2012 INFINITI G37 Owners Manual

Black plate (448,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]8-42 Maintenance and do-it-yourself. The original tires have built-in
tread wear indicators. When wear
indicators are visible, the tire(s)
should be replaced.
. Tires degrade with age and use.
Have tires, including the spare,
over 6 years old checked by a
qualified technician, because
some tire damage may not be
obvious. Replace the tires as
necessary to prevent tire failure
and possible personal injury.
. Improper service of the spare tire
may result in serious personal
injury. If it is necessary to repair
the spare tire, contact an INFINITI
retailer.
. For additional information regard-
ing tires, refer to “ Important Tire
Safety Information ” (US) or “ Tire
Safety Information ” (Canada) in
the Warranty Information Booklet. Replacing wheels and tires GUID-4EF95767-87A1-46D1-823F-01023BAE60AA
When replacing a tire, use the same size,
tread design, speed rating and load carry-
ing capacity as originally equipped. (See
“ Specifications ” (P.9-8) for recommended
types and sizes of tires and wheels.)
WARNING . The use of tires other than those
recommended or the mixed use of tires
of different brands, construction (bias,
bias-belted or radial), or tread patterns
can adversely affect the ride, braking,
handling, ground clearance, body-to-tire
clearance, tire chain clearance, speed-
ometer calibration, headlight aim and
bumper height. Some of these effects
may lead to accidents and could result in
serious personal injury.
. If the wheels are changed for any
reason, always replace with wheels
which have the same off-set dimension.
Wheels of a different off-set could cause
premature tire wear, degrade vehicle
handling characteristics and/or interfer-
ence with the brake discs/drums. Such
interference can lead to decreased brak- ing efficiency and/or early brake pad/
shoe wear. See “ Wheels and tires ” (P.9-
9) of this manual for wheel off-set
dimensions.
. When a spare tire is mounted or a wheel
is replaced, the TPMS will not function
and the low tire pressure warning light
will flash for approximately 1 minute.
The light will remain on after 1 minute.
Contact your INFINITI retailer as soon as
possible for tire replacement and/or
system resetting.
. Replacing tires with those not originally
specified by INFINITI could affect the
proper operation of the TPMS.
. Do not install a damaged or deformed
wheel or tire even if it has been repaired.
Such wheels or tires could have struc-
tural damage and could fail without
warning.
. The use of retread tire is not recom-
mended.
. For additional information regarding
tires, refer to “ Important Tire Safety
Information ” (US) or “ Tire Safety Infor-
mation ” (Canada) in the Warranty Infor-
mation Booklet.

Black plate (449,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]All-Wheel Drive (AWD) models GUID-0EB56D0C-6EAC-46F4-9C56-5E4540701594
CAUTION. Always use tires of the same type, size,
brand, construction (bias, bias-belted or
radial), and tread pattern on all four
wheels. Failure to do so may result in a
circumference difference between tires
on the front and rear axles which will
cause excessive tire wear and may
damage the transmission, transfer case
and differential gears.
. ONLY use spare tires specified for the
AWD model.
If excessive tire wear is found, it is
recommended that all four tires be re-
placed with tires of the same size, brand,
construction and tread pattern. The tire
pressure and wheel alignment should also
be checked and corrected as necessary.
Contact an INFINITI retailer.
Wheel balance GUID-E8819382-6D86-409C-A6FD-5113A53508AB
Unbalanced wheels may affect vehicle
handling and tire life. Even with regular
use, wheels can get out of balance. There-
fore, they should be balanced as required. Wheel balance service should be per-
formed with the wheels off the vehicle.
Spin balancing the wheels on the vehicle
could lead to mechanical damage.
For additional information regarding tires,
refer to “ Important Tire Safety Information ”
(US) or “ Tire Safety Information ” (Canada)
in the INFINITI Warranty Information Book-
let.
Care of wheels GUID-C1AC6B0A-3969-4BA4-85FF-DEEAE1EBA8AB
See “ Cleaning exterior ” (P.7-2) for details
about care of the wheels.
Spare tire (TEMPORARY USE ONLY
(T-type) spare tire) GUID-3D33E4D2-DC59-460C-941C-8160D646B5B6
Observe the following precautions if the T-
type spare tire must be used, otherwise
your vehicle could be damaged or involved
in an accident.
WARNING . The T-type spare tire should be used for
emergency use. It should be replaced
with the standard tire at the first
opportunity to avoid possible tire or
differential damage. . Drive carefully while the TEMPORARY
USE ONLY spare tire is installed. Avoid
sharp turns and abrupt braking while
driving.
. Periodically check spare tire inflation
pressure. Always keep the pressure of
the TEMPORARY USE ONLY spare tire at
60 psi (420 kPa, 4.2 bar). Always keep
the pressure of the full size spare tire (if
so equipped) at the recommended pres-
sure for standard tires, as indicated on
the Tire and Loading Information label.
For Tire and Loading Information label
location, see “ Tire and Loading Informa-
tion label ” in the index of this manual.
. With the TEMPORARY USE ONLY spare
tire installed do not drive your vehicle at
speeds faster than 50 MPH (80 km/h).
. When driving on roads covered with
snow or ice, the TEMPORARY USE ONLY
spare tire should be used on the front
wheels and original tire used on the rear
wheels (drive wheels). Use tire chains
only on the two rear original tires.
. Tire tread of the TEMPORARY USE ONLY
spare tire will wear at a faster rate than
the standard tire. Replace the spare tire
as soon as the tread wear indicators
Maintenance and do-it-yourself
8-43

