2012 INFINITI G37 Owners Manual

Black plate (368,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]5-48 Starting and driving4. Push the ignition switch to the OFF
position. GUID-9AE6B52C-4B9A-4759-99F6-02BACA32F56E
SSD0927
WARNING . The sonar system is a convenience but it
is not a substitute for proper parking.
Always look around and check that it is
safe to do so before parking. Always
move slowly.
. Read and understand the limitations of
the sonar system as contained in this
section. Inclement weather may affect
the function of the sonar system; this
may include reduced performance or a
false activation. . This system is not designed to prevent
contact with small or moving objects.
. The system is designed as an aid to the
driver in detecting large stationary
objects to help avoid damaging the
vehicle. The system will not detect small
objects below the bumper, and may not
detect objects close to the bumper or on
the ground.
. If your vehicle sustains damage to the
bumper fascia, leaving it misaligned or
bent, the sensing zone may be altered
causing inaccurate measurement of ob-SONAR SYSTEM (if so equipped)

Black plate (369,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]stacles or false alarms.
CAUTIONKeep the interior of the vehicle as quiet as
possible to hear the tone clearly.
The sonar system sounds a tone to warn
the driver of obstacles near the bumper.
When the “ Sonar Display ” key is ON, the
sonar indicator will also appear in the
center display. (See “ Sonar indicator ” (P.5-
49).) The system detects rear obstacles
when the selector lever is in the “ R ”
(Reverse) position.
The system may not detect objects at
speeds above 6 MPH (10 km/h) and may
not detect certain angular or moving
objects.
The sonar system detects obstacles up to
3.9 feet (1.2 m) from the bumper with a
decreased coverage area at the outer
corners of the bumper. Refer to the
illustration for approximate zone coverage
areas. As you move closer to the obstacle,
the rate of the tone increases. When the
obstacle is less than 11.8 in (30 cm) away, the tone will sound continuously.
Keep the corner/center sonar (located on
the bumper fascia) free from snow, ice and
large accumulations of dirt (do not clean
the sonar with sharp objects). If the sonar
is covered, it will affect the accuracy of the
sonar system.
The sensitivity level of the corner/center
sonar can be adjusted (higher or lower) in
the SONAR setting display. (See “ How to
use SETTING button ” (P.4-14) for the
“ Sonar ” settings.) SSD0928
* 1
Rear view monitor display
* A
Corner sonar indicator
* B
Center sonar indicator
SONAR INDICATOR GUID-BCE909B1-A1DD-4D6D-AC06-E3739C301FD2
With the “ Sonar Display ” key ON in the
“ Sonar ” settings, when the corner/center
sonar detects obstacles near the bumper, a
tone will sound and the sonar indicator will
appear in the center display. When the rear
view monitor is displayed, the sonar
indicator will appear in the upper corner
of the display
* 1
.
The sonar indicators
* A
and
* B
indicate
the position of the object and the distance
Starting and driving
5-49

Black plate (370,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]5-50 Starting and drivingto the object with its color and rate of
blinking.
When an object is detected, the indicator
(green) appears and blinks (the tone
sounds intermittently). When the vehicle
moves closer to the object, the color of the
indicator turns yellow and the rate of
blinking increases (the rate of the tone
increases). When the corner of the vehicle
is very close to the object, less than 11.8 in
(30 cm) away, the indicator stops blinking
and turns red (the tone sounds continu-
ously).
When the rear view monitor is displayed,
the colors of the sonar indicator and the
distance guide lines in the rear view
indicate different distances to the object.
The sonar indicator can be turned off in the
SONAR setting display. (See “ How to use
SETTING button ” (P.4-14) for the “ Sonar ”
settings.) When the sonar indicator is off,
only a tone sounds when the sonar detects
obstacles. SSD0929
SONAR SYSTEM OFF SWITCH GUID-446340A3-E5C0-4566-9701-88DF98FE3774
The sonar system OFF switch on the
instrument panel allows the driver to turn
the sonar system on and off. To turn the
sonar system on and off, the ignition
switch must be in the “ ON ” position. The
indicator light
* 1
on the switch will
illuminate when the system is turned off.
If the indicator light flashes when the
sonar system is not turned off, it may
indicate a malfunction in the sonar system. GUID-7A26DC9E-F480-487F-A4C2-174FF498CC5C
WARNING If the engine is not running or is turned off
while driving, the power assist for the
steering will not work. Steering will be
harder to operate.
The power assisted steering uses a hy-
draulic pump, driven by the engine, to
assist steering.
If the engine stops or the drive belt breaks,
you will still have control of the vehicle.
However, much greater steering effort is
needed, especially in sharp turns and at
low speeds.POWER STEERING

