[ Edit: 2012/ 1/ 17 Model: V36-D ]4-30 Monitor, climate, audio, phone and voice recognition systems. Objects on the monitor may not be clear
in a dark place or at night. This is not a
malfunction.
. If dirt, rain or snow attaches to the
camera, the rearview monitor may not
clearly display objects. Clean the cam-
era.
. Do not use alcohol, benzine or thinner
to clean the camera. This will cause
discoloration. To clean the camera,
wipe with a cloth dampened with
diluted mild cleaning agent and then
wipe with a dry cloth.
. Do not damage the camera as the
monitor screen may be adversely af-
fected.
. Do not use wax on the camera window.
Wipe off any wax with a clean cloth
dampened with mild detergent diluted
with water. GUID-FF3BF386-CA16-4E70-96E6-5D697D98198B
SAA1499
Center ventilators
SAA1500
Side ventilators SAA0564B
Rear (if so equipped)
Open or close, and adjust the air flow
direction of ventilators. : This symbol indicates that the vents are
closed.
: This symbol indicates that the vents are open.VENTILATORS

Black plate (209,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]GUID-75B26382-3BA8-4480-A2A3-F834A9B75BC4
WARNING. The air conditioner cooling function
operates only when the engine is run-
ning.
. Do not leave children or adults who
would normally require the support of
others alone in your vehicle. Pets should
not be left alone either. On hot, sunny
days, temperatures in a closed vehicle
could quickly become high enough to
cause severe or possibly fatal injuries to
people or animals.
. Do not use the recirculation mode for
long periods as it may cause the interior
air to become stale and the windows to
fog up.
Start the engine and operate the automatic
climate control system.
When the “ STATUS ” button is pushed, the
automatic climate control status screen
will appear. (See “ How to use STATUS
button ” (P.4-9).) SAA2723
Models with navigation system
SAA1520
Models without navigation system You can individually set the driver and front
passenger side temperature using each
temperature control button (if so
equipped).
Monitor, climate, audio, phone and voice recognition systems
4-31AUTOMATIC CLIMATE CONTROL

Black plate (210,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-32 Monitor, climate, audio, phone and voice recognition systems SAA1527
Type A
1. “ AUTO ” automatic climate control ON
button/Temperature control dial (dri-
ver side)
2. “ A/C ” air conditioner ON/OFF button
3. “
” fan speed increase button
4. “
” front defroster button
5. “ MODE ” manual air flow control but-
ton
6. “ DUAL ” zone control ON/OFF button/
Temperature control dial (passenger
side)
7. “ OFF ” button for climate control sys-
tem 8. “
” fan speed decrease button
9. “ ” rear window defroster button
(See “ Rear window and outside mirror
defroster switch ” (P.2-34).)
10. “
” intake air control button
AUTOMATIC CLIMATE CONTROL
(Type A) GUID-151D8DEB-308A-4CDF-88B6-06B2B74B49FD
Automatic operation GUID-8195D784-259C-4F5D-A82B-8C0A6AA48082
Cooling and/or dehumidified heating
(AUTO): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
This mode may be used all year round. The
system works automatically to control the inside temperature, air flow distribution
and fan speed after the preferred tempera-
ture is set manually.
1. Push the “ AUTO ” button on. (The
indicator on the button will illuminate
and AUTO will be displayed.)
2. Turn the temperature control dial (dri-
ver side) to set the desired tempera-
ture. .
The temperature can be set within
the following range.
— For U.S.: 60 to 90 8 F (16 to 32 8 C)
— For Canada: 64 to 90 8 F (18 to
32 8 C) .
The temperature of the passenger
compartment will be maintained
automatically. Air flow distribution
and fan speed will also be controlled
automatically.
3. You can individually set driver and front
passenger side temperature using each
temperature control button. When the
“ DUAL ” button is pushed or the pas-
senger side temperature control button
is turned, the DUAL indicator will come
on. To turn off the passenger side
temperature control, push the “ DUAL ”
button.