Black plate (450,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]8-44 Maintenance and do-it-yourselfappear.
. Do not use the spare tire on other
vehicles.
. Do not use more than one spare tire at
the same time.
CAUTION. Do not use tire chains on a TEMPORARY
USE ONLY spare tire. Tire chains will not
fit properly and may cause damage to
the vehicle.
. Because the TEMPORARY USE ONLY
spare tire is smaller than the original
tire, ground clearance is reduced. To
avoid damage to the vehicle, do not
drive over obstacles. Also do not drive
the vehicle through an automatic car
wash since it may get caught.

Black plate (451,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]9 Technical and consumer information Capacities and recommended fuel/lubricants .......... 9-2
Fuel recommendation ......................................... 9-4
Engine oil and oil filter recommendation ............ 9-6
Air conditioning system refrigerant and
lubricant recommendations ................................ 9-7
Specifications ......................................................... 9-8
Engine ................................................................ 9-8
Wheels and tires ................................................ 9-9
Dimensions ...................................................... 9-11
When traveling or registering your vehicle in
another country .................................................... 9-11
Vehicle identification ............................................ 9-12
Vehicle Identification Number (VIN) plate .......... 9-12
Vehicle identification number
(chassis number) .............................................. 9-12
Engine serial number ....................................... 9-12
F.M.V.S.S./C.M.V.S.S. certification label ............. 9-13
Emission control information label ................... 9-13
Tire and loading information label .................... 9-14
Air conditioner specification label ..................... 9-14
Installing front license plate ................................. 9-15
Sedan .............................................................. 9-15 Coupe (except for INFINITI Performance Line,
Aerodynamic Package models) ........................ 9-17
Coupe (INFINITI Performance Line,
Aerodynamic Package models) ........................ 9-19
Vehicle loading information .................................. 9-20
Terms ............................................................. 9-20
Vehicle load capacity ...................................... 9-21
Loading tips .................................................... 9-22
Measurement of weights ................................. 9-23
Towing a trailer .................................................... 9-23
Flat towing ...................................................... 9-23
Uniform tire quality grading ................................. 9-24
Treadwear ....................................................... 9-24
Traction AA, A, B and C ................................... 9-24
Temperature A, B and C .................................. 9-24
Emission control system warranty ........................ 9-25
Reporting safety defects ....................................... 9-26
Readiness for Inspection/Maintenance (I/M) test
(US only) .............................................................. 9-27
Event Data Recorders (EDR) .................................. 9-27
Owner ’ s Manual/Service Manual
order information ................................................. 9-28

Black plate (452,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]9-2 Technical and consumer information GUID-83DC73A1-0226-4579-85B6-0002CD56C740
The following are approximate capacities. The actual refill capacities may be a little different. When refilling, follow the procedure
instructed in the “ 8. Maintenance and do-it-yourself ” section to determine the proper refill capacity. Capacity (Approximate)
Recommended specifications
US measure Imp measure Liter
Fuel 20 gal 16-5/8 gal 76 See “ Fuel recommendation ” (P.9-4).
Engine oil (VQ37VHR)*1
. Engine oil with API Certification Mark*2*3
. Viscosity SAE 5W-30Drain and refill
With oil filter change 5-1/8 qt 4-3/8 qt 4.9
Without oil filter change 4-7/8 qt 4 qt 4.6
Engine oil (VQ25HR)*1
Drain and refill
With oil filter change 5 qt 4-1/8 qt 4.7
Without oil filter change 4-5/8 qt 3-7/8 qt 4.4
Cooling system (VQ37VHR)
Automatic transmission
model With reservoir 9 qt 7-1/2 qt 8.5
Pre-diluted Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalentReservoir 7/8 qt 3/4 qt 0.8
Manual transmission model With reservoir 9-1/8 qt 7-5/8 qt 8.6
Reservoir 7/8 qt 3/4 qt 0.8
Cooling system (VQ25HR)
AWD With reservoir 9-1/4 qt 7-3/4 qt 8.8
Reservoir 7/8 qt 3/4 qt 0.8
2WD With reservoir 8-3/4 qt 7-1/4 qt 8.3
Reservoir 7/8 qt 3/4 qt 0.8
Automatic transmission fluid — — — Genuine NISSAN Matic S ATF*4
Manual transmission gear oil — — — Genuine NISSAN Manual Transmission Fluid (MTF)
HQ Multi 75W-85 or API GL-4, Viscosity SAE 75W-85
Differential gear oil — — — For 7A/T 2WD models:
API GL-5 Synthetic Gear Oil Viscosity SAE 75W-90*6
All other models:
Genuine NISSAN Differential Oil Hypoid Super GL-5 80W-90 or API GL-5, Viscosity SAE
80W-90*5
Transfer fluid — — — Genuine NISSAN Matic J ATF*7CAPACITIES AND RECOMMENDED FUEL/
LUBRICANTS

