2012 INFINITI G37 Owners Manual

Black plate (104,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]2-26 Instruments and controls SIC3264
TRIP COMPUTER GUID-FA55F5BE-A6B8-4E7E-AC55-ED2A35F5EAE6
Switches for the trip computer are located
on the right side of the combination meter
panel. To operate the trip computer, push
the side or front of the switches as shown
above.
* A
switch
* B
switch
When the ignition switch is pushed to the
ON position, modes of the trip computer
can be selected by pushing the
switch
* A
.
Each time the
switch
* A
is pushed, the
display will change as follows: Current fuel consumption ? Average fuel
consumption and speed ? Elapsed time
and trip odometer ? Distance to empty
(dte) ? Outside air temperature (ICY) ?
Setting ? Warning check
1. Current fuel consumption GUID-68872F59-1473-4975-A038-16336C4914A6
The current fuel consumption mode shows
the current fuel consumption.
2. Average fuel consumption (MPG
or l (liter)/100 km) and speed (MPH
or km/h) GUID-970652AF-3316-41FA-92BD-2EBCE8A3AE40
Fuel consumption: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
The average fuel consumption mode shows
the average fuel consumption since the
last reset. Resetting is done by pushing the
switch
* B
for longer than 1 second.
(The average speed is also reset at the
same time.)
The display is updated every 30 seconds.
At about the first 1/3 mile (500 m) after a
reset, the display shows “——” .
Speed: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
The average speed mode shows the
average vehicle speed since the last reset.
Resetting is done by pushing the
switch
* B
for longer than 1 second. (The average fuel consumption is also reset
at the same time.)
The display is updated every 30 seconds.
The first 30 seconds after a reset, the
display shows “——” .
3. Elapsed time and trip odometer
(mls or km) GUID-30877500-42E1-4C43-AC8D-A3CFB91E6B66
Elapsed time: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
The elapsed time mode shows the time
since the last reset. The displayed time can
be reset by pushing the
switch
* B
for
longer than 1 second. (The trip odometer is
also reset at the same time.)
Trip odometer: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
The trip odometer mode shows the total
distance the vehicle has been driven since
the last reset. Resetting is done by pushing
the
switch
* B
for longer than 1
second. (The elapsed time is also reset at
the same time.)
4. Distance to empty (dte — mls or
km) GUID-B742AF0B-DD41-497D-AF93-CAE2072D2205
The distance to empty (dte) mode provides
you with an estimation of the distance that
can be driven before refueling. The dte is
constantly being calculated, based on the

Black plate (105,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]amount of fuel in the fuel tank and the
actual fuel consumption.
The display is updated every 30 seconds.
The dte mode includes a low range warning
feature. If the fuel level is low, the warning
is displayed on the screen.
When the fuel level drops even lower, the
dte display will change to “——” .
. If the amount of fuel added is small, the
display just before the ignition switch
is pushed to the OFF position may
continue to be displayed.
. When driving uphill or rounding curves,
the fuel in the tank shifts, which may
momentarily change the display.
5. Outside air temperature (ICY — 8 F
or 8 C) GUID-35621BA5-D61E-4ECD-9628-F300D193449A
The outside air temperature is displayed in
8 F or 8 C in the range of − 22 to 131 8 F ( − 30
to 55 8 C).
The outside air temperature mode includes
a low temperature warning feature. If the
outside air temperature is below 37 8 F
(3 8 C), the warning is displayed on the
screen.
The outside temperature sensor is located
in front of the radiator. The sensor may be affected by road or engine heat, wind
directions and other driving conditions.
The display may differ from the actual
outside temperature or the temperature
displayed on various signs or billboards.
6. Setting GUID-9F18B5C6-F437-4D24-B240-415AA28B0E09
Setting cannot be made while driving. A
message “ Setting can only be operated
when stopped ” is also displayed on the
dot matrix crystal display.
The
switch
* A
and switch
* B
are
used in the setting mode to select and
decide a menu.
SKIP: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Push the switch
* A
to move to the
warning check mode.
Push the
switch
* B
to select other
menus.
ALERT: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
There are 3 submenus under the alert
menu.
. BACK
Select this submenu to return to the top
page of the setting mode.
. TIME TO REST
Select this submenu to specify when the “ time to rest ” indicator activates.
. ICY
Select this submenu to display the low
outside temperature warning.
MAINTENANCE: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
There are 5 submenus under the main-
tenance menu.
. BACK
Select this submenu to return to the top
page of the setting mode.
. ENGINE OIL
Select this submenu to set or reset the
distance for changing the engine oil.
. OIL FILTER
Select this submenu to set or reset the
distance for replacing the oil filter.
. TIRE
Select this submenu to set or reset the
distance for replacing tires.
. OTHER
Select this submenu and set or reset
the distance for replacing items other
than the engine oil, oil filter and tires.
DISPLAY: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
There are 3 submenus under the display
menu.
Instruments and controls
2-27

