2012 INFINITI G37 Owners Manual

Black plate (136,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]2-58 Instruments and controls. any door is opened with the ignition
switch in any position
— remain on while the door is opened.
When the door is closed, the lights
go off.
OFF position GUID-544F2395-1EF1-447D-9281-F30C0F022BEE
When the switch is in the OFF position
* 3
,
the lights will not illuminate, regardless of
the condition.
CAUTIONDo not use for extended periods of time with
the engine stopped. This could result in a
discharged battery. GUID-4767303A-3063-498C-B5AA-4C1CC218222A
SIC2064
Type A
SIC3869
Type B The light on the vanity mirror will turn on
when the cover on the vanity mirror is
opened.
When the cover is closed, the light will turn
off.
The lights will also turn off after 15
minutes when the lights remain illumi-
nated to prevent the battery from becom-
ing discharged.VANITY MIRROR LIGHTS

Black plate (137,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]GUID-3B0103FD-8C82-48ED-ABBE-0FF7FE9A8F16
The light illuminates when the trunk lid is
opened. When the trunk lid is closed, the
light will turn off.
The light will also turn off after 15 minutes
when the light remains illuminated after
the ignition switch has been pushed to the
OFF or LOCK position to prevent the
battery from becoming discharged. GUID-0BF67760-C562-4D9A-8217-C1A104712017
HomeLink ®
Universal Transceiver provides
a convenient way to consolidate the func-
tions of up to three individual hand-held
transmitters into one built-in device.
HomeLink ®
Universal Transceiver:
. Will operate most Radio Frequency (RF)
devices such as garage doors, gates,
home and office lighting, entry door
locks and security systems.
. Is powered by your vehicle ’ s battery. No
separate batteries are required. If the
vehicle ’ s battery is discharged or is
disconnected, HomeLink ®
will retain all
programming.
Once HomeLink ®
Universal Transceiver is
programmed, retain the original transmit-
ter for future programming procedures
(Example: new vehicle purchases). Upon
sale of the vehicle, the programmed
HomeLink ®
Universal Transceiver buttons
should be erased for security purposes.
For additional information, see “ Program-
ming HomeLink ®
” (P.2-60).
WARNING . Do not use HomeLink ®
Universal Trans-
ceiver with any garage door opener that
lacks safety stop and reverse features as required by federal safety standards.
(These standards became effective for
opener models manufactured after April
1, 1982.) A garage door opener which
cannot detect an object in the path of a
closing garage door and then automati-
cally stop and reverse, does not meet
current federal safety standards. Using a
garage door opener without these fea-
tures increases the risk of serious injury
or death.
. During programming procedure, your
garage door or security gate may open
or close. Make sure that people and
objects are clear of the garage door,
gate, etc. that you are programming.
. Your vehicle ’ s engine should be turned
off while programming HomeLink ®
Uni-
versal Transceiver.
Instruments and controls
2-59TRUNK LIGHT HomeLink ®
UNIVERSAL TRANSCEIVER (if so
equipped)

Black plate (138,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]2-60 Instruments and controlsPROGRAMMING HomeLink ® GUID-C1A6C78C-5674-4502-BB48-800218FBC19E
To program your HomeLink ®
Transceiver to
operate a garage door, gate, or entry door
opener, home or office lighting, you need
to be at the same location as the device.
Note: Garage door openers (manufactured
after 1996) have “ rolling code protection ” .
To program a garage door opener equipped
with “ rolling code protection ” ; you will
need to use a ladder to get up to the
garage door opener motor to be able to
access the “ smart or learn ” program
button. SIC3612
1. To begin, push and hold the 2 outer
HomeLink ®
buttons (to clear the mem-
ory) until the indicator light
* A
blinks
(after 20 seconds). Release both but-
tons.
2. Position the end of the hand-held
transmitter 1-3 inches away from the
HomeLink ®
surface. SIC3613
3. Using both hands, simultaneously push
and hold both the HomeLink ®
button
you want to program and the hand-held
transmitter button.
DO NOT release the buttons until step 4
has been completed.
4. Hold down both buttons until the
indicator light on HomeLink ®
flashes,
changing from a “ slow blink ” to a
“ rapid blink ” . This could take up to 90
seconds. When the indicator light
blinks rapidly, both buttons may be
released. The rapidly flashing light
indicates successful programming. To
activate the garage door or other