Black plate (453,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]Power steering fluid (PSF)
Refill to the proper oil level according to the instructions in the “ 8.
Maintenance and do-it-yourself ” section. Genuine NISSAN PSF or equivalent*8
Brake and clutch fluid Genuine NISSAN Super Heavy Duty Brake Fluid*9 or equivalent DOT 3
Multi-purpose grease
Without limited slip differential — — —
NLGI No. 2 (Lithium soap base)
With limited slip differential — — —
Air conditioning system refrigerant — — — HFC-134a (R-134a)*10
Air conditioning system lubricants — — — NISSAN A/C System Oil
Type S or exact equivalent
Window washer fluid — — — Genuine NISSAN Windshield Washer Concentrate Cleaner & Antifreeze or equivalent
*1:
For additional information, see “ Engine oil ” (P.8-11) for changing engine oil.
*2: INFINITI recommends Genuine NISSAN Ester Engine Oil available at an INFINITI retailer.
*3: For additional information, see “ Engine oil and oil filter recommendation ” (P.9-6).
*4: Using automatic transmission fluid other than Genuine NISSAN Matic S ATF will cause deterioration in driveability and automatic transmission durability, and may damage the automatic
transmission, which is not covered by the INFINITI new vehicle limited warranty.
*5: For hot climates, viscosity SAE 90 is suitable for ambient temperatures above 32 8 F (0 8 C).
*6: See an INFINITI retailer for service for synthetic oil.
*7: Using transfer fluid other than Genuine NISSAN Matic J ATF will cause deterioration in driveability and transfer durability, and may damage the transfer, which is not covered by the INFINITI new
vehicle limited warranty.
*8: DEXRON TM
VI type ATF may also be used.
*9: Available in mainland USA through an INFINITI retailer.
*10: For additional information, see “ Vehicle identification ” (P.9-12) for air conditioner specification label.
Technical and consumer information
9-3

Black plate (454,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]9-4 Technical and consumer informationFUEL RECOMMENDATION GUID-FD3A9510-2D82-4C2F-81D2-3EECA4BDE202
VQ25HR engine GUID-DECF13E8-0D22-45CE-9350-2A04A0BCABEB
INFINITI recommends the use of unleaded
premium gasoline with an octane rating of
at least 91 AKI (Anti-Knock Index) number
(Research octane number 96).
If unleaded premium gasoline is not
available, you may use unleaded regular
gasoline with an octane rating of at least
87 AKI number (Research octane number
91), but you may notice a decrease in
performance.
VQ37VHR engine GUID-62D6EF4E-F486-46EA-A1E0-D4BB9121EA3A
Use unleaded premium gasoline with an
octane rating of at least 91 AKI (Anti-Knock
Index) number (Research octane number
96).
If premium gasoline is not available,
unleaded regular gasoline with an octane
rating of 87 AKI number (Research octane
number 91) may be temporarily used, but
only under the following precautions:
. Have the fuel tank filled only partially
with unleaded regular gasoline, and fill
up with unleaded premium gasoline as
soon as possible. . Avoid full throttle driving and abrupt
acceleration.
However, for maximum vehicle perfor-
mance, the use of unleaded premium
gasoline is recommended.
CAUTION . Using a fuel other than that specified
could adversely affect the emission
control system, and may also affect
warranty coverage.
. Under no circumstances should a leaded
gasoline be used, because this will
damage the three-way catalyst.
. Do not use E-85 fuel in your vehicle. Your
vehicle is not designed to run on E-85
fuel. Using E-85 fuel can damage the fuel
system components and is not covered
by the INFINITI vehicle limited warranty.
Gasoline specifications GUID-E8A76FAE-F1E8-41BA-ACCF-E439B6733579
INFINITI recommends using gasoline that
meets the World-Wide Fuel Charter (WWFC)
specifications where it is available. Many
of the automobile manufacturers devel-
oped this specification to improve emis-
sion system and vehicle performance. Ask your service station manager if the gaso-
line meets the World-Wide Fuel Charter
(WWFC) specifications.
Reformulated gasoline GUID-21D3DE2D-574C-45D2-AE5B-28DCCCBF286C
Some fuel suppliers are now producing
reformulated gasolines. These gasolines
are specially designed to reduce vehicle
emissions. INFINITI supports efforts to-
wards cleaner air and suggests that you
use reformulated gasoline when available.
Gasoline containing oxygenates GUID-ABC4FC82-F0F7-44E4-BDD3-2D84252E0A47
Some fuel suppliers sell gasoline contain-
ing oxygenates such as ethanol, MTBE and
methanol with or without advertising their
presence. INFINITI does not recommend the
use of fuels of which the oxygenate content
and the fuel compatibility for your INFINITI
cannot be readily determined. If in doubt,
ask your service station manager.
If you use oxygenate-blend gasoline,
please take the following precautions as
the usage of such fuels may cause vehicle
performance problems and/or fuel system
damage.
. The fuel should be unleaded and have
an octane rating no lower than that
recommended for unleaded gasoline.