Black plate (106,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]2-28 Instruments and controls. BACK
Select this submenu to return to the top
page of the setting mode.
. LANGUAGE
Select this submenu to choose English
or French for display.
. UNIT
Select this submenu to choose the unit
from MPG or l/100 km.
7. Warning check GUID-482A5E02-822A-440D-A025-9008CF97C341
SKIP: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Push the switch
* A
to move to the
warning check mode.
Push the
switch
* B
to select other
menus.
DETAIL: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
This item is available only when a warning
is displayed.
Select this menu to see the details of
warnings. GUID-DFF4C042-E077-4731-87B8-3AE0A5EBC365
SIC2132
Your vehicle has two types of security
systems, as follows:
. Vehicle security system
. INFINITI Vehicle Immobilizer System
The security condition will be shown by the
security indicator light. VEHICLE SECURITY SYSTEM GUID-171432EC-AF0D-4FCE-9944-7525D5E43E15
The vehicle security system provides visual
and audio alarm signals if someone opens
the doors, hood, or trunk lid when the
system is armed. It is not, however, a
motion detection type system that acti-
vates when a vehicle is moved or when a
vibration occurs.
The system helps deter vehicle theft but
cannot prevent it, nor can it prevent the
theft of interior or exterior vehicle compo-
nents in all situations. Always secure your
vehicle even if parking for a brief period.
Never leave your Intelligent Key(s) in the
vehicle, and always lock it when unat-
tended. Be aware of your surroundings,
and park in secure, well-lit areas whenever
possible.
Many devices offering additional protec-
tion, such as component locks, identifica-
tion markers, and tracking systems, are
available at auto supply stores and speci-
alty shops. Your INFINITI retailer may also
offer such equipment. Check with your
insurance company to see if you may be
eligible for discounts for various theft
protection features.SECURITY SYSTEMS

Black plate (107,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]SIC2045
How to arm the vehicle security
system GUID-284AD2C3-F1E7-4BEE-9749-AD5EE84FDA8A
1. Close all windows.
The system can be armed even if the
windows are open.
2. Push the ignition switch to the OFF
position.
3. Remove the Intelligent Key from the
vehicle.
4. Close all doors, hood and trunk. Lock
all doors. The doors can be locked with
the Intelligent Key, door handle request
switch, power door lock switch or
mechanical key. 5. Confirm that the security indicator light
comes on. The security indicator light
stays on for about 30 seconds. The
vehicle security system is now pre-
armed. After about 30 seconds the
vehicle security system automatically
shifts into the armed phase. The
security light begins to flash once every
approximately 3 seconds. If, during this
30-second pre-arm time period, the
door is unlocked, or the ignition switch
is pushed to ACC or ON, the system will
not arm.
Even when the driver and/or passengers
are in the vehicle, the system will activate
with all doors, hood, and trunk lid locked
with the ignition switch in the LOCK
position. When pushing the ignition switch
to the ACC or ON position, the system will
be released.
Vehicle security system activation GUID-957137B0-269E-4187-8DB6-D258DE6DE960
The vehicle security system will give the
following alarm:
. The headlights blink and the horn
sounds intermittently.
. The alarm automatically turns off after
approximately 1 minute. However, the
alarm reactivates if the vehicle is tampered with again.
The alarm is activated by:
. Unlocking the door or opening the trunk
lid without using the button on the
Intelligent Key, the door handle request
switch or the mechanical key. (Even if
the door is opened by releasing the
door inside lock knob, the alarm will
activate.)
. Opening the hood.
How to stop an activated alarm GUID-8B3CB6FD-B499-42C1-8E7D-2ABD15A79496
The alarm will stop by unlocking a door by
pushing the unlock button on the Intelli-
gent Key, the door handle request switch
or using the mechanical key. The alarm will
not stop if the ignition switch is pushed to
the ACC or ON position.
If the system does not operate as de-
scribed above, have it checked by an
INFINITI retailer.
Instruments and controls
2-29

Black plate (108,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]2-30 Instruments and controlsINFINITI VEHICLE IMMOBILIZER
SYSTEM GUID-CB62A730-6D41-4D19-9D5A-68BEE6A43E01
The INFINITI Vehicle Immobilizer System
will not allow the engine to start without
the use of the registered Intelligent Key.
Never leave these keys in the vehicle.
Statement related to section 15 of FCC
rules for INFINITI Vehicle Immobilizer
System (CONT ASSY - CARD SLOT)
FCC Notice:
For USA:
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any interfer-
ence received, including interference that
may cause undesired operation.
NOTE:
Changes or modifications not expressly
approved by the party responsible for
compliance could void the user ’ s authority
to operate the equipment. For Canada:
This device complies with RSS-210 of
Industry Canada. Operation is subject to
the following two conditions: (1) this
device may not cause interference, and
(2) this device must accept any interfer-
ence, including interference that may
cause undesired operation of the device.
SIC2045
Security indicator light GUID-8038519A-3397-41F4-B7BF-EDCD0A1F79A5
The security indicator light is located on
the meter panel. It indicates the status of
the INFINITI Vehicle Immobilizer System.
The light blinks after the ignition switch
was in the LOCK position. This function
indicates the security systems equipped on
the vehicle are operational.
If the INFINITI Vehicle Immobilizer System
is malfunctioning, this light will remain on
while the ignition switch is in the ON
position.