Black plate (371,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]GUID-D12A8E6E-B2CE-4633-80C5-8B66D102DAA5
BRAKING PRECAUTIONS GUID-69469B45-E0A5-4BC3-B99F-C3213CC27874
The brake system has two separate hy-
draulic circuits. If one circuit malfunctions,
you will still have braking at two wheels.
Vacuum assisted brakes GUID-95686AE6-7A34-4D3E-9305-085085C76F84
The brake booster aids braking by using
engine vacuum. If the engine stops, you
can stop the vehicle by depressing the
brake pedal. However, greater foot pres-
sure on the brake pedal will be required to
stop the vehicle and the stopping distance
will be longer.
When the brake pedal is depressed slowly
and firmly, you may hear a clicking noise
and feel a slight pulsation. This is normal
and indicates that the Brake Assist System
is operating.
Wet brakes GUID-B2433212-C5E2-4B61-9394-8ED34BB6A681
When the vehicle is washed or driven
through water, the brakes may get wet.
As a result, your braking distance will be
longer and the vehicle may pull to one side
during braking.
To dry brakes, drive the vehicle at a safe
speed while lightly tapping the brake pedal
to heat-up the brakes. Do this until the
brakes return to normal. Avoid driving the vehicle at high speeds until the brakes
function correctly.
PARKING BRAKE BREAK-IN GUID-B441C7AD-F0BB-453E-A531-8E92178C3484
Break in the parking brake shoes whenever
the stopping effect of the parking brake is
weakened or whenever the parking brake
shoes and/or drums/rotors are replaced,
in order to assure the best braking
performance.
This procedure is described in the vehicle
service manual and can be performed by
an INFINITI retailer.
Using the brakes GUID-EB3F3C9C-0F2F-47F8-8239-331D9D489654
Avoid resting your foot on the brake pedal
while driving. This will cause overheating
of the brakes, wearing out the brake and
pads faster and reduce gas mileage.
To help save the brakes and to prevent the
brakes from overheating, reduce speed
and downshift to a lower gear before going
down a slope or long grade. Overheated
brakes may reduce braking performance
and could result in loss of vehicle control. WARNING . While driving on a slippery surface, be
careful when braking, accelerating or
downshifting. Abrupt braking or accel-
erating could cause the wheels to skid
and result in an accident.
. If the engine is not running or is turned
off while driving, the power assist for
the brakes will not work. Braking will be
harder.
Starting and driving
5-51BRAKE SYSTEM

Black plate (372,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]5-52 Starting and driving GUID-8E268035-E356-4B89-AC5F-810CD9DB8C79
BRAKE ASSIST GUID-0BC62A24-2073-43FC-B791-6C3D51778617
When the force applied to the brake pedal
exceeds a certain level, the Brake Assist is
activated generating greater braking force
than a conventional brake booster even
with light pedal force.
WARNINGThe Brake Assist is only an aid to assist
braking operation and is not a collision
warning or avoidance device. It is the
driver ’ s responsibility to stay alert, drive
safely and be in control of the vehicle at all
times.
PREVIEW FUNCTION (Intelligent
Cruise Control system equipped
models) GUID-BC7D2384-44AA-4BCF-9239-DF7DEC96A526
When the Preview Function identifies the
need to apply emergency braking by
sensing a vehicle ahead in the same lane
and the distance and relative speed from
it, it applies the brake pre-pressure before
the driver depresses the brake pedal and
helps improve brake response by reducing
pedal free play. . This system will not operate when the
vehicle is moving at approximately 20
MPH (32 km/h) or less.
. The pre-pressure function ceases when
the following conditions are met:
1) When the driver depresses the
accelerator pedal or the brake
pedal.
2) If the driver does not operate the
accelerator or brake pedal within
approximately 1 second. SSD0338
. The sensor will not detect:
1) Pedestrians or objects in the road-
way
2) Oncoming vehicles in the same lane
3) Motorcycles traveling offset in the
travel lane as illustrated
WARNING . This system is only an aid to assist
braking operation and is not a collision
warning or avoidance device. It is the
driver ’ s responsibility to stay alert, drive
safely and be in control of the vehicle atBRAKE ASSIST

Black plate (373,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]all times.
. As there is a performance limit to the
Preview Function, never rely solely on
this system. This system does not
correct careless inattentive or absent-
minded driving, or overcome poor visi-
bility in rain, fog, or other bad weather.
Reduce vehicle speed by depressing the
brake pedal, in order to maintain a safe
distance between vehicles.
. The system may not detect the vehicle in
front of you in certain road or weather
conditions. The Preview Function may
not operate properly under the following
conditions. The vehicle is still driveable
under normal conditions and the Brake
Assist will operate.
— When rain, snow or dirt adhere to
the system sensor
— When strong light (for example, at
sunrise or sunset) is directly shining
on the front of the vehicle
— Winding or hilly roads may cause
the sensor to temporarily not detect
a vehicle in the same lane or may
detect objects or vehicles in other
lanes. — Vehicle position in the lane may
cause the sensor to temporarily not
detect a vehicle in the same lane or
may detect objects or vehicles in
other lanes.
SSD0471
Warning light and display GUID-A2927947-1E33-4EB3-9D1D-6799F67E6AB2
When the Preview Function is not operating
properly, a chime sounds and the system
warning light (orange) will come on.
Action to take: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
If the warning light comes on, park the
vehicle in a safe place. Turn the engine off,
restart the engine and resume driving.
If the indicator stays on, it may indicate
that the Preview Function is malfunction-
ing (the brake is operative). Although the
Vehicle is still driveable under normal
conditions, have the vehicle checked at
an INFINITI retailer.
Starting and driving
5-53