Black plate (139,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]programmed device, push and hold the
programmed HomeLink ®
button - re-
leasing when the device begins to
activate.
5. If the indicator light on HomeLink ®
blinks rapidly for two seconds and then
turns solid, HomeLink ®
has picked up a
“ rolling code ” garage door opener
signal. You will need to proceed with
the next steps to train HomeLink ®
,
completing the programming may re-
quire a ladder and another person for
convenience.
6. Push and release the program button
located on the garage door opener ’ s
motor to activate the “ training mode ” .
This button is usually located near the
antenna wire that hangs down from the
motor. If the wire originates from under
a light lens, you will need to remove the
lens to access the training button.
NOTE:
Once you have pushed and released
the training button on the garage door
opener ’ s motor and the “ training light ”
is lit, you have 30 seconds in which to
perform step 7. For convenience, use
the help of a second person to assist
when performing this step. 7. Quickly (within 30 seconds of pushing
and releasing the garage door opener
training button) and firmly push and
release the HomeLink ®
button you ’ ve
just programmed. Push and release the
HomeLink ®
button up to three times to
complete the training.
8. Your HomeLink ®
button should now be
programmed. To program the remaining
HomeLink ®
buttons for additional door
or gate openers, follow steps 2 through
8 only.
NOTE:
Do not repeat step 1 unless you want to
“ clear ” all previously programmed
HomeLink ®
buttons.
If you have any questions or are having
difficulty programming your HomeLink ®
buttons, please refer to the HomeLink ®
web site at: www.homelink.com or call 1-
800-355-3515. PROGRAMMING HomeLink ®
FOR
CANADIAN CUSTOMERS GUID-FA6ED7D7-5805-4878-A033-2D4A6CF0EB88
Prior to 1992, D.O.C. regulations required
hand-held transmitters to stop transmitting
after 2 seconds. To program your hand-
held transmitter to HomeLink ®
, continue to
push and hold the HomeLink ®
button (note
steps 2 through 4 under “ Programming
HomeLink ®
” ) while you push and re-push
( “ cycle ” ) your hand-held transmitter every
2 seconds until the indicator light flashes
rapidly (indicating successful program-
ming).
NOTE:
If programming a garage door opener, etc.,
it is advised to unplug the device during
the “ cycling ” process to prevent possible
damage to the garage door opener com-
ponents.
OPERATING THE HomeLink ®
UNI-
VERSAL TRANSCEIVER GUID-6973D290-7F33-4E52-A191-FAE191D2E93A
HomeLink ®
Universal Transceiver (once
programmed) may now be used to activate
the garage door, etc. To operate, simply
push the appropriate programmed
HomeLink ®
Universal Transceiver button.
The red indicator light will illuminate while
the signal is being transmitted.
Instruments and controls
2-61