Black plate (109,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]If the light still remains on and/or the
engine will not start, see an INFINITI
retailer for INFINITI Vehicle Immobilizer
System service as soon as possible.
Please bring all Intelligent Keys that you
have when visiting an INFINITI retailer for
service. GUID-F861DBAC-D3C0-40F5-B785-25CB05F6F2E4
WARNING In freezing temperatures the washer solu-
tion may freeze on the windshield and
obscure your vision which may lead to an
accident. Warm windshield with the defros-
ter before you wash the windshield.
CAUTION . Do not operate the washer continuously
for more than 30 seconds.
. Do not operate the washer if the
reservoir tank is empty.
. Do not fill the window washer reservoir
tank with washer fluid concentrates at
full strength. Some methyl alcohol
based washer fluid concentrates may
permanently stain the grille if spilled
while filling the window washer reser-
voir tank.
. Pre-mix washer fluid concentrates with
water to the manufacturer ’ s recom-
mended levels before pouring the fluid
into the window washer reservoir tank.
Do not use the window washer reservoir tank to mix the washer fluid concentrate
and water.
Instruments and controls
2-31WINDSHIELD WIPER AND WASHER SWITCH

Black plate (110,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]2-32 Instruments and controls SIC3238
Type A
SIC4281
Type B The windshield wiper and washer operates
when the ignition switch is in the ON
position.
Push the lever down to operate the wiper
at the following speed:
* 1
Intermittent — intermittent operation
can be adjusted by turning the knob
toward
* A
(Slower) or
* B
(Faster).
When the speed sensing wiper inter-
val function is turned on, the inter-
mittent operation speed varies in
accordance with the vehicle speed.
(For example, when the vehicle speed
is high, the intermittent operation
speed will be faster.) To turn this
function on and off, see “ How to use
SETTING button ” (P.4-14).
For models with the rain-sensing auto
wiper system, see “ Rain-sensing auto
wiper system ” (P.2-33).
* 2
Low — continuous low speed opera-
tion
* 3
High — continuous high speed opera-
tion
Push the lever up
* 4
to have one sweep
operation of the wiper.
Pull the lever toward you
* 5
to operate the
washer. Then the wiper will also operate several times.

Black plate (111,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]SIC4190
RAIN-SENSING AUTO WIPER SYS-
TEM (if so equipped) GUID-48081641-8F6B-4F78-BAA1-DC74FECCE041
The rain-sensing auto wiper system can
automatically turn on the wipers and
adjust the wiper speed depending on the
rainfall and the vehicle speed by using the
rain sensor located on the upper part of
the windshield.
To set the rain-sensing auto wiper system,
push the lever down to the AUTO position
* 1
. The wiper will sweep once while the
ignition switch is in the ON position.
The rain sensor sensitivity level can be
adjusted by turning the knob toward the front
* 2
(High) or toward the rear
* 3
(Low).
. High — High sensitive operation
. Low — Low sensitive operation
To turn the rain-sensing auto wiper system
off, push up the lever to the OFF position,
or pull down the lever to the LO or HI
position.
CAUTION Do not touch the rain sensor and around it
when the wiper switch is in the AUTO
position and the ignition switch is in the
ON position. The wipers may operate un-
expectedly and cause to an injury or a wiper
damage.
. The rain-sensing auto wipers are in-
tended for use during rain. If the switch
is left in the AUTO position, the wipers
may operate unexpectedly when dirt,
fingerprints, oil film or insects are
stuck on or around the sensor. The
wipers may also operate when exhaust
gas or moisture affect the rain sensor.
. The rain-sensing auto wipers may not
operate if rain does not hit the rain sensor even if it is raining.
. When the windshield glass is coated
with water repellent, the speed of the
rain-sensing auto wipers may be high-
er even though the amount of the
rainfall is small.
. Be sure to turn off the rain-sensing
auto wiper system when you use a car
wash.
. Using genuine wiper blades is recom-
mended for proper operation of the
rain-sensing auto wiper system. (See
“ Windshield wiper blades ” (P.8-22) for
wiper blade replacement.)
Instruments and controls
2-33