Black plate (211,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4. To turn off the climate control system,
push the “ OFF ” button.
A visible mist may be seen coming from the
ventilators in hot, humid conditions as the
air is cooled rapidly. This does not indicate
a malfunction.
Heating (A/C OFF): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
The air conditioner does not activate in this
mode. When you need to heat only, use
this mode.
1. Push the “ AUTO ” button on.
2. Push the “ A/C ” button. (The A/C
indicator will turn off.)
3. Turn the temperature control dial to set
the desired temperature.
. The temperature of the passenger
compartment will be maintained auto-
matically. Air flow distribution and fan
speed are also controlled automati-
cally.
. Do not set the temperature lower than
the outside air temperature. Otherwise
the system may not work properly.
. Not recommended if windows fog up.
Dehumidified defrosting or defogging: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
1. Push the “ ” front defroster button.
(The indicator light on the button will come on.)
2. Turn the temperature control dial to set
the desired temperature.
. To quickly remove ice from the outside
of the windows, push the fan speed
increase button “
” and set it to the
maximum position.
. As soon as possible after the wind-
shield is clean, push the “ AUTO ” button
to return to the auto mode.
. When the “
” front defroster button
is pushed, the air conditioner will
automatically be turned on at outside
temperatures above 23 8 F ( − 5 8 C) to
defog the windshield, and the air
recirculate mode will automatically be
turned off.
Outside air is drawn into the passenger
compartment to improve the defogging
performance.
Manual operation GUID-229B673E-2AED-4344-9C09-630604A66426
Fan speed control: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Push the fan speed increase “ ” or
decrease “
” buttons to manually con-
trol the fan speed.
Push the “ AUTO ” button to return to
automatic control of the fan speed. Air recirculation: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Push the intake air control button “
” to recirculate interior air inside the
vehicle. The indicator light on the “
”
side will come on.
The air recirculation mode cannot be
activated when the air conditioner is in
the front defrosting mode “
” .
Outside air circulation: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Push the intake air control button “
” to draw outside air into the passen-
ger compartment. The indicator light on the
“
” side will come on.
Automatic intake air control: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
In the AUTO mode, the intake air will be
controlled automatically. To manually con-
trol the intake air, push the intake air
control button “
” . To return to the
automatic control mode, push the intake
air control button “
” for about 2
seconds. The indicator lights (both air
recirculation and outside air circulation
sides) will flash twice, and then the intake
air will be controlled automatically.
Monitor, climate, audio, phone and voice recognition systems
4-33

Black plate (212,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-34 Monitor, climate, audio, phone and voice recognition systemsAir flow control: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Pushing the “ MODE ” manual air flow
control button selects the air outlet to: : Air flows from center and side ventilators.
: Air flows from center and side ventilators and
foot outlets.
: Air flows mainly from foot outlets.
: Air flows from defroster and foot outlets.
To turn the system off GUID-AD1354E7-58D5-4D12-9984-BCCF1701C8CE
Push the OFF button. SAA1526
Type B
1. “ AUTO ” automatic climate control ON
button/Temperature control dial
2. Air flow control button
3. “ ” Fan speed control dial
4. “ OFF ” button
5. “
” front defroster button
6. “ ” rear window defroster button
(See “ Rear window and outside mirror
defroster switch ” (P.2-34).)
7. “
” intake air control button AUTOMATIC CLIMATE CONTROL
(Type B) GUID-A975719E-9D57-4522-8059-48964137AD90
Automatic operation GUID-EC196CB6-C7FA-4D5B-ACB7-73DE088B666C
Cooling and/or dehumidified heating
(AUTO): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
This mode may be used all year round. The
system works automatically to control the
inside temperature, air flow distribution
and fan speed after the preferred tempera-
ture is set manually.
1. Push the “ AUTO ” button on. (The
indicator on the button will illuminate
and AUTO will be displayed.)

Black plate (213,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]2. Use the temperature control dial to set
the desired temperature. .
The temperature can be set within
the following range.
— For U.S.: 60 to 90 8 F (16 to 32 8 C)
— For Canada: 64 to 90 8 F (18 to
32 8 C) .
The temperature of the passenger
compartment will be maintained
automatically. Air flow distribution
and fan speed will also be controlled
automatically.
3. To turn off the climate control system,
push the “ OFF ” button.
A visible mist may be seen coming from the
ventilators in hot, humid conditions as the
air is cooled rapidly. This does not indicate
a malfunction.
Heating (A/C OFF): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
The air conditioner does not activate in this
mode. When you need to heat only, use
this mode.
1. Push the “ AUTO ” button on.
2. Push the “ A/C ” button. (The A/C
indicator will turn off.)
3. Turn the temperature control dial to set
the desired temperature. . The temperature of the passenger
compartment will be maintained auto-
matically. Air flow distribution and fan
speed are also controlled automati-
cally.
. Do not set the temperature lower than
the outside air temperature. Otherwise
the system may not work properly.
. Not recommended if windows fog up.
Dehumidified defrosting or defogging: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
1. Push the “ ” front defroster button.
(The indicator light on the button will
come on.)
2. Turn the temperature control dial to set
the desired temperature.
. To quickly remove ice from the outside
of the windows, turn the “
” fan
speed control dial and set it to the
maximum position.
. As soon as possible after the wind-
shield is clean, push the “ AUTO ” button
to return to the auto mode.
. When the “
” front defroster button
is pushed, the air conditioner will
automatically be turned on at outside
temperatures above 23 8 F ( − 5 8 C) to
defog the windshield, and the air
recirculate mode will automatically be turned off.
Outside air is drawn into the passenger
compartment to improve the defogging
performance.
Manual operation GUID-1366819E-B7B2-452E-BFAE-A3526FCA00F5
Fan speed control: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Turn the “ ” fan speed control dial to
manually control the fan speed.
Push the “ AUTO ” button to return to
automatic control of the fan speed.
Air recirculation: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Push the intake air control button “
” to recirculate interior air inside the
vehicle. The indicator light on the “ ”
side will come on.
The air recirculation mode cannot be
activated when the air conditioner is in
the front defrosting mode “
” .
Outside air circulation: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Push the intake air control button “
” to draw outside air into the passen-
ger compartment. The indicator light on the
“
” side will come on.
Automatic intake air control: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
In the AUTO mode, the intake air will be
controlled automatically. To manually con-
Monitor, climate, audio, phone and voice recognition systems
4-35