Black plate (140,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]2-62 Instruments and controlsPROGRAMMING TROUBLE-DIAGNO-
SIS GUID-D075D2BD-E7C7-474E-83FC-B6F733CCAE46
If HomeLink ®
does not quickly learn the
hand-held transmitter information:
. replace the hand-held transmitter bat-
teries with new batteries.
. position the hand-held transmitter with
its battery area facing away from the
HomeLink ®
surface.
. push and hold both the HomeLink ®
and
hand-held transmitter buttons without
interruption.
. position the hand-held transmitter 2 to
5 in (50 to 127 mm) away from the
HomeLink ®
surface. Hold the transmit-
ter in that position for up to 15
seconds. If HomeLink ®
is not pro-
grammed within that time, try holding
the transmitter in another position -
keeping the indicator light in view at all
times.
If you continue to have programming
difficulties, please contact the INFINITI
Consumer Affairs Department. The phone
numbers are located in the Foreword of
this Owner ’ s Manual. CLEARING THE PROGRAMMED IN-
FORMATION GUID-93441B3F-2212-4876-94D6-FC87E5157313
Individual buttons cannot be cleared,
however to clear all programming, push
and hold the two outside buttons and
release when the indicator light begins to
flash (in approximately 20 seconds).
REPROGRAMMING A SINGLE
HomeLink ®
BUTTON GUID-F8D4C203-F653-4BE8-9078-5A51BCCE5405
To reprogram a HomeLink ®
Universal
Transceiver button, complete the following.
1. Push and hold the desired HomeLink ®
button. Do not release the button until
step 4 has been completed.
2. When the indicator light begins to flash
slowly (after 20 seconds), position the
hand-held transmitter 2 to 5 in (50 to
127 mm) away from the HomeLink ®
surface.
3. Push and hold the hand-held transmit-
ter button.
4. The HomeLink ®
indicator light will
flash, first slowly and then rapidly.
When the indicator light begins to flash
rapidly, release both buttons.
The HomeLink ®
Universal Transceiver but-
ton has now been reprogrammed. The new device can be activated by pushing the
HomeLink ®
button that was just pro-
grammed. This procedure will not affect
any other programmed HomeLink ®
but-
tons.
IF YOUR VEHICLE IS STOLEN GUID-5786CF0E-BD69-4511-B9FA-84F26F89F025
If your vehicle is stolen, you should change
the codes of any non-rolling code device
that has been programmed into
HomeLink ®
. Consult the Owner ’ s Manual
of each device or call the manufacturer or
retailer of those devices for additional
information.
When your vehicle is recovered, you will
need to reprogram the HomeLink ®
Uni-
versal Transceiver with your new transmit-
ter information.
FCC Notice:
For USA:
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any interfer-
ence received, including interference that
may cause undesired operation.

Black plate (141,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]NOTE:
Changes or modifications not expressly
approved by the party responsible for
compliance could void the user ’ s authority
to operate the equipment.
For Canada:
This device complies with RSS-210 of
Industry Canada. Operation is subject to
the following two conditions: (1) this
device may not cause interference, and
(2) this device must accept any interfer-
ence, including interference that may
cause undesired operation of the device.
Instruments and controls
2-63

Black plate (142,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]2-64 Instruments and controlsMEMO

Black plate (143,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]3 Pre-driving checks and adjustments Keys ....................................................................... 3-2
Intelligent Key .................................................... 3-2
Valet hand-off ..................................................... 3-3
Doors ..................................................................... 3-4
Locking with mechanical key .............................. 3-4
Opening and closing windows with the
mechanical key ................................................... 3-5
Locking with inside lock knob ............................ 3-5
Locking with power door lock switch .................. 3-5
Automatic door locks .......................................... 3-6
Child safety rear door lock (Sedan) ..................... 3-6
Intelligent Key system ............................................ 3-7
Intelligent Key operating range .......................... 3-8
Door locks/unlocks precaution .......................... 3-9
Intelligent Key operation .................................. 3-10
Battery saver system ........................................ 3-12
Warning signals ................................................ 3-12
Troubleshooting guide ...................................... 3-13
Remote keyless entry system ................................ 3-14
How to use remote keyless entry system .......... 3-14
Hood .................................................................... 3-18
Trunk lid ............................................................... 3-18
Trunk lid release switch .................................... 3-19 Trunk open request switch .............................. 3-19
Trunk release power cancel switch .................. 3-20
Interior trunk lid release ................................. 3-21
Unique front and rear parts (INFINITI Performance
Line, Aerodynamic Package models) ..................... 3-21
Fuel-filler door ...................................................... 3-23
Opening the fuel-filler door ............................. 3-23
Fuel-filler cap .................................................. 3-23
Tilt/telescopic steering ......................................... 3-26
Manual operation (if so equipped) .................. 3-26
Electric operation (if so equipped) .................. 3-26
Sun visors ............................................................ 3-27
Mirrors ................................................................ 3-28
Inside mirror ................................................... 3-28
Outside mirrors ............................................... 3-29
Vanity mirror ................................................... 3-31
Automatic drive positioner (if so equipped) .......... 3-31
Entry/exit function (Automatic Transmission
Sedan models) ................................................ 3-31
Seat synchronization function ........................ 3-32
Memory storage .............................................. 3-33
System operation ............................................ 3-34
