-134a) and the
lubricant, NISSAN A/C system oil Type S
or the exact equivalents. CAUTION The use of any other refrigerant or lubricant
will cause severe damage to the air con-
ditioning system and will require the repla-
cement of all air conditioner system
components.
The refrigerant HFC-134a (R-134a) in your
INFINITI vehicle will not harm the earth ’ s
ozone layer. Although this refrigerant does
not affect the earth ’ s atmosphere, certain
governmental regulations require the re-
covery and recycling of any refrigerant
during automotive air conditioning system
service. Your INFINITI retailer has the
trained technicians and equipment needed
to recover and recycle your air conditioning
system refrigerant.
Contact an INFINITI retailer when servicing
your air conditioning system.
Technical and consumer information
9-7

Black plate (458,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]9-8 Technical and consumer information GUID-FFBD2EF3-5719-47E5-B112-89129991741B
ENGINE GUID-0847A1B6-AE80-4107-9ADC-D17B43B8EBB3
Model VQ25HR VQ37VHR
Type Gasoline, 4-cycle Gasoline, 4-cycle
Cylinder arrangement 6-cylinder, V-slanted at 60 8 6-cylinder, V-slanted at 60 8
Bore 6 Stroke in (mm) 3.346 6 2.886 (85.0 6 73.3) 3.760 6 3.385 (95.5 6 86.0)
Displacement cu in (cm 3
) 152.31 (2,496) 225.54 (3,696)
Firing order 1-2-3-4-5-6 1-2-3-4-5-6
Idle speed rpm
No adjustment is necessary. No adjustment is necessary.
Ignition timing (B.T.D.C.) degree/
rpm
Spark plug Standard FXE22HR-11 FXE24HR-11
Spark plug gap (Normal) in (mm) 0.043 (1.1) 0.043 (1.1)
Camshaft operation Timing chain Timing chain
This spark ignition system complies with the Canadian standard ICES-002. STI0425
VQ25HR/VQ37VHR engineSPECIFICATIONS

Black plate (459,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]WHEELS AND TIRES GUID-3E66521D-4D31-4794-BCBE-4477CC2BE529
Road wheel GUID-276AC0FC-4962-4E9B-81A8-E48824CCC7A1
Sedan: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Type Size Offset in (mm)
Conventional 17 6 7-1/2J 1.77 (45)
18 6 7-1/2J 1.77 (45)
Front:
Rear: 18 6 7-1/2J
18 6 8-1/2J 1.77 (45)
1.97 (50)
Spare 17 6 4T
18 6 4T 1.18 (30)
0 (0)
Coupe: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Type Size Offset in (mm)
Conventional 18 6 8J
19 6 8-1/2J 1.69 (43)
Front:
Rear: 19 6 8-1/2J
19 6 9J 1.69 (43)
1.77 (45)
Spare 17 6 4T
18 6 4T 1.18 (30)
0 (0)
Technical and consumer information
9-9

Black plate (460,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]9-10 Technical and consumer informationTire GUID-E0E1E325-F539-434E-9CA5-8DD4F6541484
Sedan: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Type Size Pressure PSI (kPa) [Cold]
Conventional P225/55R17 95V
33 (230)P225/50R18 94V
Front:
Rear: 225/50R18 95W
245/45R18 96W
Spare (T-type) T145/80D17 107M
T145/70R18 107M 60 (420)
Coupe: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Type Size Pressure PSI (kPa) [Cold]
Conventional P225/50R18 94V 33 (230)
P225/45R19 92V 35 (240)
Front:
Rear: 225/45R19 92W
245/40R19 94W 35 (240)
Spare (T-type) T145/80D17 107M
T145/70R18 107M 60 (420)