Black plate (455,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]. If an oxygenate-blend, excepting a
methanol blend, is used, it should
contain no more than 10% oxygenate.
(MTBE may, however, be added up to
15%.)
. If a methanol blend is used, it should
contain no more than 5% methanol
(methyl alcohol, wood alcohol). It
should also contain a suitable amount
of appropriate cosolvents and corro-
sion inhibitors. If not properly formu-
lated with appropriate cosolvents and
corrosion inhibitors, such methanol
blends may cause fuel system damage
and/or vehicle performance problems.
At this time, sufficient data is not
available to ensure that all methanol
blends are suitable for use in INFINITI
vehicles.
If any undesirable driveability problems
such as engine stalling or hard hot starting
are experienced after using oxygenate-
blend fuels, immediately change to a
non-oxygenate fuel or a fuel with a low
blend of MTBE.
Take care not to spill gasoline during
refueling. Gasoline containing oxygenates
can cause paint damage. E-85 fuel GUID-BE764F0C-6A10-497C-B4F9-CD1D0E122DA3
E-85 fuel is a mixture of approximately
85% fuel ethanol and 15% unleaded
gasoline. E-85 can only be used in a
Flexible Fuel Vehicle (FFV). Do not use E-
85 fuel in your vehicle. U.S. government
regulations require fuel ethanol dispensing
pumps to be identified by a small, square,
orange and black label with the common
abbreviation or the appropriate percentage
for that region.
Aftermarket fuel additives GUID-663D952D-0F24-4D6E-ABBF-21302053695C
INFINITI does not recommend the use of
any aftermarket fuel additives (Example:
fuel injector cleaner, octane booster, intake
valve deposit removers, etc.) which are
sold commercially. Many of these additives
intended for gum, varnish or deposit
removal may contain active solvent or
similar ingredients that can be harmful to
the fuel system and engine.
Octane rating tips GUID-527A0AB1-299D-45DA-9B92-4DDA2444B93C
Using unleaded gasoline with an octane
rating lower than recommended above can
cause persistent, heavy spark knock.
(Spark knock is a metallic rapping noise.)
If severe, this can lead to engine damage.
If you detect a persistent heavy spark knock even when using gasoline of the
stated octane rating, or if you hear steady
spark knock while holding a steady speed
on level roads, have an INFINITI retailer
correct the condition. Failure to correct the
condition is misuse of the vehicle, for
which INFINITI is not responsible.
Incorrect ignition timing will result in
knocking, after-run or overheating. This in
turn may cause excessive fuel consumption
or damage to the engine. If any of the
above symptoms are encountered, have
your vehicle checked at an INFINITI retailer
or other competent service facility.
However, now and then you may notice
light spark knock for a short time while
accelerating or driving up hills. This is no
cause for concern, because you get the
greatest fuel benefit when there is light
spark knock for a short time under heavy
engine load.
CAUTION . Your vehicle is not designed to run on E-
85 fuel. Using E-85 fuel in a vehicle not
specifically designed for E-85 fuel can
damage fuel system components and is
not covered by the INFINITI new vehicle
Technical and consumer information
9-5