Black plate (374,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]5-54 Starting and drivingHow to handle the sensor GUID-89745A21-1C60-412A-886B-4129187B34E7
The sensor for the Preview Function is
common with Intelligent Cruise Control and
is located below the front bumper.
To keep the Preview Function operating
properly, be sure to observe the following:
. Always keep the sensor clean. Wipe
with a soft cloth carefully so as not to
damage the sensor.
. Do not strike or damage the areas
around the sensor. Do not touch or
remove the screw located on the
sensor. Doing so could cause failure
or malfunction. If the sensor is da-
maged due to an accident, contact an
INFINITI retailer.
. Do not attach a sticker (including
transparent material) or install an
accessory near the sensor. This could
cause failure or malfunction. ANTI-LOCK BRAKING SYSTEM (ABS) GUID-FD13D872-FF09-485D-9889-39301203B8FE
WARNING . The Anti-lock Braking System (ABS) is a
sophisticated device, but it cannot pre-
vent accidents resulting from careless or
dangerous driving techniques. It can
help maintain vehicle control during
braking on slippery surfaces. Remember
that stopping distances on slippery
surfaces will be longer than on normal
surfaces even with ABS. Stopping dis-
tances may also be longer on rough,
gravel or snow covered roads, or if you
are using tire chains. Always maintain a
safe distance from the vehicle in front of
you. Ultimately, the driver is responsible
for safety.
. Tire type and condition may also affect
braking effectiveness.
— When replacing tires, install the
specified size of tires on all four
wheels.
— When installing a spare tire, make
sure that it is the proper size and
type as specified on the Tire and
Loading Information label. See “ Tire and loading information label ” (P.9-
14) of this manual.
— For detailed information, see
“ Wheels and tires ” (P.8-33) of this
manual.
The Anti-lock Braking System (ABS) con-
trols the brakes so the wheels do not lock
during hard braking or when braking on
slippery surfaces. The system detects the
rotation speed at each wheel and varies
the brake fluid pressure to prevent each
wheel from locking and sliding. By pre-
venting each wheel from locking, the
system helps the driver maintain steering
control and helps to minimize swerving
and spinning on slippery surfaces.
Using the system GUID-CD765EBE-4FB0-423D-988E-36D396A7E6A5
Depress the brake pedal and hold it down.
Depress the brake pedal with firm steady
pressure, but do not pump the brakes. The
ABS will operate to prevent the wheels
from locking up. Steer the vehicle to avoid
obstacles.

Black plate (375,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]WARNINGDo not pump the brake pedal. Doing so may
result in increased stopping distances.
Self-test feature GUID-EC96AE96-D9F6-4F19-A5A9-937C4D6337A4
The ABS includes electronic sensors, elec-
tric pumps, hydraulic solenoids and a
computer. The computer has a built-in
diagnostic feature that tests the system
each time you start the engine and move
the vehicle at a low speed in forward or
reverse. When the self-test occurs, you may
hear a “ clunk ” noise and/or feel a pulsa-
tion in the brake pedal. This is normal and
does not indicate a malfunction. If the
computer senses a malfunction, it switches
the ABS off and illuminates the ABS
warning light on the instrument panel.
The brake system then operates normally,
but without anti-lock assistance.
If the ABS warning light illuminates during
the self-test or while driving, have the
vehicle checked by an INFINITI retailer. Normal operation GUID-36C3BA08-72B5-4E9B-96CF-93CCD7FE6655
The ABS operates at speeds above 3 to 6
MPH (5 to 10 km/h).
When the ABS senses that one or more
wheels are close to locking up, the actuator
rapidly applies and releases hydraulic
pressure. This action is similar to pumping
the brakes very quickly. You may feel a
pulsation in the brake pedal and hear a
noise from under the hood or feel a
vibration from the actuator when it is
operating. This is normal and indicates
that the ABS is operating properly. How-
ever, the pulsation may indicate that road
conditions are hazardous and extra care is
required while driving. GUID-B2222C83-77D9-46CF-971F-591ADE2397C3
The Vehicle Dynamic Control (VDC) system
uses various sensors to monitor driver
inputs and vehicle motion. Under certain
driving conditions, the VDC system helps
to perform the following functions.
. Controls brake pressure to reduce
wheel slip on one slipping drive wheel
so power is transferred to a non
slipping drive wheel on the same axle.
. Controls brake pressure and engine
output to reduce drive wheel slip based
on vehicle speed (traction control func-
tion).
. Controls brake pressure at individual
wheels and engine output to help the
driver maintain control of the vehicle in
the following conditions:
— understeer (vehicle tends to not
follow the steered path despite
increased steering input)
— oversteer (vehicle tends to spin due
to certain road or driving condi-
tions).
The VDC system can help the driver to
maintain control of the vehicle, but it
cannot prevent loss of vehicle control in
all driving situations.
When the VDC system operates, the VDC
warning light
in the instrument panel
Starting and driving
5-55VEHICLE DYNAMIC CONTROL (VDC) SYSTEM