Black plate (461,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]DIMENSIONS GUID-F7D80962-40E2-4E0D-84D0-66CBC3C97D89
in (mm)
Sedan:
Overall length (with front
license plate) 188.1 (4,779)
189.0 (4,800)*10
Overall length (without
front license plate) 187.9 (4,773)
189.0 (4,800)*10
Overall width 69.8 (1,773)
Overall height 57.2 (1,453)*1*2
57.8 (1,468)*4
Front tread 59.8 (1,520)
Rear tread 59.8 (1,520)*2
60.2 (1,530)*1*3*4
Wheelbase 112.2 (2,850)
Coupe:
Overall length (with front
license plate) 183.2 (4,653)*8
183.8 (4,669)*9
185.2 (4,705)*11
Overall length (without
front license plate) 183.1 (4,650)*8
183.7 (4,665)*9
185.0 (4,700)*11
Overall width 71.8 (1,823)
Overall height 54.8 (1,390)*5
54.9 (1,393)*6
55.4 (1,406)*7
Front tread 60.8 (1,545)
Rear tread 61.4 (1,560)
Wheelbase 112.2 (2,850) *1: Sedan/Two-Wheel Drive (2WD)/17-in
tire models
*2: Sedan/Two-Wheel Drive (2WD)/18-in
tire models (FR: 225/50R18, RR:
245/45R18)
*3: Sedan/Two-Wheel Drive (2WD)/18-in
tire models (FR, RR: 225/50R18)
*4: Sedan/All-Wheel Drive (AWD) models
*5: Coupe/Two-Wheel Drive (2WD)/18-in
tire models
*6: Coupe/Two-Wheel Drive (2WD)/19-in
tire models
*7: Coupe/All-Wheel Drive (AWD) models
*8: Coupe/Standard models
*9: Coupe/Sports models
*10: Sedan/Aerodynamic Package models
*11: Coupe/INFINITI Performance Line,
Aerodynamic Package models GUID-F8B625EB-7D94-4B40-9FAF-F75725369B65
If you plan to travel in another country,
you should first find out if the fuel
available is suitable for your vehicle ’ s
engine.
Using fuel with too low an octane rating
may cause engine damage. All gasoline
vehicles must be operated with unleaded
gasoline. Therefore, avoid taking your
vehicle to areas where appropriate fuel is
not available.
When transferring the registration of your
vehicle to another country, state, province
or district, it may be necessary to modify
the vehicle to meet local laws and regula-
tions.
The laws and regulations for motor vehicle
emission control and safety standards vary
according to the country, state, province or
district; therefore, vehicle specifications
may differ.
When any vehicle is to be taken into
another country, state, province or district
and registered, its modifications, trans-
portation, and registration are the respon-
sibility of the user. INFINITI is not
responsible for any inconvenience that
may result.
Technical and consumer information
9-11WHEN TRAVELING OR REGISTERING YOUR
VEHICLE IN ANOTHER COUNTRY

Black plate (462,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]9-12 Technical and consumer information GUID-4E2739FE-BAC9-4C7E-9643-38D98DC0DF3E
STI0431
VEHICLE IDENTIFICATION NUMBER
(VIN) PLATE GUID-987915D8-5A47-485F-B45B-A0C946DC386D
The vehicle identification number plate is
attached as shown. This number is the
identification for your vehicle and is used
in the vehicle registration. STI0492
VEHICLE IDENTIFICATION NUMBER
(chassis number) GUID-E9B6A346-25E3-4CD9-AD1F-87C2F34BAF8F
The number is stamped as shown in the
engine compartment. STI0509
ENGINE SERIAL NUMBER GUID-AB9E2BE3-5E93-4FA6-B294-3DDECD921BB9
The number is stamped on the engine as
shown.VEHICLE IDENTIFICATION

Black plate (463,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]STI0493
Sedan
STI0707
Coupe F.M.V.S.S./C.M.V.S.S. CERTIFICA-
TION LABEL GUID-AD70BE4F-4C8D-4062-B271-02A93608BDBA
The Federal/Canadian Motor Vehicle Safety
Standards (F.M.V.S.S./C.M.V.S.S.) certifica-
tion label is affixed as shown. This label
contains valuable vehicle information, such
as: Gross Vehicle Weight Ratings (GVWR),
Gross Axle Weight Rating (GAWR), month
and year of manufacture, Vehicle Identifi-
cation Number (VIN), etc. Review it care-
fully. STI0422
EMISSION CONTROL INFORMATION
LABEL GUID-CDFD071D-BEC0-4813-BF04-0E5BE8756958
The emission control information label is
attached as shown.
Technical and consumer information
9-13