Black plate (214,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-36 Monitor, climate, audio, phone and voice recognition systemstrol the intake air, push the intake air
control button “
” . To return to the
automatic control mode, push the intake
air control button “
” for about 2
seconds. The indicator lights (both air
recirculation and outside air circulation
sides) will flash twice, and then the intake
air will be controlled automatically.
Air flow control: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Pushing an air flow control button manu-
ally controls the air flow and selects the air
outlet to the following settings. : Air flows from center and side ventilators.
: Air flows from center and side ventilators and
foot outlets.
: Air flows mainly from foot outlets.
: Air flows from defroster and foot outlets.
To turn the system off GUID-72F0A526-1E4F-46F2-803C-E31F9547AE00
Push the OFF button. SAA2972
Type C
1. “ AUTO ” automatic operation button/
Temperature control dial (driver side)
2. “ A/C ” air conditioner ON/OFF button
3. “ ” fan speed increase button
4. “
” front defroster button
5. “ MODE ” manual air flow control but-
ton
6. “ DUAL ” zone control ON/OFF button/
Temperature control dial (passenger
side)
7. “ OFF ” button for climate control sys-
tem
8. “
” fan speed decrease button 9. “ ” rear window defroster button
(See “ Rear window and outside mirror
defroster switch ” (P.2-34).)
10. “
” auto-recirculation button/
intake air control button

Black plate (215,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]AUTOMATIC CLIMATE CONTROL
(Type C) GUID-4DC8C348-FAB4-42B1-9378-82EE0A7F7A61
Automatic operation (AUTO) GUID-EB1D0668-6562-4CBB-ABF3-5A4B2EF4A7B9
The AUTO mode may be used year-round
as the system automatically controls con-
stant temperature, air flow distribution and
fan speed after the desired temperature is
set manually.
To turn off the heater and air conditioner,
push the “ OFF ” button.
Cooling and dehumidified heating: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
1. Push the “ AUTO ” button.
(The AUTO indicator light will illuminate
and “ AUTO ” will appear on the display.)
2. If the A/C indicator light does not
illuminate, push the “ A/C ” button.
(The A/C indicator light will illuminate.)
3. Turn the temperature control dial (dri-
ver ’ s side) to set the desired tempera-
ture. .
The temperature can be set within
the following range.
— For U.S.: 60 to 90 8 F (16 to 32 8 C)
— For Canada: 64 to 90 8 F (18 to
32 8 C) .
When the DUAL indicator light is
turned off:
— Pushing the driver ’ s side “ AUTO ”
button changes both the driver ’ s
and front passenger ’ s side tem-
perature.
— Pushing the passenger ’ s side
“ DUAL ” button changes only the
front passenger ’ s side tempera-
ture. (The DUAL indicator light
will illuminate and “ DUAL ” will
appear on the display.) .
To set separate desired tempera-
tures for the driver and front pas-
senger, push the “ DUAL ” button, the
indicator light illuminates, and then
turn the corresponding temperature
control dial. .
To cancel the separate temperature
setting, push the “ DUAL ” button, the
indicator light turns off, and the
driver ’ s side temperature setting will
be applied to both the driver ’ s and
front passenger ’ s sides.
A visible mist may be seen coming from the
ventilators in hot, humid conditions as the
air is cooled rapidly. This does not indicate
a malfunction. Heating (A/C off): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
1. Push the “ AUTO ” button.
(The AUTO indicator light will illuminate
and “ AUTO ” will appear on the display.)
2. If the A/C indicator light illuminates,
push the “ A/C ” button.
(The A/C indicator light will turn off.)
3. Turn the temperature control dial to set
the desired temperature. .
When the DUAL indicator light is
turned off:
— Pushing the driver ’ s side “ AUTO ”
button changes both the driver ’ s
and front passenger ’ s side tem-
perature.
— Pushing the passenger ’ s side
“ DUAL ” button changes only the
front passenger ’ s side tempera-
ture. (The DUAL indicator light
will illuminate and “ DUAL ” will
appear on the display.) .
To set separate desired tempera-
tures for the driver and front pas-
senger, push the “ DUAL ” button, the
indicator light illuminates, and then
turn the corresponding temperature
control dial.
Monitor, climate, audio, phone and voice recognition systems
4-37
